Aseko ASIN Aqua NET REDOX User manual

Aseko Pool Technology
EN
asekopool.com
ASIN Aqua®NET

2ASIN Aqua NET
ASIN Aqua

3
ASIN Aqua NET
ENG
USER’S MANUAL
ASIN Aqua NET REDOX
# 12035
ASIN Aqua NET CLF
# 12036
ASIN Aqua NET DOSE
# 12034

4ASIN Aqua NET
Tube Weight 2 pc
Injection Valve 2 pc
PE Tube 1/4”
Water Valve 2 pc
ASIN Aqua
What you receive in your box
Sharp knife
Screws and dowels
pH probe
pH probe
Flowmeter
Filter
CLF chlorine free probe
CLF chlorine free probe
CLF chlorine free probe
Redox probe
Redox probe
Redox probe
Redox probe
or
or
or
or

EN
5
ASIN Aqua NET
Table of Contents
What you receive in your box
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
General safety information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6
About ASIN Aqua
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
Understanding ASIN Aqua
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9
Installing ASIN Aqua
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10
Step 1
Instaling the Probes
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12
Step 2
Connecting the measuring Water
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13
Step 3
Connecting the disinfection agent and pH agent Dosage Tubes
. . . . .
14
Step 4
Connecting the Power Supply
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15
Language setting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15
Testing ASIN Aqua Installation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16
Manual Dosing
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17
Set the parameters of your swimming pool
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17
pH Settings
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
pH Calibrating
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
Choose the function of Your ASIN Aqua
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20
1) Free chlorine probe CLF
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20
2) Redox probe RX
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22
3) Time dosing ml/m
3
per hour or per day
. . . . . . . . . . . . . . . . . . . . . . . . . . .
23
Safety functions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24
Maximal safety dose
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24
Too rapid pH change
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24
The pH change without probe response .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
24
ASIN Aqua NET
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25
Internet connection
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25
Pool Live . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
pool.aseko.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
External touch display
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28
Thermometer connection
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28
Thermometer calibration (ASIN Aqua NET)
. . . . . . . . . . . . . . . . . . . . . . . . . .
28
Maintaining ASIN Aqua
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
Spare part list
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
Pump Tube replacement
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
ASIN Aqua error messaging
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31

6ASIN Aqua NET
General safety information
This user manual has basic information that should be observed during assembly, start-up, operation, and maintenance. Therefore,
this user manual must be read by installers and operators prior to assembly and start/up, and must be accessible to every
user of this unit. Additionally, all further safety information in this document absolutely must be observed. Read and follow all
instructions. In order to minimise the danger of injury, do not allow children to use this product. Hazards from non-compliance
with safety information. Non-compliance with safety information can result in hazards to persons, the environment, and the
equipment. Non-compliance with safety information will result in a forfeit of any potential right to damage compensation.
Insufficient personnel qualification
Hazards in the event of insuciently qualied personnel,
potential consequence: Injury, heavy material damage.
•
The system operator must ensure compliance
with the required qualication level.
•
Any and all work may only be performed by
correspondingly qualied personnel.
•
Access to the system must be prevented for insuciently
qualied persons, e.g. via access codes and passwords.
Potential overdosing of chemical agents
Despite ASIN Aqua® comprehensive safety functions,
it is possible that a probe failure and other
errors could lead to an overdosing of chemical agents. Potential
consequence: Injury, heavy material damage.
•
Design your installation such that uncontrolled dosage is not possible in
the event of a probe failure or other errors, and/or such that uncontrolled
dosage is recognised and halted before damage is incurred.
•
Uncontrolled overdose of chemicals can cause harm to health and property.
Even though the device contains a number of security elements can not
be ruled out that in case of failure of the measuring probes, or the whole
device may result in overdose of chemical agents. Install the equipment
so that uncontrolled overdose of chemicals was not possible and that
uncontrolled overdose has been detected in time before causing any
harm. It is necessary to use chemicals in such quantities that an overdose
will not cause dangerous concentration of chemical agents. Do not use
chemicals in too large packages or with too high concentration.
Gaseous chlorine produced from dosing in standing
water if dosing outputs are not closed via the filter pump
If the ow switch is stuck or experiences another error, there is a risk
of dosing into standing water. Poisonous chlorine gas can be yielded
when sodium hypochlorite and pH minus come together.
Non-compliance with informational text
There is a great deal of informational text indicating hazards and their
avoidance. Not observing informational text may lead to hazards. Potential
consequence: gravest degree of injury, heavy material damage.
•
Read all informational text carefully.
•
Cancel the process if you are unable to exclude all potential hazards.

EN
7
ASIN Aqua NET
Use of new functions
Because of the continued development, a ASIN Aqua® unit may contain
functions, which are not completely described in this version of the user
manual. The use of such new or extended functions without a profound
and secure understanding by the operator may result in malfunctions and
severe problems. Potential consequence: Injury, heavy material damage.
•
Make sure to get a profound and secure understanding of a function
and relevant boundary conditions, before you start to use it.
•
Check for an updated version of the user manual or additional
documentation available for the relevant functions.
•
Make use of the integrated help function of the ASIN Aqua® to get
detailed information on functions and their parameter settings.
•
In case it should not be possible to get a profound and secure understanding
of a function based on the available documentation, do not use this function.
Overdosing if pH value is wrong
If disinfection is enabled before the pH value is stable in the ideal
range of 7.0 to 7.4, then it may lead to heavy overdosing of chlorine or
bromine. Potential consequence: Injury, heavy material damage.
•
Do not start disinfection with chlorine or bromine until the pH
value is stable in the ideal range between 7.0 and 7.4.
Conditions before using
Make sure you have a newest and updated version of the user manual
and other documentation for all functions of the unit. Use and read the
integrated help features. In case of not understanding the information
about certain features of the unit, do not use these features.
Handling chemicals for pool water treatment.
The chemicals used with the ASIN Aqua must be handled in a safe manner
to prevent damage or personal harm. Aseko recommends you always
use personal protective safety equipment when handling the pH and
chlorine agents.
Refer to the Materials Safety Data Sheet (MSDS).
WARNING:
Never mix the pH agent with the chlorine agent. When
carrying out maintenance on the clear plastic tubes or valves always rinse
with clean water to prevent mixing of the pH and chlorine agents.

8ASIN Aqua NET
About ASIN Aqua
ASEKO’s ASIN Aqua gives you pool clean and sparkling water with theminimum
amount of chemicals. By directly measuring and controlling the free
chlorine content or redox potential of your pool water with advanced CLF
(free chlorine) or redox probe. ASIN Aqua tunes your pool water using the
minimum amount of chlorine, eliminating the smell and burning of over-
treated pools. With a touch screen interface, you have complete control over
measurement andregulation of your pool. ASINAqua operates with your
existing pool ltering equipment. ASIN Aqua works also on time dosing system
for chlorine-free oxygen based desinfection agent dosing as SANOSIL.
Power supply
230 V/ 50 Hz
Power consumption
14 VA
Fuse
T80 mA
Over-voltage category
II
Ingress protection
IP50
Operating temperature
and humidity
+5 to +40°C / 60%
Weight
2,2 kg
Emplacement
wall-mounted
Measured and regulated value
Free chlorine or Redox, pH
Pump power
60 ml/min. / max 1 bar
Measuring water pressure
max 1,5 bar

EN
9
ASIN Aqua NET
Understanding ASIN Aqua
Power supply
230 V/50 Hz
Lan connector
(NET version)
Cable for pH probe
pH probe housing
Redox / CLF probe
housing
Peristaltic pump
Peristaltic pump
for pH agent
for pH agent
Cable for Redox
or CLF probe
Peristaltic pump
Peristaltic pump
for desinfection agent
for desinfection agent
Tube ttingTube tting
Water INLET for
measuring water
Water INLET for
measuring water Water OUTLET Thermometer
connection (NET version)
Connector for
external display
(NET version)
Touchscreen display

10 ASIN Aqua NET
Installing ASIN Aqua
Install your ASIN Aqua in an environment free from dust and high humidity. Mount
your ASIN Aqua on the wall with at least 30 cm of free space around all sides.
Measure, mark and drill two holes
23 centimeters apart on your wall.
Use the screws included
with ASIN Aqua.
WARNING:
Do not expose
your ASIN Aqua to direct sunlight, damp or frost as these weather conditions
cause damage. ASIN Aqua functional temperature range is 5 – 40°C.
WARNING:

Ensure pool water is chemically clean and free from
dirt before installing your ASIN Aqua.

Do not install your ASIN Aqua more than 8 m away from the
connection of the chemical agents to your pool water supply.

Do not install your ASIN Aqua with more than a2 m vertical dierence between
the xed wall mounted position to the connection of the chemical agents.
30 cm
30 cm
30 cm
30 cm
23 cm
23 cm
ø 8 mm
ø 8 mm
40°C
max
5°C
min
max 8 m
max 2 m
RECOMMENDATION:
Change Your pool water for fresh one.

EN
11
ASIN Aqua NET
WASTE
WASTE
31,5 14
31,5
AIR °C
RH %
SETTINGS
750
REDOX
7,0
pH
ASIN Aqua
POOL WATER°C
OK
31,5
14
31,5
AIR °C
RH %
750
REDOX
7,0
pH
ASIN Aqua
POOL WATER°C
OK
SETTINGS
EXTERNAL TOUCH
DISPLAY
Water-filling
Heating Thermo-
meter
If you use automatic water-filling we
recommend you to install it AFTER the
measuring-water connection. If you connect
auto water-filling BEFORE measuring-water
connection you must TURN OFF
the ASIN Aqua.
Water supply
for the probes (IN)
Water
supply
Only hand tighten
the connections.
Do not use pliers
or wrench.
Water outlet from probes (OUT)
Water from the CLF probe
must led to no pressure.
For example to Buffer
tank, skimmer or waste.
Water from the
REDOX probe can be
connected before
filtration pump.
*)
CHLOR
pH-
For best results, we recommend
use of original ASEKO or similarly
based water treatment agents.
WARNING:
Use of hydrochloric acid based
agents isstrictly prohibited!
pH 20%
Chlor 13 – 17%
Drill a hole
in the lid
for the tube
Ø 1 mm
Ø 6,2 mm
RCD Current
protector
30 mA
230 V / 50 Hz
Internet LAN
*)

12 ASIN Aqua NET
Step 1
Instaling the Probes
The CLF or Redox probe housing is on the left. The pH probe housing
is on the right. These probes are used for the analysis of the content
ofthe water in your pool. The probes allow for the accurate detection
of acidity levels and the potential voltage within your pool water.
1.
Insert your CLF or Redox probe in the left side of your ASINAqua
and attach the cable using the screw t connector.
2.
Insert your pH probe in the right side of your ASIN Aqua
and attach the cable using the screw t connector.
After inserting the probes your ASIN Aqua is ready to be
connected to the water system of your pool.
WARNING:
Only hand tighten the connections. Do not use pliers or wrench.
CLF chlorine free probe
CLF chlorine free probe
or
Redox probe
pH probe
pH probe
REDOX probe
CLF probe
pH probe

EN
13
ASIN Aqua NET
Step 2
Connecting the measuring Water
ASIN Aqua requires connection to the water from your pool. Connect
the supply to your ASINAqua after the pump and before the lter.

Thread = G 1/4".
For the water connection to your ASIN Aqua, Aseko provides water
valve with aunique Speedt connector. To connect, push the clear
plastic tube into the Speedt connector. Toremove the tube from
the connector, push the collet in, and pull on the tube.
WARNING:
Using pliers or cutters damages
your hose and results in a poor tting.
1.
Cut your clear plastic tube at 90 degree
angleto ensure proper tting.

Use a sharp knife orrazorto cut the tubes cleanly
2.
Connect the water input on the left and the water output
on the right. Make sure the water pressure is not more than 1.5 bar.
3.
The water output from your ASIN Aqua can be connected, on the tubing
before the pump or to the skimmer, the buer tank or to a drain.
After connecting the water supply, your ASIN Aqua is then set up to take
samples of the water from your pool and analyze them. The analysis allows the
monitoring of chlorine levels and pH levels ensuring your pool hygiene.
WARNING:
Only hand tighten the connections.
Do not use pliers or wrench.
WASTE
WASTE
Water supply
for the probes (IN) Water outlet from probes (OUT)
Water from the CLF probe
must led to no pressure.
For example to Buffer
tank, skimmer or waste.
Water from the
REDOX probe can be
connected before
filtration pump.
*)
Water
supply
*)
Water valve
Thread 1/4”
Tube 6 x 1
Connection
Water and chemical
6 x 1 clear plastic tube
90°
Water valve
Disconnection

14 ASIN Aqua NET
Step 3
Connecting the disinfection agent
and pH agent Dosage Tubes
Connect the pH injection valve to the pool water pipe UPSTREAM from
the chlorine injection valve. This reduces limescale build up.
1.
Cut your clear plastic tube at 90 degree angleto ensure proper tting.

Use a sharp knife orrazorto cut the tubes cleanly.
2.
Make a 6 mm hole in the lid of your chlorine container and push through
enough clear plastic tube to reach the bottom of the container.

Extra tube in your container will bend and allow air bubbles into the system.
3.
Attach the tube weigh to the end of your clear plastic tube.
4.
Connect your clear plastic tube from the chlorine to the left
side of the chlorine pump of your ASIN Aqua.
5.
Connect your clear plastic tube from the right side ofyour
chlorine pump to your chlorine injection valve.

Thread = G 1/4”.
6.
Ensure your valves are not blocked or damaged and
connect to the water supply of the pool
7.
Repeat the steps for your pH dosage connection using the pump on the right side.
WARNING:
Only hand tighten the connections. Do not use pliers or wrench.
ASIN Aqua uses a regulated amount of the chemical agents for disinfection
and pH regulation ensuring optimal eciency and consumption.
WARNING:
Do NOT connect the pH to the chlorine pump, orthe chlorine to
the pH pump. In case of a crossed connection, after ten doses your ASINAqua
displays an ERROR warning. Press the red ERROR button to list the faults. Correct
the tube installation and then resume operation of your ASIN Aqua.
CHLORINE
pH-
Drill a hole
in the lid
for the tube
Ø 1 mm
Ø 6 mm

EN
15
ASIN Aqua NET
Step 4
Connecting the Power Supply
First start:
Connect ASIN Aqua to power supply 230 V / 50Hz protected by RCD.
ASIN Aqua have no ON/OFF switch after connection to power supply
is automatically on. Select language and test the installation.
Turning off:
Unplug the ASIN Aqua from power supply 230 V / 50 Hz.
WARNING:
If the ASIN Aqua is used in a dierent manner, not specied by the manufacturer,
the apparatus may not provide the full protection it is designed for
RECOMMENDED:
To frequent switching ON/OFF (more the 4x a day) can cause damage.
Language setting
In ASIN Aqua you can choose from dierent languages:

Czech

English

German

Russian

Croatian
Setup
1.
In menu press SETTINGS
and select LANGUAGE.
Or in startup press LANGUAGE
2.
In pop-up menu select required
language then press BACK TO START
RCD Current
protector
30 mA
Timer
230 V / 50 Hz
Filter pump

16 ASIN Aqua NET
Testing ASIN Aqua Installation
WARNING:
Any blocks, bubbles, or leaks in the clear plastic
tube prevent ASIN Aqua from operating. The clear plastic tubing
allows you to see liquid ow to and from your ASIN Aqua.
Test your ASIN Aqua installation before operating to prevent damage to the
system, failure to monitor your pool, and wasting time and money. Most
problems are the result of poor connections to the pH and chlorine pumps.
Using the MANUAL DOSE OF DISINFECTANT function allows you to test both pumps.
1.
From the start screen select SETTINGS.
2.
Select DOSING TEST
3.
Select START in the yellow box
on the left of the screen.
This starts the chlorine pump
on the left of your ASIN Aqua.
4.
While the pump is running check all
the connections of your clear plastic
tubes to the chlorine pump Check
the valves are not blocked or leaking
and that there are no air bubbles.
WARNING:
Make sure uid moves
through the clear plastic tubes through
the pumps to the pool water.
5.
Select STOP.
Checking the installation and checking
the pumps ensures your ASINAqua
is integrated into your pool system.
See the level movement
in the clear plastic tube.
Check the leaks.

EN
17
ASIN Aqua NET
6.
Select START in the blue box on the
right of the screen. Thisstarts the pH
pump on the right of your ASIN Aqua.
7.
While the pump is running check all
the connections of your clear plastic
tubes to the pH pump. Check the
valves are not blocked or leaking and
that there
are no air bubbles.
WARNING:
Make sure uid moves
through the clear plastic tubes through
the pumps to the pool water.
8.
Select STOP.
Checking the installation and
pumps ensures your ASINAqua
isintegrated into your pool system.
Once everything is set up with no problems,
calibrate and set parameters for your ASINAqua.
Manual Dosing
Use Manual Dosing to raise the concentration of chlorine or pH agent
within your pool. This is required if the concentration is signicantly
below recommended levels. You can also use Manual dosing to test the
connections ofthe clear plastic tubes to the pH and chlorine pumps.
1.
In menu select SETTINGS then MANUAL DOSE pH or disinfection.
2.
In menu of manual dosing your selection is highlighted
with a black triangle at the bottom.
Set the parameters of your
swimming pool
Every swimming pool is unique. Temperature, size, location and water
hardness inuence how ASIN Aqua controls your pool water and ne-
tunes it. In order to ensure optimal performance, you have to set the
properties and values of your swimming pool in ASIN Aqua.
1.
Pool volume
2.
Pool type
Select your type of swimming pool
by clicking on the
appropriate check boxes.
3.
Water hardens
Set the hardness of the pool water.
This is measured in dH, 0-9 is soft,
9-21 is hard and 21+ is very hard.

18 ASIN Aqua NET
pH Settings
Setup of required values:
1.
From the home screen select SETTINGS then PARAMETERS.
2.
Select the blue pH button on the right.
3.
Using the – and + buttons adjust the pH
RECOMMENDATION:
Aseko Recommended pH 6,5 – 7,6.
Use low pH with pools sanitized by active oxide agent.
Use high pH with pools sanitized by salt electrolyzes systems.
For chlorine sanitized pools You can use pH 7,0.
pH Calibrating
WARNING:
The probes do NOT require calibration under most circumstances.
ASEKO calibrates the ASINAqua pH probes at the factory.
If you do not allow the probes to stabilize in water before calibrating and using your
system, ASEKO cannot ensure the accuracy of ASIN Aqua. Re-check pH calibration
once a year, replacing the probe if needed.
Calibrating the ASINAqua pH Probe:
1.
Manually check the pH level of your pool.
7,0
6,8
6,8
6,8
6,8
6,4
6,8
Use aseko tester Displayed value
Pool Tester #12170

EN
19
ASIN Aqua NET
2.
From the start screen of your
ASINAqua select SETTINGS
and then CALIBRATION.
3.
Select the blue pH button on
the right of the screen.
4.
Compare the reading given on
your ASINAqua with the reading
taken manually. Ifdierent adjust
the reading on the ASINAqua by
pressing the + and – buttons so that
they match and press OK to save.
RECOMMENDATION:
for precision calibrating use the test buer pH 7,00.
If the manually test value is
outside the pH range 6,0 - 8,0
thefollowing notication is given.
If the dierence between manually test
and current displayed pH valve is greater
than the following notication is given.
pH buer 7,00 #12065

20 ASIN Aqua NET
Choose the function
of Your ASIN Aqua
1)
Free chlorine probe CLF
2)
Redox probe RX
3)
Time dosing ml/m
3
per hour or per day

From the home screen select settings

then CHOOSE THE TYPE OF PROBE to reach the following screen.
1) If You have free chlorine probe
Your Asin Aqua is already installed, connected
to pool water and to chemical agents.

Set up the chlorine level to 0,0 mg/l

Set up the pH value to 7,0

Manually adjust the chlorine level in your pool
to 0,5 – 1,2 mg/l by using manualy dosing from ASINAqua
orhand dosing of Superchlorination agent directly to pool.
24 Wait 24 hours for the probe stabilization.
