Artiste ABH802 User manual

1
Accessories list:
Use instructions
Warranty card
Bluetooth headset
The LINE IN line
Charging cable
1 USB c
2. The LINE IN line
3. Bluetooth headset
.harging cable
1
2
Dear customer:
Thank you for purchasing our high quality electronic
product. This product uses international advanced
Bluetooth wireless audio transmission technology,
which has stable signal ( high frequency modulation,
easily to avoid other signal interference), stereo Hi-
Fi sound quality, strong versatility etc..
The scope of product: audio devices with Bluetooth ,
including PC, mobile phone, MP3, notebook, etc..
Note:
Product Introduction
Product Overview
3
1. When pair with the mobile phone ,function
of the headset may change according to type of the
mobile phone.
2. Some of the equipments , especially those without the
Bluetooth Technology Alliance (SIG) testing or approval,
may not be compatible with this product.
available

2
Turn on the headset by pressing the Power button until the blue
light flash,and it will be on the pair condition.
On
You must establish the connection between the headset and
a compatible device by pairing before you can start using.
LED Off
Turn off the headset by pressing the Power button until the
blue light shuts down.
If the mobile device support Bluetooth and has a music player ,
you can play music by the headset .
Pair
power
play / pause

3
A. Ensure that the mobile device or a music player is on and
the headset is closed.
B. Open the headset,it will enter pairing mode, the blue
light starts to flash quickly.
C.Use device Bluetooth function, begin to search for Bluetooth
devices, select "ABH802" headsets from the list of devices.
D. If necessary, please enter the password 0000 to pair the
headset. For some of the devices , you may need to match,
and then establish a connection.
E . When the headset is connected to the device and ready
for use, the blue light is on for the whole time.
F. If you want to disconnect the connection between the
headset and device or pair it with other device , you can
press the power button until the blue light slow flash and
then loose the power button .This time ,the headset is
disconnected with device; the other device can be paired.
The operation and function

4
click twice
In order to achieve the
most ideal effect,slip
each one direction on
the sensor board for
2/3 length.
Forward/Backward: Slip left or right on sensor board.
Play / Pause: Press the play / pause button or click the
sensor board twice.
Volume Up/ Down: Slip up or down to increase/ reduce the
volume.When you want to continue increasing/ reducing the
volume,slipe sensor board up/down for 2/3 length and then
hold it.
Answer: Press the play / pause button or click the sensor
board twice.when you don`t want to answer the call,press
the play / pause for 3 seconds.
Hung: Press the play / pause button or click the sensor
board twice after finishing the call.
LINE IN function : When the USB MIRCO is connected
to the audio line (3.5MM TO USB MIRCO B/M), it will
automatically disconnect Bluetooth function and
change to LINE IN, used as a wired headset.
Low battery alarm function: When the battery power is low,
the headset will issue a "beep" sound warning to turn off the
headset.
Operation:
Headset reset function:If the headset stop working,
you need to reset the headset, please connect the
headset to a charging wire /adapter , then it will reset
successfully;If it is in working , when you connect it
to a charging wire /adapter ,the headset
will automatically shut down, at this time please reset
it for normal work.

5
When wearing headset, please pay attention to distinguish
between left and right side of the headband.
Headset on both sides has a telescopic headband design, you
can adjust the headband length for more comfortable .Stretch
length was 30 ± 1mm.
3 0±1 m m
NFC Automatically turn off function: If the headset is not
connected with any equipment in about 10 minutes, it
will automatically shut down for power saving.
Wearing
Warning: Using the headset will weaken your ability to hear outside sounds. Therefore, please do not use
headset in the condition which may threaten your safety .
NFC function: Mobile phone itself must have the function
of NFC. Put mobile phone to the left side of ABH802 NFC
region. If successfully connected, it will issue a“du”
sound and shows the connection is successful on the
phone. If you want to disconnect the headset,then put
it again to the mobie phone NFC region,then they will
disconnect.

6
U S B
Charging
When it is charging , the green lights.
When the charging is completed, the green indicator light
is extinguished, charging adapter/wire can be removed.
If the battery is completely run out , it may take several
minutes for charging light to indicate the state of charge;
When the charging cable is not in use, please disconnect it
with the device. Excessive charging will shorten battery life.
If you have a fully charged battery without using ,
the battery will discharge by itself after a period of time;
The headset can be used when charging .
Note:
The headset is built with non removable and rechargeable
battery inside, do not remove the battery or so as not to damage
the headset .
When charging for first time ,it should be charged for more
than 4 hours and less than 8 hours, which can activate the
battery in best status. After that, charging only needs 2-3
hours (do not charge more than 24 hours, or it will damage
the battery life)

7
Safety
In order to obtain the best sound effects, please pay attention to distinguish between left and right side of the headband.; do not
disassemble the hardware; use dry and soft cotton to clean the headset etc.
We recommend you take the following preventive measures to prevent hearing loss :
If the volume is too large, may cause hearing loss.Adjust the appropriate volume from the minimum, increase slowly until the sound
is comfortable, clear and without distortion.
If in a comfortable volume, you have tinnitus or discomfort , please turn down the volume or stop to listen and check the hearing status.
Warning: Wireless transmission will produce electromagnetic signal, please pay attention to use the headphone when you have cardiac
pacemaker or related auxiliar y instrument.
Troubles
A: Not successfully matched :
1. Confirm the connection device with Bluetooth function has
been opened and work;
2. Check whether the headset battery power is insufficient;
3. Do not open the too many Bluetooth headsets or Bluetooth
devices at the same time, to prevent interference;
4. Confirm the headset is in pairing state and input Bluetooth
headset the password correctly;
5. If the above method still can not solve this problem,reset
the headset, pair it by description.
B.Cannot listen to music or call by headset:
1. Increase the headset volume;
2. Confirmed the device has been successfully connected.

8
Specifications
1. Connecting way:Bluetooth&Line In
2. Bluetooth® :Bluetooth V4.0
3. Transmission Mode :GFSK
4. Operating voltage:3.7V
5. Signal-to-noise ratio : > 80dB
6. THD : < 1%
7. Frequency response :30Hz-20KHz
8. Technical :guesture recognition ,AAC,apt-X,DSP,NFC;
1. Near Field Communication(NFC) function for connecting more convenient
2. Built-in CVC echo cancellation,double mic and DSP Noise reduction :clear communication
3. Display headset's battery on the iPhone ,IPad,IPod
4. Supports Aptx and AAC(optional) for sound enhancement
5. Folding design, easy to take with you
6. APT-X Hi-Fi: Playing stereo music
7. Embedded microphone for hands-free conversation from Bluetooth-enabled cell phones
8. Pause the music & Play back automatically when receives an incoming call
9. Automatically connect to the last connected Bluetooth device
10. Micro USB connector charging via AC charger or computer USB port
11. 3.5mm Line in jack allows headset to work without battery
Features
