Operator’s Manual
Manuel d’utilisation
Manual del Usuario
Wet/Dry Vacuum
Aspirateur de détritus secs et de liquides
Aspiradora Mojado/Seco
FR EN
FR
ES
P. 02
P. 20
P. 38
FOR YOUR SAFETY
Read and understand this manual before use. Keep this manual for future reference.
POUR VOTRE SÉCURITÉ
Veuillez lire attentivement et comprendre ce manuel d'utilisation avant d'utiliser l'aspirateur
de détritus secs et de liquides. Conserver ce manuel pour référence ultérieure.
PARA SU SEGURIDAD
Lea y comprenda este manual antes de usar el producto. Conserve este manual
para futura referencia.
4 Gallon / 4 Galones / 4 Gallons
Model No. • N° de modelo • Référence de modèle
VO405P 0901

2
SECTION PAGE
TABLE OF CONTENTS
Thank you for purchasing this Armor All®wet/dry vacuum cleaner. Feel confident that with
our Armor All®wet/dry vac you are obtaining a high-quality product engineered for optimal
performance.This vacuum is capable of picking up liquids and dry materials.
IMPORTANT INFORMATION
GALLONS
"Tank Size" refers to the actual tank volume and does not reect capacity available during operation.
PEAK HP
"Peak Horsepower" is a term used in the wet-dry vac industry for consumer comparison purposes. It
does not denote the operational horsepower output of a wet-dry vac, but rather the horsepower output
of a motor, including the motor’s inertial contribution, achieved in laboratory testing. In actual use,
motors do not operate at the peak horsepower shown.
FOR YOUR SAFETY: CAREFULLY READ AND UNDERSTAND ALL INSTRUCTIONS.
Warranty .........................................................................................................................................3
Important Safety Instructions ..........................................................................................................3
Double Insulation Instructions.........................................................................................................5
Extension Cords..............................................................................................................................6
Symbols..........................................................................................................................................7
Unpacking & Checking Carton Contents.........................................................................................8
General Assembly Instructions .......................................................................................................9
Dry Vacuum Operation..................................................................................................................10
Liquid Vacuum Operation..............................................................................................................12
Blower Operation ........................................................................................................................ 13
Maintenance .................................................................................................................................14
Installing & Cleaning Reusable Cloth Filter................................................................................... 15
Installing & Cleaning Foam Wet Filter...........................................................................................16
Troubleshooting ............................................................................................................................17
Exploded View ..............................................................................................................................18
Parts List.......................................................................................................................................19

3
WARRANTY
We take pride in producing a high-quality, durable product. This vac carries a limited two (2) year warranty
against defects in workmanship and materials from date of purchase under normal household use. Please
keep your receipt as proof of purchase. This warranty gives you specic legal rights, and you may have
other rights, which vary from state to state. For customer service please call 1-866-384-8432.
Not Covered by Warranty:
• Any part that has become inoperative due to misuse, negligence, direct/indirect abuse, accidents,
improper maintenance, repairs, or alterations;
• Consumables such as lters and accessories;
• Normal wear and tear of parts and attachments, such as hose, nozzles, or casters;
• Normal deterioration of the exterior nish due to use or exposure;
• Any product where serial number/data label is tampered with or removed;
• Any product purchased from an unauthorized retailer.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THIS MANUAL FOR FUTURE REFERENCE.
WARNING:
READ AND UNDERSTAND ALL INSTRUCTIONS
BEFORE USING THIS VACUUM.
Read and understand this operator’s manual and all labels on the vacuum cleaner before operating.
Safety is a combination of common sense, staying alert and knowing how your vacuum works. Use
this vacuum only as described in this manual. To reduce the risk of personal injury or damage to your
vacuum, use only manufacturer recommended accessories.
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY:
When using a vacuum, basic precautions should always be followed including the following:
• Do not run vacuum unattended.
• Do not use to pick up ammable or combustible liquids, such as gasoline, or
use in areas where they may be present.
• Do not vacuum, or use this Wet/Dry Vacuum near ammable liquids, gases, or
explosive vapors like gasoline or other fuels, lighter uids, cleaners, oil-based
paints, natural gas, hydrogen, or explosive dusts like coal dust, magnesium
dust, grain dust, or gun powder. Sparks inside the motor can ignite ammable
vapors or dust.
• Do not run vacuum unattended.

4
• Do not use to pick up ammable or combustible liquids, such as gasoline, or
use in areas where they may be present.
• Do not vacuum, or use this Wet/Dry Vacuum near ammable liquids, gases, or
explosive vapors like gasoline or other fuels, lighter uids, cleaners, oil-based
paints, natural gas, hydrogen, or explosive dusts like coal dust, magnesium
dust, grain dust, or gun powder. Sparks inside the motor can ignite ammable
vapors or dust.
• To reduce the risk of health hazards from vapors or dusts, do not vacuum toxic
materials.
• Do not use or store near hazardous materials.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or
hot ashes.
• Do not expose to rain. Store indoors.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not use with damaged cord or plug.
• If vacuum is not working as it should, has been dropped, damaged, left outdoors, or
dropped into water, return it to a service center.
• Do not pull or carry by cord, use cord as handle, close a door on cord, or pull
cord around sharp edges or corners. Keep cord away from heated surfaces.
• Do not run the vacuum over cord.
• Do not handle plug or vacuum with wet hands.
• Do not use without dust bag and/or lters in place.
• Do not allow to be used as a toy. Close attention is necessary when used by or
near children.
• To reduce the risk of injury from accidental starting, unplug power cord before
changing or cleaning lter.
• Do not leave vacuum when plugged in. Unplug from outlet when not in use and
before servicing.
• Turn o󰀨 all controls before unplugging.
• Unplug before connecting or disconnecting hose, or any other accessories.
• Do not put any object into openings. Do not use with any opening blocked; keep
free of dust, lint, hair, and anything that may reduce air ow.
• Keep hair, loose clothing, ngers, and all parts of body away from openings and
moving parts.
• Use extra care when cleaning on stairs.
• Use only as described in this manual. Use only manufacturer’s recommended
attachments.
• This appliance is provided with double insulation. Use only identical replacement
parts. See DOUBLE INSULATION INSTRUCTIONS.
CAUTION: TO REDUCE THE RISK OF INJURY FROM
MOVING PARTS - UNPLUG BEFORE SERVICING.

5
When using as blower:
• Direct air discharge only at work area.
• Do not use Wet/Dry Vacuum as a sprayer.
• Do not direct air at bystanders.
• Keep children away when blowing.
• Use safety goggles.
SAVE THESE INSTRUCTIONS
For Household Use Only
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK -
UNPLUG BEFORE CLEANING OR SERVICING.
DOUBLE INSULATED - GROUNDING NOT REQUIRED - WHEN
SERVICING USE ONLY IDENTICAL REPLACEMENT PARTS.
This Wet/Dry Vacuum is double insulated, eliminating the need for a separate grounding system.
Use only identical replacement parts. Read the instructions for Servicing Double-Insulated Wet/
Dry Vacuums before servicing. Use this vacuum as described in this manual. Observe the following
warnings that appear on the motor housing of your vacuum.
DOUBLE INSULATION INSTRUCTIONS
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK-
DO NOT EXPOSE TO RAIN. STORE INDOORS.
WARNING: FOR YOUR OWN SAFETY, READ
AND
UNDERSTAND OPERATOR’S MANUAL. DO NOT RUN UNATTENDED.
DO NOT PICK UP HOT ASHES, COALS, TOXIC, FLAMMABLE OR
OTHER HAZARDOUS MATERI ALS. DO NOT USE AROUND EXPLOSIVE
LIQUIDS OR VAPORS.
CAUTION: DO NOT VACUUM DRYWALL DUST, FIREPLACE
SOOT, OR ASH WITH STANDARD WET/DRY FILTER. THIS TYPE OF
DUST IS VERY FINE WHICH MAY NOT BE CAPTURED BY THE FILTER
AND CAUSE DAMAGE TO MOTOR. WHEN VACUUMING FINE DUST
USE A FINE DUST FILTER (SOLD SEPARATELY).

6
WARNING: SERVICING OF DOUBLE-INSULATED WET/
DRY VACUUMS
WITH A DOUBLE-INSULATED WET/DRY VACUUM, TWO SYSTEMS
OF INSULATION ARE PROVIDED INSTEAD OF GROUNDING. NO
GROUNDING MEANS IS PROVIDED ON A DOUBLE-INSULATED
APPLIANCE, NOR SHOULD A MEANS FOR GROUNDING BE ADDED.
SERVICING A DOUBLE INSULATED WET/DRY VACUUM REQUIRES
EXTREME CARE AND KNOWLEDGE OF THE SYSTEM, AND
SHOULD BE DONE ONLY BY QUALIFIED SERVICE PERSONNEL.
REPLACEMENT PARTS FOR A DOUBLE-INSULATED WET/DRY
VACUUM MUST BE IDENTICAL TO THE PARTS THEY REPLACE. YOUR
DOUBLE-INSULATED WET/DRY VAC IS MARKED WITH THE WORDS
‘DOUBLE INSULATED’ AND THE SYMBOL (SQUARE WITHIN A
SQUARE) MAY ALSO BE MARKED ON THE APPLIANCE.
When using an extension cord with your Wet/Dry Vacuum refer to the following table to determine the
required A.W.G. wire size. Before using the cleaner make sure the power cord and extension cord are
in good working condition. Make repairs or replacements before using the vacuum cleaner. Only use
extension cords that are rated for outdoor use.
EXTENSION CORDS
Length of Extension Cord
120V 25ft (7.62m) 50ft (15.24m) 100ft (30.48m) 150ft (45.72m)
Ampere Rating
A.W.G. Wire Size
More than Not more than
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not recommended

7
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with
this product.
SYMBOL SIGNAL MEANING
DANGER Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
NOTICE (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.

8
Handle
Blower Port Hose Storage
On/Off Switch
Latch Assembly
Caster
Vacuum Port
Collection Tank
Remove all contents from the box. Remove
the powerhead and take out any contents
inside the collection tank. Check each item
against the carton contents list.
Carton Contents List
NOTE: The hose and accessories for this
vacuum are 1-1/4'' (32 mm) diameter.
A C
E
F
G
H I J K
D
B
UNPACKING & CHECKING CARTON
CONTENTS
Key Description Qty
A Handle 1
B Vacuum Assembly 1
C Hose 1
D Extension Wands 3
E Floor Brush/Squeegee Nozzle 1
F Utility Nozzle 1
G Crevice tool 1
H Caster 4
I Reusable Cloth Filter 1
J Foam Wet Filter 1
K Operator’s Manual 1

9
1 2 4 5
10
3
1
2
6 7 98
11 12
GENERAL ASSEMBLY INSTRUCTIONS
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Undo the latches (Fig. 2).
3. Lift the powerhead o󰀨 the collection tank (Fig. 3).
4. Remove the contents from inside the collection tank. Make sure you have all contents as listed on
page 8 (Fig. 4).
5. Turn the collection tank upside down and insert the four casters into the sockets on the bottom of
the base. Press casters down until they snap into place (Fig. 5).
6. Insert the handle into the slots located on the top of the powerhead (Fig. 6). Apply pressure until
the handle snaps into place.
7. Your vacuum comes ready for dry vacuum cleaning. If the reusable cloth lter is not installed, refer
to page 15 for installation instructions (Fig. 7).
8. For wet vacuum cleaning, remove the reusable cloth lter, and install the supplied foam wet lter.
See page 16 for the foam wet lter installation instructions (Fig. 8).
9. Place the powerhead back on the collection tank aligning the top section with the latches, and
snap into place (Fig. 9 & 10).
10. Insert the larger end of the hose into the vacuum port on the collection tank (Fig. 11).
11. Choose the desired accessory and insert onto the free end of the hose or extension wand (Fig. 12).
UNPACKING YOUR WET/DRY VACUUM & GENERAL ASSEMBLY
WARNING:
DO NOT PLUG THE POWER CORD INTO A
POWER OUTLET. MAKE SURE THE PLUG IS DISCONNECTED BEFORE
ASSEMBLING THE WET/DRY VACUUM. TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT EXPOSE TO RAIN.

10
POLARIZED PLUG
To reduce the risk of electrical shock, this appliance has a polarized plug (one blade wider than the
other). This plug will t in a polarized outlet only one way. If the plug does not t fully in the outlet,
reverse the plug. If it still does not t, contact a qualied electrician to install the proper outlet. Do not
change the plug in any way. Double insulation eliminates the need for the three-wire grounded
power cord and grounded power supply system.
1 2 4 5 3
6 7 8
DRY VACUUM OPERATION
DRY VACUUMING
WARNING:
BE SURE TO READ, UNDERSTAND, AND APPLY
INFORMATION ENTITLED ‘IMPORTANT SAFETY INSTRUCTIONS’. DO
NOT VACUUM IN AREAS WITH FLAMMABLE GASES, VAPORS, OR
EXPLOSIVE DUSTS IN THE AIR. FLAMMABLE GASES OR VAPORS
INCLUDE BUT ARE NOT LIMITED TO: LIGHTER FLUID, SOLVENT TYPE
CLEANERS, OIL-BASED PAINTS, GASOLINE, ALCOHOL, OR AEROSOL
SPRAYS. EXPLOSIVE DUSTS INCLUDE BUT ARE NOT LIMITED TO:
COAL, MAGNESIUM, GRAIN, OR GUN POWDER. TO REDUCE THE RISK
OF HEALTH HAZARDS FROM VAPORS OR DUST, DO NOT VACUUM
TOXIC MATERIALS.
WARNING:
DO NOT PLUG THE POWER CORD INTO A
POWER OUTLET. MAKE SURE THE PLUG IS DISCONNECTED BEFORE
CHANGING THE FILTERS.

11
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. In order to prepare your vacuum for dry vacuuming, make sure the cloth lter completely covers
the lter cage. Your wet/dry vacuum comes with the reusable cloth lter pre-installed. For lter
installation instructions, see page 15 (Fig. 2 & 3).
3.
Place the powerhead back on the collection tank, and secure it in place using the latches (Fig. 4).
OPERATING INSTRUCTIONS: DRY VACUUMING
4. Insert the larger end of the hose into the vacuum port on the collection tank.
5. Push the required accessory onto the free end of the hose or extension wand (Fig. 5).
6. Verify that the switch is in the ‘O’ OFF position before plugging the power cord into the power outlet.
Plug the power cord into the outlet (Fig. 6 & 7).
7. Turn the motor on by ipping the on/o󰀨 switch to the ‘I’ ON position and begin vacuuming (Fig. 8).
8. Once you have completed vacuuming, ip the switch to the ‘O’ OFF position and unplug the power
cord from the outlet.
O = OFF I = ON
DO NOT USE THE REUSABLE CLOTH FILTER FOR LIQUID VACUUMING.
CAUTION:
DO NOT VACUUM DRYWALL DUST, FIREPLACE
SOOT, OR ASH WITH STANDARD WET/DRY FILTER. THIS IS A VERY
FINE DUST WHICH WILL NOT BE CAPTURED BY THE FILTER AND MAY
CAUSE DAMAGE TO MOTOR. WHEN VACUUMING FINE DUST USE A
FINE DUST FILTER.

12
1 2 4 5 3
6 7 8
LIQUID VACUUM OPERATION
LIQUID VACUUMING
WARNING:
BE SURE TO READ, UNDERSTAND,
AND APPLY
INFORMATION ENTITLED ‘IMPORTANT SAFETY INSTRUCTIONS’. DO
NOT VACUUM IN AREAS WITH FLAMMABLE GASES, VAPORS, OR
EXPLOSIVE DUSTS IN THE AIR. FLAMMABLE GASES OR VAPORS
INCLUDE BUT ARE NOT LIMITED TO: LIGHTER FLUID, SOLVENT
TYPE CLEANERS, OIL-BASED PAINTS, GASOLINE, ALCOHOL, OR
AEROSOL SPRAYS. EXPLOSIVE DUSTS INCLUDE BUT ARE NOT
LIMITED TO: COAL, MAGNESIUM, GRAIN, OR GUN POWDER. TO
REDUCE THE RISK OF HEALTH HAZARDS FROM VAPORS OR DUST,
DO NOT VACUUM TOXIC MATERIALS.
WARNING:
DO NOT PLUG THE POWER CORD INTO A
POWER OUTLET. MAKE SURE THE PLUG IS DISCONNECTED BEFORE
CHANGING THE FILTERS.
1. Verify that the power cord is disconnected from the outlet. Make sure that the collection tank is
clean and free of dust and dirt (Fig. 1).
2. Remove reusable cloth lter, then carefully install the foam wet lter over the lter cage and place
the powerhead back on the collection tank. For foam wet lter installation instructions, see page 16
(Fig. 2 & 3).
DO NOT USE THE REUSABLE CLOTH FILTER FOR LIQUID VACUUMING.
OPERATING INSTRUCTIONS: WET VACUUMING
3. Insert the larger end of the hose into the vacuum port on the collection tank.
4. Push the required accessory onto the free end of the hose (Fig. 4).

13
5. Verify that the switch is in the ‘O’ OFF position before plugging the power cord into the power outlet.
Plug the power cord into the outlet (Fig. 5 & 6).
6. Turn the motor on by ipping the switch to the ‘I’ ON position (Fig. 7).
7. Once you have completed vacuuming, ip the switch to the 'O' OFF position and unplug the power
cord from the outlet.
8.
After use, empty the collection tank, clean and dry the inside and outside of the collection tank (Fig. 8).
IMPORTANT! When vacuuming large quantities of liquids, do not immerse the nozzle completely in
the liquid; leave a gap at the tip of the nozzle opening to allow air inow. The machine is tted with a
oat valve that stops the suction action when the collection tank reaches its maximum capacity. You
will notice an increase in motor speed. When this happens, turn off the machine, disconnect from
power supply, and drain the liquid into a suitable receptacle or drain. To continue vacuuming, ret the
powerhead to the collection tank. After wet vacuuming, turn the machine o󰀨 and remove plug from
power supply. Empty the collection tank, clean and dry the inside and outside before storage.
REMEMBER! The foam wet lter must be removed after wet vacuuming and the reusable cloth lter
must be installed before dry vacuuming again.
1 2 4 5 3
6 7
This Wet/Dry vacuum has blowing capabilities. To use the blower feature, follow the instructions listed
below.
BLOWER OPERATION
WARNING:
ALWAYS WEAR SAFETY GOGGLES COMPLYING
WITH ANSI Z87.1 (OR IN CANADA, CSAZ94.3) BEFORE USING BLOWER.
WARNING:
KEEP BYSTANDERS CLEAR FROM BLOWING
DEBRIS.

14
WARNING:
WEAR A DUST MASK IF BLOWING CREATES
DUST THAT MIGHT BE INHALED.
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Make sure the collection tank is empty before using as a blower. Clear all dirt and debris from the
hose and collection tank.
3. Remove the hose from the vacuum port.
4. Insert the larger end of the hose into the blower port on the back side of the powerhead (Fig. 2).
5. Choose the desired accessory and insert onto the end of the hose (Fig. 3).
6. Verify that the on/o󰀨 switch is in the ‘O’ OFF position before plugging the power cord into the outlet.
Plug the power cord into the outlet (Fig. 4 & 5).
7. Before turning on the vacuum, rmly hold the loose end of the hose. Turn the motor on by ipping
the switch to the ‘I’ ON position (Fig. 6).
8. Once you have completed blowing, ip the on/o󰀨 switch to the ‘O’ OFF position. Unplug the power
cord from the outlet (Fig. 7).
MAINTENANCE
1 2 43
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Disconnect the hose from the vacuum (Fig. 2).
3. Undo the latches and remove the powerhead from the collection tank (Fig. 3). Place power head on
a soft, clean surface upside down.
4. Clear all dirt or debris from the collection tank and hose into a proper waste container (Fig. 4).
5. Clean or replace the lters.
6. Check the hose, accessories, and power cord to verify that they have not been damaged.
7. Place the powerhead back on collection tank and secure latches.
EMPTYING THE COLLECTION TANK
WARNING:
ALWAYS DISCONNECT THE PLUG FROM
THE POWER OUTLET BEFORE REMOVING THE POWERHEAD FROM
COLLECTION TANK.
IMPORTANT! Clean or change the filter regularly for best performance. ALWAYS USE THE
REUSABLE CLOTH FILTER FOR DRY VACUUMING. If the machine is used without the reusable
cloth lter, the motor will burn out and the warranty will be voided. Always keep spare lters on hand.

15
NOTICE! The lters included are made of high-quality materials designed to stop small dust particles.
The reusable cloth lter should be used for dry pick-up only. A dry reusable cloth lter is necessary to
pick up dust. If the reusable cloth lter is wet, it will clog quickly and be very di󰀩cult to clean. Handle
the lter carefully when removing it for cleaning and replacing it. Check the lters for tears or small
holes. A small hole can let dust pass through and out of the lter. Do not use a lter with holes or tears;
replace it immediately.
STORAGE
Before storing your vacuum, the collection tank should be emptied and cleaned. The accessories
should be cleaned and stored so they can be readily available when needed. Store the wet/dry
vacuum indoors.
REPAIRS
Repairs for this wet/dry vacuum should be performed only by qualied service personnel using only
identical replacement parts.
1 2 4 5 3
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Remove powerhead and place in an upside-down position.
3. Install the reusable cloth lter over the lter cage making sure the cage is completely covered
(Fig. 2 & 3).
4. Place the powerhead back onto the collection tank.
1. With the removed power head in an upside-down position, carefully remove the reusable cloth lter
from the lter cage (Fig. 4).
2. Clean the reusable cloth lter by gently tapping or brushing dirt o󰀨. Cleaning should not be done
indoors in living areas. For optimal performance a new lter is recommended.
3. Use a mild soap and water solution to wash the reusable cloth lter and rinse with clean water (Fig. 5).
4. Allow the wet lter to air dry completely before storing or installing onto the lter cage.
INSTALLING REUSABLE CLOTH FILTER
REMOVING & CLEANING REUSABLE CLOTH FILTER
INSTALLING & CLEANING REUSABLE
CLOTH FILTER

16
1 2 4 5 3
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Remove powerhead and place in an upside-down position. Follow instructions to remove the
reusable cloth lter on page 15.
3. Carefully slide the foam wet lter down over the lter cage making sure the cage is completely
covered (Fig. 2 & 3).
4. Place the powerhead back onto the collection tank.
INSTALLING FOAM WET FILTER
INSTALLING & CLEANING FOAM WET
FILTER
1. With the removed powerhead in an upside-down position, carefully remove the foam wet lter (Fig. 4).
2. Use a mild soap and water solution to wash foam wet lter and rinse with clean water (Fig. 5).
3. Allow the wet lter to air dry completely before storing or installing onto the lter cage.
CLEANING FOAM WET FILTER

17
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
The wet/dry vacuum will
not operate.
No power supply. Check the power supply, cord,
breakers, and fuses.
Faulty power cord.
Unplug and check the power cord.
If damaged, have it repaired by a
professional.
Collection tank is full. Empty the collection tank.
Switch in the wrong position. Press the ON ‘I’ button on the
power head.
The dust comes out from
the motor cover.
The reusable cloth lter is missing or
damaged.
Attach or replace the reusable
cloth lter.
Reduced e󰀩ciency and
motor/speed vibration.
There are blockages in the nozzle,
hose, or the collection tank inlets.
Unplug and check nozzle, hose
and collection tank inlets for
blockages.
The reusable cloth lter is clogged
by ne dust.
Take o󰀨 the lter and clean it or
install a new reusable cloth lter.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
UNPLUG BEFORE TROUBLESHOOTING.

18
EXPLODED VIEW
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
7
7

19
PARTS LIST
Part Part Number Description Quantity
1 551142105 Handle 1
2Power Head Assembly 1
3 551012115 Float 1
4 551012116 Filter Cage 1
5Collection Tank 1
6 551012104 Vacuum Port 1
7 551012121 Caster 4
8 551012127 Hose 1
9 551004114 Crevice Tool 1
10 551003109 Extension Wand 3
11 551296103 Floor Brush/Squeegee Nozzle 1
12 551004113 Utility Nozzle 1
13 551009111 Foam Wet Filter 1
14 551012110 Reusable Cloth Filter 1

20
Garantie……………………………………......................................................……………………………
Consignes Importantes de Sécurité…………………………….......................................................……
Instructions Relatives À La Double Isolation………………............................................................……
Cordons Prolongateurs…………………………………………........................................................……
Symboles..............................................................................................................................................
Déballage Et Vérication Du Contenu Du Carton…..........................................................................…
Instructions Relatives au Montage Général..........….................................................................……….
Utilisation de L’Aspirateur D’Atelier Sec………………........................................................……………
Aspiration de Liquides…………………………........................................................……………….…….
Utilisation Du Sou󰀪eur………………………........................................................……………………….
Entretien……………………………………………………….......................................................………..
Installation Et Nettoyage Du Filtre Réutilisable En Tissu......................................................................
Installation Et Nettoyage Du Filtre En Mousse Pour Matériaux Humides.............................................
Dépannage…………………………………………………………….........................................................
Vue Éclatée...........................................................................................................................................
Liste Des Pièces…………..............................…………………..........................................................…
Nous vous remercions pour l'acquisition de cet aspirateur d’atelier sec et humide Armor All®.
Soyez assuré(e) qu'avec Armor All®, vous obtenez un produit de qualité supérieure conçu pour
vous o󰀨rir des performances optimales. Cet aspirateur est doté de la capacité d’aspirer des
poussières et liquides.
POUR GARANTIR VOTRE SÉCURITÉ : VEUILLEZ LIRE ET ASSIMILER TOUTES LES
CONSIGNES.
INFORMATIONS IMPORTANTES
GALLONS
La «TAILLE DU RÉSERVOIR» correspond au volume réel du réservoir et ne reète pas la capacité
disponible en fonctionnement.
PUISSANCE MAX.
La «PUISSANCE MAXIMALE» est un treme utilisé dans le secteur des aspirateurs pour matières
sèches et liquides à des ns de comparaison pour les consommateurs. Il ne désigne pas la puissance
opérationnelle d’un aspirateur pour matières sèches et liquides, mais plutôt la puissance du moteur,
y compris l’apport d’inertie du moteur, atteinte en laboratoire. En utilisation réelle, les moteurs ne
fonctionnent pas à la puissance maximale indiquée.
SOMMAIRE
SECTION PAGE
21
21
24
25
25
26
27
28
29
31
32
33
34
35
36
37
FR
