Arometrix Extraction Finder User manual

©2021 Arometrix Inc. • Phone: [phone] • [email protected] • arometrix.com
Quick Start Guide
Mount Extraction Finder Adapter
securely.
On the bottom-end of Extraction
Adapter, connect a 1.5” Sanitary
Flange to Hose Adapter (or NPT or
another connection) for incoming flow.
On the top-end of the Extraction
Adapter, connect a second 1.5”
Sanitary Flange to Hose Adapter (or
equivalent) for outgoing flow.
Install a bypass, valved bleedport.Best Practice: Set up an extraction
adapter bypass (that can be quickly
actuated through 3 way valves), a
vent, and a pressure gauge.
Warning: Ensure all connections are
properly installed. Ensure the system
and installation conform to all
applicable laws and ordinances.
LEAK TEST FITTINGS TO ENSURE INTEGRITY
General Process
Flow for
Hydrocarbon
Extraction
Page 1 of 2

©2021 Arometrix Inc. • Phone: [phone] • [email protected] • arometrix.com
Quick Start Guide
Set integration to AID (Auto) Set scans to average to 5 Observe no signal or noisy signal
from reverberations during initial
startup.
Identify signal increase after initial
fluid flow, then equilibrate during full
flow.
Observe changes in Delta-9, Lipid
and Chlorophyll levels. Use the
Overlay feature to superimpose a
black line for comparison purposes.
If you chose to record, toggle the
Record button to Off. Install a USB
thumb drive. Press Transfer function.
Install the Digital Display using the
power supply and 30' sensor cable.
Connect and power the system, then
prepare extraction as you typically
would
Ensure Extraction Finder Adapter
is mounted securely.
Page 2 of 2
