MC25MM632 | Slim-Grip® Ultra™ 25mm Handlebar Phone or Midsize Tablet Mount rev.011119
Safety Precautions
Arkon is not responsible for any damages caused to your vehicle, your
device, or yourself due to the installation or use of this mount.
!
MC25MM632 | Slim-Grip® Ultra™ 25mm Handlebar Phone or Midsize Tablet Mount rev.011119
Package Contents:
(1) MC25MMB –Motorcycle Handlebar Mount
(1) SP-RMS250 – Small Robust Mount Shaft
(1) SM060-2 – Slim-Grip®Ultra™ Universal Smartphone & Tablet Holder
(1) APRM2T – 25mm Ball to Dual T-Tab Adapter
(1) AP2TSTRAP – Dual T-Slot to Dual T-Tab Elastic Securing Strap
This Motorcycle Mount fits cylindrical handlebars up to 30mm diameter
and comes with 3 handlebar spacer/adapter rings of different widths.
Select the appropriate size for optimum mounting to your handlebar.
The Slim-Grip® Ultra™ Universal Smartphone & Tablet Holder fits devices
up to 7.5 inches tall.
MC25MMB SM060-2 AP2TSTRAP
3 4
APRM2T
SP-RMS250
Place handlebar spacer/adapter ring around handlebar. Attach mount
to handlebar around spacer. Use the included hex key to securely
tighten both mounting screws.
1Attach Robust Mount Shaft by unscrewing knob to loosen collar.
Adjust angle then retighten knob to secure.
2
Handlebar Spacer/
Adapter Ring
H
Mounting Screw
Mounting Screw
Attach strap by inserting the strap’s Dual T-Tabs in to the holder’s Dual
T-Slots. Attach adapter by inserting the adapter’s Dual T-Tabs into the
strap’s Dual T-Slots. Insert screw to secure.
Attach the assembled mobile phone holder by combining the adapter
to the Robust Mount Shaft and tightening to secure.
Dual T-Tabs
Dual T-Slots
s
Set Screw

Safety Precautions
Arkon is not responsible for any damages caused to your vehicle, your
device, or yourself due to the installation or use of this mount.
Consumer Hotline:
USA [phone]
INT’L [phone]
Monday - Friday 9am - 5pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2019 Arkon Resources, Inc.
!
MC25MM632 | Slim-Grip® Ultra™ 25mm Handlebar Phone or Midsize Tablet Mount rev.011119
Insert device. Adjust mount as needed.
5
Secure strap
hook
Push down on lower legs to
mount device
6Place securing strap across the device and secure it to the
L-shaped strap hook.
