Aruba 310 Series Access Points
Installation Guide
XXX-IG-0X | Month Year 1
Aruba 310 Series access points (AP-314, AP-315, IAP-314, and IAP-315) support IEEE 802.11ac standards for a
high performance WLAN. This device is equipped with two single-band radios that provide network access and
monitor the network simultaneously. These access points deliver high-performance 802.11n 2.4GHz and
802.11ac 5GHz functionality, while also supporting 802.11a/b/g wireless services. Multi-user Multiple-in,
Multiple-output (MU-MIMO) is enabled when operating in 5GHZ mode for optimal performance.
The AP-314 and AP-315 work in conjunction with an Aruba controller, while the IAP-314 and IAP-315 can be
configured via the built-in virtual controller.
The Aruba 310 Series provides the following capabilities:
IEEE 802.11a/b/g/n/ac operation as a wireless access point
IEEE 802.11a/b/g/n/ac operation as a wireless Air Monitor
IEEE 802.11a/b/g/n/ac operation as a Spectrum Analysis
Compatible with IEEE 802.3at PoE+ power sources
Compatible with IEEE 802.3at PoE power sources
Support for MCS8 and MCS9
Centralized management, configuration, and upgrades
Integrated Bluetooth Low Energy (BLE) radio
Centralized management, configuration, and upgrades
Package Contents
The following materials are included with this product:
Aruba 310 Series access point
9/16” and 15/16” Ceiling Rail Adapters
Hardware Overview
The following sections outline the hardware components of the 310 Series access point.
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including
the original packing materials. Use these materials to repack and return the unit to the supplier if needed.

2Aruba 310 Series Access Points | Installation Guide
Figure 1 Aruba AP-315 (front view)
LED
The 310 Series access points have LED displays located on the front panel of the access point indicating the
following functions:
System Status
The System Status LED indicates the operating condition of the access point, See Table 1.
Table 1 System Status LEDs
1 Blinking: one second on/one second off
2 Flashing: mostly on, shortly off every two seconds
Radio Status
The Radio Status LED indicates the operating mode of the access point’s radios. See Table 2.
Table 2 Radio Status LEDs
Color/State Meaning
Off Device powered off
Green- solid Device ready for use
Green- blinking1Device booting, not ready for use
Amber- solid Device ready; Power Save mode (802.3af PoE)
Green/Amber- solid No software setting/network restrictions
Green/Amber - flashing2Sub-optimal uplink Ethernet speed (1G)
Red- solid System error condition
Color/State Meaning
Off Device powered off, or both radios disabled

Aruba 310 Series Access Points | Installation Guide 3
LED Display Settings
The LEDs have three operating modes that can be selected in the system management software:
Default mode: Refer to Table 1 and Table 2
Off mode: LEDs are off
Blink mode: LEDs blink green
Figure 2 310 Series Access Point (rear view)
External Antenna Connectors
The AP-314 and IAP-314 access points are equipped with four external antenna connectors located
on the front corners of the access point (see Figure 3).
Green- solid Both radios enabled in access mode
Green- blinking One radio enabled in access mode; one radio disabled
Amber- solid Both radios enabled in monitor mode
Amber- blinking One radio enabled in monitor mode; one radio disabled
Green/Amber- alternating One radio in access mode; one radio in monitor mode
Red Both radios in error mode
Color/State Meaning
USB Port
Ethernet Port
Kensington
Console Port
Lock
DC Power
Socket
Reset Button
BLE Radio
A

4Aruba 310 Series Access Points | Installation Guide
Figure 3 External Antenna Connectors
Antenna ports ANT0 and ANT1 are connected to a dual-band radio and support 2.4GHz and 5GHz. The ANT2 and
ANT3 antenna ports support 5GHz only.
Bluetooth Low Energy Radios
310 Series access points are equipped with an integrated BLE radio that provide the following capabilities:
location beacon applications
wireless console access
Console Port
The console port allows the user to connect to the access point directly to a serial terminal or laptop for local
management. Connect the device to a terminal or terminal server using an AP-CBL-SERU cable. For pin-out
details, refer to Figure 4.
Figure 4 Console Port Pin-out
Ethernet Ports
The Aruba 310 Series is equipped with a 10/100/1000Base-T auto-sensing MDI/MDX Ethernet port. The port
supports wired-network connectivity, in addition to Power over Ethernet (PoE) from IEEE 802.3af and 802.3at
ANT0 ANT1
ANT3 ANT2
!
External antennas for this device must be installed by an Aruba Certified Mobility Professional (ACMP) or other
Aruba-certified technician, using manufacturer-approved antennas only.
The Equivalent Isotropically Radiated Power (EIRP) levels for all external antenna devices must not exceed the
regulatory limit set by the host country/domain.
Installers are required to record the antenna gain for this device in the system management software.
Les antennes externes pour cet appareil doivent être installées par un professionnel de la mobilité certifié Aruba
(ACMP) ou un autre technicien certifié Aruba, en utilisant uniquement des antennes approuvées par le fabricant.
Les niveaux équivalents de puissance à rayonnement isotrope (EIRP) pour tous les périphériques d'antenne
externe ne doivent pas dépasser la limite réglementaire définie par le pays hôte / domaine.
Les installateurs doivent enregistrer le gain d'antenne pour cet appareil dans le logiciel de gestion du système.
1: NC
2: RX
3: TX
4: GND
5: GND
1 3.3V
2 RX
3 TX
4 GND
Pin Signal

Aruba 310 Series Access Points | Installation Guide 5
compliant power sources. This device accepts 56V DC (802.3at), or 48V DC (802.3af) nominal as a standard
powered device (PD) from power sourcing equipment, including PoE midspan injector or a PoE-sourcing network
infrastructure. The port is an RJ45 connector with pin-out details shown in Figure 2.
Figure 5 Ethernet Port Pin-Out
Kensington Lock Slot
The 310 Series is equipped with a Kensington lock slot for additional security.
USB Interface
The 310 Series is equipped with a USB port for connectivity with cellular modems and other USB client devices.
When powered by an 802.3at or DC source, the USB port can supply power up to 5W.
The USB interface is disabled when the access point is powered by an 802.3af PoE source.
Figure 6 USB Port
Reset Button
The reset button can be used to reset the access point to factory default settings or turn off/on the LED display.
To reset the access point to factory default settings, follow this procedure:
1. Power off the access point.
2. Press and hold the push button using a small, narrow object, such as a paper clip.
3. Power-on the access point without releasing the push button. The System Status LED will flash within 5
seconds.
4. Release the reset button.
The system status LED will flash again within 15 seconds indicating that the reset is completed. The access point
will now continue to boot with the factory default settings.
Power
The Ethernet port supports PoE-in, allowing the device to draw power from an 802.3at source.
If PoE is unavailable, the 310 Series access points have a single 12V/36W DC power input to support the AP-AC-
12V30UN AC-to-DC power adapter kit (sold separately).
When both 802.3at and DC power sources are available, the DC power source takes precedence. The access
point simultaneously draws a minimal current from the PoE source. In the event that the DC source fails, the
access point switches to the 802.3at source.
The 310 Series operates without restriction when powered by 802.3at compliant and DC power sources. In this
mode, the USB interface is enabled and supports up to 1A/5W to a powered device (PD). When powered by an
802.3af PoE+ source, the access point operates in power-saving mode. In this mode, the USB interface is
disabled. See Table 3 for power modes.
1000Base-T Gigabit
Ethernet Port
RJ45 Female
Pin-Out
Signal Name
1
2
3
4
5
6
7
8
BI_DC+
BI_DC-
BI_DD+
BI_DD-
BI_DA+
BI_DA-
BI_DB+
BI_DB-
Function
Bi-directional pair +C
Bi-directional pair -C
Bi-directional pair +D
Bi-directional pair -D
Bi-directional pair +A
Bi-directional pair -A
Bi-directional pair +B
Bi-directional pair -B

6Aruba 310 Series Access Points | Installation Guide
Table 3 Power Modes
Before You Begin
Refer to the sections below before beginning the installation process.
Pre-Installation Checklist
Before installing your Aruba 310 Series access point, be sure that you have one of the following:
Cat5E UTP cable (or better) with network access installed in the wall box
One of the following power sources:
IEEE 802.3at or 802.3af-compliant Power over Ethernet (PoE) source. The PoE source can be any power
source equipment (PSE) controller or midspan PSE device.
Aruba AP-AC-12V30UN adapter kit (sold separately)
For AP-314 and AP-315 access points only:
Aruba controller provisioned on the network:
Layer 2/3 network connectivity to your access point
One of the following network services:
Aruba Discovery Protocol (ADP)
DNS server with an “A” record
DHCP Server with vendor-specific options
Pre-Installation Connectivity
Before installing access points in a network environment, make sure that they are able to locate and connect to
the controller after power on.
Verify the following conditions:
When connected to the network, each access point is assigned a valid IP address
Access points are able to locate the controller
Refer to the ArubaOS Quick Start Guide for instructions on locating and connecting to the controller.
Pre-Installation Network Requirements
After WLAN planning is complete and the appropriate products and their placement have been determined, the
Aruba controller(s) must be installed and initial setup performed before the Aruba access points are deployed.
For initial setup of the controller, refer to the ArubaOS Quick Start Guide for the software version installed on the
controller.
Power Source Limitations USB Output
DC (AP-AC-12V30B) No restrictions 1A/5W
802.3at PoE No restrictions 1A/5W
802.3af PoE+ USB disabled Disabled
!
FCC Statement: Improper termination of access points installed in the United States configured to non-US
model controllers is a violation of the FCC grant of equipment authorization. Any such willful or intentional
violation may result in a requirement by the FCC for immediate termination of operation and may be subject to
forfeiture (47 CFR 1.80).
Aruba Networks, Inc., in compliance with governmental requirements, has designed the 310 Series access points
so that only authorized network administrators can change the settings. For more information about access
point configuration, refer to the ArubaOS Quick Start Guide/Aruba Instant Quick Start Guide and ArubaOS User
Guide/Aruba Instant User Guide.
The instructions for this section are applicable to AP-314 and AP-315 only.

Aruba 310 Series Access Points | Installation Guide 7
Identifying Specific Installation Locations
The 310 Series access point can be mounted to a wall or on the ceiling. Use the access point
placement map generated by Aruba’s RF Plan software application to determine the proper
installation location(s). Each location should be as close as possible to the center of the intended
coverage area and should be free from obstructions or obvious sources of interference. These RF
absorbers/reflectors/interference sources impact RF propagation and should have been accounted
for during the planning phase and adjusted for in RF plan.
Identifying Known RF Absorbers/Reflectors/Interference Sources
Identifying known RF absorbers, reflectors, and interference sources while in the field during the installation
phase is critical. Make sure that these sources are taken into consideration when you attach an access point to its
fixed location.
RF absorbers include:
Cement/concrete—Old concrete has high levels of water dissipation, which dries out the concrete, allowing
for potential RF propagation. New concrete has high levels of water concentration in the concrete, blocking
RF signals.
Natural Items—Fish tanks, water fountains, ponds, and trees
Brick
RF reflectors include:
Metal Objects—Metal pans between floors, rebar, fire doors, air conditioning/heating ducts, mesh windows,
blinds, chain link fences (depending on aperture size), refrigerators, racks, shelves, and filing cabinets.
Do not place an access point between two air conditioning/heating ducts. Make sure that access points are
placed below ducts to avoid RF disturbances.
RF interference sources include:
Microwave ovens and other 2.4 or 5 GHz objects (such as cordless phones)
Cordless headset such as those used in call centers or lunch rooms
Access Point Installation
Refer to the following steps to install the Aruba 310 Series access points using the AP Ceiling Rail Mount Kit (AP-
220-MNT-C1).
Using the Ceiling Rail Adapter
The 310 Series access point ships with two ceiling rail adapters for 9/16” and 15/16” ceiling rails. Additional wall
!
RF Radiation Exposure Statement: This equipment complies with RF radiation exposure limits. This equipment
should be installed and operated with a minimum distance of 13.78 inches (35cm) between the radiator and
your body for 2.4 GHz and 5 GHz operations. This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
Déclaration sur les limites d'exposition aux radiofréquences: cet équipement est conforme aux limites
d'exposition aux rayonnements radioélectriques spécifiées. Il doit être installé et utilisé à une distance minimale
de 35 cm par rapport à votre corps pour les fréquences de 2,4 et 5 GHz. Cet émetteur-récepteur ne doit pas être
utilisé ou situé à proximité d'autres antennes ou émetteurs-récepteurs.
!
All Aruba access points should be professionally installed by an Aruba-Certified Mobility Professional (ACMP).
The installer is responsible for ensuring that grounding is available and meets applicable national and electrical
codes. Failure to properly install this product may result in physical injury and/or damage to property.
Tous les points d'accès Aruba doivent impérativement être installés par un professionnel agréé. Ce dernier doit
s'assurer que l'appareil est mis à la terre et que le circuit de mise à la terre est conforme aux codes électriques
nationaux en vigueur. Le fait de ne pas installer correctement ce produit peut entraîner des blessures
corporelles et / ou des dommages matériels.

8Aruba 310 Series Access Points | Installation Guide
mount adapters for other rail adapters for other rail styles are available as accessory kits.
1. Pull the necessary cables through a prepared hole in the ceiling tile near where the access point will be
placed.
2. Place the adapter against the back of the access point with the adapter at an angle of approximately 30
degrees to the tabs. See Figure 7.
3. Twist the adapter clockwise until it snaps into place in the tabs. See Figure 7.
Figure 7 Attaching the Ceiling Rail Adapter
4. If necessary, connect the console cable to the console port on the back of the access point.
5. Hold the access point next to the ceiling tile rail with the ceiling tile rail mounting slots at approximately a 30-
degree angle to the tile rail. See Figure 8. Make sure that any cable slack is above the ceiling tile.
6. Pushing toward the ceiling tile, rotate the access point clockwise until the device clicks into place on the
ceiling tile rail.
Figure 8 Mounting the Access Point
7. On the (I)AP-314, install the external antennas according to the manufacturer’s instructions, and connect the
antennas to the antenna interfaces on the access points.
Connecting Required Cables
Install cables in accordance with all applicable local and national regulations and practices.
Software
Aruba 310 Series requires ArubaOS 6.5.0.0 or higher. For instructions on choosing operating modes and initial
!
The installer is responsible for securing the access point onto the ceiling tile rail in accordance with the steps
below. Failure to properly install this product may result in physical injury and/or damage to property.

Aruba 310 Series Access Points | Installation Guide 9
software configuration, refer to the ArubaOS User Guide and ArubaOS Quick Start Guide.
Verifying Post-Installation Connectivity
The integrated LED on the access point can be used to verify that the access point access point is receiving power
and initializing successfully (see Table 1 and Table 2). Refer to the ArubaOS Quick Start Guide for further details on
verifying post-installation network connectivity.
Configuring the 310 Series
Access Point Provisioning/Reprovisioning
Provisioning parameters are unique to each access point. These local access point parameters are initially
configured on the controller, and are then pushed out to the access points and stored on the devices. Aruba
recommends that provisioning settings be configured via the ArubaOS Web UI only. Refer to the ArubaOS User
Guide for complete details.
Access Point Configuration
Configuration parameters are network or controller specific and are configured and stored on the controller.
Network configuration settings are pushed out to the access points, but remain stored on the controller.
Configuration settings can be configured via the ArubaOS Web UI or ArubaOS CLI. Refer to their respective
guides for further details. See the ArubaOS User Guide.
Electrical and Environmental Specifications
For additional specifications on this product, please refer to the product data sheet at arubanetworks.com
Electrical
Ethernet:
100/1000T Base-T auto-sensing Ethernet RJ45 interface
IEEE 802.3u (100 Base-T). IEEE 802.3ab (1000 Base-T)
Power:
48VDC power interference, support powering through an AC-to-DC power adapter (AP-AC-48V36B)
Maximum power consumption (excluding USB): 20W (PoE) or 18.5W (DC)
Environmental
Operating:
Temperature: 0°C to +40°C (+32°F to +104°F)
Humidity: 5% to 93% non-condensing
Storage and transport:
Temperature: -40°C to +70°C (-40°F to +158°F)
!
Access points are radio transmission devices and are subject to governmental regulation. Network
administrators responsible for the configuration and operation of access points must comply with local
broadcast regulations. Specifically, access points must use channel assignments appropriate to the location in
which the access point is used.
The instructions for this section are applicable to AP-314 AP-315 only.
If a power adapter other than the Aruba-approved adapter is used in the US or Canada, it should be NRTL listed,
with an output rated 48VDC, minimum 2A, marked “LPS” and “Class 2”, and suitable for plugging into a standard
power receptacle in the US and Canada.

10 Aruba 310 Series Access Points | Installation Guide
Humidity: 5% to 93% non-condensing
Proper Disposal of Aruba Equipment
Dispose of Aruba products per local regulation. For the most current information about Global Environmental
Compliance and Aruba products, see our website at arubanetworks.com.
Waste of Electrical and Electronic Equipment
Aruba products at end of life are subject to separate collection and treatment in the EU
Member States, Norway, and Switzerland and therefore are marked with the symbol shown at
the left (crossed-out wheelie bin). The treatment applied at end of life of these products in
these countries shall comply with the applicable national laws of countries implementing
Directive 2002/96EC on Waste of Electrical and Electronic Equipment (WEEE).
China RoHS
Aruba products also comply with China environmental declaration requirements and are packaged with the
following “EFUP25” label.
!
For indoor use only. The access point, AC adapter, and all connected cables are not designed for outdoor use.

Aruba 310 Series Access Points | Installation Guide 11
Taiwan RoHS
Table-APIN0314/APIN0315-20180213
無線接收盒 : 802.11ac Wireless Access Point
Type Designation: APIN0314_APIN0315
European Union RoHS
Aruba products comply with the EU Restriction of Hazardous Substances Directive 2011/65/EC (RoHS). EU RoHS
restricts the use of specific hazardous materials in the manufacture of electrical and electronic equipment.
Specifically, restricted materials under the RoHS Directive are Lead (including Solder used in printed circuit
assemblies), Cadmium, Mercury, Hexavalent Chromium, and Bromine. Some Aruba products are subject to the
exemptions listed in RoHS Directive Annex 7 (Lead in solder used in printed circuit assemblies).
India RoHS
This product complies with RoHS requirements as prescribed by E-Waste (Management & Handling) Rules,
governed by the Ministry of Environment & Forests, Government of India.
Turkey RoHS
Ukraine RoHS
Regulatory Information
For the purpose of regulatory compliance certifications and identification, this product has been assigned a

12 Aruba 310 Series Access Points | Installation Guide
unique regulatory model number (RMN). The regulatory model number can be found on the product nameplate
label, along with all required approval markings and information. When requesting compliance information for
this product, always refer to this regulatory model number. The regulatory model number is not the marketing
name or model number of the product.
AP-314/IAP-314 RMN: APIN0314
AP-315/IAP-315 RMN: APIN315
Federal Communication Commission
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit that is different from that to which the receiver is
connected.
Consult the dealer or an experienced radio or television technician for help.
European Union
The Declaration of Conformity made under RED 2014/53/EU is available for viewing at:
arubanetworks.com, then navigate to the Declarations of Conformity > Access Point folder, select the
document that corresponds to your device’s model number as it is indicated on the product label.
This radio transmitter model has been approved to operate with the antenna types listed in the online ordering
guide (link provided below) with the maximum permissible gain indicated. Antenna types not included in this list,
having a greater gain than the maximum gain indicated for the type, are strictly prohibited for use with this
device. Compliance is only assured if the Aruba approved accessories as listed in the ordering guide are used.
https://www.arubanetworks.com/assets/og/OG_AP-310Series.pdf
Wireless Channel Restrictions
5150-5350MHz band is limited to indoor only in the following countries; Austria (AT), Belgium (BE), Bulgaria (BG),
!
Changes or modifications to this unit not expressly approved by the party responsible for regulatory compliance
could void the user’s authority to operate this equipment.
Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la
conformité est susceptible d'annuler son droit d'utilisation.
!
Improper termination of access points installed in the United States configured to a non-US model controller is a
violation of the FCC grant of equipment authorization. Any such willful or intentional violation may result in a
requirement by the FCC for immediate termination of operation and may be subject to forfeiture (47 CFR 1.80).
The network administrator(s) is/are responsible for ensuring that this device operates in accordance with local/
regional laws of the host domain.
!
Changes or modifications to this unit not expressly approved by the part responsible for compliance could void
the user’s authority to operate this equipment.
Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la
conformité est susceptible d'annuler son droit d'utilisation.

Aruba 310 Series Access Points | Installation Guide 13
Croatia (HR), Cyprus (CY), Czech Republic (CZ), Denmark (DK), Estonia (EE), Finland (FI), France (FR), Germany (DE),
Greece (GR), Hungary (HU), Iceland (IS), Ireland (IE), Italy (IT), Latvia (LV), Liechtenstein (LI), Lithuania (LT),
Luxembourg (LU), Malta (MT), Netherlands (NL), Norway (NO), Poland (PL), Portugal (PT), Romania (RO), Slovakia
(SK), Slovenia (SL), Spain (ES), Sweden (SE), Switzerland (CH), Turkey (TR), United Kingdom (UK).
Industry Canada
This Class B digital apparatus meets all of the requirements of the Canadian Interference-Causing Equipment
Regulations.
In accordance with Industry Canada regulations, this radio transmitter and receiver may only be used with an
antenna, the maximum type and gain of which must be approved by Industry Canada. To reduce potential radio
interference, the type of antenna and its gain shall be chosen so that the equivalent isotropic radiated power
(EIRP) does not exceed the values necessary for effective communication.
This device complies with Industry Canada's license-exempt RSS regulations. Operation of this device is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation.
When operated in the 5.15 to 5.25 GHz frequency range, this device is restricted to indoor use to reduce the
potential for harmful interference with co-channel Mobile Satellite Systems.
This radio transmitter model APIN0314 has been approved by Industry Canada to operate with the antenna
types listed in the online ordering guide (link provided below) with the maximum permissible gain indicated.
Antenna types not included in this list, having a greater gain than the maximum gain indicated for that type, are
strictly prohibited for use with this device. http://www.arubanetworks.com/assets/og/OG_AP-310Series.pdf
Déclaration d’Industrie Canada
Conformément aux réglementations d’Industrie Canada, cet émetteur-récepteur radio doit être utilisé
uniquement avec une antenne dont le type et le gain maximal doivent être approuvés par Industrie Canada.
Pour réduire les interférences radio potentielles, le type d’antenne et son gain doivent être choisis de façon à ce
que la puissance isotrope rayonnée équivalente (PIRE) ne dépasse pas les valeurs nécessaires à une
communication efficace.
Ce périphérique est conforme aux règlements RSS exempts de licence d’Industrie Canada. L’utilisation de ce
périphérique est soumise aux deux conditions suivantes : (1) ce périphérique ne doit pas provoquer
d’interférences, et (2) ce périphérique doit accepter toute interférence, y compris les interférences susceptibles
de provoquer un dysfonctionnement.
En cas d'utilisation dans la plage de fréquences de 5,15 à 5,25 GHz, cet appareil doit uniquement être utilisé en
intérieur afin de réduire les risques d'interférence avec les systèmes satellites mobiles partageant le même
canal.
Ce modèle d'émetteur radio APIN0314 a été approuvé par Industrie Canada pour fonctionner avec les types
d'antenne énumérés dans le guide de commande en ligne (lien ci-dessous) avec le gain maximal admissible
indiqué. Les types d'antennes non inclus dans cette liste, ayant un gain supérieur au gain maximal indiqué pour
ce type, sont strictement interdits pour une utilisation avec cet appareil. http://www.arubanetworks.com/assets/
og/OG_AP-310Series.pdf
Frequency Range MHz Max EIRP
2402-2480 9 dbm
2412-2472 20 dbm
5150-5250 23 dbm
5250-5350 23 dbm
5470-5725 30 dbm
5725-5850 N/A for EU
!
Lower power radio LAN product operating in 2.4 GHz and 5 GHz bands. Please refer to the ArubaOS User Guide/
Instant User Guide for details on restrictions.

14 Aruba 310 Series Access Points | Installation Guide
Japan
Brazil
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência
prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em
caráter primário.
Mexico
La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o
dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debeaceptar cualquier interferencia,
incluyendo la que pueda causar su operación no deseada.
Este equipo ha sido diseñado para operar con las antenas que enseguida se enlistan, en el punto 4: https://
www.arubanetworks.com/assets/og/OG_AP-310Series.pdf y para una ganancia máxima de antena de 8.5 dBi.
El uso con este equipo de antenas no incluidas en esta lista o que tengan una ganancia mayor que 8.5 dBi
quedan prohibidas La impedancia requerida de la antena es de 50 ohms.
Morocco
Нормативные требования Евразийского Экономического Союза
Russia
HPE Russia: ООО "Хьюлетт Паккард Энтерпрайз" Российская Федерация, 125171, г.
Москва, Ленинградское шоссе, 16А, стр.3, Телефон: [phone] Факс: [phone]
4677
'HPE Belarus': ИООО «Хьюлетт-Паккард Бел», Республика Беларусь, 220030, г. Минск,
ул. Интернациональная, 36-1, Телефон/факс: [phone]
'HPE Kazakhstan': TOO «Хьюлетт-Паккард (К)», Республика Казахстан, 050040, г.
Алматы, Бостандыкский район, проспект Аль-Фараби, 77/7, Телефон/факс: + 7 727 355 35 50
Kazakhstan
ЖШС "Хьюлетт Паккард Энтерпрайз" Ресей Федерациясы, 125171, Мәскеу, Ленинград тас жолы, 16A блок
3, Телефон: [phone] Факс: [phone]
«HEWLETT-PACKARD Bel» ЖШС, Беларусь Республикасы, 220030, Минск қ., Интернациональная көшесі, 36/
1, Телефон/факс: [phone]
ЖШС «Хьюлетт-Паккард (К)», Қазақстан Республикасы, 050040, Алматы к., Бостандык ауданы, Әл-Фараби
даңғ ылы, 77/7, Телефон/факс: [phone]

Aruba 310 Series Access Points | Installation Guide 15
Korean
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용 환경에서 사용하는 경우 전파간섭
의 우려가 있습니다 .
=> 사용자 안내문은 “ 업무용방송통신기자재 ’ 에만 해당된다
Taiwan
第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得
擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現
象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機
設備之干擾。
1. 應避免影響附近雷達系統之操作。
2. 高增益指向性天線只得應用於固定式點對點系統。
3. 電磁波暴露量 MPE 標準值1 mW/cm2, 送測產品實測值為 : 0.900 mW/cm2
Medical
1. Equipment not suitable for use in the presence of flammable mixtures.
2. Connect to only IEC 60950-1 or IEC 60601-1 3rd edition certified products and power sources. The end user is
responsible for the resulting medical system complies with the requirements of IEC 60601-1 3rd edition.
3. Wipe with a dry cloth, no additional maintenance required.
4. No serviceable parts, the unit must be sent back to the manufacturer for repair.
5. No modifications are allowed without Aruba approval.
Expected Service Life 10 years. For additional compliance information, refer to the regulatory label on the back of
this device.

16 Aruba 310 Series Access Points | Installation Guide
Contact Aruba
Copyright
© Copyright 2018 Hewlett Packard Enterprise Development LP
Open Source Code
This product includes code licensed under the GNU General PublicLicense, the GNU Lesser General Public License, and/or
certain other open source licenses.
A complete machine-readable copy of the source code corresponding to such code is available upon request. This offer is valid
to anyone in receipt of this information and shall expire three years following the date of the final distribution of this product
version by Hewlett Packard Enterprise Company.
To obtain such source code, send a check or money order in the amount of US $10.00 to:
Hewlett Packard Enterprise Company
Attn: General Counsel
3000 Hanover Street
Palo Alto, CA 94304
USA
Warranty
This hardware product is protected by an Aruba warranty. For more details visit www.hpe.com/us/en/support.html
Main Site http://www.arubanetworks.com
Support Site http://www.arubanetworks.com
Airheads Social Forums and
Knowledge Base http://community.arubanetworks.com/
North America Telephone [phone] (toll free)
1-408-754-1200
International Telephone http://arubanetworks.com/support-services/contact-support/
Software Licensing Site http://hpe.com/networking/support
End-of-Life Information http://arubanetworks.com/support-services/end-of-life/
Security Incident Response Team
(SIRT) Site: http://www.arubanetworks.com/support-service/security-bulletins/
Email: [e-mail]
