Argo DAKOTA User manual

V 05/21
11
DAKOTA
This product is only suitable for well insulated spaces or
occasional use.
OPERATING INSTRUCTIONS
Read the instructions carefully before installing and operating the appliance or performing
maintenance operations. Observe all the safety instructions; failure to observe the instructions may
cause accidents and/or damages. Store these instructions for future reference.
ELECTRIC CONVECTOR HEATER
EN

V 05/21
12
GENERAL SAFETY INFORMATION
Use this convector only as outlined in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock or
injury to persons.
This convector is designed for domestic use. It must not be used for
commercial or industrial purposes.
Ensure that the mains voltage complies with that indicated on the
convector data plate (220-240V~ 50-60Hz).
This appliance can be used by children aged from 8 years and
above and people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
Remove the convector from its packaging and check that it is in good
condition before use. Keep any plastic bags away from children.
Check the cord and plug before using the convector to ensure that
they have not been damaged during transport.
This product is not a toy.
Children under the age of 3 must be kept away if not continuously
supervised.
Children aged between 3 and 8 must only turn the appliance on / off
as long as it has been placed or installed in its normal operating
position and that they receive surveillance or instructions regarding
the safe use of the appliance and understand the dangers.
Children between 3 and 8 years of age must not insert the plug,
adjust or clean the appliance or carry out maintenance by the user.
CAUTION - Some parts of this product can become very hot and
cause burns. Particular attention has to be given where children
and vulnerable people are present.
WARNING: In order to avoid hazard due to inadvertent resetting of
the thermal cut-out, this appliance must not be supplied through and
external switching device, such as a timer, or connected to a circuit
that is regularly switched on and off by the utility.
WARNING: do not use the convector with a controller or any
other external device that activates the appliance automatically,

V 05/21
13
as there may be a risk of fire if the fan heater is covered or
incorrectly positioned.
Disconnect the mains power when the appliance is not used or for
cleaning operations.
To disconnect the convector, turn off the appliance with the ON/OFF
switch on the side and remove the plug from the socket. Pull on the
plug only. Do not pull the cord.
Avoid placing fingers or foreign objects in the air inlet/outlet grilles,
as this may lead to electric shock or fire and may damage the
convector. To avoid the risk of fire, do not block the grilles or tamper
with them in any way while the convector operates.
Do not use the convector if the cord or plug is damaged. If the power
cable is damaged, it must be replaced by the manufacturer or its
technical assistance service or in any case by a person with a similar
qualification, in order to prevent any risk.
Do not place any objects on the cord and do not bend it. During
operation, the cord must be entirely unwound.
It is not advisable to use extension cords, as these may overheat
and cause the risk of fire. Do not use a single extension cord to
operate more than one convector.
The convector heats up significantly during operation. Risk of burn.
To avoid injury, do not allow skin to come into contact with a hot
surface. Use the handle to move the convector. Keep flammable
materials, such as furniture, cushions, blankets, paper, cloths,
curtains and suchlike at least 1 m from the front and back
Do not immerse the cord, plug or any other element of the panel in
water or other liquids.
Do not touch the plug or convector with wet hands.
Avoid using the convector in dusty environments or in the presence
of flammable vapors (e.g. in workshops or garages).
Do not place the convector above or near another heat source.
WARNING: AVOID COVERING THE CONVECTOR TO PREVENT IT
FROM OVERHEATING.
The symbol below signals the above warning:

V 05/21
14
The convector may cause risk of fire if, while in operation, is covered
by or comes into contact with flammable material including curtains,
drapery, blankets, etc. KEEP THE CONVECTOR AWAY FROM
THESE MATERIALS.
Do not insert and avoid accidental insertion of any external objects
into the ventilation or discharge outlets as this may lead to electric
shock, fire or damage the convector.
A convector contains parts that generate arcs or sparks. It must not
be used in potentially dangerous areas such as areas at risk of fire
or explosion, or areas loaded with chemical substances or humidity.
Do not use the convector on soft surfaces such as beds, where the
grilles may be covered. Always stand the convector on a flat, stable
surface when in operation, in order to prevent it from overturning.
Arrange the cord in such a way that the convector and other objects
do not rest on it. Do not run the cord under carpets. Do not cover the
cord with blankets, carpets or similar materials. Place the cord far
away from busy areas, or in a place where it cannot be accidentally
pulled-out.
Never position the convector where it may fall into a bath or other
containers of water.
Never position the convector on a wet floor.
In any case, the adjustment switches must never be accessible by
anyone in a bath or shower.
The heating appliance must not be positioned immediately below a
power outlet.
The socket must be earthed.
Do not allow the electric cord to touch the metal structure of the
convector when it is hot or in operation, in order to avoid the high
temperatures ruining the cord.
Do not operate the convector outdoors. Do not use the convector in
front of or near an open window.
WARNING: do not use the convector with an external controller
or any other external device that activates the convector
automatically, as there may be a risk of fire if the convector is
covered or incorrectly positioned.
Upon initial start-up, the convector may emit a slight, harmless smell.
This smell is a normal effect of the initial heating up of the internal
heating elements, and should not recur later on.

V 05/21
15
Do not attempt to repair, disassemble or modify the convector. The
convector does not contain parts that can be repaired by the user.
Turn the switch off and unplug before carrying out any maintenance
work or moving the convector. Always unplug from the socket when
the convector is not in use.
WARNING: ALWAYS UNPLUG WHEN CARRYING OUT
MAINTENANCE WORK OR MOVING THE CONVECTOR.
Do not place anything on the convector; avoid placing wet garments
on the convector.
Turn the appliance off if unattended in order to avoid accidents.
If the convector is not used for prolonged periods, disconnect the
plug, replace the convector in its box and store it in a dry, ventilated
place.
Ensure that the air inlet /outlet are not close to walls or curtains when
the convector is in use, so as to avoid obstructing the convector and
hampering its efficiency.
Place the convector at a distance of at least 1 meter from walls and
objects.
Should you hear an abnormal noise or detect an unusual smell when
using the convector, cease use and unplug immediately.
Do not expose the elderly or children to a continuous flow of air.
Do not use the convector if it has been damaged or dropped.
Do not use the convector without the feet mounted and do not use
feet other than those supplied with the product.
WARNING:
THE ON/OFF SWITCH IS NOT THE ONLY MEANS TO
DISCONNECT THE POWER SUPPLY. ALWAYS PULL OUT THE
PLUG FROM THE SOCKET IN THE EVENT OF MAINTENANCE
OPERATIONS, WHEN MOVING THE PANEL OR WHEN NOT IN
USE.

V 05/21
16
DESCRIPTION OF PARTS
1. Air outlet
2. Handle
3. Display and touch control panel
4. ON/OFF switch
5. Foot
HOW TO INSTALL THE APPLIANCE
The convector can be used on the floor, after assembling the feet.
MONTARE I PIEDINI IN DOTAZIONE
The convector is packed without feet. These must therefore be assembled before using the appliance.
Assemble the feet as shown in the figure and put the convector in an upright position. Position the unit on a flat,
stable surface.
1. Turn the convector upside down 2. Insert the feet. The longest part
must be positioned behind on
the rear the convector.
3. Tighten the wing nuts on the feet.
1
2
3
4
5

V 05/21
17
CONTROL PANEL AND FUNCTIONS
TOUCH CONTROL PANEL ON THE APPLIANCE
4
1
57
2
8
3
6
1 Low power heating LED
LED on display
2 High power heating LED
3 Display Temperature/Timer
4 Standby button
Operation buttons
5 Button -
6 Heating setting button
7 Button +
8 Brightness/Timer button
Connect the power cord to an appropriate power outlet (220-240V ~ 50-60Hz).
Press the power button located on the side of the convector, a beep will sound.
The button will light up on the control panel. Then press the Standby button on the panel to switch
on the convector. Press the same button to switch off the convector.
It is advisable to unplug the power cord if the product is not in use.
Heating mode selection button
Press this button to select the heating mode between high and low. According to the selection made on the
display, the corresponding LEDs will light up:
Icon on display
Heating power Low 1250W High
2000W

V 05/21
18
Temperature selection buttons and
Press the buttons on the control panel to select the desired temperature between 10 ° C up to 35 ° C.
When the temperature reaches 10 ° C, press the button and the anti-freeze function will be activated,
will appear on the display . When the anti-freeze function is active, the reference temperature is 7 ° C.
Timer Button and Display Illumination
Timer function: Press and hold the button for about 3 seconds, the display will show 0h, then press the
and buttons to select the operating interval from 1 to 9 hours (the time increases by 1 hour at each
selection), on the display the set time will be shown.
Display lighting function: The standard lighting is 100%, press the button to change the intensity of the
lighting in the following circular sequence 100% -> 50% -> 25% -> 0%
When the lighting intensity is 0%, the display is off, the Standby button and the Timer / Display lighting
button are always lit with a lighting intensity of 25%, if no selection is made.
MAINTENANCE AND STORAGE
ALWAYS UNPLUG THE APPLIANCE BEFORE CLEANING OR MAINTENANCE.
IMPORTANT: DO NOT SUBMERGE THE CONVECTOR IN WATER.
Cleaning the outside surface of the appliance
Turn the switch off and unplug before carrying out any maintenance work or moving the appliance.
Use a soft cloth to remove any dust from the convector.
If the convector is excessively dirty, use a soft cloth moistened with water and a mild detergent at a temperature lower
than 50°C. Let the convector dry completely before use.
Do not use corrosive detergents or solvents such as petrol. Do not wash the appliance with water. Do not use oils,
chemical substances or other items to clean that may damage the surface.
Use a vacuum cleaner to remove dust from the air inlet/outlet grilles.
STORAGE
If the appliance is not used for prolonged periods, it must be stored together with this manual in its original packaging, in
a cool and dry place.

V 05/21
19
Table 2
INFORMATION REQUIREMENTS FOR ELECTRIC LOCAL SPACE HEATERS
Annex II - Ecodesign requirements - Requirements for product information -
COMMISSION REGULATION (EU) 2015/1188 of 28 April 2015 implementing Directive 2009/125/EC of the European
Parliament and of the Council with regard to ecodesign requirements for local space heaters
Model identifier(s): DAKOTA
Item Symbol Value unit Item unit
Heat output Type of heat input, for electric storage local space
heaters only (select one)
Nominal heat output Pnom 1,9 kW manual heat charge control, with
integrated thermostat
[no]
Minimum heat output
(indicative)
Pmin 1,25 kW manual heat charge control with room
and/or outdoor temperature feedback
[no]
Maximum continuous
heat output
Pmax,c 1,9 kW electronic heat charge control with room
and/or outdoor temperature feedback
[no]
Auxiliary electricity
consumption
fan assisted heat output [no]
At nominal heat output elmax 0 kW Type of heat output/room temperature control
(select one)
At minimum heat output elmin 0 kW single stage heat output and no room
temperature control
[no]
In standby mode elsb 0 kW Two or more manual stages, no room
temperature control
[no]
with mechanic thermostat room
temperature control
[no]
with electronic room temperature control [yes]
electronic room temperature control plus
day timer
[no]
electronic room temperature control plus
week timer
[no]
Other control options (multiple selections
possible)
room temperature control, with presence
detection
[no]
room temperature control, with open
window detection
[no]
with distance control option [no]
with adaptive start control [no]
with working time limitation [no]
with black bulb sensor [no]
Seasonal energy efficiency of space heating ηS(%) 37
Contact details : ARGOCLIMA SPA - Via A. Varo,35 - Alfianello (BS) - ITALY -
www.argoclima.com

V 05/21
20
Information for correct disposal of the product in accordance with the European Directive 2012/19/EU
At the end of its working life this equipment must not be disposed of as an household waste. It must be taken to special local
community waste collection centres or to a dealer providing this service. Disposing of electrical and electronic equipment
separately avoids possible negative effects on the environment and human health deriving from an inappropriate disposal and
enables its components to be recovered and recycled to obtain significant savings in energy and resources. In order to
underline the duty to dispose of this equipment separately, the product is marked with a crossed-out dustbin.
www.argoclima.com
