ArtFox SHINE BAR 18Q User manual

User Manual
Please read the instructions carefully
SHINE BAR 18Q

1
TABLE OF CONTENTS
1. Safety Instructions
2. Technical Specifications
3. Installation
4. How to set the unit
5. How to control the unit
6. DMX512 Configuration
7. DMX512 Connections
8. Troubleshooting
9. Fixture Cleaning

2
1. Safety Introductions
WARNING
Please keep this User Manual for future consultation. If you sell the fixture to another
user, be sure that they also receive this instruction booklet.
Unpack and check carefully there is no transportation damage before using the fixture.
It’s important to ground the yellow/green conductor to earth in order to avoid electric
shock.
Disconnect main power before servicing and maintenance.
The unit must be installed in a location with adequate ventilation, at least 50cm from
adjacent surfaces. Be sure that no ventilation slots are blocked.
Maximum ambient temperature is Ta : 40℃. Don’t operate it where the temperature is
higher than this.
Unit surface temperature may reach up to 85 ℃. Don’t touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool
down before replacing or serving.
In the event of serious operating problem, stop using the fixture immediately. Never try
to repair the fixture by yourself. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center. Always use the same type spare parts.
Do not connect the device to any dimmer pack.
Do not touch any wire during operation and there might be a hazard of electric shock.
To prevent or reduce the risk of electrical shock or fire, do not expose the fixture to rain
or moisture.
The housing must be replaced if they are visibly damaged.
Do not look directly at the LED light beam while the fixture is on.
There are no user serviceable parts inside the fixture. Do not open the housing or
attempt any repairs by yourself. In the unlikely event your fixture may require service,
please contact your nearest dealer.
Due to the magnifying type lens, please keep the lens out of contact with direct sunlight.
Direct sunlight can cause heat to build up inside of the unit, which will seriously damage
unit.
Please read the instructions carefully which includes important
information about the installation, operation and maintenance.

3
2. Technical Specifications
Voltage：AC100-240V, 50/60Hz;
Power consumption：200W
Light source: 18pcs*10W RGBW 4 in 1 LED;
Control mode：DMX ,Master-slave，Sound
DMX Channel:9/23/72CH
Dimmer:0-100% Linear dimming
IP:IP65
Net weight：6.7KG
Colors: RGBW color Mixing
3. Installation
The unit should be mounted via its screw holes on the bracket. Always ensure that the
unit is firmly fixed to avoid vibration and slipping while operating. Always ensure that the
structure to which you are attaching the unit is secure and is able to support a weight of 10
times of the unit’s weight. Also always use a safety cable that can hold 12 times of the
weight of the unit when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at a place where is
out of the touch of people and has no one pass by or under it，the range of mounting height
is 0~30 M.
4. How to set the unit
1．Key instruction：
A．function
B．+ Button
C．- Button
D．Enter
A B C D
Operation Description: Press the function key A will cycle out Ten different functional
effects, the first two digits of the digital tube represents the current function (refer to the
function table). The last two digits represent the address of the function, the address code,

4
or the speed, the parameters. Press B or C to change its parameter value. Press the D key
to confirm
2. LED display window function table, (all the features selected by pressing the D key to
confirm)
No
Display
Function
1
A001
DMX512 Address
2
23ch/-9ch-
72ch
Channel selection (23 channels, 9 channels, 72 channels)B, C
key addition and subtraction
3
CC00
Colorful jump,(01-99) B, C key to modify the jump speed
4
Ed00
Colorful gradient, pulse change, (01-99) B, C key to modify the
gradient speed
5
Er00
Colorful running 1(01-99) B, C key to modify the pulse speed
6
Po00
Colorful running 2, (01-99) B, C key to change the pulse speed
7
tr00
Running change, (00-8) B, C key to modify the running pattern
8
tU00
Running change, (00-99) B, C key to modify the running speed
9
BE50
Colorful control running change B, C key to modify the voice
sensitivity
10
R200
Red color, (000-255) B, C key to modify the color value
11
G200
Green current，（000—255）B、C key to modify the current
12
B200
Blue current，（000—255）B、C key to modify the current
13
W200
White current（000—255）B、C key to modify the current
14
ID00
Light ID，（01—14）B、C Key to modify the ID value（For point
control effect, can achieve more than one water effect）
15
OPRT
Master-slave
3Background LED display window function table, (in 14-channel mode, press the function
key to enter, all the features press the D key to confirm)
NO
Display
Description
1
R200
Red current，（20—255）B, C key to modify the current
2
G200
Green current，（20—255）B, C key to modify the current
3
B200
Blue current，（20—255）B、C key to modify the current
4
W200
White current，（20—255）B、C key to modify the current

5
5. How To Control The Unit
You can operate the unit in three ways:
1. By master/slave built-in preprogram function
2. By easy controller
3. By DMX controller
6. DMX512 Configuration
DMX512 9CH
NO
Function
Description
CH1
Total dimmer
Total dimmer, linear dimming, dark to bright
CH2
Total strobe
Total strobe, from slow to fast
CH3
Function selection 1
0--25：No 26--35：No
36--45：Colorful flow (jump); (Id code staggered, can
achieve more than one lamp water, by 1 - 6 channel
control)
46—55:Colorful water (gradient); (Id code staggered,
can achieve more than one lamp water, by 1 - 6
channel control)56—65:Color selection(controlled by 1
channel)66--75：Jumping（controlled by 1 channel）
76—85:Gradual change （controlled by 1 channel ）
86--95 ：Running pattern 1 （controlled by 1-6
channel）116--125：Running pattern 2；（controlled by
1-6 channel）
。。。。。。。。
236--245 ：Running pattern 15 ；（ controlled by 1
channel）246--255：Sound（controlled by 1 channel）
CH4
Function selection 2
0--5：No
6--255 Fixed 255 tricks；（controlled by 1 channel）
Function 3
Colorful direction of water control（0--127：Left flow；
128--255：Right flow；）

6
CH5
Function selection1
Function speed, from slow to fast
CH6
R Dimmer
R Dimmer, linear dimming, from dark to bright
CH7
G Dimmer
G Dimmer, linear dimming, from dark to bright
CH8
B Dimmer
B Dimmer, linear dimming, from dark to bright
CH9
W Dimmer
W Dimmer, linear dimming, from dark to bright
DMX512 23CH
NO
Function
Description
CH1
Total Dimmer
Total dimmer, linear dimming, dark to bright
CH2
Total strobe
Total strobe, from slow to fast
CH3
Function selection 1
0--25：No26--35：Colorful color flow；（controlled
by 1 channel）36--45：Colorful color flow(Jump)；（Id
code staggered, can achieve more than one Water
effect ，controlled by 1 -6channel）
46--55 ：Colorful water (gradient) ；（ Id code
staggered, can achieve more than one Water
effect ，controlled by 1 -6channel）
56--65：Color selection；（controlled by 1 channel）
66--75：Jump ；（controlled by 1 channel）
76--85：Gradient, pulse change；（controlled by 1
channel）86—95: Running pattern 1 （controlled by
1-6 channel）116--125：Running pattern 2（controlled
by 1-6 channel ）。。。。。。。。 236--245 ：Running
pattern 15 （controlled by 1-6 channel）246--255：
Sound；（controlled by 1-6 channel）
CH4
Function selection 2
0—5No6--255：Fixed 250 tricks ；
Function 3
Colorful direction of water control（0--127：Left flow；
128--255：Right flow；）
CH5
Function selection1
Function speed, from slow to fast
CH6
1 Dimmer
R、G、B、W Dimmer
CH7
2 Dimmer
R、G、B、W Dimmer

7
CH8
3 Dimmer
R、G、B、W Dimmer
CH9
4 Dimmer
R、G、B、W Dimmer
CH10
5 Dimmer
R、G、B、W Dimmer
CH11
6 Dimmer
R、G、B、W Dimmer
CH12
7 Dimmer
R、G、B、W Dimmer
CH13
8 Dimmer
R、G、B、W Dimmer
CH14
9 Dimmer
R、G、B、W Dimmer
CH15
10 Dimmer
R、G、B、W Dimmer
CH16
11 Dimmer
R、G、B、W Dimmer
CH17
12 Dimmer
R、G、B、W Dimmer
CH18
13 Dimmer
R、G、B、W Dimmer
CH19
14 Dimmer
R、G、B、W Dimmer
CH20
15 Dimmer
R、G、B、W Dimmer
CH21
16 Dimmer
R、G、B、W Dimmer
CH22
17 Dimmer
R、G、B、W Dimmer
CH23
18 Dimmer
R、G、B、W Dimmer
DMX512 72CH
NO
Function
Description
CH1
R1 Dimmer
R1 Dimmer, linear dimming, from dark to bright
CH 2
G1 Dimmer
G1 Dimmer, linear dimming, from dark to bright
CH 3
B1 Dimmer
B1 Dimmer, linear dimming, from dark to bright
CH 4
W1 Dimmer
W1 Dimmer, linear dimming, from dark to bright
CH 5
R2 Dimmer
R2 Dimmer, linear dimming, from dark to bright
CH 6
G2 Dimmer
G2 Dimmer, linear dimming, from dark to bright
CH 7
B2 Dimmer
B2 Dimmer, linear dimming, from dark to bright
CH8
W2 Dimmer
W2 Dimmer, linear dimming, from dark to bright
CH9
R3 Dimmer
R3 Dimmer, linear dimming, from dark to bright
CH10
G3 Dimmer
G3 Dimmer, linear dimming, from dark to bright
CH11
B3 Dimmer
B3 Dimmer, linear dimming, from dark to bright
CH12
W3 Dimmer
W3 Dimmer, linear dimming, from dark to bright
CH13
R4 Dimmer
R4 Dimmer, linear dimming, from dark to bright

8
CH14
G4 Dimmer
G4 Dimmer, linear dimming, from dark to bright
CH15
B4 Dimmer
B4 Dimmer, linear dimming, from dark to bright
CH16
W4 Dimmer
W4 Dimmer, linear dimming, from dark to bright
CH17
R5 Dimmer
R5 Dimmer, linear dimming, from dark to bright
CH18
R5 Dimmer
R5 Dimmer, linear dimming, from dark to bright
CH19
B5 Dimmer
B5 Dimmer, linear dimming, from dark to bright
CH20
W5 Dimmer
W5 Dimmer, linear dimming, from dark to bright
CH21
R6 Dimmer
R6 Dimmer, linear dimming, from dark to bright
CH22
G6 Dimmer
G6 Dimmer, linear dimming, from dark to bright
CH23
B6 Dimmer
B6 Dimmer, linear dimming, from dark to bright
CH24
W6 Dimmer
W6 Dimmer, linear dimming, from dark to bright
CH25
R7 Dimmer
R7 Dimmer, linear dimming, from dark to bright
CH26
G7 Dimmer
G7 Dimmer, linear dimming, from dark to bright
CH27
B7 Dimmer
B7 Dimmer, linear dimming, from dark to bright
CH28
W7 Dimmer
W7 Dimmer, linear dimming, from dark to bright
CH29
R8 Dimmer
R8Dimmer, linear dimming, from dark to bright
CH30
G8 Dimmer
G8 Dimmer, linear dimming, from dark to bright
CH31
B8 Dimmer
B8 Dimmer, linear dimming, from dark to bright
CH 32
W8 Dimmer
W8 Dimmer, linear dimming, from dark to bright
CH 33
R9 Dimmer
R9 Dimmer, linear dimming, from dark to bright
CH 34
G9 Dimmer
G9 Dimmer, linear dimming, from dark to bright
CH 35
B9 Dimmer
B9 Dimmer, linear dimming, from dark to bright
CH 36
W9 Dimmer
W9 Dimmer, linear dimming, from dark to bright
CH 37
R10 Dimmer
R10 Dimmer, linear dimming, from dark to bright
CH 38
G10 Dimmer
G10 Dimmer, linear dimming, from dark to bright
CH 39
B10 Dimmer
B10 Dimmer, linear dimming, from dark to bright
CH 40
W10 Dimmer
W10 Dimmer, linear dimming, from dark to bright
CH 41
R11 Dimmer
R11 Dimmer, linear dimming, from dark to bright
CH 42
G11 Dimmer
G11 Dimmer, linear dimming, from dark to bright
CH 43
B11 Dimmer
B11 Dimmer, linear dimming, from dark to bright
CH44
W11 Dimmer
W11 Dimmer, linear dimming, from dark to bright
CH45
R12 Dimmer
R12 Dimmer, linear dimming, from dark to bright
CH 46
G12 Dimmer
G12 Dimmer, linear dimming, from dark to bright

9
CH 47
B12 Dimmer
B12 Dimmer, linear dimming, from dark to bright
CH 48
W12 Dimmer
W12 Dimmer, linear dimming, from dark to bright
CH 49
R13 Dimmer
R13 Dimmer, linear dimming, from dark to bright
CH 50
G13 Dimmer
G13 Dimmer, linear dimming, from dark to bright
CH 51
B13 Dimmer
B13 Dimmer, linear dimming, from dark to bright
CH 52
W13 Dimmer
W13 Dimmer, linear dimming, from dark to bright
CH 53
R14 Dimmer
R14 Dimmer, linear dimming, from dark to bright
CH 54
G14 Dimmer
G14 Dimmer, linear dimming, from dark to bright
CH 55
B14 Dimmer
B14 Dimmer, linear dimming, from dark to bright
CH 56
W14 Dimmer
W14 Dimmer, linear dimming, from dark to bright
CH 57
R15 Dimmer
R15 Dimmer, linear dimming, from dark to bright
CH 58
G15 Dimmer
G15 Dimmer, linear dimming, from dark to bright
CH 59
B15 Dimmer
B15 Dimmer, linear dimming, from dark to bright
CH 60
W15 Dimmer
W15 Dimmer, linear dimming, from dark to bright
CH 61
R16 Dimmer
R16 Dimmer, linear dimming, from dark to bright
CH62
G16 Dimmer
G16 Dimmer, linear dimming, from dark to bright
CH63
B16 Dimmer
B16 Dimmer, linear dimming, from dark to bright
CH64
W16 Dimmer
W16 Dimmer, linear dimming, from dark to bright
CH65
R17 Dimmer
R17 Dimmer, linear dimming, from dark to bright
CH66
G17 Dimmer
G17 Dimmer, linear dimming, from dark to bright
CH67
B17 Dimmer
B17 Dimmer, linear dimming, from dark to bright
CH68
W17 Dimmer
W17 Dimmer, linear dimming, from dark to bright
CH69
R18 Dimmer
R18 Dimmer, linear dimming, from dark to bright
CH70
G18 Dimmer
G18 Dimmer, linear dimming, from dark to bright
CH71
B18 Dimmer
B18 Dimmer, linear dimming, from dark to bright
CH72
W18 Dimmer
W18 Dimmer, linear dimming, from dark to bright
7. DMX512 Connections
mode connection：

10
1. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the
fixture to the input of the next fixture. The cable cannot be branched or split to a “Y”
cable. Inadequate or damaged cables, soldered joints or corroded connectors can
easily distort the signal and shut down the system.
2. The DMX output and input connectors are pass-through to maintain the DMX circuit
when one of the units’ power is disconnected.
3. At last fixture, the DMX cable has to be terminated with a terminator to reduce signal
errors. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a
3-pin XLR-plug and plug it in the DMX-output of the last fixture.
4. Each lighting fixture needs to have an address set to receive the data sent by the
controller. The address number is between 0-511 (usually 0 & 1 are equal to 1).
5. 3 pin XLR connectors are more popular than 5 pins XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+),Pin4/5:
not used
8. Troubleshooting
Following are a few common problems that may occur during operation. Here are some
suggestions for easy troubleshooting:
A. The fixture does not work, no light
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly.
2. If the DMX LED is on and no response to the channel, check the address settings and

11
DMX polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB
of the fixture or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage cables that may
cause damage or interference to DMX interface circuit.
C. Some fixtures don’t respond to the easy controller
1. You may have a break in the DMX cabling.
2. Check the LED for the response of the master/ slave mode signal.
D. No response to the sound
1. Make sure the fixture does not receive DMX signal.
2. Check microphone to see if it is good by tapping the microphone.
E. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB is broken.
2. The motor’s drive IC on the PCB might be out of condition.
9. Fixture Cleaning
The cleaning of internal must be carried out periodically to optimize light output. Cleaning
frequency depends on the environment in which the fixture operates: damp, smoky or
particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every
30/60 days.
