Argom Tech A1002 User manual

Brand Name: Argom
Model Name: A1002
FCC ID: Q34-A1002
Mobile Phone

2
User Manual
Dear customer:
Thank you for choosing this mobile phone. This mobile phone incorporates the
latest world advanced functions, enabling simple and convenient operation，satisfying
your special requirements.
The mobile phone supports T-FLASH (memory) card and Dual SIM standby. It
integrates the following available functions: SMS, MP3, MP4, Camera, FM radio,
Alarm, Video recorder and Calendar, enabling you arranging your work, study and
life freely; with long standby duration, as well as service and calculator, your
communication will be easier and smoother; powerful File manager allows you to
manage the files conveniently. In addition, the chord ringtone allows you selecting
music to set as ringtone; the personalized appearance also can satisfy your selection.
Note: User Manual is used to guide the user about the functionality of the phone.
Some functions may vary due to modifications and up gradations of software or due to
print mistakes.

3
Content
About the phone........................................................................................4
Display settings.............................................................................................................................4
Keys functions ..............................................................................................................................4
Getting started...........................................................................................5
First call ........................................................................................................................................5
Installing SIM cards and memory card .........................................................................................5
Battery and charging.....................................................................................................................6
Switching on/off............................................................................................................................6
Using hands free kit ......................................................................................................................7
Keypad lock..................................................................................................................................7
Specified keys...............................................................................................................................7
Language and input methods ........................................................................................................8
Calling........................................................................................................8
Making Calls.................................................................................................................................8
Receiving Calls.............................................................................................................................8
Rejecting Calls..............................................................................................................................8
Adjust volume...............................................................................................................................8
Menu guide................................................................................................9
Phonebook.....................................................................................................................................9
Messages.......................................................................................................................................9
Call center.....................................................................................................................................9
Multimedia....................................................................................................................................9
Fun & Games..............................................................................................................................10
Organizer.....................................................................................................................................10
Profiles........................................................................................................................................10
Settings........................................................................................................................................10
STK.............................................................................................................................................11
ATV.............................................................................................................................................11
Appendix..................................................................................................11
Appendix A: Please take care of your mobile phone ..................................................................11
Appendix B: Troubleshooting.....................................................................................................12
Appendix C: Abbreviation and explanation................................................................................13
Appendix D: Optional parts........................................................................................................13

4
About the phone
The mobile phone has 23 keys, one display, one earphone, charger/data cable port and
one external memory card (T-FLASH card) interface.
Display settings
The display area consists of three parts:
1> the top line displays icons, indicating the signal intensity and battery status.
2> the center area displays the text and figures, including numbers, words and dynamic icons.
3> the bottom line displays different options for operating, such as menu, names, ok and back.
Keys functions
Keys
Functions
Left soft key
Press this key to enter the main menu under standby mode;
Press this key to confirm the function you choose;
Right soft key
Press this key to enter phonebook list under standby mode;
Press this key to go back to previous menu;
SIM1/SIM2 Call
key
Press this key to call out;
Press to pick up phone when there is an incoming call;
Press to enter call logs under standby mode.
End key
Power Off: Long press to power off under standby mode;
Power On: Long press to power on if the phone is power off;
Press this key to go back to standby screen.
Messages key
Press this key to messages interface;
Navigation keys
Press them to scroll the options when browsing a function list. In edit state,
press direction keys to navigate. Under standby mode, press a direction key to
enter the specified function page. You can also customize direction keys to
match the desired functions. In conversation status, press up or down direction
key to adjust the sound volume.
OK key
Press OK key to confirm and enter main menu. Under standby mode, long

5
press this key to open/close the torch.
Number keys
Dial numbers under standby mode and enter numbers and characters in
editing mode.
* key
Under standby mode, press * key twice to display “+” to call international
numbers; ”P”and “W”to call extension numbers. Under players and FM mode,
press * key to decrease volume.
# key
Under standby mode, press and hold this key to switch between current
profile and meeting profile. Help to lock the keypad with pressing left soft key
first. Under players and FM mode, press # key to increase volume.
Getting started
First call
1> Insert the SIM cards (switch off the phone at first). For detailed installation guide, please refer to
“Installing the SIM card”.
2> Charge the battery. Refer to “Battery and charging”.
3> Press and hold the End key to switch on the mobile phone.
4> If the display prompts, enter the four-digit password and press “OK “key.
5> If the display prompts, enter the PIN code (provided together with the SIM card) and press” OK” key.
6> Enter area code and telephone number and then press the Call key/left soft key to dial out by SIM1/
SIM2 .
Note: Before using the mobile phone, please insert valid SIM cards and charge the battery.
Installing SIM cards and memory card
When you register mobile phone, you can apply for two different telephone numbers and two SIM cards
(Subscriber Identity Module). With the two cards, you can use the functions of the mobile phone. The SIM card
saves the parameters required by the communication, and personal information, including PIN code (personal
identity number), contacts, short messages and other system services.
Since the mobile phone doesn’t have enough space, you may need to install a memory card (T-FLASH
card).
To install the T-FLASH card: open the rear cover, take out the battery, insert the T-FLASH card into the slot,
install the battery and then turn on the mobile phone. To remove the T-FLASH card: open the buckle and take
out the T-FLASH card, and then lock the buckle.

6
Warning: Do not bend or scratch the SIM card, or contact static, dust or water; if the SIM card is lost,
please contact your network operator. Please switch off the mobile phone before installing the SIM card. The
SIM card is inserted into the rear side of the mobile phone.
Note: The T-flash card is tiny. Please keep it away from children to avoid swallowed. If the SIM card is
invalid or damaged, the phone displays “Insert SIM card”. Switch off the phone and take out the SIM card, and
then re-insert it into the slot properly. If the SIM card is damaged, please contact your network operator. If the
SIM card is locked, please contact your network operator.
Battery and charging
Installing the battery
Only use qualified battery and accessories. When the battery isn’t used, put it in the protective case.
Note: Please operate according to the figure to avoid damaging the battery contact.
Charging the battery
The new battery will reach its optimized performance after complete charging and discharging for several
times.
Please charge in time when the battery voltage is low. Over discharging will damage the battery.
Disconnect the charger from the AC power supply and the mobile phone after charging. While charging, the
battery status icon flashes from right to left, and stops flashing after charging. It is normal that the battery
becomes warm in the charging process.
Using 2-in-1 charger (charger + data cable)
The 2-in-1 charger may charge the battery through the mobile phone.
1> Connect the data cable and charger
2> Connect the data cable of the 2-in-1 charger to the I/O slot of the mobile phone.
3> Connect the charger plug of the 2-in-1 charger to the appropriate power outlet.
4> During charging, the icon of battery status blinks until the charging completes.
5> After charging, the battery icon stops flashing, and you can pull out the 2-in-1 charger.
Note: If the battery voltage is too low and can’t turn on the mobile phone, the charging icon may appear
on the screen after several minutes. The mobile phone may be turned on or off during charging.
Warning: Make sure that the local voltage and power match the rated voltage and power of the 2-in-1
charger.
Switching on/off
1> Press and hold the End key to switch on the mobile phone. The screen shows the power on video.
2> If the phone lock is activated, please input the password and press “OK” key. The default password is
1122.
3> If the PIN code is activated, please input the code and press “OK” key. The PIN code is provided by
the network operator.
4> Access to standby interface.
5> Press and hold the End key to switch off the mobile phone.

7
Password
The mobile phone and SIM cards have several passwords, which will prevent your mobile phone and SIM
cards from illegal operation. Press “OK” key after inputting the valid password (expressed in *). If there is
misinput; please press the “Clear” key to delete the error and then input the correct numbers. You can change the
PIN code, PIN2 code and phone password in “Settings – Security settings –SIM1/SIM2/ phone security”.
The phone password is the phone lock, which can prevent your mobile phone from illegal operation. The
phone password is provided together with the mobile phone by the manufacturer. The default password is 1122.
If the mobile phone is locked, you need to enter the password to turn on the mobile phone.
SIM1 PIN （SIM2 PIN）
PIN code: The PIN (Personal Identity Number) code is provided with the SIM card and will prevent your
SIM card from illegal operation. If the PIN lock is activated, the screen displays “Enter PIN” when you turn on
the mobile phone. While entering PIN code, the screen shows * instead. You can get the PIN code when you get
the SIM card from the network operator.
PIN2: the personal identity number required by certain functions such as call expense.
PUK and PUK2 (8-digit)
You also need to input PUK (personal unblocking key) code to change locked PIN code. To change the
locked PIN2, use PUK2. If the codes are not provided with the SIM card, please contact local service provider.
Warning: If you enter invalid PIN code for three times consecutively, the SIM card will be locked. In this
case, please contact the local network operator. The SIM card may be damaged permanently if you try to decode
by yourself.
Using hands free kit
With the hands free kit, you can make or answer calls without holding the mobile phone. When you inert
the hands free kit into the earphone port, the hands free kit can be used as the handset and the microphone of the
mobile phone.
Keypad lock
When the keypad is locked, the mobile phone will be locked automatically if there is no operation in
certain period of time. To unlock: Press the left soft key and # key.
Note: When the keypad is locked, it will be invalid. If there is new call, you can answer as usual, and the
mobile phone will resume the locked status after the call
Specified keys
1> Under player interface, press * key/# key to decrease/increase the volume of players and FM.
2> In the dial interface, press and hold the # key to activate/deactivate the meeting mode.
3> In dialing interface, press and hold * key to input “+”, “P” or “W”; “+” is used to call
international numbers and “P” and “W” are used to call extension numbers.

8
Language and input methods
The mobile phone provides English, Russian, Turkish, Arabic and Persian languages. And the phone
provides ABC/ abc / RU /ru / TR/ tr/ Arabic / Arabic numeric / Persian / Numeric input methods. You may need
to input text when you use the phone. For example: store a name in the phonebook or write a short message. In
edit state, press # key to switch input methods of body text. And you can press * key to enter symbol selection
screen.
Calling
When the marks of network providers to appear on screen, you can call or answer the
call. The signal strength is showing on the top left corner.
Making Calls
Enter area code and phone number and press call key to dial out by SIM1/SIM2.
Use the right soft key to delete if there is wrong input. Press and hold right soft key to clear all
characters.
Making a call from the phonebook
Open the phonebook list, scroll to search the desired number, press call key to dial out by SIM1/SIM2.
Latest numbers redial
Under standby mode, press call key to access the call history.
Press the up/down key to reach the desired number or name and press call key to dial out by SIM1/SIM2.
Receiving Calls
Press call key to receive an incoming call.
During a call, you can operate by pressing Left soft key: Hold, End single call, Phonebook and so on;
and you can also set Mute on/off.
Press end key to end a call.
Rejecting Calls
Press end key to reject a call.
Adjust volume
You can press Up/Down navigation keys to adjust volume during a call.

9
Menu guide
Phonebook
Contacts saved in the mobile phone contain the following information: the telephone name, number, Email
address, Caller picture and Caller ringtone. You can add new contacts to phone or SIM1/SIM2. Press <Menu>
under the standby mode and then select Phonebook if you desire to enter in the function.
Messages
Press <Menu> under the standby mode and then select Messages if you desire to enter in the function. Enter
this menu, you can view: Write message, Inbox, Drafts, Outbox, Sent messages, Broadcast messages, SMS
templates and SMS settings. You can operate them respectively.
Write message: You can enter this function menu to write short messages to send.
Inbox: You can read the received short messages in the Inbox, including SIM1 messages and SIM2
messages..
Drafts: Save the edited text message and you can perform operations respectively.
Outbox: If the message isn’t sent successfully, the message will be saved in the Outbox.
Sent messages: Turn on “Save sent message” in SMS settings, messages will be saved in Sent
messages.
SMS templates: You can check, use, edit and remove the templates.
SMS settings: You can set SIM1, SIM 2, memory status, save sent messages, preferred storage and so
on.
Call center
Press <Menu> and select Call center under the standby mode if you are desired to enter in this function.
Enter this menu; you can view SIM1/ SIM2 call history and call settings.
Call history: This mobile phone can register the missed calls, answered calls and dialed numbers of
SIM.
Call settings: You can set SIM1 call settings, SIM 2 call settings and advanced settings such as auto
redial and answer mode.
Multimedia
This mobile phone provides several amusement functions so that you can enjoy your time as your need. It
provides Camera, Image viewer, Video recorder, Video player, Audio player, Sound recorder and FM radio. With
this function, you can perform the multimedia functions, such as snap, shoot or record the voice. Press <Menu>
and then select Multimedia under the standby mode if desired to enter in this function.
Camera: In this menu, you can take pictures with the embedded camera and adjust the camera settings.
The camera lens is in the rear side of the mobile phone and the screen is the viewfinder window.
Image viewer: All the pictures are saved in image viewer, you can view, send, use as, rename, delete

10
the pictures as you need.
Video recorder: Press OK key to start video recording. The recording time depends on the time limit
and the capacity of the memory card.
Video player: Enter Video player. Press left soft key to enter options: Play, Send, Rename, Delete,
Delete all files and Storage.
Audio player: Audio Player supports several audio format files. Enter the list of music and you can
perform the following operation: Play, Details, Refresh list and settings.
Sound recorder: The mobile phone supports AMR/WAV recording formats. You can record
conversations, which may be saved to the Audio folder under File Manager.
FM radio: To use the FM Radio, please insert the earphone first and then listen to it.
Fun & Games
This phone provides a puzzle game for fun. You can set audio and volume for this game.
Organizer
This mobile phone provides several extra functions so that you can arrange your daily life conveniently, such
as File manager, Bluetooth, Calculator, Calendar, Alarm, World clock, Electric torch and Stopwatch. Press
<Menu > under the standby mode and select Organizer if you desire to enter in the function.
File manager: Enter in the game window. There is a game Puzzle, with the game settings menu.
Bluetooth: You can active Bluetooth to exchange files with other devices.
Calculator: You can use calculator to do some simple arithmetical operation.
Calendar: You can use calendar to check any day you want.
Alarm: The mobile phone allows setting 5 alarm clocks and the default option is Off. You can
customize the alarm as you need.
World clock: You can check the world clock of different cities.
Electric torch: On/Off the electric torch.
Stopwatch: You can use Typical stopwatch or nWay stopwatch to count time.
Profiles
This mobile phone provides four profiles for you. There are general, silent, meeting and outdoor profiles.
You can activate or customize these profiles.
Settings
This mobile phone provides several basic settings as following: Dual SIM settings, Phone settings, Network
settings, Security settings, Restore settings and Shortcuts,. Press <Menu> under the standby window and then
select Settings if you desire to enter in this function.
Dual SIM settings: Set status for SIM1/SIM2.
Phone settings: You can set some phone settings such as Time and data, language, display and so on.
