IPmitter IPMIT430 User manual

© 2022 System Q Ltd
1
IPMITTER 5.8GHz 48V 900Mbps IP Bridge
IPmitter is a registered trademark of System Q Ltd
Document ref: qIPMIT430
IPmitter.com
IPMIT430 / IPMIT460 - Quick Start Guide
www.systemq.com/pdf/man
ual/xIPMIT430.pdf
The IPMIT430s can be used to "bridge" an wireless IP connection for IP cameras or other IP devices
wireless between two points, devices connect via the RJ45 port on the IPmitter.
Powering
Option 1 - Power from 12V DC (via the 2.1mmDC Socket), the current consumption is 300mA.
The IPMIT430 is polarity sensitive so connections must be made correctly.
Option 2 - Power the camera using 48V PoE, in the RJ45 WAN/POE Socket
The IPMIT430 will take approximately 3 minutes to boot up.
1 = Function Button
2 = LED Display
3 = Setting
4 = 12V DC. 2.1mm DC Socket
5 = Reset/Pair Button
6 = WAN - 10Mbs / 100Mbs / 1000Mbs 48 PoE network socket
7 = LAN - 10Mbs / 100Mbs network socket
Standard WiFi Bridge Setup
For more setup options see the full manual

This symbol indicates that equipment must not be mixed with general household waste. For treatment, recovery and recycling please return to your local designated
WEE/CG0783SS collection point as defined by your local council.
© 2022 System Q Ltd
2
IPMITTER 5.8GHz 48V 900Mbps IP Bridge
IPmitter is a registered trademark of System Q Ltd
Document ref: qIPMIT430
All specificationsare approximate.System Q Ltdreservesthe right to change product specifications or features without notice. Whilst every effort is
made to ensure that these instructionsare complete and accurate, System Q Ltd cannot be held responsible for anylosses, no matter how they arise,
from errors or omissionsin these instructions, or the performance or non-performance of the equipment refered to.
Available Channels – 36 - 64 and 100-140 (In multiples of 4)
The IPmitters as default are on H100 (Host and channel 100), and need pairing up before installing. One
IPmitter needs to be set to H (Host) and the other to C (Client), they both have to be set to the same channel
number.
Example - Pairing on channel 100
1. Power both IPmitters, and leave to boot up for at least 3 mins.
2. Press the F (function) button and"H" will flash. Press the S (setting) button to change to "C100"
3. Press the F button 3 times, then the whole display will flash to indicate the settings have been saved, once
it boots back up the display will show "C036".
4. Now press the RST(reset) button for 1 second on both IPmitters. The display will change to a P with a
rotating segment whilst pairing and will show P and a value once paired. Pairing can take up to 5 minutes.
NOTE : - Keep both IPmitters at least 2m apart during pairing, if the IPmitters are too close they will "de-
sense" and not pair.
- Do not attempt to pair both IPmitters connected to the same PoE switch, they will detect a network
loop and not pair.
ERR - On display
1. Default both IPmitters (press and hold rst button for at least 10 seconds).
2. Attempt pairing process again.
The strength will range P-01 (Good) to P-75 (Poor). If P-95 shows then the IPmitters have not paired.
Eventually the display will go off.
To add more clients (up to 4) to one host then set the channel on the new client and press the reset buttons
on the new client and the Host.
www.zipdvr.com/howto/TIP459-How-To-Add-IP-
Cameras.html
If using the IPMIT430 with a ZIP Recorder then the cameras
needs to be manually configured, scan the QR code to the
left for the "how to guide"
LAN Port 1 Speed
10Mbs / 100Mbs
LAN Port 2 Speed
10Mbs / 100Mbs / 1000Mbs
Frequency
5.8Ghz
Wireless Data Speed
900Mbps
Wireless Standard
IEEE802.11AC/A
PoE Voltage
48V
12V Input Option
Yes
Max Tx Distance
2000m (Recommend 1000m)
Easy Pair Technology
Yes
Support 1 - 1
Yes
Support 1 - Many
Yes
Modes
Access Point / Repeater
Mounting
Wall Or Pole (Not Supplied)
Dimensions
260 x 88 x 56mm
