Arrow®GT30LI™
Cordless Glue Gun
GT30LI™

2
ENGLISH
GENERAL TOOL SAFETY WARNINGS 3–4
DEFINITION OF SYMBOLS USED ON TOOL & FUNCTIONAL DESCRIPTION 5
OPERATION INSTRUCTIONS 6–8
TOOL MAINTENANCE AND ACCESSORIES 9
WARRANTY 10
Class II Tool
Outil de classe II
Herramienta clase II
To avoid injury and misuse, please read
the instruction manual before operation.
Pour éviter tout risque de blessures et
une mauvaise utilisation, prière de lire
le manuel d’utilisation avant l’utilisation.
A fin de evitar lesiones y mal uso, lea el
manual de instrucciones antes de usar
la herramienta.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
Respecter tous les messages de sécurité
suivant ce symbole pour éviter tout
risque de blessures ou de décès.
Observe todos los mensajes de
seguridad que aparecen junto a este
símbolo para evitar posibles lesiones o
la muerte.
Always wear safety glasses when
operating the tool.
Toujours porter des lunettes de sécurité
en utilisant l’outil.
Siempre use anteojos de seguridad
cuando utilice esta herramienta.
GT30LI™CORDLESS
GLUE GUN

3
1. Do not touch heated nozzle area of glue gun
or melted glue. Touching any heated portions of the
product may result in personal injury, such as a burn.
2. Keep work area clean and keep electrical
contacts clear of debris. Work environment
should be clean, dry, well lit and clear of
flammable materials. Cluttered, dark areas and
flammable materials may result in a risk of fire, electric
shock or personal injury.
3. Keep children and bystanders away while
operating the tool. Distractions can cause you to lose
control.
4. Always use safety glasses. Following this rule will
reduce the risk of eye injury.
5. Do not harm the cord. Never use the cord for
carrying, pulling or unplugging the glue gun
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
6. Glue gun tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
glue gun tools. Modifying plug and failure to use
proper outlet increases risk of electric shock.
WARNING When using electric tools, basic safety precautions should always
be followed to reduce the risk of fire, electrical shock and personal injury.
CAUTION: Read Safety Rules and Operating Instructions Carefully.
READ ALL SAFETY INSTRUCTIONS:
7. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
8. Disconnect tools when not in use.
9. Do not touch the glue stick or trigger except to
dispense glue. If you insert the glue stick into the glue gun
using too much force can cause hot glue to unexpectedly
discharge from the nozzle. Following this rule may reduce
the risk of accidental glue discharge.
10. Do not expose this tool to rain or wet conditions.
Water entering a corded electric tool will increase the risk
of electric shock.
11. When not in use, the tool should be stored indoors.
12. Store idle glue gun out of the reach of children,
and do not allow persons unfamiliar with the
tool or these instructions to operate the glue
gun. Electric tools are dangerous in the hands of untrained
users.
13. Do not pull glue sticks from gun. The feed
mechanism may become damaged or impaired. If you
desire to change types of glue, cut off protruding end of
glue stick and feed the remainder through with the new
type of glue stick.
GENERAL TOOL SAFETY WARNINGS

4
SAFETY PRECAUTIONS: WARNING!
• Do not touch heated nozzle or melted glue –
touching any heated portions of the product may result
in personal injury, such as a burn. Operating temperature
of the nozzle is 380˚F (193˚ C).
• When glue is hot do not lay glue gun on its side always
use stand.
• Property damage and personal injury may result from
extended contact with tip of hot glue gun.
• Place the glue gun in the upright position when idle using
the base stand provided.
• Do not leave unattended.
• For general indoor household use only and should not be
used for outdoor or industrial purposes.
• Do not use near water, liquids or rain.
• Do not use this product in areas where the risk of explosion
is present.
• USE ONLY RECOMMENDED ATTACHMENTS. Use of an
attachment not recommended or sold by the manufacturer
may result in a risk of fire, electric shock or personal injury.
• UNPLUG POWER CORD when not in use.
• Turn off glue gun by placing the switch to the OFF
position and unplug charging stand when not in use.
• Allow glue gun to cool before storing.
• Do not try to remove unused portion of glue sticks from
glue gun after use.
• Do not use a damaged glue gun.
• Do not disassemble or attempt to repair this appliance –
service must be performed only by an authorized
service representative.
• Children shall not play with appliance. However, this
appliance can be used by children aged 8 and above, as
well as by person with reduced physical, sensory or mental
capabilities, provided that they are supervised and are
instructed about using the appliance in a safe way and
understand the hazards involved.
• Cleaning and user maintenance shall not be made by
children without supervision.
• Keep away from children under the age of 8 and animals.
• Do not carry the tool by the cord or pull cord to disconnect
it from the outlet.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similar qualified persons
in order to avoid hazard.
• Recharge the power tool only with the charger specified
by the manufacturer. A charger that is suitable for one type
of power tool may create a risk of fire when used with
another power tool.
• Under abusive conditions and extreme temperature, liquid
may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes,
seek medical help. Liquid ejected from the battery may
cause irritation or burns.
• Do not store tool in locations where the temperature
may reach or exceed 104°F (40°C). Extended periods
of extreme heat may cause damage to the battery and
possible fire.
• Do not dispose of the tool by incineration. The batteries
may explode in fire.
GENERAL TOOL SAFETY WARNINGS

5
FUNCTIONAL DESCRIPTION
V ...................... Volts
A ...................... Amperes
Hz .................... Hertz
- ...................... Alternating Current
Obey all safety messages that follow this
symbol to avoid possible injury or death.
Always wear safety glasses
when operating the tool.
Class II Tool
DEFINITION OF SYMBOLS USED ON TOOL
& FUNCTIONAL DESCRIPTION
Retractable
Drip Pad
Charging Plug
Glue Stick Opening
Charging Stand
Temperature
Indicator
Battery Level
Indicator
ON/OFF Switch
Trigger

6
BEFORE INITIAL OPERATION
The battery is supplied partially charged. Before first use, charge the battery for at least 3 hours. The battery can be
charged at any time and interruption of the charging process will not impact the service life or damage the battery.
Never charge the battery in temperatures above 104° (40° C) or below 50° (10° C).
Charging:
Connect the plug to a 100 – 240 V 50/60Hz power source.
Place the glue gun into the charging stand. Battery level indicator will light up red.
Charging Complete:
1. Battery level indicator will light up green when glue gun is fully charged and ready to use.
2. Remove glue gun from charging stand.
3. Disconnect charging stand from power supply.
IMPORTANT When using electric tools, basic safety precautions should always
be followed to reduce the risk of fire, electrical shock and personal injury.
OPERATING INSTRUCTIONS

7
OPERATION
1. Insert glue stick into glue stick opening at rear of tool.
2. If desired, extend retractable drip pad at front of charging stand.
3. To turn the glue gun on, press and hold ON/OFF switch until temperature indicator lights up green. The temperature
indicator will remain green when glue gun has reached proper working temperature.
4. Allow glue to melt inside heat chamber for one minute before attempting to use.
5. To glue, pull the trigger to regulate glue flow and apply as needed. Do not force trigger if glue does not enter gun
easily. If this occurs, allow an additional thirty seconds of heat up time. Use caution to avoid hot nozzle and glue as it
can cause burns.
6. Release trigger to stop the flow of glue. Apply pressure to work piece for approximately sixty (60) seconds
for complete bonding.
7. To turn the glue gun off, press and hold ON/OFF switch until temperature indicator goes off. Place used glue gun down
carefully and allow to cool before storage.
NOTE: Glue gun is equipped with an automatic safety shut-off feature that switches off after 10 minutes. To reactivate,
simply turn gun back on.
OPERATING INSTRUCTIONS

8
DISPOSAL
Improper disposal of obsolete lithium ion batteries is unsafe and can cause environmental damage. Please dispose of
this product via an approved waste removal company or your municipal waste disposal authority. Contact your local
municipality for regulations in your area.
TIPS ON USING
1. The working time of hot melt glue can be extended to fifty to sixty (50 to 60) seconds by applying the adhesive in large
drops (1/2” diameter) or shortened to less than ten (10) seconds by extruding the adhesive in a thin line.
2. Large areas are difficult to bond because the adhesive frequently will harden before you have extruded the right amount.
3. Preheat surfaces, (especially metals) to improve bond strength. Direct sunlight will accomplish this.
4. The adhesive remaining in an unheated glue gun will re-melt upon heating.
5. Do not use on items that will be subject to temperatures above 140˚F (60˚C).
6. Do not use hot melt glue to hold heavy loads.
7. Some paints and stains can weaken the adhesive. You may need to paint or stain before gluing.
OPERATING INSTRUCTIONS

9
TOOL MAINTENANCE
The GT30LI™tool is virtually maintenance free. Keep tool
clean and free of dust. Wipe clean with a dry cloth; do not
use harsh chemicals to clean. The GT30LI™tool contains no
user serviceable parts. In the unlikely event that your tool
should need service contact:
Arrow Fastener Company, LLC
271 Mayhill Street, Saddle Brook, N.J. 07663
Tel. [phone]
FOR BEST RESULTS USE ONLY ARROW®SUPERIOR
QUALITY ARROW®MINI GLUE STICKS —
MG12, MG24-4 ALL PURPOSE CLEAR
For crafts, hobbies and general repairs.
For woodworking, ceramics, leather, canvas, fabrics,
cardboard, plastics, metal, etc. Press surfaces together.
Sets in thirty to sixty (30 to 60) seconds. Available in
packages of 12-4"(100mm) sticks (MG12) and 24-4"
(100mm) sticks (MG24-4).
Arrow®Mini Glue Sticks are available at retail outlets,
hardware stores, lumberyards and wherever fine tools
are sold.
GT30LI™GT30LI™EU
GT30LI™UK GT30LI™AUS
68RJ
E231647
MADE IN CHINA 95C1
120V
AC 60Hz
12W
220V—240V
TOOL MAINTENANCE & ACCESSORIES

10
WARRANTY
2 YEAR LIMITED WARRANTY
All parts of Arrow Fastener products containing electrical
or electronic components or parts (other than batteries) are
warranted to the original purchaser to be free from defects
in material and workmanship for two years from the date
of purchase.
Arrow Fastener will repair or replace, FREE OF CHARGE,
during the warranty period, any product that proves to be
defective in material or workmanship under normal use. If
repair is not practical, Arrow Fastener may elect to replace
the product or refund the purchase price in exchange for
return of the defective product. For best performance, use
genuine Arrow®glue sticks.
Please contact Arrow Fastener by calling 1-800-776-2228
or by writing: Arrow Fastener Company, LLC
271 Mayhill Street
Saddle Brook, NJ 07663
Attn: Product Warranty Department.
Labor charges incurred by the original purchaser to repair
the product are excluded. This limited warranty does not
cover damage to the product relating to normal wear and
tear, misuse, abuse or neglect. No warranty is provided for
the batteries.
Proof of purchase from the original purchaser must be made
available to Arrow Fastener for all warranty claims. This is
the exclusive warranty by Arrow Fastener Company for its
products containing electrical or electronic components or
parts (other than batteries).
Implied Warranties. TO THE EXTENT PERMITTED BY LAW,
ANY IMPLIED WARRANTY, INCLUDING ANY WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, IS LIMITED TO THE SAME DURATION AS THE
APPLICABLE EXPRESS WARRANTY. Some states do not allow
limitations on how long an implied warranty lasts, so the
above limitation may not apply to you.
Limitation of Liability. Arrow Fastener SHALL NOT
BE RESPONSIBLE FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES WHETHER ARISING OUT OF
BREACH OF WARRANTY, BREACH OF CONTRACT, TORT,
OR OTHERWISE. Some states do not allow the exclusion of
incidental or consequential damages, so the above exclusion
and limitation may not apply to you.
This limited warranty gives you specific legal rights, and you
also may have other rights, which vary from state to state. In
Canada, the above provisions are not intended to operate
where prohibited by law and do not preclude the operation
of any applicable provincial protection statute which may in
certain circumstances extend the express warranty herein.
Australian customers: Our goods come with guaranties that
cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or a refund for a major failure
and for compensation for any other reasonably foreseeable
loss or damage.
You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure
does not amount to a major failure. To obtain the benefits of
this warranty, you must send the product securely packaged
with proof of purchase and postage prepaid to:
Service Department, Arrow Fastener Co., LLC,
271 Mayhill Street, Saddle Brook, New Jersey 07663

11

For the GT30LITM manual translation in French and
Spanish please visit www.Arrowfastener.com
Pour le manuel de GT30LITM traduit en Français et en
espagnol veuillez visiter www.Arrowfastener.com
Para el manual de GT30LITM traducido en francés y en
español por favor visite www.Arrowfastener.com
Arrow Fastener Company, LLC
271 Mayhill Street, Saddle Brook, NJ 07663
©2018 Arrow Fastener Co. LLC
Rev 07/18
