Arista ARP-3600AP-E01 Series User manual

Thank you for purchasing our ARP-3600AP-E01 Series Fanless Touch Panel Computer.
Arista Corporation's ARP-3600AP-E01 Series touch panel computer is a kind of industrial-level
fanless touch screen All-in-One computer with high performance and low power consumption. We
are condent that you will be pleased with the performance and reliability of your new touch panel
computer. This ARP-3600AP-E01 Series touch panel computer is designed to be operated in harsh
environments and meet the performance requirements of today's demanding industrial applications.
The ARP-3600A-E01 Series touch panel computer provides auto-input synchronization and easy to
use interfaces.
Publication date: 2016/03/24
Version No.: V1.5
USER MANUAL
Talk to us. We listen.
ARP-3600AP-E01 Series Fanless Touch Panel Computer
ARP-3610AP-E01 ARP-3615AP-E01 ARP-3617AP-E01
ARP-3619AP-E01 ARP-3621AP-E01 ARP-3624AP-E01

2
Product safety precautions
Important: Read all the contents of this instruction manual carefully before
you rst use the ARP-3600AP-E01 Series touch panel computer.
Read all of these instructions and save this manual for later use. Follow all warnings and
instructions on the product.
• Relative humidity: 25%~80%
• Storage temperature: -20oC to 60oC(-4F to 140F)
• Operation temperature: 0~50oC(32F to 122F)
• Unplug the unit when not in use for an extended period of time.
• Consult a service technician if the ARP-3600AP-E01 Series touch panel computer
does not operate normally when you have followed the instructions in this manual.
• Do not attempt to repair this product yourself. Always get a qualified service
technician to carry out adjustments or repairs.
• Do not place heavy objects on the unit.
• Use only the power cord supplied with the unit. In the event that another power cord
isused,onethatisdi󰀨erentthantheoneprovidedbythesupplier,makesurethatit
iscertiedbythelocalandapplicablenationalstandards.
• If the power cable is faulty in any way, please contact the manufacturer or the nearest
authorized repair service provider for a replacement.
• The power supply cord is used as the main disconnect device. Ensure that the socket
outlet is easily accessible after installation.
• Overloaded AC outlets, extension cords, frayed power cords, and broken plugs are
extremelydangerous.Theymay,andcan,resultinanelectricalshockorrehazard.
Call an authorized service technician for any replacements.
• Hands must be dry when plugging the power cord into an AC outlet to prevent
electrical shock. Do not damage the power cord by disassembling, bending, pulling
orexposingittoheatasitmaycauseareorelectricalshock.
• Make sure to completely insert the power plug into an AC outlet. Insecure
connectionscancauseare.
• Ensure that the power source is grounded correctly.
• Unplug the ARP-3600AP-E01 Series touch panel computer if cleaning is needed. The
unitmaybewipedwithadryorslightlydampclothwhenthepoweriso󰀨.

3
Contents
Product safety precautions ................................................................................................2
Contents...............................................................................................................................3
Chapter 1 Welcome .........................................................................................................4
Features............................................................................................................................................4
Product specications....................................................................................................................5
Unpacking ........................................................................................................................................6
Chapter 2 Basics.................................................................................................................7
Product overview.......................................................................................................7
Physical dimensions .....................................................................................................................9
Chapter 3 Connections ...................................................................................................15
Pins in the Serial port( COM1~COM4).......................................................................................16
Pins in the VGA port......................................................................................................................17
Pins in the GPIO port........................................................................................................18
Pins in the DC-IN power connector...............................................................................................19
Mounting the computer............................................................................................20
Connecting to a display............................................................................................22
Connecting to keyboard or mouse............................................................................................23
Connecting to network............................................................................................24
Connecting to the COM port............................................................................................24
Connecting the power supply.............................................................................25
Connecting the battery power............................................................................................27
Installing memory module/expansion card..................................................................................28
Adjustment on touch screen..................................................................................31
Chapter 4 BIOS Setup.......................................................................................................33
Introduction....................................................................................................33
Entering the setup..............................................................................................34
Main Menu..........................................................................................36
Advanced Menu............................................................................................37
Chipset Menu....................................................................................44
Security Menu................................................................................................47
Boot Menu................................................................................................48
Save&Exit Menu.........................................................................................49
Chapter 5 Appendix.........................................................................................................50
Care and Maintenance ................................................................................................................50
Product Limited Warranty............................................................................................................51
Disposal and Recycling Information.............................................................................55
Disclaimer and Copyright Notice...............................................................................................55
Contents

4
Features
• Compact design, easy to use, supports hot-plug.
• Black color or stainless steel bezel.
• 10”, 15”, 17”,19”, 21”, 24” color TFT LCD display, color supports up to 8 bit per color,
total 16.7 million colors.
• Faster in running, lower in power consumption.
• Intel 1.9GHz E3845 Quad Core Atom Processor
• Intel E3845 Chipset
• Double Data Rate (DDR) memory technology, supports up to 8GB of system memory
using 1333DIMM.
• Supports up to four USB ports: . 1 x USB 3.0, 3 x USB 2.0 ports
• Supports Touch function for quick operation(5-Wire resistive touch screen).
• Supports display resolution up to 1280(x3) x 1024
• Supports up to four serial ports, and theserialport(COM1)canbeindividuallycongured
to RS-232, RS-422 or RS-485 mode.
• Build-in expansion connectors: CFAST Card slot, MINI-PCIE slot, the MINI-PCIE slot
supports Wi-Fi function and Solid State Drives(SSD).SATA DOM, 2.5” HDD, 2.5” SSD.
• Supports programmable GPIO port(4-bit Input, 4-bit Output).
• Two Dual Gigabit RJ45 LAN ports, provides high-speed and stable network connections.
• Support External Smart Battery power input.
• Panel moutable for better stability.
• Strengthenedprotectiveglass(anti-reectiveoptional).
• Sunlight readable option.
• High brightness, contrast and wide viewing angles.
• Built-in lightning & surge protection.
• Super interference rejection.
Applications
• O󰀩ceelectronics
• Instrumentation and measuring equipment
• Machine tools
• Audiovisual equipment
• Home appliances
• Communication equipment other than trunk lines
Do not use the products covered herein for the following equipment that demands
extremely high performance in terms of functionality, reliability, or accuracy.
Aerospace equipment
Communication equipment for trunk lines

5
Product specications
Display
Display Type Active Matrix TFT LCD
Brightness 400 NITS
Contrast Ratio 500:1
Max Resolution 1280 x 1024
Colors Supported 16 Million
Dot size 0.264
Viewing Angles 60 agrees(up), 80 agrees(down), 80 agrees(left), 80 agrees(right)
Backlight 50,000 hours typical
Touch Screen 5 wire resistive touch
System
CPU Intel 1.9GHz E3845 Quad Core Atom Processor
Chipset Intel E3845 chipset
Memory Up to 8GB, DDR3 SO-DIMM (1333MHz)
Video interface VGA, HDMI
Storage option SATA DOM, CFAST SSD, Mini PCIe DOM
Compactash N/A
GPIO 8-bit GPIO
BIOS American megatrends
Connectors
Video connector 1 x VGA, 1 x HDMI
USB port 4 x USB2.0 port
Serial port 3x RS-232(COM2,COM3, COM4), 1x RS-232/422/485 port(COM1)
GPIO 1 x GPIO port
LAN 2 x LAN, Dual Gigabit LAN
Keyboard/Mouse 1x PS2 keyboard, 1x PS2 mouse
CFAST Card 1 x CFAST Card slot
Power 1x DC-IN power, 1 x Battery power input
Operating system
OS Support Windows, Thin SP3 7.0 Manager
Physical information
Mounting Panel mounting
Physical dimension
ARP-3610AP-E01: 11.50*8.80*4.20 inch/ 292*224*107 mm (L*W*D)
ARP-3615AP-E01: 14.50*11.80*4.36 inch/ 369*300*111 mm (L*W*D)
ARP-3617AP-E01: 15.88*13.34*4.58 inch/ 403*339*116 mm (L*W*D)
ARP-3619AP-E01: 17.80*14.60*4.87 inch/ 452*371*124 mm (L*W*D)
ARP-3621AP-E01: 20.98*12.99*4.58 inch/ 533*330*116 mm (L*W*D)
ARP-3624AP-E01: 23.91*14.50*4.51 inch/ 607*368*115 mm (L*W*D)
Mechnical information
Power requirement ( Max ) 24VDC/2A ( DIN-Rail power supply), Battery power(12V,4A)
Power consumption ( Max ) 48W
Heat dissipation 85 BTU/hr
Operation temperature 0~50OC [32~122F]
Storage temperature -20~60OC [-4~140F]
Relative humidity 20~90% RH [no condensation]

6
Open the package and inspect the items carefully to make sure no item is damaged and all
items listed are present in your package. t ures
ARP-3600AP-E01 Series touch panel computer
Unpacking
AC power cable x1
DIN-Rail AC/DC power supply x1
DC power cable x1 Mounting bolts and screws

7
Product overview
Chapter 2 Basics
Side
Bottom
Front
ARP-3600AP-E01 Series Touch Panel Computer

8
Speed LED Activity LED
LED Indications on the LAN port
Status Description
Activity
LED
O󰀨 No network connection
On Data transmission activity
Speed
LED
O󰀨 Data transmission at the rate of 10Mbps
Orange Data transmission at the rate of 1Gbps
Green Data transmission at the rate of 100Mbps
PWR LED: Power LED indicator -The LED lights up when you turn on the system,
andbeo󰀨whenthesystemisinstandbymode.
HDD LED: Hard Disk Activity LED indicator-The read or write activities of the
hard disk cause the LED to light up.
1234
5
6
78
9
11
10
12
13
1. PS/2 Keyboard connector 8. CFAST card slot
2. PS/2 Mouse connector 9. USB port
3. USB ports 10. Power LED(up)/HDD LED(down) indicator
4. HDMI port 11. 24V DC-IN power connector
5. GPIO port 12. Battery power input connector
6. RJ45 LAN port 13. Serial ports (COM1~COM4)
7. VGA port

9
Thediagramsbelowshowthephysicaland specicdimensionsoftheARP-3600AP-E01
Series touch panel computer.
Physical dimension
268.0mm
10.6"
292.1mm
11.5"
106.9mm
4.2" 50.25mm
2.0"
34.5mm
1.4"
200.4mm 7.9"
140.5mm 5.53"
223.5mm
8.8"
201.4mm
7.9"
33.3mm
1.3"
For ARP-3610AP-E01

10
Thediagramsbelowshowthephysicaland specicdimensionsoftheARP-3600AP-E01
Series touch panel computer.
Physical dimension
For ARP-3615AP-E01
344.0mm
13.5"
368.5mm
14.5"
96.1mm 3.8"
277.0mm 10.9"
140.5mm 5.5"
299.8mm
11.8"
201.4mm
7.9"
71.3mm
2.8"
56.5mm
2.22"
54.4mm
2.14"

11
For ARP-3617AP-E01
377.5mm
14.86"
403.4mm
15.88"
56.5mm
2.22"
59.8mm
2.36"
135.0mm 5.32"
316.0mm 12.44"
140.5mm 5.53"
338.8mm
13.34"
201.4mm
7.93"
88.0mm
3.47"

12
For ARP-3619AP-E01
427.0mm
16.81"
452.1mm
17.80"
56.5mm
2.22"
67.1mm
2.64"
164.7mm 6.48"
345.6mm 13.61"
140.5mm 5.53"
370.8mm
14.60"
201.4mm
7.93"
112.8mm
4.44"

13
For ARP-3621AP-E01
501.0mm
19.72"
533.0mm
20.98"
56.5mm
2.22"
59.8mm
2.35"
127.8mm 5.03"
308.7mm 12.15"
140.5mm 5.53"
330.0mm
12.99"
201.4mm
7.93"
149.8mm
5.90"

14
For ARP-3624AP-E01
584.8mm
23.02"
607.3mm
23.91"
114.6mm
4.51"
57.9mm
2.28"
164.5mm 6.48"
345.7mm 13.61"
140.5mm 5.53"
368.3mm
14.50"
201.4mm
7.93"
191.7mm
7.55"
L(Overall Length) W(Overall width) H(Overall Height)
ARP-3610AP-E01 11.50”/292.1mm 8.80”/223.5mm 4.20”/106.9mm
ARP-3615AP-E01 14.50”/368.5mm 11.80”/299.8mm 4.36”/110.9mm
ARP-3617AP-E01 15.88”/403.4mm 13.34”/338.8mm 4.58”/116.3mm
ARP-3619AP-E01 17.80”/452.1mm 14.60”/370.8mm 4.87”/123.6mm
ARP-3621AP-E01 20.98”/533.0mm 12.99”/330.0mm 4.58”/116.3mm
ARP-3624AP-E01 23.91”/607.3mm 14.50”/368.3mm 4.51”/114.6mm

15
Connectors are located at the bottom of ARP-3600AP-E01 Series touch panel computer.
Chapter 3 Connections
This section describes the connections/connectors available on the ARP-3600AP-E01 Series
touch panel computer.

16
Pins in the serial port(COM1~COM4)
6789
1 2 3 4 5
Pin NO. Denition(RS-232 mode) Denition(RS-422/RS-485 mode)
1 DCD, data carrier detect TX-, Transmit data ground (RS-422/RS-485)
2 RXD, Receive data TX+, Transmit data(RS-422/RS-485)
3TXD, Transmit data RX+, Receive data (RS-422)
4 DTR, Data terminal ready RX-, Receive data ground (RS-422)
5 GND, Signal ground GND, Signal ground
6 DSR, Data set ready N.C.
7 RTS, Request to send N.C
8 CTS, Clear to send N.C
9 Ring-IN, Ring indicator N.C.
Note: COM1 port is available for RS-232 mode(default), RS-422 mode or RS-485 Mode.

17
Pins in the VGA port
2345
6
78
9
10
1112131415
Pin NO. Pin Assignment Denition
1 VGA R VGA Red signal
2 VGA G VGA Green signal
3 VGA B VGA Blue signal
4 NC No connection
5 GND Ground
6 GND Ground
7 GND Ground
8 GND Ground
9 NC No connection
10 GND Ground
11 NC No connection
12 CRT DDC Data The data of display data channel
13 VGA HS VGA H-Sync signal
14 VGA VS VGA V-Sync signal
15 CRT DDC Clock The clock of display data channel
1

18
Pins in the GPIO port
123456 78910
The GPIO (General Purpose Input/Output) port is optional and can be used as
expansion input or output ports by software routines as needed.
Pin NO. Pin Assignment Denition
1 +V5S +V5S
2 I/O_BUS_GPIO1 GPIO input
3 I/O_BUS_GPIO2 GPIO output-
4 I/O_BUS_GPIO3 GPIO input
5 I/O_BUS_GPIO4 GPIO output
6 I/O_BUS_GPIO5 GPIO input
7 I/O_BUS_GPIO6 GPIO output
8 I/O_BUS_GPIO7 GPIO input
9 I/O_BUS_GPIO8 GPIO output
10 GND Ground
GPIO
settings
Input Ouput
I/O_BUS_GPIO1 GPIO42 0xFFF240 bit2 I/O_BUS_GPIO2 GPIO71 0xFFF270 bit1
I/O_BUS_GPIO3 GPIO50 0xFFF250 bit0 I/O_BUS_GPIO4 GPIO16 0xFFF210 bit6
I/O_BUS_GPIO5 GPIO52 0xFFF250 bit2 I/O_BUS_GPIO6 GPIO75 0xFFF270 bit5
I/O_BUS_GPIO7 GPIO43 0xFFF240 bit3 I/O_BUS_GPIO8 GPIO81 0xFFF280 bit1

19
Pins in the DC-IN power connector
2
Pin NO. Denition
1 GND
2 24V
1

20
Mounting the computer
1. Panel mounting
The ARP-3600AP-E01 Series touch panel computer can be placed on a shelf, table,
or mounted onto a wall or board. To mount it onto a wall or board, you will require the
mounting bolts and screws found in the accessory box.
Please follow the steps shown in the diagram below:
Step2. Situate the bottom cover of ARP-3600AP-E01 Series touch panel computer
within the place on a board or a wall where the mounting holes are pre-drilled. And align
the mounting bolts installed on the four sides of ARP-3600AP-E01 Series touch panel
computer with the mounting holes on the wall or board.
Step1. There are mounting slots located on the four sides of the ARP-3600AP-E01 Series
touchpanelcomputer.Asshown inthegurebelow,putandslidethesuppliedmounting
bolts into the mounting slots.
Wall or board
Mounting hole
Mounting bolt
Mounting slot
Mounting bolt
