AREBOS AR-HE-KV02 User manual

User’s Manual –AREBOS Electric Heater
1
Electric Heater
AR-HE-KV02 Timer,
AR-HE-KV03 TimerTurbo
Please follow all security measures in this user´s manual to ensure a secure use.
Thank you for trusting in AREBOS.

User’s Manual –AREBOS Electric Heater
2
List of contents
1. Safety instructions.................................... 3
2. Mounting ................................................. 5
3. Commissioning ......................................... 6
3.1 Timer operation............................................................................................................................. 6
3.2 Setting the timer............................................................................................................................ 6
4. Technical specifications ............................ 7
5. Cleaning and storage ................................ 7
6. Disposal instruction.................................. 8
6.1 Disposal of the packaging.............................................................................................................. 8
6.2 Disposal of waste equipment ........................................................................................................ 8
6.3 Meaning of the "dustbin".............................................................................................................. 8
EU Declaration of Conformity ...................... 9

User’s Manual –AREBOS Electric Heater
3
Please read and save these instructions. Read through this user’s manual carefully before using
product. Protect yourself and others by observing all safety information, warnings and cautions.
Failure to comply with instructions could result in personal injury and/or damage to product or
property. Please retain instructions for future reference.
1.Safety instructions
Explanation of the symbols
•IMPORTANT: Please read the operating instructions completely before using the heater and
keep them for later use.
•Improper use of this device can cause serious and extensive health and property damage.
Please read the following instructions carefully. Familiarize yourself with the device before
using it. This is the only way to ensure safe and perfect operation of the heat convector.
•Caution: Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
•Warning! Never leave the electric heater unattended!
•Warning! The device is not equipped with a room temperature control device. Under no
circumstances should you use the heater in rooms where there are people who are unable
to leave the room on their own, with the exception of permanent supervision.
•The heater is not intended for use in the bathroom, laundry, or similar premises. Do not
install the heater in the immediate vicinity of a bathtub, shower or swimming pool.
•This device must not be used by persons (including children) who have limited physical,
sensory or mental abilities or a lack of experience and knowledge, unless instructed and
supervised by a responsible person in the safe use of the device.
•This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
•Children aged from 3 years and less than 8 years shall only switch on/off the appliance
provided that it has been placed or installed in its intended normal operating position and
they have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children aged from 3 years and less than 8 years shall
By means of a CE marking, it can be recognized that a product complies with the
legal requirements of European legal standards and therefore may be traded
within the European Community.
This product must not be disposed of with household waste!

User’s Manual –AREBOS Electric Heater
4
not plug in, regulate and clean the appliance or perform user maintenance.
•Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
•Children of less than 3 years should be kept away unless continuously supervised.
•Children must be supervised to ensure that they do not play with the appliance.
•Do not use the device outdoors.
•This appliance is approved for domestic use only.
•Make sure that the electric heater is always on firm, level ground.
•When setting up the device, ensure a safe and stable position. Only use the device in an
upright position. If the unit has fallen down, unplug the power cord, put the unit upright
again and let it cool down before putting it back into operation.
•Do not place the heater on very deep pile carpets.
•Only use the heater after the feet have been installed correctly.
•Before connecting the electric heater to the power supply, check that the voltage indicated
on the rating plate corresponds to the voltage of the mains supply and that the socket is
earthed.
•The heater must not be covered to avoid excessive heating/overheating of the heater.
•Make sure that the cable does not come into contact with the hot surface of the heater.
•Never use the device with a damaged cable; if the power cable is damaged, it must be
replaced by a recognized service center or a similarly qualified person. If the plug is damaged,
refer to the detailed description below to replace the plug.
•Do not use the cord to carry the power tool, hang it up or pull the plug out of the socket.
Keep the cable away from heat, oil, sharp edges or moving parts of the unit. Damaged or
entangled cables increase the risk of an electric shock.
•Do not cover or block any of the heat outlet grilles or the air intake openings of the heater.
•Placing the heater in the immediate vicinity of curtains or furniture may cause a fire.
•Do not place the heater in front of or directly under a power outlet.
•Do not put any objects in the heat outlet or the air intake grilles of the heater.
•Never use the device near flammable liquids or flammable dust.
•Keep power tools away from rain or moisture.
•Never touch the power plug with wet hands.
•The penetration of water into a power tool increases the risk of an electric shock.
•Always unplug the power cord when changing the location of the heater.
•Do not touch the hot parts of the convector with bare fingers during operation. Always use
heat-insulated gloves or pot holders to touch the convector and its parts. Make other users
aware of the dangers!
•Check regularly. Use of this device may cause wear on certain parts. Therefore, check the
device regularly for any damage and defects.

User’s Manual –AREBOS Electric Heater
5
2.Mounting
•Before using the heater, the feet must be attached to the unit (enclosed with the package
separately). These are attached to the underside of the device using the 4 tapping screws
provided. Please make sure that they are correctly attached to the bottom end of the side
paneling.
Wall mounting
1. The electric heater is equipped with 4 angle brackets, screws and plastic plugs, so that the
heater can also be mounted on a wall if required.
2. If you have decided to attach the device to the wall, do not screw on the feet. The spatial
location must be chosen carefully. The heater must not be located in front of or below a
socket or shelf, and not in the immediate vicinity of a curtain or other obstructions. In
addition, observe the above safety instructions.
3. Once you have selected the location of your heater, you will need to drill two holes 0.315 in
(8 mm) in diameter and 1.69 in (43 mm) deep with a horizontal distance of 19.13 in (486
mm) and a minimum distance of 15.75 in (400 mm) from the ground. Any flooring or carpet
must be considered. If baseboards are present, the mounting holes must be at least 15.75 in
(400 mm) above the top edge of the skirting board. Using the plastic dowels and fixing
screws, two of the mounting brackets are attached to the wall. The other pair of mounting
brackets are attached to the bottom of the heater. These are fastened by means of the fixing
screws of the feet so that the clamps protrude beyond the back of the heater and thereby
keep the bottom of the heater away from the wall.
4. If required, these clips can be fixed to the wall using the remaining dowels and screws. If you
choose this option, we recommend that you hang the heater at the top mounting points and
then mark the hole positions of the bottom brackets on the wall before drilling the mounting
holes.

User’s Manual –AREBOS Electric Heater
6
3.Commissioning
•Note: Should the heater give off a slight odor or smoke when used for the first time or after
prolonged storage, this will be normal and will disappear after a longer period of use of the
heater.
1. Look for a suitable location for your electric heater, taking into account the above safety
instructions.
2. Insert the mains plug into a suitable socket.
3. Fully turn the thermostat switch clockwise to the maximum setting.
4. Turn on the heating elements using the toggle switches on the side panel. When the heaters
are on, the switches light up. For the highest possible heat output, please switch both
switches on.
5. When the desired room temperature has been reached, the thermostat switch should be
turned slowly counterclockwise until a click sound is heard and the lights on the switches are
off. After that, the heater keeps the set room temperature by automatically turning it on and
off.
6. In the minimum position (completely counterclockwise), the heater provides an antifreeze
program. In this position, depending on the size of the room, the heater gets the
temperature above the freezing point.
•This model is additionally equipped with a 24-hour timer. Each of the 96 segments equals 15
minutes. With the help of this timer, it is possible to preset the time and duration of the
period(s) for which the heater should operate in any 24-hour period.
3.1 Timer operation
•The middle of the timer has a 3-position slide switch.
•In the middle position (indicated by the clock icon), the timer will turn the heater on and off
at the times set by the segments (see Setting the timer below).
•The position indicated by the (I) overrides the timer. The timer turns the heater on and off at
the times determined by the sections. (see timer setting below)
•In the position marked (O), the timer continues to run, but no power is supplied to the
heater.
3.2 Setting the timer
•Make sure the slide switch on the timer is in the middle position next to the clock icon.
•Turn the outer ring of the timer clockwise until the current time matches the arrow pointer.
If e.g. the current time to set the timer is 8 o'clock in the evening, turn the outer ring until
the number 20 is in line with the arrow.
•Set the time for the heater to run by pulling the segments around the outer ring forward for
the required running time.
•After the time is set, the heater will run according to the desired operating time.
•When set, the heater operates every day at the programmed time. Note that the heater
must always be connected to an electrical outlet, the element switches must be on and the
thermostat must be set to turn on the heater.
•If the heater is to run continuously, the slide switch on the timer should be set to (I).
•If you want to switch back to timer mode, the slide switch of the timer should be set to the
middle clock position.
•Note: When used in timer mode, it should be noted that the heater can be turned on
unattended.

User’s Manual –AREBOS Electric Heater
7
4.Technical specifications
Modell
AR-HE-KV02Timer
AR-HE-KV03TimerTurbo
Power supply
2000 W
2000 W
Heating steps
Step 1
750 W
750 W
Step 2
1250 W
1250 W
Step 3
2000 W
2000 W
Power input
230 V; 60 Hz
230 V; 60 Hz
Dimensions
23.23 x 4.53 x 14.57 in (590 x
115 x 370 mm)
23.23 x 4.53 x 14.57 in (590 x
115 x 370 mm)
Cable length
1,6 m
1,6 m
Thickness
4.53 in (11,5 cm)
4.53 in (11,5 cm)
Protection class
I
I
Weight
6.61 lbs (3 kg)
7.94 lbs (3,6 kg)
White/Black
White/Black
5.Cleaning and storage
•Disconnect the device from the power supply before each cleaning and allow it to cool
completely.
•Clean the outside of the heater with a damp cloth and then polish it with a dry cloth. Do not
use cleaning or abrasives. Make sure that no water penetrates into the heater.
•Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
•If the heater is not going to be used for a long time, it should be protected from dust and
stored in a clean, dry place.

User’s Manual –AREBOS Electric Heater
8
6.Disposal instruction
6.1 Disposal of the packaging
•Please make reference to the guidelines and standards for appropriate disposal of the packaging
valid in your region. In part, the package may consist of plastic bags - watch this respect, with
special care to ensure that this is not out of the reach of children. There is a risk of suffocation!
6.2 Disposal of waste equipment
•Equipment must be disposed of in accordance with the rules and regulations of the local waste
disposal.
6.3 Meaning of the "dustbin"
Protect our environment; electrical appliances do not belong in household
waste. Use the provided for the disposal of electrical equipment collection
points and enter your electrical and electronic equipment that you no longer
use. They help ensure that the potential effects of incorrect disposal on the
environment and human health to be avoided. So, do your part to recycle,
recycling and other forms of recovery of waste electrical and electronic
equipment. Information on where the devices are disposed of, please contact
your local authorities or local Governments.
Our customer service number: [phone]
Canbolat Vertriebs GmbH • Gneisenaustraße 10-11 • 97074 Würzburg

User’s Manual –AREBOS Electric Heater
9
EU Declaration of Conformity
We,
Canbolat Vertriebs GmbH, Gneisenaustraße 10-11, 97074 Würzburg, Germany,
Hereby declare that the product named below, seen its design and construction as well as according
to our sales, has been complied with the relevant and basic health and safety EU-requirements.
Name of the product: Electric heater
Model Nr.: AR-HE-KV02Timer, AR-HE-KV03TimerTurbo
Art. Nr.: 4260551587658, 4260551587665
If the product has any modification not allowed by us, this declaration loses its validity.
Tested acc. to:
EU Standard:
EN 62233:2008
EN 60335-2-30:2009+A11:12
EN 60335-1:2012+AC:14+A11:14
Date/Manufacturer Signature/Location: Würzburg, 29 June 2020
Identification of the signatory:
Korhan Canbolat, head of the company
Authorised representative for the technical documentation:
Korhan Canbolat
Office address:
Canbolat Vertriebs GmbH
Gneisenaustraße 10-11
D-97074 Würzburg
Return address can be found in the imprint: https://www.arebos.de/impressum/
VAT identification number: DE 263752326
Court of the Commercial Register is Würzburg, HRB 10082
WEEE Reg.-No. DE 61617071
