ARTHUR HOLM AH17D3 RHDGA TALK User manual

User manual
AH17D3 RHDGA TALK
AH19D3 RHDGA TALK
Electrically motorised monitor for furniture integration, with
DynamicTalk. Horizontal and vertical working positions

Table of contents
EC REGULATIONS & SECURITY 4
SAFETY INSTRUCTIONS 5
APPLICATIONS 6
BOX CONTENTS 6
FEATURES 7
PREPARATION FOR INSTALLATION 8
CONTROLS 10
MONITOR OSD MENU 13
INPUT CONNECTORS 16
DYNAMICTALK HANDLING 21
MONITOR AHnet PROTOCOL 22
DYNAMICTALK AHnet PROTOCOL 24
INPUT SIGNALS 29
PRODUCT WARRANTY 31

Welcome
Thank you for purchasing an ARTHUR HOLM product.
Our product range has been designed to create the perfect meeting room,
where the screens are a part of the interior design as well as essential
communication tools.
Please, read this installation and operating instructions carefully and keep
them in a safe place for future reference.
We remain at your entire disposal if you have any suggestions that would
help us improve our products.
Henrik Holm
General Manager

4
EC Regulations and Security
ATTENTION: Do not disassemble or modify the device in any way.
This symbol warns of the presence of dangerous un-insulated voltages
inside some of the components, of sufficient magnitude to expose people
to risk of electronic shock.
This symbol draws attention to important use and maintenance instructions
in the manual that accompanies the unit.
This symbol indicates that the equipment conforms to the norms
established by the European Community.
This symbol indicates that the equipment has some potential entrapment
hazard parts.

5
Safety instructions
PLUGS
– Do not dismantle any part of the monitor power connector
– Disconnect the power plug from the AC outlet when the monitor is not
going to be used for an indefinite period of time
POWER AND EXTENSIONS CORDS
– Use the appropriate power cord with the correct plug type
– Do not overload wall outlets or power cords
– Make sure the total ampere passed through a extension cord does not
exceed the maximum allowed by the cable used
– Do not place anything on the power cord
– Do not locate this product where a person may walk or trip over the cord
Wiring connected to hazardous voltage requires installation by qualified
personnel or the use of ready-made flexible cables.
For your security, your equipment must be connected to an electrical
outlet with grounding connection protection.
The operating electrical outlet must be in an easily accessed place.
ENVIRONMENT
– Install the equipment on an elevated, flat surface
– Install the equipment in a ventilated area
– Avoid exposing the equipment to:
Rain or water
Excessive heat, cold or humidity
Areas exposed to direct sunlight
Dirty areas
Equipment generating strong magnetic fields
– Avoid placing open containers of liquid, near the equipment
– Keep a minimum distance of 30mm in order to have good ventilation
– Never place any sources of flames, such as lighted candles, etc. above the device
– If you are using the device in extreme weather conditions and/or tropical
climates, the equipment should be installed in a room which ensures a
reasonable level of temperature and humidity
- To prevent damage the equipment must be firmly anchored to the surface,
as shown in the installation instructions
- When the monitor is closed, the maximum static load is 15Kg /33 lbs

6
System Description
APPLICATIONS
The AH17D3 RHDGA TALK and AH19D3 RHDGA TALK systems are professional
TFT displays with DynamicTalk and an electrical lift system for installation into a
horizontal furniture surface. The mechanism offers both horizontal and vertical
working positions. With the push of a button, the monitor is lifted. Giving it a
180 degree turn, the monitor is ready to be folded down levelled with the desk
surface.
The DynamicTalk system is a universal motorised microphone lift system
remotely controllable through RS422 or GPI with a Dynamic LED Ring for
“Ready to Talk” and “Talk” indicators (in PA mode).
BOX CONTENTS
Before the installation of your monitor, please check the contents of the
shipping box, it must contain the following items:
- Monitor unit
- Two power cords (one for the monitor and one for the DynamicTalk)
- Two power supplies 100-240Vac, 50-60Hz. Output 12V (one for the monitor
and one for the DynamicTalk)
- Remote control
- User Manual

7
System Description
FEATURES
- TFT Active Matrix display
AH17D3 RHDGA TALK 17", widescreen format, FULL HD
AH19D3 R16GA TALK 19", widescreen format, FULL HD
- Motorised monitor and DynamicTalk with electrical engine for furniture
integration
- Horizontal and vertical working positions
- Up/Down function operated by buttons on the cover plate
- Low power consumption
- Low radiation
- Quick response time
- Data inputs DVI-I & DVI-D. HDCP compliant
- Addressable RS422 monitor control by AHnet protocol, RJ45 connector
CAT5
- Dynamic LED Ring for “Ready to Talk” and “Talk” indicators (in PA mode)
- Push button on cover plate to externally use (GPO)
- Push button to "Mute" function in PA mode, or to use as GPO in conference
mode
- Integrated DynamicTalk for microphones with a maximum length of 500mm,
including foam. The microphone foam should be taken into consideration on
the total microphone length

8
Preparation for Installation
Before the installation of the device, please make sure to follow these steps:
- Remove the two lateral transport plastic screws M8x30 on the
- Remove the two front transport plastic screws M8x30

9
Preparation for Installation
Follow the next steps to pack the device for a safe shipment:
Permanent press button 1 until the monitor housing gets released from the
frame. Insert the two plastic screws (M8x30) entirely. To close the monitor,
permanent press button 2 until the monitor housing touches the two plastic
screws.
The next step is to insert the two lateral plastic screws (M8x30). Starting
by the right hand side, turn the plastic screw into the frame until it touches
the aluminium housing; without moving the aluminium housing (very fine
tolerances). Next, insert the plastic screw into the left side by turning it until
it touches the aluminium housing.
Dynamic3 with cover plate


Dynamic3 with external
control buttons

10
Controls
REMOTE IR CONTROL
POWER Switch ON/OFF the monitor
MENU Activates the OSD menu on screen
UP Cursor control up on the OSD menu
DOWN Cursor control down on the OSD menu. When
the OSD menu is not active on screen, selects
the input source
LEFT Cursor control left on the OSD menu
RIGHT Cursor control right on the OSD menu
OK Selects the function on the OSD menu
MONITOR ADDRESS
Below the monitor, there is a screen to configure the monitor. Press the UP
or DOWN buttons to change the function. Press the OK button to select the
function. Change the parameter using the UP or DOWN buttons and press
OK again to save the changes.
AHnet ID Selects the number AHnet ID to RS422 to externally control
the monitor
Input select Selects the input source signal (DVIA, DVI1 or DVI2)
Brightness Configuration of the monitor brightness level
Contrast Configuration of the monitor contrast level
Backlight Configuration of the monitor backlight level
Status information List of the monitor status to service

11
Controls
MONITOR MOVEMENT CONTROLS
On the upper cover plate, there are three buttons to control the up and
down monitor movements and three buttons to control the DynamicTalk
functions and to external control other devices (GPO):
1. Raising the monitor
To rise up and tilt the monitor display, press the rear button (1) on the right
hand side of the cover plate. Adjust the angle by permanent pressing this
button (1) while the monitor is open; the screen will slowly move between
90° to 110°. When the screen is then on the desired working angle, release
the button (1). To memorize this working angle permanently, press the
middle button (2) during 2 seconds.
2. Retracting the monitor (upwards the screen):
To fold down the monitor with the screen facing up, press the middle button
(2). In this position, the screen is completely visible and can be used in a
complete flat horizontal position, levelled with the table top.
It is recommended that no objects or parts of the body that could obstruct
the retracting movement of the display, are not on the top of the cover
plate.

12
Controls
3. Retracting the monitor (downwards the screen):
To fold down the monitor with the screen facing down, going into storage
position, press the front button (3). This button will also turn on or off the
monitor when the monitor is fully closed and the screen is facing up.
It is recommended that no objects or parts of the body that could obstruct
the retracting movement of the display, are not on the top of the cover
plate.
4. Microphone UP/DOWN: Controls the UP and DOWN microphone lift
movement
5. Customised button: This push button is used to control external devices.
The contact close button (GPO) is present on SubD9 connector to external
control other devices.
6. TALK or GPO button: This push button has two different functions:
- PA mode: In PA mode, this button is used as MUTE function. When
pressing the button once, the LED ring will appear in red indicating that
the MUTE function is deactivated and it’s ready for the user to talk to the
audience. Press the button again to activate de MUTE function and silent
the microphone, which will be indicated by the green LED ring.
- Conference mode: In conference mode the microphone is controlled
by the external conference system. In this case, the button then has
no function and the contact close of the push button is present on the
SubD9 control connector (GPO). In this case, there are two GPO buttons
available.
7. Dynamic LED Ring: The system has a LED ring to indicate the status
of the microphone: RED indicates that the MUTE function is deactivated
and GREEN indicates that the MUTE is activated. When the equipment
is configured to work in conference mode, the LED ring is externally
controlled by GPI on the SubD9 external control connector.

13
OSD menu
ACCESSING THE MENU SYSTEM
– With the OSD off, push the MENU button to activate the main OSD menu
– Press the UP and DOWN button to move from one function to another.
Please refer to the following sections below to view a complete list of
all the functions available for the monitor
– Press the OK button to enable the item
– When a function is selected, press the LEFT and RIGHT buttons in order to
change the parameter of the function
Press the Menu button to access to the main menu
CSM Configuration of the image colour
Cool
Normal
Warm
User (manually adjustment of red, green and blue colours)
PSM Configuration of the bright image
Dynamic
Standard
Mild
Game
User (manually adjustment of brightness and contrast)
Contrast Image contrast adjustment
Brightness Image brightness adjustment

14
OSD menu
SCREEN
Input Input signal selection
DVI-A
DVI 1
DVI 2
ARC Aspect image on screen
Full The image is showed on full screen
16:9 Shows the image on screen with 16:9 aspect
Aspect Shows the image on full screen but keeps the
original aspect ratio of the input image
4:3 Shows the image on screen with 4:3 aspect
1:1 Shows the image on screen with the
original resolution
Backlight Adjusts the backlight of the screen
Flip Flips the image on screen
Off: Image with no flip
1 Vertical flip
2 Horizontal flip
3 Rotate
OSD-Flip Flips the menu on screen (OSD)
Off Image with no flip
1 Vertical flip
2 Horizontal flip
3 Rotate

15
OSD menu
SETUP
Language OSD language selection
PC Control Adjusts the image on screen. Only on ARGB (analogue)
input
H-Pos Adjust the image on screen horizontally
V-Pos Adjust the image on screen vertically
Phase Adjust the phase
Clock Adjust the clock
Auto Adjust Auto adjust the image on screen
Reset PC image control reset
1050 Selection of the exact input resolution. Only for ARGB
(analogue) input
1400 x 1050
1680 x 1050
WXGA Selection of the exact input resolution. Only for ARGB
(analogue) input
1024 x 768
1280 x 768
1360 x 768
BG Colour Background colour of the screen when there is no input
signal. The monitor only goes to stand by mode when black
colour is selected
BLACK
RED
GREEN
BLUE

16
Input connectors
MONITOR INPUT CONNECTORS
DVI 1/ DVI A DVI-I input signal. Connect a DVI (digital) input signal and
select DVI 1 on the OSD monitor menu. Use a DVI to VGA
adapter to connect an ARGB (analogue) input signal and
select DVI-A on the OSD monitor menu
DVI 2 DVI-D input signal. Connect a DVI (digital) input signal and
select DVI 2 on the OSD monitor menu
- Use high quality DVI cables with 2m maximum length
12V D.C. Power supply input connector. XLR-4 connector:
1,2: Ground
3,4: 12Vdc
GPI Monitor external contact close control. SubD9 female
1. GPI1 +
2. GPI1 –
3. GPI2 +
4. GPI2 –
5. GPI3 –
6. GPI3 +
7. N.C.
8. +12Vdc (600mA max.)
9. Ground
- Use GPI1 (1:12Vdc, 2:Ground) to open the monitor
- Use GPI2 (3:12Vdc, 4: Ground) to close the monitor with the
screen facing up
- Use GPI3 (6:12Vdc, 5:Ground) to close he monitor with the
screen facing down

17
Input connectors
MONITOR INPUT CONNECTORS
Termination Activate (ON) the termination, ONLY on the last unit of the
RS422 bus
AHnet RJ45 CAT5 connector for addressable RS422 control. There
is a loop through connector to use as signal RS422 output.
Up to 30 monitors can be connected on the same RS422 bus
USB USB connectors for mouse, keyboard, touch screen and
WebCam. Those connectors are active depending of the
monitor model

18
Input connectors
MICROPHONE INPUT CONNECTORS
Microphone out: XLR3 microphone connector installed in the DynamicTalk
12V D.C. IN: XLR4 connector to the power supply
1,2: Ground
3,4: 12Vdc
GPI: SubD 9 pins female connector to contact close external functions
PIN FUNCTION
1,6 Contact close of the customised push button on upper cover
plate (middle button). 100mA Max.
8,9
Only in conference
mode
Contact close of the TALK push button on the upper cover
plate, only in conference mode. This function does not work
when the device is configured in PA mode. 100mA Max.
2
Only in conference
mode
Activates the RED LED ring in conference mode, connecting
to GPI ground
3
Only in conference
mode
Activates the GREEN LED ring in conference mode,
connecting to GPI ground
4 Connect this pin to GPI ground to RISE the microphone
5 Connect this pin to GPI ground to LOWER the microphone
7 GPI ground
NOTE: In conference MODE, if the 2 and 3 pins are not connected to the
ground, the upper ring LED is off.

19
Input connectors
MICROPHONE INPUT CONNECTORS
Settings: 6 dip switch to configure the DynamicTalk.
DIP SWITCH FUNCTION
1,2,3
ON: DynamicTalk configured in PA mode. The TALK push
button controls the microphone mute function
OFF: DynamicTalk configured in conference mode. The
TALK push button has no function, the contact close
is available on GPO connector and the LED ring is
controlled externally (GPI)
4,5 Factory only. Leave those dip switches off
6Termination of the RS422 bus. Configure to ON only on
the last device of the RS422 bus
AHnet: RJ45 CAT5 connector for addressable RS422 control. There is a
loop through connector to use as signal RS422 output. You can connect up
to 30 devices on the same RS422 bus
AHnet ADDRESS: Using the AHnet protocol, this is the number of the
device into the RS422 addressable bus

20
Input connectors
MICROPHONE LENGTH SETTING PROCEDURE
DynamicTalk is designed to work with microphones of different lengths. Two
signs to identify an incorrect setup of the microphone length are:
- The microphone do not goes down completely.
- The microphone goes down too slowly and gets stuck inside.
The microphone length can be adjusted using the Monitor Configurator
Tool, but there is also a quick procedure that doesn’t require the use of a
PC or cable:
1. Disconnect the Power connector
2. Set switch 5 to ON position
3. Set the length of the microphone in the rotatory switch,
in cm. For instance, if the microphone is 40cm, set the
rotatory switch as: tens=4, unit=0
4. Connect to Power. There will be a 5 beep sound
5. Disconnect Power
6. Set switch 5 to OFF position
7. Set the AHnet address in the rotatory switch, the default
setting is address 01 (tens=0, units=1).
8. Connect the Power connector
