Soltech Cosmo 20W User manual

01
COSMO
Flood Lights
20W 50W
Installation Manual
SOLTECH Provides Advanced LED
Technology Powered With Eco-friendly,
Clean, Solar Energy.

02 03
01 Introduction 02 Specification
Thank you for purchasing COSMO Urban Lighting Products.
Important
Please read these instructions before installation to ensure optimum results
and longevity of your lights. The solar panel should be charged in full
sunlight for 8 to 9 hours before initial first use to provide optimum results.
Features
• Adjusting the solar panel angle maximizes solar collection & allows
snow to slide off.
• The solar flood light has a separate solar panel to collect energy
from the sun.
• (IAP) Intelligent Adaptive Program Battery Control Technology
that stays lit all night, even through cloudy or rainy days.
• The light can be used separately from the solar panel for both
indoor and outdoor uses
• Use outdoor as a flag pole light, sign light, billboard light, or wall pack
• Use indoor as bus stop & shelter lighting
• 6 operating modes for indoor and outdoor use
• Remote control can adjust brightness and set the timer
• LED Indicators show 3 levels power storage
• The easiest way to bring lighting to both indoor and outdoor applications
Activation
Press and Hold the button located in the image
to the right to activate the light.
The battery indicator light will display as follows:
GREEN : >70% Battery Life
ORANGE: 30%–70% Battery Life
RED: 10%–30% Battery Life
*Please note that you must connect the light to the solar panel before
usage, otherwise the light will not turn on. After charging the light in
bright sunlight for at least 48 hours before first time usage, press
the Activation button. This will now allow the light to turn on when
it senses darkness and turns off when it senses sufficient lighting. The
sensor is located within the solar charging panel.
COSMO 20W COSMO 50W
3.1 inches
7.1 inches
8.0 inches
7.2 inches
4.1 inches
3.1 inches13.0 inches
4.1 inches
6 Operating Modes 6 Operating Modes
20W
COSMO 20W
50W
COSMO 50W
Mono-Crystalline Silicon 14V 5W Mono-Crystalline Silicon 14V 10W
28.86WH 3.7V 2.6AH 57.72WH 3.7V 2.6AH
3,000 6,000
PC & Aluminum PC & Aluminum
150 lm/W 120 lm/W
7.5 hrs (1000W/m2)7.5 hrs (1000W/m2)
12–14 Hours 12–14 Hours
-4 °F to 140 °F -4 °F to 140 °F
32 °F to 113°F 32 °F to 113°F
LED Nominal Power
Specifications
Solar Panel
Lithium Ion Battery
CCT
Lumen Output@4,000K
IP65
13.1 ft
IP65
13.1 ft
LED
EPA
Waterproof Rate
Cable Length
> 70 > 70
Solar Panel 8.0 X 7.1 Inches
Light 7.2 X 4.1 X 3.1 Inches
Solar Panel 15.0 X 7.3 Inches
Light 13.0 X 4.1 X3.1 Inches
OSRAM 3030
0.67 ft 1.28 ft
OSRAM 3030
4,000K 4,000K
CRI
Casting
Efficiency@4,000K
Product Size
* Charging Time
Run Time (@Full Power)
Operation Mode
* Operating Temperature
* Charging Temperature
* The temperature can impact the battery’s charging and normal operation. * The solar charge time data is base on 77 degree F ambient temperature with the
panel pointed directly at the solar radiation. The standard radiation value is 1000W/m2.
- - - -
Ordering Information Chart
STL-SWL=COSMO
SERIES WATTAGE COLOR
TEMPERATURE
MOUNTING
OPTIONS FINISH
20=20W
50=50W
4=4,000K
5=5,000K
WM=WALL MOUNT BK=BLACK
7.3 inches
15.0 inches

04 05
03 Installation
WALL MOUNT
Connect
1. Attach the bracket on the
wall, then screw the solar panel
onto the bracket.
2. Screw the bracket onto the
fixture housing and mount it
onto the wall.
3. Connect the light and solar
panel cables.
Package Contents
1. Lamp (with bracket)
2. Solar Panel
3. Bracket for Solar Panel
4. Remote Control
5. Expansion pillar-hinge (4pcs)
6. Small Gasket (4 pcs)
7. Screw PA4*25 (4 pcs)
8. Large Gasket (2 pcs)
9. Screw M5*16 (2 pcs)
Additonal Notes
1. Prior to activation, allow for at least 48 hours of charging time
in bright sunlight for the battery to be sufficiently charged.
2. Install the solar panel where it will receive optimal sunlight without
any obstructions. If you are using this solar light in extreme
conditionsabove 131° Fahrenheit or below 32° Fahrenheit, the battery
an solar charging panel will functionless optimally as it gets colder.
3. When using the solar light in less than optimal conditions (cloudy,
or not much direct sunlight), it may take longer to fully charge
the battery.
OPERATING MODES
LIGHTING MODE INDICATOR
Red: M1
Green: M2
Orange: M3
T: Green Light Flashes
BATTERY CAPACITY INDICATOR
Green: >70%
Orange: 30%–70%
Red: 10%–30%
Note: The fixture is in low
voltage protection status when
the red light flashes.
Warning
1. Keep device away from fire and oil to avoid explosion.
2. Severe shock to Solar powered light is to be avoided.
3. Do not disassemble the light without assistance from an expert.
20W 50W
50% 5Hrs + 10% Till Dawn
30% 5Hrs + 10% Till Dawn
20% Till Dawn
M1
M2
M3
100% 2Hrs + 50% 5Hrs +
10% Till Dawn
+
100% 2Hrs + 30% 5Hrs +
10% Till Dawn
+
100% 2Hrs + 20%
Till Dawn
+
M1
M2
M3
T
T
T
50% 5Hrs + 10% Till Dawn
30% 5Hrs + 10% Till Dawn
20% Till Dawn
M1
M2
M3
100% 2Hrs + 50% 5Hrs +
10% Till Dawn
+
100% 2Hrs + 30% 5Hrs +
10% Till Dawn
+
100% 2Hrs + 20%
Till Dawn
+
M1
M2
M3
T
T
T

06 07
04 Luminous Distribution 05 Warranty
COSMO is covered by a 3 year limited warranty. COSMO
urban light warrants to the original purchaser that this
product is free from defects in materials and workmanship
for the period of 3 years from date of purchase. To obtain
warranty service please contact your local distributor or sales
rep for further instruction.
COSMO 20W
COSMO 50W
0
30
60
90
120
150
-/+180
-150
-120
-90
-60
-30
0
80
160
240
320
400
0
30
60
90
120
150
-/+180
-150
-120
-90
-60
-30
0
80
160
240
320
400
SOLTECH Provides
Advanced LED
Technology Powered
With Eco-friendly,
Clean, Solar Energy.

08
Copyright©2021–2022 SOLTECH LLC,
All Rights Reserved.
SOLTECH LLC reserves the right to update all
product data sheets at any time. Consult SOLTECH
marketing specialists for publication updates at
[email protected]
1460 Park Avenue.
Emeryville, CA 94608 USA
www.soltechlighting.com
