KSB Vitalobe Installation instructions

Hygienic Pump
Vitalobe
Installation/Operating Manual

Legal information/Copyright
Installation/Operating Manual Vitalobe
Original operating manual
All rights reserved. The contents provided herein must neither be distributed, copied, reproduced,
edited or processed for any other purpose, nor otherwise transmitted, published or made available to a
third party without the manufacturer's express written consent.
Subject to technical modification without prior notice.
© KSB SE & Co. KGaA, Frankenthal 31/08/2018

Contents
3 of 116
Vitalobe
Contents
Glossary .................................................................................................................................................. 5
1 General.................................................................................................................................................... 6
1.1 Principles ...........................................................................................................................................................6
1.2 Installation of partly completed machinery....................................................................................................6
1.3 Target group.....................................................................................................................................................6
1.4 Other applicable documents............................................................................................................................6
1.5 Symbols .............................................................................................................................................................6
1.6 Key to safety symbols/markings.......................................................................................................................7
2 Safety...................................................................................................................................................... 8
2.1 General..............................................................................................................................................................8
2.2 Intended use .....................................................................................................................................................8
2.3 Personnel qualification and training...............................................................................................................8
2.4 Consequences and risks caused by non-compliance with this manual .........................................................9
2.5 Safety awareness ..............................................................................................................................................9
2.6 Safety information for the operator/user.......................................................................................................9
2.7 Safety information for maintenance, inspection and installation ................................................................9
2.8 Unauthorised modes of operation................................................................................................................10
2.9 Explosion protection ......................................................................................................................................10
2.9.1 Marking ..............................................................................................................................................10
2.9.2 Temperature limits.............................................................................................................................10
2.9.3 Monitoring equipment......................................................................................................................11
3 Transport/Temporary Storage/Disposal............................................................................................. 12
3.1 Checking the condition upon delivery..........................................................................................................12
3.2 Transport.........................................................................................................................................................12
3.3 Storage/preservation......................................................................................................................................13
3.4 Return to supplier...........................................................................................................................................14
3.5 Disposal ...........................................................................................................................................................14
4 Description of the Pump (Set)............................................................................................................. 15
4.1 General description ........................................................................................................................................15
4.2 Designation.....................................................................................................................................................15
4.3 Name plate......................................................................................................................................................18
4.4 Design details..................................................................................................................................................18
4.5 Configuration and function...........................................................................................................................20
4.6 Noise characteristics .......................................................................................................................................21
4.7 Overview of pump sizes: discharge pressure ................................................................................................21
4.8 Scope of supply...............................................................................................................................................21
4.9 Dimensions and weights ................................................................................................................................21
5 Installation at Site................................................................................................................................ 22
5.1 Safety regulations...........................................................................................................................................22
5.2 Checks to be carried out prior to installation...............................................................................................22
5.3 Installing the pump set ..................................................................................................................................23
5.3.1 Installation on a foundation .............................................................................................................23
5.3.2 Installation on machine mounts .......................................................................................................24
5.4 Piping ..............................................................................................................................................................25
5.4.1 Connecting the piping.......................................................................................................................25
5.4.2 Permissible forces and moments at the pump nozzles....................................................................27
5.4.3 Auxiliary connections.........................................................................................................................28
5.5 Protective equipment.....................................................................................................................................34
5.6 Checking the coupling alignment .................................................................................................................35
5.7 Electrical system..............................................................................................................................................36
5.7.1 Frequency inverter operation ...........................................................................................................36
5.8 Electrical connection ......................................................................................................................................36

Contents
4 of 116 Vitalobe
5.8.1 Connecting the motor .......................................................................................................................37
5.8.2 Earthing..............................................................................................................................................37
5.9 Checking the direction of rotation................................................................................................................37
6 Commissioning/Start-up/Shutdown................................................................................................... 38
6.1 Commissioning/Start-up.................................................................................................................................38
6.1.1 Prerequisites for commissioning/start-up .........................................................................................38
6.1.2 Filling in the lubricant .......................................................................................................................38
6.1.3 Priming and venting the pump.........................................................................................................39
6.1.4 Start-up...............................................................................................................................................39
6.1.5 Checking the shaft seal......................................................................................................................41
6.1.6 Shutdown ...........................................................................................................................................41
6.1.7 Seal supply system..............................................................................................................................41
6.2 Operating limits..............................................................................................................................................43
6.2.1 General operating limits....................................................................................................................43
6.2.2 Ambient temperature........................................................................................................................43
6.2.3 Operating temperature.....................................................................................................................43
6.2.4 Frequency of starts.............................................................................................................................44
6.2.5 Fluid handled .....................................................................................................................................44
6.2.6 Operating data...................................................................................................................................45
6.3 Shutdown/storage/preservation ....................................................................................................................45
6.3.1 Measures to be taken for shutdown ................................................................................................45
6.4 Returning to service .......................................................................................................................................46
7 Servicing/Maintenance........................................................................................................................ 47
7.1 Safety regulations...........................................................................................................................................47
7.2 Cleaning ..........................................................................................................................................................48
7.2.1 Cleaning in place (CIP).......................................................................................................................48
7.2.2 SIP (steaming in place).......................................................................................................................49
7.3 Servicing/Inspection........................................................................................................................................50
7.3.1 Supervision of operation...................................................................................................................50
7.3.2 Inspection work..................................................................................................................................52
7.3.3 Lubrication and lubricant change of rolling element bearings ......................................................53
7.4 Drainage/cleaning ..........................................................................................................................................55
7.5 Dismantling the pump set..............................................................................................................................56
7.5.1 General information/Safety regulations...........................................................................................56
7.5.2 Preparing the pump set.....................................................................................................................57
7.5.3 Removing the complete pump set from the piping ........................................................................57
7.5.4 Dismantling the pump.......................................................................................................................57
7.5.5 Dismantling the bearing housing .....................................................................................................65
7.6 Reassembling the pump set...........................................................................................................................70
7.6.1 General information/Safety regulations...........................................................................................70
7.6.2 Adjusting the clearances ...................................................................................................................72
7.6.3 Fitting the bearing housing ..............................................................................................................73
7.6.4 Installing the rotor casing .................................................................................................................80
7.6.5 Adjusting the rotor clearances and completing the assembly........................................................85
7.7 Spare parts stock.............................................................................................................................................91
7.7.1 Ordering spare parts..........................................................................................................................91
7.7.2 Recommended spare parts stock for 2 years' operation to DIN24296 ..........................................91
8 Trouble-shooting.................................................................................................................................. 93
9 Related Documents.............................................................................................................................. 95
9.1 Exploded view and list of components .........................................................................................................95
9.1.1 Vitalobe design standard BB.............................................................................................................95
9.1.2 Vitalobe design standard B ...............................................................................................................99
10 EU Declaration of Conformity........................................................................................................... 112
11 Certificate of Decontamination......................................................................................................... 113
Index ................................................................................................................................................... 114

Glossary
5 of 116
Vitalobe
Glossary
Certificate of decontamination
A certificate of decontamination is enclosed by the
customer when returning the product to the
manufacturer to certify that the product has been
properly drained to eliminate any environmental
and health hazards arising from components in
contact with the fluid handled.
CIP (cleaning in place)
Procedure during which the inside of the pump is
cleaned with a cleaning agent. The pump does not
need to be dismantled.
Discharge line
The pipeline which is connected to the discharge
nozzle
Hydraulic system
The part of the pump in which the kinetic energy
is converted into pressure energy
In-line design
A pump whose suction and discharge nozzle are
arranged opposite each other and have the same
nominal diameter.
Pool of pumps
Customers/operators’ pumps which are purchased
and stored regardless of their later use.
Pump
Machine without drive, additional components or
accessories
Pump set
Complete pump set consisting of pump, drive,
additional components and accessories
SIP (steaming in place)
Procedure during which the inside of the pump is
sterilised with steam. The pump does not need to
be dismantled.
Suction lift line/suction head line
The pipeline which is connected to the suction
nozzle

1 General
6 of 116 Vitalobe
1 General
1.1 Principles
This operating manual is supplied as an integral part of the type series and variants
indicated on the front cover.
The manual describes the proper and safe use of this equipment in all phases of
operation.
The name plate indicates the type series and size, the main operating data, the order
number and the order item number. The order number and order item number
clearly identify the pump set and serve as identification for all further business
processes.
In the event of damage, immediately contact your nearest KSB Service centre to
maintain the right to claim under warranty.
1.2 Installation of partly completed machinery
To install partly completed machinery supplied by KSB refer to the sub-sections under
Servicing/Maintenance.
1.3 Target group
This operating manual is aimed at the target group of trained and qualified specialist
technical personnel. (ðSection2.3,Page8)
1.4 Other applicable documents
Table1: Overview of other applicable documents
Document Contents
Data sheet Description of the technical data of the pump (set)
General arrangement drawing/
outline drawing
Description of mating and installation dimensions
for the pump (set), weights
Hydraulic characteristic curve Characteristic curves showing head, NPSHrequired,
efficiency and power input
General assembly drawing1) Sectional drawing of the pump
Sub-supplier product literature1) Operating manuals and other product literature
describing accessories and integrated machinery
components
Spare parts lists1) Description of spare parts
Piping layout1) Description of auxiliary piping
List of components1) Description of all pump components
For accessories and/or integrated machinery components, observe the relevant
manufacturer's product literature.
1.5 Symbols
Table2: Symbols used in this manual
Symbol Description
✓Conditions which need to be fulfilled before proceeding with the
step-by-step instructions
⊳Safety instructions
⇨Result of an action
⇨Cross-references
1) If agreed to be included in the scope of supply

1 General
7 of 116
Vitalobe
Symbol Description
1.
2.
Step-by-step instructions
Note
Recommendations and important information on how to handle
the product
1.6 Key to safety symbols/markings
Table3: Definition of safety symbols/markings
Symbol Description
!DANGER
DANGER
This signal word indicates a high-risk hazard which, if not avoided,
will result in death or serious injury.
!WARNING
WARNING
This signal word indicates a medium-risk hazard which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION
This signal word indicates a hazard which, if not avoided, could
result in damage to the machine and its functions.
Explosion protection
This symbol identifies information about avoiding explosions in
potentially explosive atmospheres in accordance with EU Directive
2014/34/EU (ATEX).
General hazard
In conjunction with one of the signal words this symbol indicates a
hazard which will or could result in death or serious injury.
Electrical hazard
In conjunction with one of the signal words this symbol indicates a
hazard involving electrical voltage and identifies information about
protection against electrical voltage.
Machine damage
In conjunction with the signal word CAUTION this symbol indicates
a hazard for the machine and its functions.

2 Safety
8 of 116 Vitalobe
2 Safety
!DANGER
All the information contained in this section refers to hazardous situations.
In addition to the present general safety information the action-related safety
information given in the other sections must be observed.
2.1 General
This operating manual contains general installation, operating and maintenance
instructions that must be observed to ensure safe operation of the system and
prevent personal injury and damage to property.
The safety information in all sections of this manual must be complied with.
The operating manual must be read and understood by the responsible specialist
personnel/operators prior to installation and commissioning.
The contents of this operating manual must be available to the specialist personnel
at the site at all times.
Information attached directly to the product must always be complied with and kept
in a perfectly legible condition at all times. This applies to, for example:
▪Arrow indicating the direction of rotation
▪Markings for connections
▪Name plate
The operator is responsible for ensuring compliance with all local regulations not
taken into account in this operating manual.
2.2 Intended use
▪The pump (set) must only be operated in the fields of application and within the
use limits specified in the other applicable documents.
▪Only operate pumps/pump sets which are in perfect technical condition.
▪Do not operate the pump (set) in partially assembled condition.
▪Only use the pump to handle the fluids described in the data sheet or product
literature of the pump model or variant.
▪Never operate the pump without the fluid to be handled.
▪Observe the minimum flow rates indicated in the data sheet or product literature
(to prevent overheating, bearing damage, etc).
▪Observe the minimum flow rate and maximum flow rate indicated in the data
sheet or product literature (to prevent overheating, mechanical seal damage,
cavitation damage, bearing damage, etc).
▪Do not throttle the flow rate on the suction side of the pump (to prevent
cavitation damage).
▪Consult the manufacturer about any use or mode of operation not described in
the data sheet or product literature.
2.3 Personnel qualification and training
All personnel involved must be fully qualified to transport, install, operate, maintain
and inspect the machinery this manual refers to.
The responsibilities, competence and supervision of all personnel involved in
transport, installation, operation, maintenance and inspection must be clearly
defined by the operator.
Deficits in knowledge must be rectified by means of training and instruction
provided by sufficiently trained specialist personnel. If required, the operator can
commission the manufacturer/supplier to train the personnel.
Training on the pump (set) must always be supervised by technical specialist
personnel.

2 Safety
9 of 116
Vitalobe
2.4 Consequences and risks caused by non-compliance with this manual
▪Non-compliance with these operating instructions will lead to forfeiture of
warranty cover and of any and all rights to claims for damages.
▪Non-compliance can, for example, have the following consequences:
– Hazards to persons due to electrical, thermal, mechanical and chemical
effects and explosions
– Failure of important product functions
– Failure of prescribed maintenance and servicing practices
– Hazard to the environment due to leakage of hazardous substances
2.5 Safety awareness
In addition to the safety information contained in this manual and the intended use,
the following safety regulations shall be complied with:
▪Accident prevention, health regulations and safety regulations
▪Explosion protection regulations
▪Safety regulations for handling hazardous substances
▪Applicable standards, directives and laws
2.6 Safety information for the operator/user
▪Fit protective equipment (e.g. contact guards) supplied by the operator for hot,
cold or moving parts, and check that the equipment functions properly.
▪Do not remove any protective equipment (e.g. contact guards) during operation.
▪Provide the personnel with protective equipment and make sure it is used.
▪Contain leakages (e.g. at the shaft seal) of hazardous fluids handled (e.g.
explosive, toxic, hot) so as to avoid any danger to persons and the environment.
Adhere to all relevant laws.
▪Eliminate all electrical hazards. (In this respect refer to the applicable national
safety regulations and/or regulations issued by the local energy supply
companies.)
▪If shutting down the pump does not increase potential risk, fit an emergency-
stop control device in the immediate vicinity of the pump (set) during pump set
installation.
2.7 Safety information for maintenance, inspection and installation
▪Modifications or alterations of the pump (set) are only permitted with the
manufacturer's prior consent.
▪Use only original spare parts or parts/components authorised by the
manufacturer. The use of other parts/components can invalidate any liability of
the manufacturer for resulting damage.
▪The operator ensures that maintenance, inspection and installation is performed
by authorised, qualified specialist personnel who are thoroughly familiar with
the manual.
▪Only carry out work on the pump (set) during standstill of the pump.
▪Only perform work on the pump set when it has been disconnected from the
power supply (de-energised).
▪The pump (set) must have cooled down to ambient temperature.
▪Pump pressure must have been released and the pump must have been drained.

2 Safety
10 of 116 Vitalobe
▪When taking the pump set out of service always adhere to the procedure
described in the manual. (ðSection6.3,Page45)
▪Decontaminate pumps which handle fluids posing a health hazard.
▪As soon as the work has been completed, re-install and re-activate any safety-
relevant devices and protective devices. Before returning the product to service,
observe all instructions on commissioning. (ðSection6.1,Page38)
2.8 Unauthorised modes of operation
Never operate the pump (set) outside the limits stated in the data sheet and in this
manual.
The warranty relating to the operating reliability and safety of the supplied pump
(set) is only valid if the equipment is used in accordance with its intended use.
(ðSection2.2,Page8)
2.9 Explosion protection
!DANGER
Always observe the information on explosion protection given in this section when
operating the product in potentially explosive atmospheres.
Only pumps/pump sets marked as explosion-proof and identified as such in the data
sheet may be used in potentially explosive atmospheres.
Special conditions apply to the operation of explosion-proof pump sets to EU
Directive 2014/34/EU (ATEX).
Especially adhere to the sections in this manual marked with the symbol opposite and
the following sections, (ðSection2.9.1,Page10) to
The explosion-proof status of the pump set is only assured if the pump set is used in
accordance with its intended use.
Never operate the pump set outside the limits stated in the data sheet and on the
name plate.
Prevent impermissible modes of operation at all times.
2.9.1 Marking
Pump The marking on the pump refers to the pump part only.
Example of such marking:
II 2 G c TX (EN 13463-1) or II 2G Ex h IIC T5-T1 Gb (ISO 80079-36)
Refer to the individual Temperature Limits table for the temperatures permitted for
the individual pump variants.
The pump complies with the requirements of type of protection constructional safety
"c" to ISO80079-37.
Shaft coupling An EC manufacturer's declaration is required for the shaft coupling; the shaft
coupling must be marked accordingly.
Motor The motor must be considered separately.
2.9.2 Temperature limits
In normal pump operation, the highest temperatures are to be expected on the
surface of the pump casing, at the shaft seal and in the bearing areas.
The surface temperature at the pump casing corresponds to the temperature of the
fluid handled. If the pump is heated in addition, the operator of the system is
responsible for observing the specified temperature class and fluid temperature
(operating temperature).
The table below lists the temperature classes and the resulting theoretical
temperature limits of the fluid handled (a possible temperature rise in the shaft seal
area has already been taken into account).
The temperature class specifies the maximum permissible temperature at the surface
of the pump set during operation.
For the permissible operating temperature of the pump in question refer to the data
sheet.

2 Safety
11 of 116
Vitalobe
Table4: Temperature limits
Temperature class to EN13463-1 or
ISO80079-36
Maximum permissible fluid temperature
T1 Temperature limit of the pump
T2 Temperature limit of the pump
T3 150°C
T4 105°C
If the pump is to be operated at a higher temperature, if there is no data sheet or if
the pump is part of a pool of pumps, contact KSB for the maximum permissible
operating temperature.
Motor supplied by the
operator
If a pump is supplied without motor (as part of a pool of pumps), the motor specified
in the pump data sheet must meet the following conditions:
▪The permissible temperature limits at the motor flange and motor shaft must be
higher than the temperatures generated by the pump.
▪Contact the manufacturer for the actual pump temperatures.
2.9.3 Monitoring equipment
The pump (set) must only be operated within the limits specified in the data sheet
and on the name plate.
If the system operator cannot warrant compliance with these operating limits,
appropriate monitoring devices must be used.
Check whether monitoring equipment is required to ensure that the pump set
functions properly.
In a potentially explosive atmosphere the pump sets must be equipped with a
pressure relief valve. If the pump has not been fitted by the manufacturer with a
pressure relief valve, the operator must fit the pump with a pressure relief valve (e.g.
bypass valve) on site.
Contact KSB for further information on monitoring equipment.

3 Transport/Temporary Storage/Disposal
12 of 116 Vitalobe
3 Transport/Temporary Storage/Disposal
3.1 Checking the condition upon delivery
1. On transfer of goods, check each packaging unit for damage.
2. In the event of in-transit damage, assess the exact damage, document it and
notify KSB or the supplying dealer and the insurer about the damage in writing
immediately.
3.2 Transport
DANGER
The pump (set) could slip out of the suspension arrangement
Danger to life from falling parts!
▷Always transport the pump (set) in the specified position.
▷Never attach the suspension arrangement to the free shaft end or the motor
eyebolt.
▷Observe the information about weights, centre of gravity and fastening points.
▷Observe the applicable local accident prevention regulations.
▷Use suitable, permitted lifting accessories, e.g. self-tightening lifting tongs.
To transport the pump/pump set suspend it from the lifting tackle as shown.
The motor shroud, if fitted, must be removed before transporting the pump set.
Fig.1: Transporting the pump
Fig.2: Transporting the pump set

3 Transport/Temporary Storage/Disposal
13 of 116
Vitalobe
Fig.3: Lifting the pump
3.3 Storage/preservation
If commissioning is to take place some time after delivery, we recommend that the
following measures be taken for pump (set) storage.
CAUTION
Damage during storage due to humidity, dirt or vermin
Corrosion/contamination of the pump (set)!
▷For outdoor storage cover the pump (set) or the packaged pump (set) and
accessories with waterproof material.
CAUTION
Wet, contaminated or damaged openings and connections
Leakage or damage to the pump!
▷Clean and cover pump openings and connections as required prior to putting
the pump into storage.
Store the pump (set) in a dry, protected room where the atmospheric humidity is as
constant as possible.
Rotate the shaft by hand once a month, e.g. via the motor fan.
If properly stored indoors, the equipment is protected for a maximum of 12months.
New pumps/pump sets are supplied by our factory duly prepared for storage.
For storage periods of longer than 60days protect the coupling surfaces with a
suitable preservative.
For storing a pump (set) which has already been operated, observe the instructions
in (ðSection6.3.1,Page45) .

3 Transport/Temporary Storage/Disposal
14 of 116 Vitalobe
3.4 Return to supplier
1. Drain the pump as per operating instructions.
2. Flush and clean the pump, particularly if it has been used for handling noxious,
explosive, hot or other hazardous fluids.
3. If the pump has handled fluids whose residues could lead to corrosion damage
in the presence of atmospheric humidity or could ignite upon contact with
oxygen also neutralise the pump and blow through with anhydrous inert gas to
ensure drying.
4. Always complete and enclose a certificate of decontamination when returning
the pump.
Indicate any safety measures and decontamination measures taken.
(ðSection11,Page113)
NOTE
If required, a blank certificate of decontamination can be downloaded from the
following web site: www.ksb.com/certificate_of_decontamination
3.5 Disposal
WARNING
Fluids handled, consumables and supplies which are hot and/or pose a health
hazard
Hazard to persons and the environment!
▷Collect and properly dispose of flushing fluid and any fluid residues.
▷Wear safety clothing and a protective mask if required.
▷Observe all legal regulations on the disposal of fluids posing a health hazard.
1. Dismantle the pump (set).
Collect greases and other lubricants during dismantling.
2. Separate and sort the pump materials, e.g. by:
- Metals
- Plastics
- Electronic waste
- Greases and other lubricants
3. Dispose of materials in accordance with local regulations or in another
controlled manner.

4 Description of the Pump (Set)
15 of 116
Vitalobe
4 Description of the Pump (Set)
4.1 General description
▪Hygienic pump
Pump for handling fluids which are neither chemically aggressive nor abrasive and
which do not require hermetic sealing.
Fig.4: Installing the pump set
Pump in long-coupled design with coupling and geared motor with/without
frequency inverter. Horizontal or vertical connection nozzles. Drive ratings from 1 to
90kW.
Shaft seal
Designs:
▪G: External, single mechanical seal without flushing system
▪VG: External, single mechanical seal with flushing system
▪L: Shaft seal ring
▪Q: Double mechanical seal in back-to-back arrangement
4.2 Designation
Table5: Designation example
Position
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
V L B 1 0 0 / 0 4 0 2 G D B Y 3 1 A E C C S P P H S A
See name plate and data sheet
Table6: Designation key
Position Code Description
1-4 Pump type
VLB Vitalobe B
VLBB Vitalobe BB
5-8 Size, e.g.
100/ Rotor diameter [mm]
... ...
550/ Rotor diameter [mm] Vitalobe B
660/ Rotor diameter [mm] Vitalobe B
680/ Rotor diameter [mm] Vitalobe B
9-11 Motor rating PN [kW]
007 0,70
... ...
550 55,00
12 Number of motor poles
13 Scope of supply
G Baseplate

4 Description of the Pump (Set)
16 of 116 Vitalobe
Position Code Description
13 V Trolley
14-15 Shaft seal type
DB Double mechanical seal, external, in back-to-back arrangement
J Single mechanical seal, external
JY Single mechanical seal, external flushing system (quench)
L Lip seal
16-18 Seal code, single mechanical seal
Y31 BGEFG
Y32 BGVFG
Y34 BGMFG
Y41 BU3EFG
Y42 BU3VFG
Y44 BU3MFG
Y51 U3U3EFG
Y52 U3U3VFG
Y54 U3U3MFG
Seal code, double mechanical seal in back-to-back arrangement
Q31 GBEFG Vitalobe B
GBEFG Vitalobe B
Q32 GBVFG Vitalobe B
GBVFG Vitalobe B
Q34 GBMFG Vitalobe B
GBMFG Vitalobe B
Q41 U3BEFG Vitalobe B
U3BEFG Vitalobe B
Q42 U3BVFG Vitalobe B
U3BVFG Vitalobe B
Q44 U3BMFG Vitalobe B
U3BMFG Vitalobe B
Q51 U3U3EFG Vitalobe B
U3U3EFG Vitalobe B
Q52 U3U3VFG Vitalobe B
U3U3VFG Vitalobe B
Q54 U3U3MFG Vitalobe B
U3U3MFG Vitalobe B
Seal code, lip seal
HN S.S./PTFE Vitalobe B / VitalobeBB
S1 H-ECOPUR FDA Vitalobe B
S16 H-ECOPUR FDA Vitalobe BB
UM FKM Vitalobe B
19 Pipe connection
A Flange APV
B Thread DIN 11864-1A
C Flange DIN 11864-2A
D Clamped connection DIN 11864-3A
E Thread DIN 11853
F Thread RJT
G Flange Varivent
I Thread ISO 2853 (IDF)

4 Description of the Pump (Set)
17 of 116
Vitalobe
Position Code Description
19 L Flange EN 1092-1
M Thread DIN 11851 (hygienic pipe union)
S Thread SMS
T Clamped connection DIN 32676-A
U Clamped connection DIN32676-C (Tri-Clamp)
V Clamped connection ISO 2852
Z Flange ANSI B16.5 Class 150
20 O-ring material (casing/impeller)
E EPDM
F FFKM (Kaflon)
K FFKM (Kalrez)
M FEP (encapsulated)
T PTFE (Viton core)
V FKM
21 Pump casing material
C Stainless steel 1.4409
D Super duplex stainless steel 1.4469/ 1.4410
M Monel 400 2.4360
T Titanium B348 GR5
X Hastelloy C276 2.4819
22 Rotor material
C Stainless steel 1.4409
D Super duplex stainless steel 1.4469/ 1.4410
E EPDM-coated (core 1.4404) -
F Stainless steel sliding alloy ASTM A494 CY5SNBIM
M Monel 400 2.4360
N NBR -
T Titanium B348 GR5
X Hastelloy C276 2.4819
23 Motor shroud
S With shroud
O Without shroud
24 Drain
P Casing drain via piping
V Casing drain via valve
D Casing drain with plug
O No drain
25 Safety valve
B By-pass
O Without safety valve
P Pneumatic safety valve
V Mechanical safety valve
26 Position of nozzles
H Horizontal
V Vertical
27 Design
S Standard
X Non-standard (BT3D, BT3)
28 Product generation

4 Description of the Pump (Set)
18 of 116 Vitalobe
Position Code Description
28 A Vitalobe
4.3 Name plate
BB 440/022 4 KHTGM
9971234567 000100 / 01
Q (m /h)
3 H (m)
1
2
4
3
8
7
6
Vitalobe Year 16
Ord.Nr.
S/Nr. Item.
n (1/min)
5
L024882 1
10 120 300
Johann-Klein-Straße 9
Deutschland
67227 Frankenthal
KSB SE & Co. KGaA
Fig.5: Name plate (example)
1 Pump type, type series, size,
version
2 KSB order number
3 Serial No. 4 Flow rate
5 Year of construction 6 Item number
7 Head 8 Speed
4.4 Design details
Design
▪Standard design with materials to Regulation (EC) No.1935/20042)
▪Design to ATEX
Design
▪Hygienic rotary lobe pump
▪Long-coupled design
▪In-line design
▪Wetted parts made of stainless steel 1.4404/1.4409 (AISI316L/CF3M)
▪Cleanability levels 1+2 to EN13951 for Vitalobe designB
▪Cleanability levels 3+4 to EN13951 for Vitalobe designBB
Pump casing
▪Rotor casing
Impeller type
▪Tri-lobe, bi-lobe, gear-shaped or bi-wing rotor
Bearings
▪Size 100: deep groove ball bearing and needle bearing
▪Sizes 105 to 115: tapered roller bearings
▪Sizes 215 to 490: double tapered roller bearings
▪Sizes 550 to 680: cylindrical roller bearing and two-row deep groove ball bearings
Shaft seal
▪Single mechanical seals with or without flushing system to EN12756
▪Double mechanical seals to EN12756
2) Only for Vitalobe design BB

4 Description of the Pump (Set)
19 of 116
Vitalobe
Different seal types
▪Seal type Y: external single mechanical seal, with or without flushing system
▪Seal type Q: external double mechanical seal in back-to-back arrangement
▪Seal type L: shaft seal ring, single or double
Clearance
▪The rotors rotate in the casing without touching each other.
The clearances depend on the application.
▪Standard clearance for minimum leakage flow and best hydraulic efficiency
▪Enlarged clearance for high pressures or high temperatures
Drive
Speed and torque of the motor are adjusted to the values required for the pump by
means of a gear unit.
▪Surface-cooled KSB squirrel-cage motor
▪Type of construction B5, V1
▪Thermal class F
▪3 PTC thermistors
▪Duty cycle: continuous duty S1
▪Winding 50Hz, 220-240V/ 380-420V≤2.20kW; 380-420V/ 660-
725V≥3.00kW
Connections
▪Axial suction nozzle, tangential discharge nozzle
▪Adjustable through 360°
Types of connection:
▪Threaded connection to DIN11851 (hygienic pipe union)
▪Threaded connection to DIN11853
▪Threaded connection to DIN11864-1-GS-A
▪Threaded connection to SMS standard
▪Threaded connection to ISO2853 (IDF)
▪Threaded connection to RJT standard
▪Clamped connection to DIN32676-C (Tri-Clamp/Tri-Clover fitting)
▪Clamped connection to DIN11864-3-NKS-A
▪Clamped connection to DIN32676-A
▪Clamped connection to ISO2852
▪Flange to EN1092-1
▪Flange to DIN11864-2-NF-A
▪Flange to ANSI B16.5 Class 150
▪APV flange
▪Varivent flange
▪Other connection types on request

4 Description of the Pump (Set)
20 of 116 Vitalobe
4.5 Configuration and function
1 2 34 5 6789
10
11
12
1314
Fig.6: Sectional drawing
1 Suction nozzle 2 Pump casing / cover
3 Impeller (tri-lobe) 4 Impeller screw
5 Mechanical seal 6 Drive shafts
7 Bearings 8 Oil filler plug
9 Driving shaft 10 Spur gearing
11 Bearing bracket 12 Cover plate
13 Foot 14 Discharge nozzle
Design The pump is designed with a radial fluid inlet and outlet in either horizontal or
vertical position. The hydraulic system is connected to the motor by a shaft coupling.
Normally, frequency inverter controlled geared motors are used. The pump and the
motor are mounted on a common baseplate.
Design standard The Vitalobe pump series is available in two design standards, which only differ in
the pump head design. The bearing bracket and gears are identical.
Design standardB: available for sizes 100-680; non-countersunk rotor screws,
confined O-rings
Design standardBB: available for sizes 100-490; counter-sunk rotor screws, flush
mounted O-rings
Function The fluid is pumped by two counter-rotating impellers (3) with intermeshing rotary
lobes inside the pump casing (2). Each impeller (3) is mounted on a shaft (6) by means
of a screw (4). The shafts run in bearings located in the bearing housing (11). Shaft
rotation is synchronised via spur gears (10), which transfer the torque of the driving
shaft (9) to the driven shaft. The impellers (3) inside the casing (2) are synchronised
such that they do not contact each other. As soon as the impeller lobes disengage,
the increasing volume between the lobes creates a vacuum on the suction side,
drawing the fluid through the suction nozzle (1) into the pump casing. The fluid is
trapped in the space between the impellers (between the lobes) and transported
through the rotor casing to the pump's discharge nozzle (14). As soon as the
impellers re-engage, the volume between them decreases, the pressure at the
discharge (14) increases, and the fluid is forced out of the pump casing. The pump set
