Machine Model 45-725 Wire Prepper Lite Owners Manual
PN 6-119897 Rev. 1.00 Date August 25, 2015
Artos Engineering Company
21605 GatewayCt.
Brookfield, WI 53045
Phone [phone] Fax [phone]
www.artosnet.com
[email protected]

1
TABLEOFCONTENTS

CustomerSafetyNotice..................................................................................................................2
LimitsofUse....................................................................................................................................2
Introduction....................................................................................................................................2
Unpacking.......................................................................................................................................3
OperatorControlFeatures..............................................................................................................3
ON‐OFFSwitch............................................................................................................................3
ControlButtons...........................................................................................................................3
PuttingtheMachinetoWork.........................................................................................................4
OperatingInstructions....................................................................................................................4
VoltageSelection............................................................................................................................5
FuseReplacement...........................................................................................................................5
BladeReplacement.........................................................................................................................5
Maintenance...................................................................................................................................6
TroubleShooting.............................................................................................................................6
MachineWillNotFunction,AllSwitchesDoNotWork..............................................................6
CuttersCyclesContinuously.......................................................................................................6
CuttersDoNotCutMaterialCleanly..........................................................................................7
Accessories......................................................................................................................................7




2
CustomerSafetyNotice
Useofthismachineforpurposesotherthanthosestatedinthismanualmayresultindamage
tothemachineorpersonalinjury.

WARNING
Donotmanuallydisableguardswitchesorsafetycovers.Personalinjurycanresult.
Donotperformanymaintenanceonthemachineunlesstheelectricalsupplytothemachineis
disconnected.
Donotattempttoreplacethebladesorthefeedrollersunlesstheelectricpoweris
disconnectedfromthemachine.
Donotoperatemachinewithoutwearingpropereyeprotection
Donotwearlooseclothingorjewelrythatmightgetcaughtintheoperatingpartsofthe
machine
Donotoperatemachineinadamporwetlocation
Donotoperateifliquidisspilledonorinthemachine
Donotoperatemachineonanungroundedelectricalsystem
Donotalter,modify,ormisusethemachine
Donotoperatemachineunlessallinstructionsarereadandunderstood
Donotoperatemachineinagaseousorhazardousenvironment.
LimitsofUse
TheWirePrepper®SystemIIisintendedforuseinadryindoorworkingenvironment.The
machinecannotbeexposedtoliquidsprayormist,damagewillresult.Circuitsshouldneverbe
removedortamperedwithorinjurymayresult.

Introduction
YourWirePrepper®LiteWireCutteraccuratelymeasures,cutsandcountswire,tubingand
heatshrinkabletubingautomaticallyfrom30AWG(0.05mm2)to10AWG(2.5mm2)diameter.
Itcanalsobeusedtopreparemulti‐conductorandsemi‐rigidcabletoamaximumdiameterof
0.312in.(7.9mm).Itistheperfectchoiceforyourvolumeproductionpreparation
requirements.AnyonecaneasilyoperatetheWirePrepper®LiteWireCutterwithoutspecial
training,anditrequiresnotoolsorspecialset‐up.Datacanbeenteredineitherinchesor
metricmeasurementsthroughtheuser‐friendlyelectroniccontrols,andlengthsfrom0.04in.
(0.1cm)to9999.99inchesorcentimeterscanbecut.Thiselectronicmachineisportable,
weighinglessthan9kg(20pounds).

WehopethatyouarepleasedwiththepurchaseofyourWirePrepper®LiteWireCutter.You
willobtaintheoptimumperformancefromyourWirePrepper®LiteWireCutterifyouread,
understandandfollowtheinstructionswithinthismanual.ThankyouforpurchasingtheWire
Prepper®LiteWireCutter.


3
Unpacking
YourWirePrepper®LiteWireCutterhasbeenshippedinastaticdissipativepackaging.Observe
precautionsforhandlingelectrostaticsensitivedevices.Savethisboxandpackingmaterialfor
futuretransportation.

OperatorControlFeatures
ON‐OFFSwitch‐Turnsmainpoweronandoff.Locatedonthebackofthecase.Contains
machinefuses.

ControlButtons
Run/Stop—startsandstopsmeasuresandcutmachinecycle.
Length—Allowslengthdatatobeenteredfrom1‐9,999inches
Quantity—Allowsquantitytobeenteredfrom1‐9,999pieces.
Jog—Activateswirefeedmotor.
Cut—Activateswirecutter.
Program—Allowsaccesstowiredrivespeed,wirebatches,lengthcalibration,mode(inchesor
centimeters),pausetimebetweenbatches,anddemoprogram.
Clear—Usedtocleardatafromdisplay.
Enter—Usedtoenterdataonceithasbeendisplayed
UnitofMeasure—Allowsmachinetobesetuptomeasureineitherinchesorcentimeters.
Keyboard—0thru9keyboardwithdecimalpointforenteringnumericaldata,tosetlengthand
quantity.



4
PuttingtheMachinetoWork
‐PlugthecordintoON‐OFFswitchpowermodule.
‐Insertwireinthefirstfeedtubeuntilthewiretouchesthefeedrollers.Whilepushing
thewirelightlyagainstthefeedrollersrotatetherollersbyhandtofeedthewirethru
thesecondfeedtubeandoutpastthecuttingblade.
‐The WirePrepper®LiteWireCutterisnowreadytomeasureandcutwire. 




OperatingInstructions
EnteringCutLength
‐PressLENGTH
‐Enterdesiredlength
‐PressENTER

EnteringQuantity
‐PressQUANTITY
‐Enterdesiredquantity
‐PressENTER


5
ChangingUnitofMeasure
‐ PresstheDecimalButton“.” 
‐
Press1forinchesandpress2forcentimeters. 


VoltageSelection
Tochangeselectedvoltage:removethefusecartridgeusingasmallbladescrewdriverorsimilar
tool;selectthedesiredvoltagebymatchingthearrowonthefusecartridgetothearrow
locatedonthefrontoftheunit(lowerrightcorner);replacethefusecartridgemakingsurethe
voltageselectionarrowalignswiththearrowlocatedinthefrontoftheunit.


FuseReplacement
Removethefusecartridgeusingasmallbladescrewdriverorsimilartool.Replacetwo3AMP,
3AGtimedelayor3.15amp,5x20mm.Timedelayfuses,andinsertthefusecartridgeback
intotheunit;makingcertainthePROPERVOLTAGESELECTIONARROWalignswiththe
rectanglelocatedbelowthefusereceptacle.

BladeReplacement
‐ Unplugtheunit 
‐
Loosenthescrewholdingtheblade(use0.05hexwrench)andreplacetheblade. 
VoltageSelectionArrow

6
‐ Tightenscrewuntilsnug—makeasamplecutandtightenorloosenscrewsasneededto
produceacleancut. 
Maintenance
‐ Periodicoilingofthebladearmisrequired.Twodropsofoilwherethebladearmpivots.
Thefrequencywilldependonusage. 


TroubleShooting
MachineWillNotFunction,AllSwitchesDoNotWork
 Turnthemachineoffandthenbackontoresetthemachineelectronics. 
CuttersCyclesContinuously
 Checkcutterhomesensorswitchlocatedunderthetopplate.Whenthecutterarmisin
thehomeposition,thesteelvaneshouldbeinsidetheswitchslot.Adjustthesteelvane
sothatthecuttingbladeclearsthecuttingholewheninthehomeposition.


OIL HERE
HomeSensorSwitch
BladeClearsCuttingHole

7
CuttersDoNotCutMaterialCleanly
Checkcuttingbladesforsharpness. 
NOTE:Fixedbladecanberotated180°touseothercuttingedge.SeeBladeInstallation.
Increasepressureatcuttingbladesbyturningbladeclipsetscrewclockwise
1
/
8
”to
1
/
4
”
turn(use0.05hexwrench).Makeasamplecuttoassurecompletecleancutting. 


Accessories
PremiumWireDe‐Reeler(Part#45‐712)
ForusewithWireProcessingequipmentand6”–16”Dia.wirereels.





