ASD ASD-FLSL-20N50A-WH User manual

E-mail: [email protected]
ASD LIGHTING CORP
Web site: www.asd-lighting.com
For most up-to-date spec sheets please refer to asd-lighting.com
English
LED SLIM FLOODLIGHT
Model Watts Voltage Dimmable Lumens CCT Finish Dimensions (LxWxH) Cord Bracket
FLSL-A ARM
ASD-FLSL-20N50A-WH 20W 120 V - 2,040 lm 5,000 K White 6-5/8" x 4-13/16" x 1-5/8"  Arm
ASD-FLSL-20N50A-BZ 20W 120 V - 2,040 lm 5,000 K Bronze 6-5/8" x 4-13/16" x 1-5/8"  Arm
ASD-FLSL-20N50A-BZ-2PACK 20W 120 V - 2,040 lm 5,000 K Bronze 6-5/8" x 4-13/16" x 1-5/8"  Arm
ASD-FLSL-20N50A-BK 20W 120 V - 2,040 lm 5,000 K Black 6-5/8" x 4-13/16" x 1-5/8"  Arm
ASD-FLSL-30N30A-WH 30W 120 V - 3,056 lm 3,000 K White 7-1/4" x 5-13/16" x 1-11/16"  Arm
ASD-FLSL-30N30A-BZ 30W 120 V - 3,056 lm 3,000 K Bronze 7-1/4" x 5-13/16" x 1-11/16"  Arm
ASD-FLSL-30N30A-BK 30W 120 V - 3,056 lm 3,000 K Black 7-1/4" x 5-13/16" x 1-11/16"  Arm
ASD-FLSL-30N50A-WH 30W 120 V - 3,056 lm 5,000 K White 7-1/4" x 5-13/16" x 1-11/16"  Arm
ASD-FLSL-30N50A-BZ 30W 120 V - 3,056 lm 5,000 K Bronze 7-1/4" x 5-13/16" x 1-11/16"  Arm
ASD-FLSL-30N50A-BK 30W 120 V - 3,056 lm 5,000 K Black 7-1/4" x 5-13/16" x 1-11/16"  Arm
ASD-FLSL-30N50A-BK-2PACK 30W 120 V - 3,056 lm 5,000 K Black 7-1/4" x 5-13/16" x 1-11/16"  Arm
ASD-FLSL-50N30A-WH 50W 120 V - 5,100 lm 3,000 K White 9-1/16" x 8-1/16" x 1-3/4"  Arm
ASD-FLSL-50N30A-BZ 50W 120 V - 5,100 lm 3,000 K Bronze 9-1/16" x 8-1/16" x 1-3/4"  Arm
ASD-FLSL-50N30A-BK 50W 120 V - 5,100 lm 3,000 K Black 9-1/16" x 8-1/16" x 1-3/4"  Arm
ASD-FLSL-50N50A-WH 50W 120 V - 5,100 lm 5,000 K White 9-1/16" x 8-1/16" x 1-3/4"  Arm
ASD-FLSL-50N50A-BZ 50W 120 V - 5,100 lm 5,000 K Bronze 9-1/16" x 8-1/16" x 1-3/4"  Arm
ASD-FLSL-50N50A-BZ-2PACK 50W 120 V - 5,100 lm 5,000 K Bronze 9-1/16" x 8-1/16" x 1-3/4"  Arm
ASD-FLSL-50N50A-BK 50W 120 V - 5,100 lm 5,000 K Black 9-1/16" x 8-1/16" x 1-3/4"  Arm
FLSL-Y YOKE
ASD-FLSL-50N50Y-BZ 50W 120 V - 5,100 lm 5,000 K Bronze 8-1/4" x 6-13/16" x 1-5/16"  Yoke
ASD-FLSL-50N50Y-BK 50W 120 V - 5,100 lm 5,000 K Black 8-1/4" x 6-13/16" x 1-5/16"  Yoke
ASD-FLSL-100N50Y-BZ 100W 120 V - 10,200 lm 5,000 K Bronze 12-7/8" x 9-13/16" x 1-9/16"  Yoke
ASD-FLSL-100N50Y-BK 100W 120 V - 10,200 lm 5,000 K Black 12-7/8" x 9-13/16" x 1-9/16"  Yoke
ASD-FLSL-100N50Y-BK-2PACK 100W 120 V - 10,200 lm 5,000 K Black 12-7/8" x 9-13/16" x 1-9/16"  Yoke
ASD-FLSL-150N50Y-BZ 150W 120 V - 15,868 lm 5,000 K Bronze 14-15/16" x 11-5/8" x 1-9/16"  Yoke
ASD-FLSL-150N50Y-BK 150W 120 V - 15,868 lm 5,000 K Black 14-15/16" x 11-5/8" x 1-9/16"  Yoke
ASD-FLSL-200N50Y-BZ 200W 120 V - 21,404 lm 5,000 K Bronze 16-7/16" x 13-1/8" x 1-5/8"  Yoke
ASD-FLSL-200N50Y-BK 200W 120 V - 21,404 lm 5,000 K Black 16-7/16" x 13-1/8" x 1-5/8"  Yoke
DESIGN


         
illuminance.
INSTALLATION




APPLICATION
        


ADVANTAGES

          

BronzeFinish:
Black
White
Catalog number
Notes
Type

E-mail: [email protected]
ASD LIGHTING CORP
Web site: www.asd-lighting.com
For most up-to-date spec sheets please refer to asd-lighting.com
English
LED SLIM FLOODLIGHT
PRODUCT SPECIFICATIONS:
Construction & Materials
Housing Aluminum
Lens 
Finish White, Bronze, Black
Weight
ASD-FLSL-20N50A-WH  ASD-FLSL-30N50A-BK  ASD-FLSL-50N50Y-BZ 
ASD-FLSL-20N50A-BZ ASD-FLSL-30N50A-BK-2PACK  ASD-FLSL-50N50Y-BK
ASD-FLSL-20N50A-BZ-2PACK  ASD-FLSL-50N30A-WH

ASD-FLSL-100N50Y-BZ 
ASD-FLSL-20N50A-BK  ASD-FLSL-50N30A-BZ ASD-FLSL-100N50Y-BK
ASD-FLSL-30N30A-WH

ASD-FLSL-50N30A-BK ASD-FLSL-100N50Y-BK-2PACK 
ASD-FLSL-30N30A-BZ ASD-FLSL-50N50A-WH ASD-FLSL-150N50Y-BZ 
ASD-FLSL-30N30A-BK ASD-FLSL-50N50A-BZ ASD-FLSL-150N50Y-BK
ASD-FLSL-30N50A-WH ASD-FLSL-50N50A-BZ-2PACK  ASD-FLSL-200N50Y-BZ 
ASD-FLSL-30N50A-BZ ASD-FLSL-50N50A-BK  ASD-FLSL-200N50Y-BK
Optical system

ASD-FLSL-20N50A-WH
2,040 lm
ASD-FLSL-30N50A-BK 3,056 lm ASD-FLSL-50N50Y-BZ 5,100 lm
ASD-FLSL-20N50A-BZ ASD-FLSL-30N50A-BK-2PACK ASD-FLSL-50N50Y-BK
ASD-FLSL-20N50A-BZ-2PACK ASD-FLSL-50N30A-WH
5,100 lm
ASD-FLSL-100N50Y-BZ
10,200 lmASD-FLSL-20N50A-BK ASD-FLSL-50N30A-BZ ASD-FLSL-100N50Y-BK
ASD-FLSL-30N30A-WH
3,056 lm
ASD-FLSL-50N30A-BK ASD-FLSL-100N50Y-BK-2PACK
ASD-FLSL-30N30A-BZ ASD-FLSL-50N50A-WH ASD-FLSL-150N50Y-BZ 15,868 lm
ASD-FLSL-30N30A-BK ASD-FLSL-50N50A-BZ ASD-FLSL-150N50Y-BK
ASD-FLSL-30N50A-WH ASD-FLSL-50N50A-BZ-2PACK ASD-FLSL-200N50Y-BZ 21,404 lm
ASD-FLSL-30N50A-BZ ASD-FLSL-50N50A-BK ASD-FLSL-200N50Y-BK
 3,000K; 5,000 K
CRI > 70
Environmental system
Work environment 
 
 R > 36,000 hrs; C > 97,000 hrs
Electrical system
 120 V

ASD-FLSL-20N50A-WH
0.18 A
ASD-FLSL-30N50A-BK
0.27 A
ASD-FLSL-50N50Y-BZ 0.5 A
ASD-FLSL-20N50A-BZ ASD-FLSL-30N50A-BK-2PACK ASD-FLSL-50N50Y-BK
ASD-FLSL-20N50A-BZ-2PACK ASD-FLSL-50N30A-WH ASD-FLSL-100N50Y-BZ
0.9 AASD-FLSL-20N50A-BK ASD-FLSL-50N30A-BZ ASD-FLSL-100N50Y-BK
ASD-FLSL-30N30A-WH
0.27 A
ASD-FLSL-50N30A-BK ASD-FLSL-100N50Y-BK-2PACK
ASD-FLSL-30N30A-BZ ASD-FLSL-50N50A-WH ASD-FLSL-150N50Y-BZ 1.37 A
ASD-FLSL-30N30A-BK ASD-FLSL-50N50A-BZ ASD-FLSL-150N50Y-BK
ASD-FLSL-30N50A-WH ASD-FLSL-50N50A-BZ-2PACK ASD-FLSL-200N50Y-BZ 1.82 A
ASD-FLSL-30N50A-BZ ASD-FLSL-50N50A-BK ASD-FLSL-200N50Y-BK
 0W

ASD-FLSL-20N50A-WH
20W
ASD-FLSL-30N50A-BK 30W ASD-FLSL-50N50Y-BZ 50W
ASD-FLSL-20N50A-BZ ASD-FLSL-30N50A-BK-2PACK ASD-FLSL-50N50Y-BK
ASD-FLSL-20N50A-BZ-2PACK ASD-FLSL-50N30A-WH
50W
ASD-FLSL-100N50Y-BZ
100WASD-FLSL-20N50A-BK ASD-FLSL-50N30A-BZ ASD-FLSL-100N50Y-BK
ASD-FLSL-30N30A-WH
30W
ASD-FLSL-50N30A-BK ASD-FLSL-100N50Y-BK-2PACK
ASD-FLSL-30N30A-BZ ASD-FLSL-50N50A-WH ASD-FLSL-150N50Y-BZ 150W
ASD-FLSL-30N30A-BK ASD-FLSL-50N50A-BZ ASD-FLSL-150N50Y-BK
ASD-FLSL-30N50A-WH ASD-FLSL-50N50A-BZ-2PACK ASD-FLSL-200N50Y-BZ 200W
ASD-FLSL-30N50A-BZ ASD-FLSL-50N50A-BK ASD-FLSL-200N50Y-BK
 > 0.9
 270 V 

ASD-FLSL-20N50A-WH
0.072 A
ASD-FLSL-30N50A-BK 0.1 A ASD-FLSL-50N50Y-BZ 0.167 A
ASD-FLSL-20N50A-BZ ASD-FLSL-30N50A-BK-2PACK ASD-FLSL-50N50Y-BK
ASD-FLSL-20N50A-BZ-2PACK ASD-FLSL-50N30A-WH
0.167 A
ASD-FLSL-100N50Y-BZ
0.334 AASD-FLSL-20N50A-BK ASD-FLSL-50N30A-BZ ASD-FLSL-100N50Y-BK
ASD-FLSL-30N30A-WH
0.1 A
ASD-FLSL-50N30A-BK ASD-FLSL-100N50Y-BK-2PACK
ASD-FLSL-30N30A-BZ ASD-FLSL-50N50A-WH ASD-FLSL-150N50Y-BZ 0.5 A
ASD-FLSL-30N30A-BK ASD-FLSL-50N50A-BZ ASD-FLSL-150N50Y-BK
ASD-FLSL-30N50A-WH ASD-FLSL-50N50A-BZ-2PACK ASD-FLSL-200N50Y-BZ 0.667 A
ASD-FLSL-30N50A-BZ ASD-FLSL-50N50A-BK ASD-FLSL-200N50Y-BK
 1 kV / 2 kV 

E-mail: [email protected]
ASD LIGHTING CORP
Web site: www.asd-lighting.com
For most up-to-date spec sheets please refer to asd-lighting.com
English
LED SLIM FLOODLIGHT
L
N
G
Power
connector
Ground connect green
120 V
L (live/hot) connect black
N (neutral) connect white
FIXTURE
L
NDRIVER
G
1.

2. Pole installation:


3. J-box installation:


MODELS WITH ARM INSTALLATION STEPS:
12
POLE
MOUNTING
WALL
MOUNTING
3
1.
2. 

3. 

MODELS ON YOKE INSTALLATION STEPS:
123
ELECTRICAL SCHEMATIC DIAGRAM:
INSTALLATION GUIDE
IMPORTANT SAFETY INFORMATION:
Please read all the instructions below before installation.




WARNING
RISK OF PERSONAL INJURY – READ and follow all WARNINGS and
installation instructions.
Risk of cuts:          

Risk of electric shock:       
          

Risk of Fire:



Regular and voluntary certications


PACKAGE CONTENTS:
Description Q-ty
 
 3
Box 1
A

E-mail: [email protected]
ASD LIGHTING CORP
Web site: www.asd-lighting.com
For most up-to-date spec sheets please refer to asd-lighting.com
English
LED SLIM FLOODLIGHT
ORDERING INFORMATION
Model UPC Pcs. per carton Carton size Carton weight GTIN 14
FLSL-A ARM
ASD-FLSL-20N50A-WH 819201027163 10 10.1" x 9.3" x 7.3"  30819201027164
ASD-FLSL-20N50A-BZ 810050731911 10 10.1" x 9.3" x 7.3"  30810050731912
ASD-FLSL-20N50A-BZ-2PACK 810128112062 18.5" x 6.9" x 5.5"  10810128112069
ASD-FLSL-20N50A-BK 819201027125 10 10.1" x 9.3" x 7.3"  30819201027126
ASD-FLSL-30N30A-WH 819201027194 10 12" x 9.4" x 7.9"  30819201027195
ASD-FLSL-30N30A-BZ 810050731928 10 12" x 9.4" x 7.9"  40810050731926
ASD-FLSL-30N30A-BK 819201027187 10 12" x 9.4" x 7.9"  40819201027185
ASD-FLSL-30N50A-WH 819201027200 10 12" x 9.4" x 7.9"  30819201027201
ASD-FLSL-30N50A-BZ 810050731935 10 12" x 9.4" x 7.9"  30810050731936
ASD-FLSL-30N50A-BK 819201027170 10 12" x 9.4" x 7.9"  30819201027171
ASD-FLSL-30N50A-BK-2PACK 810128112079 18.9" x 7.5" x 6.5"  10810128112076
ASD-FLSL-50N30A-WH 819201027224 10 18.5" x 10.2" x 8.7"  30819201027225
ASD-FLSL-50N30A-BZ 810050731942 10 18.5" x 10.2" x 8.7"  30810050731943
ASD-FLSL-50N30A-BK 819201027217 10 18.5" x 10.2" x 8.7"  30819201027218
ASD-FLSL-50N50A-WH 819201027248 10 18.5" x 10.2" x 8.7"  30819201027249
ASD-FLSL-50N50A-BZ 810050731959 10 18.5" x 10.2" x 8.7"  30810050731950
ASD-FLSL-50N50A-BZ-2PACK 810128112086 19.9" x 9.3" x 8.7"  10810128112083
ASD-FLSL-50N50A-BK 819201027231 10 18.5" x 10.2" x 8.7"  30819201027232
FLSL-Y YOKE
ASD-FLSL-50N50Y-BZ 810050731966 10 15.4" x 8.7" x 7.5"  30810050731967
ASD-FLSL-50N50Y-BK 819201027255 10 15.4" x 8.7" x 7.5"  40819201027253
ASD-FLSL-100N50Y-BZ 810050731973 4 13.2" x 10.3" x 7.3"  30810050731974
ASD-FLSL-100N50Y-BK 819201027279 13.2" x 10.3" x 7.3"  40819201027277
ASD-FLSL-100N50Y-BK-2PACK 810128112093 13.2" x 10.2" x 7.5"  10810128112090
ASD-FLSL-150N50Y-BZ 810050731980 4 15.2" x 12.1" x 7.3"  40810050731988
ASD-FLSL-150N50Y-BK 819201027293 4 15.2" x 12.1" x 7.3"  30819201027294
ASD-FLSL-200N50Y-BZ 810050731997 4 16.7" x 13.7" x 7.5"  30810050731998
ASD-FLSL-200N50Y-BK 819201027309 4 16.7" x 13.7" x 7.5"  30819201027300
