Argo LOOP User manual

11
V 12/19
LOOP
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance operations.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage.
Keep these instructions in a safe place for future reference.
DESK AND FLOOR FAN
(AIR CIRCULATOR)
EN

12
V 12/19
GENERAL SAFETY INFORMATION
Use this fan only as outlined in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock or
injury to people.
Ensure that the mains power complies with the voltage specified on
the fan ’s data plate (220-240V~/50-60Hz).
This product is not a toy. Children should be adequately supervised
to ensure that they do not play with the appliance.
This appliance is not suitable for use by people (including children)
with reduced physical, sensory or mental abilities, or without the
necessary experience and knowledge, unless they have been
adequately supervised and instructed concerning use of the
appliance by a person responsible for their safety.
Cleaning and maintenance designed to be carried out by the user
must not be carried out by children without supervision.
Do not restrict the air inlet and outlet grilles.
Disconnect the mains power when the appliance is not used or for
cleaning operations.
Do not place anything on the appliance, use the appliance to dry
clothing (danger of overheating if it is covered).
Avoid placing fingers or foreign objects in the air inlet/outlet grilles,
as this may lead to electric shock or fire and may damage the
appliance.
To avoid the risk of fire, do not block the grilles or tamper with them
in any way while the fan operates.
Do not use the appliance if the cord or plug are damaged. If the
power supply cord is damaged, it must be replaced by the
manufacturer, dealer or a similarly qualified person so as to avoid
any safety risks.
Do not operate the appliance if it has fallen from a height or has
suffered damage in any way. Contact qualified technical personnel
to examine the appliance or perform any electrical or mechanical
repairs.

13
V 12/19
The most common cause of overheating is the build-up of dust in the
appliance. Remove dust deposits by unplugging the appliance and
cleaning the air outlets and grilles with the aid of a vacuum cleaner.
Do not use abrasive detergents for cleaning this appliance. Clean
the appliance with the aid of a damp (not wet) cloth rinsed in hot
soapy water. Always remove the plug from the mains socket before
cleaning.
Do not use the fan in dusty environments or in the presence of
flammable vapors (for example in a laboratory or in a garage)
Use the fan in a well-ventilated area
The fan has inside parts that generate arcs or sparks. It must not be
used in areas that could be dangerous, such as areas at risk of fire,
explosion, chemical substances or humidity-laden atmospheres
Do not use the fan in environments with temperatures above 40 °C
To disconnect the fan, push the switch to OFF and remove the plug
from the socket. Pull on the plug only. Avoid pulling on the cord
when disconnecting the fan.
Do not place any objects on the cord and do not bend it.
It is not advisable to use extension cords, as these may overheat
and cause the risk of fire. Do not use a single extension cord to
operate multiple appliances.
Do not immerse the cord, plug or any other element of the appliance
in water or other liquids.
Do not touch the plug with wet hands.
Do not place the fan above or near another heat source.
Do not connect the appliance to the mains power before it has been
properly assembled and positioned.
Do not run the cord under carpets. Do not cover the cord with
blankets, carpets or similar materials. Place the cord far away from
busy areas or where it cannot be accidentally pulled-out.
Do not position the fan below a socket outlet.
Do not operate the appliance outdoors.

14
V 12/19
WARNING: DO NOT DEPEND ON THE ON/OFF BUTTON
SWITCH AS THE SOLE MEANS OF DISCONNECTING POWER.
WHEN SERVICING OR MOVING THE FAN, ALWAYS UNPLUG
THE POWER CORD.
A fan has hot and arcing or sparkling parts inside. It must not be
used in potentially dangerous locations such as flammable,
explosive, chemical-laden or wet atmosphere
Do not place the fan on soft surfaces, like a bed, where openings
may become blocked. Always place the fan on a stable, flat, level
surface when operating, to avoid the chance of the overturning.
Locate the power cord so the fan or other objects are not resting
on it
Fire hazard if, during operation, the fan is covered or in contact
with flammable material including curtains, draperies. Blankets,
clothes, furniture and papers (which must be kept at a distance of
1 m from the front, sides and back).
KEEP THE FAN AWAY FROM SUCH MATERIALS
WARNING: Do not use the fan with a programmer or any
other external device that turns on the fan automatically, as
there are risks of fire if the fan is covered or incorrectly
positioned.
Always unplug the fan when not in use.
In order to avoid accidents turn unit off if unattended
In the event of any problems (abnormal noise or a strange smell)
switch off the appliance immediately, do not attempt to repair it
and take it to your local after sales service.

15
V 12/19
DESCRIPTION OF PARTS
FRONT VIEW REAR VIEW
1
2
3
4
5
6
7
8
1. Front guard
2. Fan stand
3. Soft Touch button (on fan base)
4. Display
5. Oscillating base
6. Read Guard
7. Micro lock of read guard
8. Power cord

16
V 12/19
HOW TO USE THE APPLIANCE
Connect the power cord to a suitable power socket (220-240 V/50Hz~).
Do not use this fan in an area with high humidity, rich of dust or water.
Position the unit vertically on a flat, stable surface.
Press ON/OFF on the fan base or remote control. A sound will indicate that the appliance is on.
This fan can be used as a fan, with 3 modes NATURAL, SLEEP and NORMAL and 3 fan speed options (low - L, medium -
M and high - H).
DISPLAY AND SOFT TOUCH BUTTONS
DISPLAY
TASTI SOFT TOUCH
(posti sulla base del ventilatore)
ON / OFF BUTTON: After inserting the plug into the socket, press the ON / OFF button on the base of the fan to switch on
the product. A red LED indicator on the display (POWER) will indicate that the product is on.
SPEED BUTTON: As soon as the fan is switched on it is set to the Medium ventilation speed, the blue LED indicator on
the display will be on (M) and after 3 seconds it will switch to Low speed (the blue LED indicator will be on (L).
Touch the SPEED button on the fan base to change the ventilation speed in the following sequence: Low (L) -> Medium
(M) -> High (H).
MODE BUTTON: Touch the MODE button on the fan base to select the desired ventilation mode; when it is switched on
for the first time it is set to Natural mode (the blue LED indicator will be on in the display), again touching the MODE
button it will switch to the next Sleep mode (the blue LED indicator will be lit on the display), touching again on switch to
Normal mode. The sequence will then be: Natural -> Sleep -> Normal.
TIMER BUTTON: Touch the Timer button to set the automatic switch-off (Auto-OFF) after 1 hour (the blue LED indicator
will be lit on 1H). Subsequently touching the Timer button it is possible to set a different number of hours of operation,
according to the sequence (expressed in hours of operation): Timer OFF -> 1H -> 2H -> 3H -> 4H -> 5H -> 6H -> 7H
(each touch of the Timer button corresponds to 1 hour of setting the Timer).
SOFT TOUCH BUTTONS
(positioned on fan base)

17
V 12/19
OSCILLATION BUTTON (OSC): By touching the OSC button the fan oscillation is activated (upwards and downwards),
the blue LED indicator on the display will be lit on OSC
Pressing again on OSC activates the oscillation of the base (to the right and to the left) the blue LED indicator on the
display will be lit on OSC
Touching OSC again will stop the oscillation of the base, then of the fan and finally, touching a third time, the oscillation
function will be completely interrupted.
REMOTE CONTROL
The buttons on the remote control correspond exactly to the functions of the buttons on the fan base.
HOW TO INSERT / REMOVE THE REMOTE CONTROL BATTERY (refer to the side drawing).
Open the battery door on the back of the remote control (press the back and pull
the door with the side hook)
Place the battery in the door, making sure to check that the polarities are
correctly positioned.
Insert the door on the remote control.
Use 1 Lithium / Manganese button cell, type CR2025 - 3V, complying with the
Batteries Directive no. 2006/66 / EC and modest from Directive 56/2013 / EU.
Remove the battery if the remote control is not used for a long time.
INFORMATION FOR CORRECT DISPOSAL OF THE BATTERIES IN ACCORDANCE WITH EUROPEAN
DIRECTIVE 2006/66/EC and amendments Directive 56/2013/EC
Please replace the battery when its electrical charge has been exhausted: at the end of its useful life, it must not
be disposed of together with unsorted waste. It must be must be delivered to appropriate separated waste
disposal plants or to dealers that provide a similar service. Separate waste disposal of batteries prevents
potential negative effects on the environment and human health resulting from inadequate disposal, and also
allows the materials from which it is made to be recovered and recycled in order to achieve significant savings in
terms of energy and resources. The separate disposal obligation is underlined by the crossed-out dustbin
symbol appearing on the battery. Illegal disposal of the product by the user shall result in the application of
of administrative sanctions as defined by current regulations.

18
V 12/19
ALWAYS UNPLUG THE APPLIANCE BEFORE CLEANING OR MAINTENANCE.
IMPORTANT: DO NOT SUBMERGE THE FAN IN WATER.
Cleaning the outside surface of the appliance
Turn the switch off and unplug before carrying out any maintenance work or moving the appliance.
Use a soft cloth to remove any dust from the fan.
If the fan is excessively dirty, use a soft cloth moistened with water and a mild detergent at a temperature lower than 50°C.
Let the fan dry completely before use.
Do not use corrosive detergents or solvents such as petrol. Do not wash the appliance with water. Do not use oils,
chemical substances or other items to clean that may damage the surface.
Use a vacuum cleaner to remove dust from the air inlet/outlet grilles.
To dismantle the parts, follow the instructions below:
Unscrew the screw of the rear guard in counter-clockwise direction.
Press the micro lock of the rear guard to the get the front guard unlocked.
MAINTENANCE AND STORAGE

19
V 12/19
Remove the front guard and clean it with soft cloth.
Unscrew the cap nut of the blade in counter-clockwise direction and remove the blade with caution. Clean then the blade
with a soft cloth.
When the cleaning is completed, you could re-install the appliance in a opposite order of the installating procedures
mentioned as above.
STORAGE
If the appliance is not used for prolonged periods, disconnect the power cord and store the appliance with this manual in
its original packaging, in a cool and dry place. In the event of a prolonged period of inactivity, remove the battery from the
remote control.

20
V 12/19
INFORMATION FOR THE CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EUROPEAN DIRECTIVE
2012/19/EU
This appliance may not be scrapped with domestic waste at the end of its life cycle. We call your attention to the crucial role
played by the consumer in the re-use, recycling and other forms of recovery of such waste.
The appliance must be scrapped by a sorted waste disposal centre or by returning it to the retailer (no charge is levied for
this service), when you purchase a new equivalent appliance.
Sorted disposal of electric and electronic equipment prevents the negative effects on the environment and human health
resulting from improper scrapping, and also allows the materials from which it is made to be recovered and recycled, with
significant savings in terms of energy and resources.
The sorted disposal requirement is indicated by the crossed waste bin label affixed to the appliance.
www.argoclima.com
