Arista ARP-2200AP SERIES User manual

USER MANUAL

Arista ARP-2200AP User Manual 2 |P a g e
Copyright
The documentation and the software included with this product are copyrighted 2010 by Arista Corporation. All rights are reserved.
Arista reserves the right to make improvements in the products described in this manual at any time without notice. No part of this
manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of
Arista Corporation. Information provided in this manual is intended to be accurate and reliable. However, Arista assumes no
responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use.
Acknowledgements
VIA is a trademark of VIA Technologies, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Corp.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
For more information on this and other Arista products, please visit our websites at:
http://www.goarista.com
For technical support and service, please visit our support website at:
http://support.goarista.com
This manual supports ARP-2200AP Series.

Arista ARP-2200AP User Manual 3 |P a g e
Product Warranty (2 years)
Arista Corporation supports its customers, before, during and after the sale. Arista provides one of the most comprehensive warranty
and support programs in the industry. From the date that your product is invoiced, Arista will provide a full two year depot warranty
which covers defects in design, materials, and workmanship. For out-of-warranty repairs, you will be billed according to the cost of
replacement materials, service time and freight.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU speed, Arista products used, other hardware
and software used, etc.) Note anything abnormal, and list any onscreen messages when the problem occurs.
2. Call your dealer and describe the problem. Please have the manual, product, and any helpful information readily available.
3. If the product is diagnosed as defective, obtain an RMA (return merchandize authorization) number from the dealer. This
allows Arista to process the return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement Order Card and a photocopy proof of
purchase date (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is
not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to the dealer.
For more information on the warranty, refer the following link:
http://www.goarista.com/downloads/documents/Arista_RMA_and_Product_Warranty_Policy_100222_v2.pdf

Arista ARP-2200AP User Manual 4 |P a g e
Technical Support and Assistance
1. Visit the Arista web site at www.goarista.com/support where you can find the latest information about the product.
2. Contact your distributor, sales representative, or Arista’s customer service center for technical support if you need additional
assistance. Please have the following information ready before you call:
Product name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Warnings, Cautions and Notes
Sl.No.
Symbols
Descriptions
1
Warning! Warnings indicate conditions, which if not observed, can
cause personal injury!
2
Caution! Cautions are included to help you avoid damaging
hardware or losing data.
Ex.: There is a danger of a new battery exploding if it is incorrectly
installed. Do not attempt to recharge, force open, or heat the battery.
Replace the battery only with the same or equivalent type
recommended by the manufacturer. Discard used batteries according
to the manufacturer’s instructions.
3
Note! If the unit you have bought is basic (i.e. without a CPU, HDD,
or SDRAM), you will find this optional item in the accessory box.
Document Feedback
To assist us with making improvements to this manual, we welcome comments and constructive criticism. Please send all suggestions
in writing to: [e-mail].

Arista ARP-2200AP User Manual 5 |P a g e
Packing List
Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with
the table, please contact your dealer immediately.
Sl.No.
Description
Qty
1
ARP-2200AP Series Panel PC
1
2
1 CD disk for utility and drivers
1
3
12V@2A, [email protected] power adapter
1
4
gasket (already stick on Panel PC)
1
5
Power cord
1
6
Mounting screws and mounting brackets
7
Additional Information and Assistance
1. Visit the Arista web site at www.goarista.com to find the latest information about the product.
2. Contact the distributor, sales representative, or Arista’s customer service center for technical support and additional
assistance. Please have the following information ready before calling:
Product name and serial number
Description of peripheral attachments
Description of software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Contact information:
Arista US Representative
Arista India Representative
Arista Taiwan Representative
Arista Corporation
40675 Encyclopedia Circle
Fremont, CA
94538-2475
Free: 1.877.827.4782
Phone: [phone]
Fax: [phone]
Arista Automation Pvt.Ltd.
Plot No.413, New No.15,
Ram Nagar 1st St, Velachery, Chennai-42
Tel: [phone]
Fax: [phone]
Arista Taiwan
3F, No.501-10, Zhongzhen Rd,
Xindian City 231, Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
.

Arista ARP-2200AP User Manual 6 |P a g e
Revision History
Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with
the table, please contact your dealer immediately.
Sl.No.
Revision By
Approved By
Revision History
Revision Date
1
Navan
Paul Shu
ARP-2200 Series Users’ Manual
(Initial Draft Version)
4/21/2010
2
3
4
5
6
7

Arista ARP-2200AP User Manual 7 |P a g e
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for
cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment from overheating. DO NOT COVER THE
OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to the user’s manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE TEMPERATURE MAY GO
BELOW -20°C (-4°F) OR ABOVE 60°C (140°F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.
17. The sound pressure level at the operator’s position according to IEC 704-1:1982 is no more than 70 dB (A).
DISCLAIMER: Arista Corporation reserves the right to make changes, without notice, to any product, including circuits and/or
software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or
liability for the use of the described product(s) conveys no license or title under any patent, copyright, or masks work rights to
these products, and make no representations or warranties that these products are free from patent, copyright, or mask work right
infringement, unless otherwise specified. Applications that are described in this manual are for illustration purposes only. We
make no representation or warranty that such application will be suitable for the specified use without further testing or
modification.
Safety Precaution - Static Electricity

Arista ARP-2200AP User Manual 8 |P a g e
Follow these simple precautions to protect yourself from harm and the products from damage.
To avoid electrical shock, always disconnect the power from the PC chassis before working on it. Don’t touch any
components on the CPU card or other cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush of power while connecting a jumper or
installing a card may damage sensitive electronic components.

Arista ARP-2200AP User Manual 9 |P a g e
Table of Contents
CHAPTER 1GENERAL INFORMATION...............................................................................................................13
1.1 Introduction............................................................................................................................................................13
1.2 Specifications........................................................................................................................................................14
1.2.1. ARP-2215AP Specifications ........................................................................................................................... 14
1.2.2. ARP-2217AP Specifications ........................................................................................................................... 16
1.2.3. ARP-2219AP Specifications ........................................................................................................................... 18
1.3 Dimensions............................................................................................................................................................20
CHAPTER 2HARDWARE INSTALLATION ...........................................................................................................23
2.1. A Quick Tour of ARP-2200AP Series....................................................................................................................23
2.2. Preparing for First-Time Usage.............................................................................................................................23
2.3. Installation and Mounting Procedures...................................................................................................................23
2.3.1. Mounting on Panel Cutout............................................................................................................................ 23
CHAPTER 3DRIVER INSTALLATION FOR WINDOWS XP-PRO ............................................................................28
3.1. Driver Installation –ARP2200AP A00 Model........................................................................................................28
3.1.1. Chipset Device Driver Software .................................................................................................................... 28
3.1.2. Display Driver Software................................................................................................................................. 31
3.1.3. Sound Card Driver Software.......................................................................................................................... 34
3.1.4. LAN Driver Software...................................................................................................................................... 36
3.2. Driver Installation –ARP2200AP D00 Model........................................................................................................41
3.2.1. Intel Chipset Device Software ....................................................................................................................... 41
3.2.2. Intel Graphic Media Accelerator Driver ........................................................................................................ 44
3.2.3. LAN Driver ..................................................................................................................................................... 48
3.2.4. Audio Driver .................................................................................................................................................. 50
CHAPTER 4ACP ENABLED ARP-2200AP SETUP ...........................................................................................53
4.1. The Boot Process..................................................................................................................................................53
4.2. IP Address Assignment.........................................................................................................................................54
4.2.1. DHCP ............................................................................................................................................................. 54
4.2.2. Static IP.......................................................................................................................................................... 55
4.2.3. Hybrid IP Addressing ..................................................................................................................................... 57
4.3. Configuring New Hardware...................................................................................................................................58

Arista ARP-2200AP User Manual 10 |P a g e
4.4. Create New Terminal Mode ..................................................................................................................................59
4.5. Replace or Create New Terminal Mode................................................................................................................59
4.6. Auto-Creation of Terminals...................................................................................................................................60
4.6.1. Enabling Auto-Create .................................................................................................................................... 60
4.6.2. Configuring Default Terminal........................................................................................................................ 61
CHAPTER 5ARP-2200AP SERIES OPTIONAL ACCESSORIES ...........................................................................66
5.1. Introduction............................................................................................................................................................66
5.2. Accessories...........................................................................................................................................................66
5.2.1. Power Supply ................................................................................................................................................ 66
CHAPTER 6CONNECTOR PIN ASSIGNMENTS ...................................................................................................69
6.1. USB Port ...............................................................................................................................................................69
6.2. COM Ports.............................................................................................................................................................69
6.2.1. COM1 Serial Port........................................................................................................................................... 69
6.2.2. COM2 Serial Port........................................................................................................................................... 69
6.2.3. COM3 Serial Port........................................................................................................................................... 70
6.2.4. COM4 Serial Port........................................................................................................................................... 70
6.2.5. COM5 Serial Port........................................................................................................................................... 71
6.2.6. COM6 Serial Port........................................................................................................................................... 71
6.3. Ethernet.................................................................................................................................................................72
6.4. VGA Port...............................................................................................................................................................72
6.5. PS/2 Mouse and Keyboard...................................................................................................................................73
6.6. Touchscreen..........................................................................................................................................................74
6.7. Mounting Bracket ..................................................................................................................................................74
6.8. Audio .....................................................................................................................................................................74
CHAPTER 7VIDEO ALIGNMENT (CALIBRATION)................................................................................................76
7.1. Options to Launch.................................................................................................................................................76
7.2. Running the Alignment Program...........................................................................................................................76
7.3. Calibrate Touch Screen (ACP ThinManager) .......................................................................................................77
CHAPTER 8MAINTENANCE AND TROUBLESHOOTING .......................................................................................80
8.1. Electrostatic Discharge .........................................................................................................................................81
8.1.1. Grounding Methods...................................................................................................................................... 81

Arista ARP-2200AP User Manual 11 |P a g e
8.2. Instructions Specific to Lithium Battery.................................................................................................................81
8.3. FCC Statement......................................................................................................................................................82
8.4. Exclusion of Accident Liability Obligation..............................................................................................................82
8.5. Liability Limitation / Exemption from Warranty Obligation.....................................................................................82
8.6. Reinstalling the Operating System........................................................................................................................82
8.6.1. Reinstalling the Drivers ................................................................................................................................. 82
8.7. Troubleshooting.....................................................................................................................................................82
CHAPTER 9CERTIFICATES AND COMPLIANCE..................................................................................................84

Arista ARP-2200AP User Manual 12 |P a g e
Chapter 1 General Information
General Information
This chapter gives background information on the ARP-5500AX Series.
Sections include:
Specifications
Dimensions

Arista ARP-2200AP User Manual 13 |P a g e
Chapter 1 General Information
1.1 Introduction
Congratulations!
Thank you for having purchased an industrial fanless computer from Arista Corporation. ARP-2200AP Series is designed to operate in
an industrial environment, features the very latest technologies.
Arista Corporation’s ARP-2200AP is an industrial fanless panel mount LCD computer. The standard configured units are offered with
1 GB of DDR or 2 GB DDR2-667, 160GB HDD, CD RW drive, choice of 15”, 17”, 19” LCD display and as well with the choice of
either 1.5GHz C7 CPU or 1.83GHz Core 2 Duo processor . The ARP-2200AP Series offers quick access hard disk bay, dual gigabit
Ethernet connectivity, five COM ports and six USB 2.0 ports and one PCI expansion slot. Unique to the ARP-2200AP Series is its
quick access HDD bay, which provides for prompt maintenance or replacements. The ARP-2200AP Series goes above and beyond
other fanless panel computing solutions in the marketplace.
The energy efficient ARP-2200AP Series fanless panel PC’s combines industry leading connectability with cutting-edge functionality.
Designed as high reliability, extreme environment control solutions, this series is ideally suited for demanding industrial
environments. The ARP-2200AP Series is designed as a ruggedized industrial solution with an all metal chassis and rock solid
construction and offers a highly evolved design with a proprietary chassis, advanced thermal heat sinks, and unique dual quick-access
HDD bay. This series is also available with 4GB, 6GB and 8GB solid state drives, providing 100% motionless, and 100% fanless
industrial panel computing. To maintain data integrity, the series is available with RAID 0/1 configurations.
When properly installed, the front panels offer NEMA 4 (Black Color Powder Coated) / 4X (Stainless Steel (optional)) and IP65
ingress protection. This feature makes ARP-2200AP an ideal solution for process automation in food and beverage plants and
chemical plants. The ARP-2200AP is available with DC24V or AC power input options and the AC power supply input voltage
ranges between 110V and 220V and this series operates from 0ºC to 50ºC.
The ARP-2200AP Series is also incorporated thin client technology into its design which gives easy replacement, server failover,
advantages to critical industrial applications.
ARP-2200AP industrial fanless panel mount LCD computer is suitable for a wide range of process automation applications in extreme
environmental conditions. The rugged NEMA4/4X and IP65 compliant ARP-2200AP Series features optional 1.5GHz C7 CPU or
1.83GHz Core 2 Duo processor and advanced thermal management system. As a result, the ARP-2200AP Series is compliant with the
ingress protection standard IP65 and is suitable for applications in hygiene sensitive environments in the food and confectionery
industries. This protects the series from flour dust, water, cleaning materials, and grease during production.
Arista Corporations’ ARP-2200AP Series industrial fanless panel mount LCD computer is housed in a polished stainless steel
enclosure and meets the most rigorous food hygienic standards. The fully enclosed design without any ventilation slots or external
fans makes this series completely splash-proof. It is equipped with a high-contrast, extremely durable industrial display with a

Arista ARP-2200AP User Manual 14 |P a g e
resolution of 1024 x 768 pixels to guarantee good readability under poor conditions. With the organized thermal management system,
the PC can be heated up to operating temperature and started within a short span of time in the food production industry.
ARP-2200AP Series fully sealed enclosure offers excellent chemical and corrosion resistance and hence an ideal solution for
petroleum refining, chemical industries and wastewater treatment where chemical compound are extensively used. The ARP-2200AP
Series enclosure is fully sealed through gasket which prevents chemical gas flowing into the unit causing electronic components
damage.
1.2 Specifications
The section describes the complete specification and ratings of ARP-2200AP Series fanless industrial panel display PC.
1.2.1. ARP-2215AP Specifications
The following table lists ARP-2215AP model’s complete specification and rating details.
ARP-2215AP
ARP-2215AP-A00
ARP-2215AP-D00
LCD Panel
Display Size (Diagonal)
15-inch
15-inch
Resolution
1024 x 768
1024 x 768
Backlight Life Time
30,000 Hours
30,000 Hours
Visual Characteristics
Colors
16 Million
16 Million
Aspect Ratio
4:3
4:3
Viewing Angle (V/H)
1200/ 1300
1200/ 1300
Response Time (Typical)
12 ms
12 ms
Pixel Pitch (mm)
0.297 x 0.297
0.297 x 0.297
Contrast Ratio
500:1
500:1
Brightness
250 nits
250 nits
Touch Screen
Technology
5 Wire Resistive
5 Wire Resistive
Touch Rating
35 Million Touches
35 Million Touches
MTBF
490,000 Hours
490,000 Hours
Interface
RS-232
RS-232
Driver
Win XP Pro, XP
Win XP Pro

Arista ARP-2200AP User Manual 15 |P a g e
System
CPU
VIA 1.5 GHz C7 CPU
Core 2 Duo Mobile
Chipset
VIA CN 700
GME965 + ICH8M
Memory
Up to 1 GB
Up to 4 GB
Display
CN 700 Integrated S3 Graphic Engine
GME965 GMA X3100
VRAM
Up to 64 MB Share with System
DVMT 4.0 up to 384 MB Video Memory
Storage Option
Up to 2 x 2.5-inch SATA HDD, RAID 0/1
Support
Up to 2 x 2.5-inch SATA HDD, RAID 0/1
Support
Compact Flash
Optional CF
Optional CF
Keyboard / Mouse
2 x PS / 2 Connectors
2 x PS / 2 Connectors
Audio
Line in, Line Out, Mike-In
Line in, Line Out, Mike-In
Watchdog Timer
Programmable 1~255 sec
Programmable 1~255 sec
Expansion Slot
1 x PCI
1 x PCI
I/O Communication
USB Port
6 x USB 2.0
6 x USB 2.0
Serial Port
5 x RS-232, 1 x RS-232/422/485
5 x RS-232, 1 x RS-232/422/485
IEEE 1394
N/A
2 x IEEE 1394B
LAN
Dual Gigabit LAN
Dual Gigabit LAN
Parallel Port
1 x Port
1 x Port
OS Support
OS Support
Win XP Pro, XP
Win XP Pro
Power / Thermal Specs.
Power Requirement (Max)
120VAC/0.775A, 24VDC/3.8A
120VAC/0.96A, 24VDC/4.8A
Power Consumption (Max)
93W
115W
Heat Dissipation
317 BTU / Hour
391 BTU / Hour
Physical Information
Mounting
Panel Mount
Panel Mount
Net Weight
16.1 lbs / 7.31 kg
16.1 lbs / 7.31 kg
Physical / Dimension (LxWxH)
14.51 x 11.08 x 4.52 inch / 368.55 x 298.82 x
14.51 x 11.08 x 4.52 inch / 368.55 x 298.82

Arista ARP-2200AP User Manual 16 |P a g e
114.86 mm
x 114.86 mm
Cutout Dimension (LxW)
13.65 x 11.02 inch / 346.65 x 279.82 mm
13.65 x 11.02 inch / 346.65 x 279.82 mm
Environmental
Operating Temperature
00~ 500C (320~ 1220F)
00~ 500C (320~ 1220F)
Storage Temperature
-200~ 600C(-40~ 1400F)
-200~ 600C(-40~ 1400F)
Relative Humidity
5% ~ 95% (Non-Condensing)
0% ~ 95% (Non-Condensing)
Rating
NEMA 4 / 4X Bezel
NEMA 4 / 4X Bezel
Certification
1.2.2. ARP-2217AP Specifications
The following table lists ARP-2217AP model’s complete specification and rating details.
ARP-2217AP
ARP-2217AP-A00
ARP-2217AP-D00
LCD Panel
Display Size (Diagonal)
17-inch
17-inch
Resolution
1280 x 1024
1280 x 1024
Backlight Life Time
50,000 Hours
50,000 Hours
Visual Characteristics
Colors
16 Million
16 Million
Aspect Ratio
4:3
4:3
Viewing Angle (V/H)
1400/ 1400
1400/ 1400
Response Time (Typical)
12 ms
12 ms
Pixel Pitch (mm)
0.264 x 0.264
0.264 x 0.264
Contrast Ratio
800:1
800:1
Brightness
300 nits
300 nits
Touch Screen
Technology
5 Wire Resistive
5 Wire Resistive
Touch Rating
35 Million Touches
35 Million Touches
MTBF
490,000 Hours
490,000 Hours

Arista ARP-2200AP User Manual 17 |P a g e
Interface
RS-232
RS-232
Driver
Win XP Pro, XP
Win XP Pro
Front Bezel
NEMA 4
Black Powder Coated
Black Powder Coated
NEMA 4X
Stainless Steel (Optional)
Stainless Steel (Optional)
System
CPU
VIA 1.5 GHz C7 CPU
Core 2 Duo Mobile
Chipset
VIA CN 700
GME965 + ICH8M
Memory
Up to 1 GB
Up to 4 GB
Display
CN 700 Integrated S3 Graphic Engine
GME965 GMA x 3100
VRAM
Up to 64 MB Share with System
DVMT 4.0 up to 384 MB Video Memory
Storage Option
Up to 2 x 2.5-inch SATA HDD, RAID 0/1
Support
Up to 2 x 2.5-inch SATA HDD, RAID 0/1
Support
Compact Flash
Optional CF
Optional CF
Keyboard / Mouse
2 x PS / 2 Connectors
2 x PS / 2 Connectors
Audio
Line in, Line Out, MIC-In
Line in, Line Out, MIC-In
Watchdog Timer
Programmable 1~255 sec
Programmable 1~255 sec
Expansion Slot
1 x PCI
1 x PCI
I/O Communication
USB Port
6 x USB 2.0
6 x USB 2.0
Serial Port
5 x RS-232, 1 x RS-232/422/485
5 x RS-232, 1 x RS-232/422/485
IEEE 1394
N/A
2 x IEEE 1394B
LAN
Dual Gigabit LAN
Dual Gigabit LAN
Parallel Port
1 x Port
1 x Port
OS Support
OS Support
Win XP Pro, XP
Win XP Pro
Power / Thermal Specs.
Power Requirement (Max)
120VAC/0.775A, 24VDC/3.8A
120VAC/0.96A, 24VDC/4.8A
Power Consumption (Max)
108W
130W

Arista ARP-2200AP User Manual 18 |P a g e
Heat Dissipation
368 BTU / Hour
442 BTU / Hour
Physical Information
Mounting
Panel Mount
Panel Mount
Net Weight
19.9 lbs / 9.03 kg
19.9 lbs / 9.03 kg
Physical / Dimension (LxWxH)
15.88 x 13.34 x 4.86 inch / 403.35 x 338.84 x
123.50 mm
15.88 x 13.34 x 4.86 inch / 403.35 x 338.84
x 123.50 mm
Cutout Dimension (LxW)
14.97 x 12.43 inch / 380.19 x 315.67 mm
14.97 x 12.43 inch / 380.19 x 315.67 mm
Environmental
Operating Temperature
00~ 500C (320~ 1220F)
00~ 500C (320~ 1220F)
Storage Temperature
-200~ 600C(-40~ 1400F)
-200~ 600C(-40~ 1400F)
Relative Humidity
0% ~ 95% (Non-Condensing)
0% ~ 95% (Non-Condensing)
Rating
NEMA 4 / 4X Bezel
NEMA 4 / 4X Bezel
Certification
1.2.3. ARP-2219AP Specifications
The following table lists ARP-2219AP model’s complete specification and rating details.
ARP-2219AP
ARP-2219AP-A00
ARP-2219AP-D00
LCD Panel
Display Size (Diagonal)
19-inch
19-inch
Resolution
1280 x 1024
1280 x 1024
Backlight Life Time
50,000 Hours
50,000 Hours
Visual Characteristics
Colors
16 Million
16 Million
Aspect Ratio
4:3
4:3
Viewing Angle (V/H)
1780/ 1780
1780/ 1780
Response Time (Typical)
20 ms
20 ms
Pixel Pitch (mm)
0.294 x 0.294
0.294 x 0.294
Contrast Ratio
700:1
700:1
Brightness
300 nits
300 nits

Arista ARP-2200AP User Manual 19 |P a g e
Touch Screen
Technology
5 Wire Resistive
5 Wire Resistive
Touch Rating
35 Million Touches
35 Million Touches
MTBF
490,000 Hours
490,000 Hours
Interface
RS-232
RS-232
Driver
Win XP Pro, XP
Win XP Pro
Front Bezel
NEMA 4
Black Powder Coated
Black Powder Coated
NEMA 4X
Stainless Steel (Optional)
Stainless Steel (Optional)
System
CPU
VIA 1.5 GHz C7 CPU
Core 2 Duo Mobile
Chipset
VIA CN 700
GME965 + ICH8M
Memory
Up to 1 GB
Up to 4 GB
Display
CN 700 Integrated S3 Graphic Engine
GME965 GMA x 3100
VRAM
Up to 64 MB Share with system
DVMT 4.0 up to 384 MB Video Memory
Storage Option
Up to 2 x 2.5 inch SATA HDD, RAID 0/1
Support
Up to 2 x 2.5 inch SATA HDD, RAID 0/1
Support
Compact Flash
Optional CF
Optional CF
Keyboard / Mouse
2 x PS / 2 Connectors
2 x PS / 2 Connectors
Audio
Line in, Line Out, MIC-In
Line in, Line Out, MIC-In
Watchdog Timer
Programmable 1~255 sec
Programmable 1~255 sec
Expansion Slot
1 x PCI
1 x PCI
I/O Communication
USB Port
6 x USB 2.0
6 x USB 2.0
Serial Port
5 x RS-232, 1 x RS-232/422/485
5 x RS-232, 1 x RS-232/422/485
IEEE 1394
N/A
2 x IEEE 1394B
LAN
Dual Gigabit LAN
Dual Gigabit LAN
Parallel Port
1 x Port
1 x Port
OS Support

Arista ARP-2200AP User Manual 20 |P a g e
OS Support
Win XP Pro, XP
Win XP Pro
Power / Thermal Specs.
Power Requirement (Max)
120VAC/0.775A, 24VDC/3.8A
120VAC/0.96A, 24VDC/4.8A
Power Consumption (Max)
113W
135W
Heat Dissipation
385 BTU / Hour
459 BTU / Hour
Physical Information
Mounting
Panel Mount
Panel Mount
Net Weight
23.3 lbs / 10.57 kg
23.3 lbs / 10.57 kg
Physical / Dimension (LxWxH)
17.8 x 14. 6 x 4.86 inch / 452.12 x 370.84 x
123.50 mm
17.8 x 14. 6 x 4.86 inch / 452.12 x 370.84 x
123.50 mm
Cutout Dimension (LxW)
16.90 x 13.70 inch / 429.20 x 347.92 mm
16.90 x 13.70 inch / 429.20 x 347.92 mm
Environmental
Operating Temperature
00~ 500C (320~ 1220F)
00~ 500C (320~ 1220F)
Storage Temperature
-200~ 600C(-40~ 1400F)
-200~ 600C(-40~ 1400F)
Relative Humidity
0% ~ 95% (Non-Condensing)
0% ~ 95% (Non-Condensing)
Rating
NEMA 4 / 4X Bezel
NEMA 4 / 4X Bezel
Certification
1.3 Dimensions
This section describes the line drawings and appropriate product dimensions specific to ARP-2200 Series.
