ARTHUR HOLM Dynamic 1H User manual

User Guide
Danish craftmanship
Mediterranean soul
Technology Serving Design
Dynamic1H
HDCP compliant aluminium foldable motorised monitors

TABLE OF CONTENTS
REGULATIONS AND SECURITY 5
SAFETY INSTRUCTIONS 5
SYSTEM DESCRIPTION 7
CONTROLS 11
OSD MENU 13
ISD MENU 16
INPUT CONNECTORS 22
AHnet PROTOCOL 24
VIDEO SIGNALS 28
AHLink 29
INFORMATION ON DISPOSAL 32
WARRANTY TERMS AND CONDITIONS 33

WELCOME
Thank you very much for purchasing an Arthur Holm product.
Please, read these installation and operating instructions carefully and
keep them in a safe place for future consultations.
We remain at your entire disposal if you have any suggestions.
Henrik Holm
General Manager
[email protected]

ABOUT US
The Company
Arthur Holm has its origins in the Danish furniture designer Jorgen Alex
Jensen, who was active during the sixties and the seventies. His design
inspiration and his concept of ergonomics have been continued by his
family, who is the design force behind Arthur Holm product range. The
result of combining Scandinavian design tradition with Mediterranean
creativity, exibility and emotion is a wide product range built on more
than 25 years of craftsmanship.
Arthur Holm offers a professional product range where tomorrow’s
technology is shaped into valued materials with design exibility and
customisation, specially created to enhance communication in reception,
collaboration, conference and meeting areas.
The art of customisation
Arthur Holm offers a range of ingenious products whose designs are based
on quality materials and the latest technology. Products which endow
meeting and conference rooms with silent, ergonomic, innovative and
aesthetic solutions that integrate into the furniture, hang from the walls as
works of art or are used as interactive points of information.
The world of Arthur Holm
Arthur Holm offers a selection of unique, elegant, versatile, exible and
ergonomic products that are being used in meeting and conference
rooms, reception areas, huddle rooms, control rooms, auditoriums and
public zones of leading companies throughout the world.
The numbers speak for themselves! We currently own 33 product patents,
have presence in over 45 countries with products and solutions inmore
than 25,000 installations.
It will be our pleasure to work with you, designing your unique and
personalised environment. Our broadcast electronic engineers will
provide the latest technology while our design team will offer you the most
exclusive appearance.
Our team puts its heart, passion and pride in all our designs.

5
SAFETY INSTRUCTIONS
Plugs
• Do not dismantle any part of the monitor power connector.
• Disconnect the power plug from the AC outlet when the monitor is not
going to be used for an indenite period of time.
Power and extensions cords
• Use the appropriate power cord with the correct plug type.
• Do not overload wall outlets or power cords.
• Make sure the total ampere passed through an extension cord does not
exceed the maximum allowed by the cable used.
• Do not place anything on the power cord.
• Do not locate this product where a person may walk or trip over the
cord.
REGULATIONS AND SECURITY
ATTENTION: Do not disassemble or modify the monitor in any way.
This symbol warns of the presence of dangerous un-insulated
voltages inside some of the components, of sufcient magnitude
to expose people to risk of electronic shock.
This symbol draws attention to important use and maintenance
instructions in the manual that accompanies the unit.
This symbol indicates that the equipment conforms to the norms
established by the European Community.
This symbol indicates D.C. current.
This symbol indicates that the equipment has some potential
entrapment hazard parts.

6
Wiring connected to hazardous voltage requires installation by
qualied personnel or the use of ready-made exible cables.
For your security, your equipment must be connected to an
electrical outlet with grounding connection protection.
Since the plug is used to disconnect the monitor, the operating
electrical outlet must be in an easily accessible place.
Environment
• Install the equipment on an elevated, at surface.
• Install the equipment in a ventilated area.
• Avoid exposing the equipment to:
∙Rain or water
∙Excessive heat, cold or humidity
∙Area exposed to direct sunlight
∙Dirty areas
∙Equipment generating strong magnetic elds
• Avoid placing open containers of liquid, near the equipment.
• Keep a minimum distance of 30 mm in order to have good ventilation.
• Never place above the monitor any sources of ames such as lighted
candles, etc.
• If you are using the monitor in extreme weather conditions and/or
tropical climates, the equipment should be installed in a room which
ensures a reasonable level of temperature and humidity.
• To prevent damage the equipment must be rmly anchored to the
surface, as shown on the installation instructions.
SAFETY INSTRUCTIONS

7
SYSTEM DESCRIPTION
Applications
Dynamic1H motorised foldable monitors provide a horizontal motorised
movement. The screen is always visible, it raises and leans and can be
stopped at any position between 0 and 70°. A smart memory system
enables both the set up and recall of the desired tilting position. Built
entirely of aluminium and with a black edged anti-reection glass,
Dynamic1H monitors are extremely elegant, discreet and timeless.
Features
• Adjustable position
• Position memory
• Interactive Setup Display
• Maintenance free
• Energy saving design
• Safety system
• Serial control & Remote diagnostic
• Wireless connectivity for setup and control

8
SYSTEM DESCRIPTION
Available Models
MODEL DESCRIPTION
AH12D1HGA
HDCP compliant 12,1" widescreen foldable monitor with the
screen always facing up. Can work in a horizontal position
levelled with the desk surface and can be lifted up to 70º.
Both the monitor housing and cover plate are made of
anodised aluminium. The monitor is protected by a 3 mm.
double-sided antireective black edged glass. DVI-I and
DVI-D inputs. Interactive Setup Display allowing the control,
setup and diagnose of the monitors. Monitors provide RS-422
I/O allowing the remote control of movements, speeds, safety
settings, brightness, contrast and backlight. The monitors are
equipped with AMMC: an auto mechanical movement
calibration system.
AH17D1HGA
HDCP compliant 17,3" foldable monitor with the screen
always facing up. Can work in a horizontal position levelled
with the desk surface and can be lifted up to 70º. Both the
monitor housing and cover plate are made of anodised
aluminium. The monitor is protected by a 3 mm. double-
sided antireective black edged glass. DVI-I and DVI-D
inputs. Interactive Setup Display allowing the control, setup
and diagnose of the monitors. Monitors provide RS-422 I/O
allowing the remote control of movements, speeds, safety
settings, brightness, contrast and backlight. The monitors
are equipped with AMMC: an auto mechanical movement
calibration system.
AH22D1HGA
HDCP compliant 21,5" foldable monitor with the screen
always facing up. Can work in a horizontal position levelled
with the desk surface and can be lifted up to 70º. Both the
monitor housing and cover plate are made of anodised
aluminium. The monitor is protected by a 3 mm. double-
sided antireective black edged glass. DVI-I and DVI-D
inputs. Interactive Setup Display allowing the control, setup
and diagnose of the monitors. Monitors provide RS-422 I/O
allowing the remote control of movements, speeds, safety
settings, brightness, contrast and backlight. The monitors
are equipped with AMMC: an auto mechanical movement
calibration system.

9
SYSTEM DESCRIPTION
Options
AH12D1HGA AH17D1HGA AH22D1HGA
CL (Min.5 units)
Laser engraved logo
CL (Min.5 units)
Laser engraved logo
CL (Min.5 units)
Laser engraved logo
TS170HDG
Projected capacitive
multitouch screen
TS2216G
Projected capacitive
multitouch screen
DTalk (Min.10 units)
Built-in DynamicTalkM
DTalk (Min.10 units)
Built-in DynamicTalkM
CCUSBD1H
USB passthrough
CCUSBD1H
USB passthrough
CC2USBD1H
2 USB passthroughs
CC2USBD1H
2 USB passthroughs
CCUSBPowerD1H
USB power
CCUSBPowerD1H
USB power
AHDL
DynamicLoop
AHDL
DynamicLoop
AHDSS (Min.10 units)
DynamicShare
AHDSS (Min.10 units)
DynamicShare
AHHC (Min.10 units)
HDMI xed
AHHC (Min.10 units)
HDMI xed
AHDSPB
Priority
AHDSPB
Priority
CABD1H (Min.10 units)
Black anodised
CABD1H (Min.10 units)
Black anodised
CABD1H (Min.10 units)
Black anodised
GFD1H (Min.10 units)
Gold nish
GFD1H (Min.10 units)
Gold nish
GFD1H (Min.10 units)
Gold nish
BFD1H (Min.10 units)
Bronze nish
BFD1H (Min.10 units)
Bronze nish
BFD1H (Min.10 units)
Bronze nish
CPD1H (Min.10 units)
Painted
CPD1H (Min.10 units)
Painted
CPD1H (Min.10 units)
Painted

10
Box Contents
Before the installation of your retractable monitor, please check the
contents of the shipping box, it must contain the following items:
• Monitor
• Power cord
• Remote control (1 per 5 monitors)
• Power supply 100-2 40Vac, 50-60Hz. Output 12V
• User guide
Important note: This monitor can only work with the power supply
included in the shipping box. This power supply can not be replaced by
any other rather than the original one.
SYSTEM DESCRIPTION

11
CONTROLS
IR sensor
The IR sensor is located on the lower side of the screen.
Monitor movement controls
On the monitor top frame, there are 3 buttons to control the UP and
DOWN monitor movements.
1. Opening the monitor (button 3): Press button 3 to rise the display up
to the maximum angle. Press and hold this button to rise the monitor
and release it to stop it at the desired position. Please, make sure
that no objects are located on top of the monitor.
2. Position memory (button 2): Press button 2 to raise the display at the
memorised position. To save the position, press and hold button 2 for
3 seconds (you will hear a “beep” sound when the desired position
has been saved). Please, make sure that no objects are located on
top of the monitor.
3. Closing the monitor (button 1): Press button 1 to fold the monitor
completely. The monitor will fold while holding down this button,
release it to stop it at the desired position. Please, make sure that
no objects are located on top of the monitor. When the screen is on
horizontal position, use this button to turn off the screen.
3. Control DOWN button
2. Position memory button
1. Control UP button

12
CONTROLS
Remote control
POWER Switch ON/OFF the monitor
MENU Activates the OSD menu on screen
UP Control up on the OSD menu
DOWN Control down on the OSD menu
LEFT Control left on the OSD menu
RIGHT Control right on the OSD menu
OK Selects the function on the OSD menu. When the OSD
menu is not active on screen, selects the input source

13
OSD MENU
Accessing the menu system
• With the OSD off, push the MENU button to activate the main OSD
menu.
• Press the UP and DOWN buttons to move from one function to another.
Please refer to the following sections below to view a complete list of
all the functions available for the monitor.
• Press the OK button to conrm.
• When a function is selected, press the LEFT and RIGHT buttons in order
to change the parameter of the function.
Press the MENU button to access to the main menu.
Picture Mode: Adjusts the mode of the image
∙Dynamic
∙Standard
∙Mild
∙User: Contrast - Brightness - Colour - Sharpness - Tint
Colour Temperature: Adjusts the colour of the image
∙Cool
∙Medium
∙Warm
∙User: Red - Green - Blue

14
OSD MENU
Aspect Ratio: Adjusts the image aspect on screen
∙4:3
∙16:9
∙Zoom1
∙Zoom2
∙Just scan
Noise Reduction: Adjusts the image noise lter
∙Off
∙Low
∙Medium
∙High
∙Default
Screen: (Only for analogue signals)
∙Auto Adjust
∙Horizontal Position
∙Vertical Position
∙Size
∙Phase
Backlight: Adjusts the backlight screen's level
Colour Range: Adjusts the colour range
∙0 - 255
∙16 - 235

15
OSD MENU
Option
Language: OSD language selection
Restore Factory Default: Adjusts the parameters to the initial factory
parameters
Blending: OSD window transparency
∙Low
∙Medium
∙High
∙Off
OSD Duration: Adjusts the time that the OSD menu window remains on
the screen
Software Update (USB): Port to use for rmware's upgrade.
Mirror:
0. Image with no ip
1. Vertical ip
2. Horizontal ip
3. Rotate

16
ISD MENU
The Interactive Setup Display is an LCD screen located at the monitor
casing inside the desk that allows the setup and provides useful diagnose
and historical data of the device.
- To start using it -
∙WELCOME DISPLAY & DATA :
1) Bootloader Version
The display will show a Bootloader Version message (example: Bootl. Ver:
1.01). Bootloader is a program which allows the system to be able to update
itself. The ISD has a Bootloader and therefore is capable of updating to new
versions in order to constantly improve the user experience.

17
ISD MENU
2) FirmWare
Data that refers to the rmware version (FW) of the equipment (example: FW
Ver = 1.32). If you wish to update the FW version, please contact us.
3) Serial Number
Serial number of the device (example: serial number of the device =
02658748). The serial number is stored inside each device.
The serial number can also be obtained via AHnet and AHlink.
- OSD MENU -
∙AHNET (GENERAL PROTOCOL)
CONTROLS
· The ISD will show the AHnet address which will be accompanied by an
acoustic signal "BEEP" (example: Address: (001)). Once the signal has been
heard, the "UP & DOWN" buttons will allow the user to scroll through all the
variety of menus that the device contains. To enter into any specic menu,
simply press the "OK" button.
· How to modify the values within each menu? The values can be selected
through the "UP & DOWN" buttons. To save the selected value, press the "OK"
button or wait 3 seconds for it to be automatically saved.
The connection through RS422 allows the control of up to 30 devices per
line. The last device (an only the last one) needs to have the termination
activated.

18
ISD MENU
∙MENUS GENERAL INFORMATION
1) AHnet - Adress
The address must be set from 1 to 60.
2) VIDEO INPUT SELECTION
The device provides the following inputs:
DVI1 = DVI-I (DVI-A and DVI1-D)
DVI2= DVI-D (DVI-2D)
This menu allows the selection of 1 of these 3 inputs.
3) MONITOR BRIGHTNESS
Brightness level (0 – 100).
4) MONITOR CONTRAST
Contrast level (0 – 100).

19
ISD MENU
5) MONITOR BACKLIGHT
Backlight level (0 – 100).
6) POSITION
It is a diagnostic option that informs about the position of the device.
7) SENSORS INFORMATION
It is a diagnostic option that informs about the internal state of the sensors.
8) AHnet - INFORMATION
This menu is useful for programing and diagnose.
It provides information about the AHnet command that has been received
by the device.
Example: AHnet = 0 (FA) 1 (01) 2 (01) 3 (01) 4 (00)

20
ISD MENU
9) UNIT OPENS
It is a diagnostic option that provides historical data.
It is very useful to analyze how the device has been used during its lifecycle
and it provides information about how many movements the device has
done.
10) UNIT STOPS
It is a diagnostic option that provides historical data. It is very useful to
analyze how the device has been used during its lifecycle.
It provides information about the number of times that the device has
been protected and made emergency stops.
11) SERIAL NUMBER
Provides the device's serial number.
The serial number can also be obtained via AHnet and AHlink.
12) MONITOR DOWN
Only use this function as per manufacturer advice.
