Asko OCS8456S User manual

Dear customer!
Thank you for choosing this quality product from ASKO. We hope it will
meet your expectations and fulfil your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
Operating instructions
COMBINED STEAM OVEN
BO4CS2L1-42 OCS8456S

2
We thank you for your trust and the
purchase of our appliance.
This detailed instruction manual is supplied to make the
use of this product easier. The instructions should allow
you to learn about your new appliance as quickly as
possible.
Make sure you have received an undamaged appliance.
If you do find transport damage, please contact the
seller from which you purchased the appliance, or the
regional warehouse from which it was supplied. The
telephone number can be found on the invoice or on the
delivery note.
Instructions for installation and connection are supplied
on a separate sheet.
Instructions for use are also available at our website:
www.asko.com / < http://www.asko.com />
Important information
Tip, note

3
COMBINED STEAM OVEN 4
TECHNICAL SPECIFICATIONS 4
CONTROL UNIT 7
IMPORTANT SAFETY INSTRUCTIONS 8
BEFORE CONNECTING THE OVEN: 9
BEFORE USING THE APPLIANCE FOR THE
FIRST TIME 10
FILLING THE WATER TANK 12
SWITCHING ON THE APPLIANCE FOR THE
FIRST TIME 13
STEPS OF THE COOKING
PROCESS (1–7) 14
STEP 1: CHOOSING THE BASIC COOKING
MENUS AND SETTINGS 14
STEP 2: TIMER FUNCTIONS –DURATION 19
STEP 3: STEP COOKING 20
STEP 4: START THE COOKING PROCESS 22
STEP 5: END OF COOKING AND SWITCHING
OFF THE OVEN 22
STEP 6: SELECTING ADDITIONAL FUNCTIONS 24
STEP 7: CHOOSING THE GENERAL SETTINGS 26
DESCRIPTIONS OF SYSTEMS (COOKING
MODES) AND COOKING TABLES 27
MAINTENANCE & CLEANING 43
CONVENTIONAL OVEN CLEANING 43
USING THE STEAM CLEAN FUNCTION
TO CLEAN THE OVEN 44
CLEANING THE STEAM SYSTEM 44
CLEANING THE FILTER FOAM 45
REMOVING AND CLEANING THE WIRE GUIDES 46
REMOVING AND INSERTING THE OVEN DOOR 47
REMOVING AND INSERTING THE OVEN DOOR
GLASS PANE 48
REPLACING THE BULB 49
TROUBLESHOOTING TABLE 50
DISPOSAL 51
COOKING TEST 52
CONTENTS

4
Control unit
Oven door
Oven handle
Guides
– Cooking levels
Water tank door
4
3
2
1
(DESCRIPTION OF THE OVEN AND EQUIPMENT – DEPENDING ON THE MODEL)
The figure represents one of the built-in appliance models. Since the appliances for which these instructions were drawn
up may have different equipment, some functions or equipment may be described in the manual that may not be present
in your appliances.
TECHNICAL SPECIFICATIONS
(DEPENDING ON THE MODEL)
The rating plate indicating the basic information about
the appliance is located at the edge of the oven and it is
visible when the oven door is opened.
A Serial number
B Code/ID
C Type
D Brand
E Model
F Technical data
G Compliance symbols
COMBINED STEAM OVEN

5
WIRE GUIDES
The wire guides allow preparation of the food on five
levels (please note that the levels/guides are counted
from the bottom up). Guides 3 and 4 are intended for grilling.
TELESCOPIC PULL-OUT GUIDES
Telescopic pull-out guides may be fitted for the 2nd and
3rd level. There are several different designs of the pull-out
guides (depending on the model):three partially extendible,
one fully and two partially extendible, and three fully
extendible guides.
OVEN DOOR SWITCH
The switches deactivate oven heating and the fan when the
oven door is opened during the cooking process. When the
door is closed, the switches turn the heaters back on.
COOLING FAN
The appliance is fitted with a cooling fan that cools the
housing and the appliance control panel.
EXTENDED OPERATION OF THE COOLING FAN
After the oven is switched off, the cooling fan continues to
operate for a short while in order to cool the oven. (Extended
cooling fan operation depends on the temperature in the
center of the oven).
OVEN EQUIPMENT AND ACCESSORIES
(depending on the model)
GLASS BAKING DISH is used for cooking with all oven
systems. It can also be used as a serving tray.
The GRID is used for grilling or as support for a pan, baking
tray or baking dish with the food.
There is a safety latch on the grid. Therefore, the grid has
to be lifted slightly at the front when pulling it out from the oven.
The SHALLOW BAKING SHEET is used for baking pastry
and cakes.
The DEEP BAKING TRAY is used for roasting meat and
baking moist pastry. It can also be used as a drip tray.
Never place the deep baking tray in the first guide during
the cooking process, except when grilling food or using the
roasting spit and you are only using the deep tray as a drip tray.
STEAM SET (INOX) is used for cooking vegetables,
potatoes, fish or meat. The tray prevents contact
between the food and condensate collected in the deep
tray.
Always use the entire steam set (only for steam
cooking)on the 2nd guide.
In case of wire guides, the tray should always be inserted into
the groove between the two wire profiles.
With telescopic extendible guides, first pull out the guides
of one level and place the grid or the baking tray onto them.
Then, push them in with your hand as far as they will go.
Close the oven door when the telescopic guides are
retracted all the way into the oven.
2
3
The appliance and some of the accessible parts tend
to heat up during cooking. Use oven mitts.

6
SYNCHRONIZATION BAR
The bar can be installed or removed on the fully
retractable telescopic guides. First, completely pull out
both guides of the desired level. Insert the bar into the
two slots on the guides and push the guides in with your
hand until they stop.
BAKING PAN SUPPORT allows easy removal of baking
pans from the oven while they are still hot.
PROBE for roasting larger chunks of meat.
DESCALING AGENT for cleaning the steam system.
TEST PAPER STRIP for testing water hardness.
MECHANICAL DOOR LOCK prevents the opening of oven
door until the lock is released.
To open it, gently push your thumb to the right while pulling
the door outwards.

7
AUTOMATIC
QUICK ACCESS
TO STEAM
PROGRAMS
PROFESSIONAL MODE MY RECIPES
EXTRA
FUNCTIONS
GENERAL
SETTINGS
NOTE:
The keys will respond better if you touch them with a larger area of your fingertip. Each time you press a key, this will be
acknowledged by a short acoustic signal.
1ON/OFF KEY 2OVEN
LIGHTING
ON/OFF KEY
3BACK KEY
Touch briefly to
return to previous
menu.
Touch and hold
to return to main
menu.
4Selection and
CONFIRMA-
TION KNOB
Select the setting
by rotating the knob.
Confirm your
selection by
pressing the knob.
5MINUTE
MINDER/
ALARM
6CHILD LOCK
KEY
Locking the
control unit
7START/STOP
KEY
Long touch: START
Long touch during
operation: STOP
8DISPLAY –
displays all
settings
CONTROL UNIT

8
CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM FOR FUTURE REFERENCE.
This appliance may only be used by children aged 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if supervision or instructions are provided to them concerning use of the appliance in a
safe way and if they understand the hazards involved. Do not let the children play with
the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
WARNING: The appliance and some of its accessible parts may become very hot during
use. Be careful not to touch the heaters. Children younger than 8 years should be constantly
supervised.
The appliance becomes very hot during use. Be careful not to touch the oven heaters.
WARNING: The accessible parts of the appliance may become hot during use. Children
should be kept away from the oven.
Only use the temperature probe recommended for use in this oven.
WARNING: Before replacing the light bulb, make sure the appliance has been disconnected
from the power mains, in order to prevent the hazard of an electric shock.
Do not use abrasive cleaners or sharp metal scrapers to clean the oven as they may damage the
finish or the protective enamel coating. Such damages may lead to cracking of the glass.
Do not use steam cleaners or high pressure cleaners to clean the appliance as this may result in an
electric shock.
The appliance is not intended to be controlled with external timers or special control systems.
The appliance is intended for household use. Do
not use it for any other purpose, such as room heating,
drying of pets or other animals, paper, fabrics, herbs etc.
as this may lead to injury or fire hazard.
The appliance may only be connected to the power
mains by an authorized service technician or expert.
Tampering with the appliance or non-professional repair
thereof may result in risk of severe injury or damage to
the product.
If the power cords of other appliances located near
this appliance are caught in the oven door, they may
be damaged, which may in turn result in a short circuit.
Therefore, keep the power cords of other appliances at a
safe distance.
If the power cord is damaged, it should be replaced by
the manufacturer or an authorized service technician, in
order to avoid hazard.
Do not line the oven walls with aluminium foil and do
not place baking trays or other cookware on the oven
bottom. Aluminium foil would prevent air circulation
in the oven, hinder the cooking process, and ruin the
enamel coating.
Oven door become very hot during operation. A
third glass is installed for extra protection, reducing
the temperature of the outside surface (only with some
models).
Oven door hinges may be damaged when under
excessive load. Do not place heavy pans on open oven
door and do not lean against open oven door when
cleaning the oven cavity. Never stand on the open oven
door and do not let children to sit on it.
Make sure the vents are never covered or obstructed in
any other way.
IMPORTANT SAFETY INSTRUCTIONS

9
Safe and correct use of the steam oven
Leave the appliance at room temperature for some
time before connecting it to the power mains to allow all
components to adapt to room temperature. If the oven
is stored at a temperature near or below freezing point,
there is a danger for some components, especially the
pumps.
The appliance should not operate in an environment
with a temperature below 5 °C. Below this temperature,
the water that remains in the pumps could freeze. If the
appliance is turned on in such conditions, the pumps
could be damaged.
If the appliance does not work correctly, disconnect it
from the power mains.
Do not store items in the oven, which could cause
danger when the oven is switched on.
Do not use distilled water that is not suitable for
ingestion.
After the steam cooking is completed, there is some
residual steam in the oven. Open the oven door carefully,
as there is danger of scalding with steam.
Clean the oven once it has cooled down to room
temperature.
After the cooking process, the remaining water in the
steam system is pumped back into the water tank.
Therefore, the water there could be hot. Be careful when
emptying the water tank.
To prevent the build-up of limescale, leave the oven door
open after cooking to allow the oven cavity to cool down to
room temperature.
BEFORE CONNECTING THE OVEN:
Carefully read the instructions for use before
connecting the appliance. Repair or any warranty
claim resulting from incorrect connection or use of the
appliance shall not be covered by the warranty.

10
After receiving the appliance remove all parts, including
any transport equipment (cardboard and polystyrene
inserts), from the oven.
Clean all accessories and utensils with warm water and
regular detergent. Do not use any abrasive cleaners.
Before using the oven for the first time, heat it with
the upper and lower heater system at 200 °C for
approximately one hour. The characteristic ”new
appliance” scent will be released; make sure the room is
well ventilated.
STEAM COOKING
Healthy and natural, steam cooking preserves the full
flavour of foods. This cooking method releases no
odours. There is no need to add salt to the water or to
add herbs and spices.
Following are the advantages of steam cooking:
Cooking (braising, roasting)starts before the
temperature inside the oven reaches 100 °C. Slow
cooking (braising, roasting)is also possible at lower
temperatures.It is healthy: vitamins and minerals are
well preserved because only a small share of them is
dissolved in the condensation water that touches the
food.
There is no need to add any fat during the cooking
process. The steam maintains the taste of food. It does
not add odours, nor the taste of the grill or the pan.
Furthermore, it takes nothing away because the food
is not diluted in the water. Steam does not spread the
flavour or smell; therefore, meat or fish can be cooked
together with vegetables. Steam is also suitable for
blanching, defrosting and reheating or keeping the food
warm.
BEFORE USING THE APPLIANCE FOR THE FIRST TIME

11
TESTING WATER HARDNESS
Water hardness test should be carried out before first use.
A warning will appear on the display: ”Use the test paper to measure water hardness.”
Soak the test paper strip (supplied with the
appliance)in water for one (1)second.
Wait one minute and observe the number of stripes
on the paper. Enter the information on the number
of stripes into the appliance. Rotate the KNOB and
confirm the selection with the CHECK MARK.
4 green stripes Soft
1 red stripe Slightly hard
2 red stripes Medium hard
3 red stripes Hard
4 red stripes Very hard
The highest water hardness is set as a factory default.
CHANGING THE WATER HARDNESS SETTING
Water hardness can also be set in the menu CHOOSING THE GENERAL SETTINGS.
If the correct water hardness level is not set, this could
affect appliance operation and its useful life.

12
FILLING THE WATER TANK
The tank allows for independent water supply to the steamer. The tank volume amounts to approx. 1.3 litres (maximum
water level –see marking). This amount of water allows approximately 3 hours of cooking time with max. steam cycle (hot
air with steam on ”high” system).
Clean the water tank before the first use.
Always fill the water tank with clean and cool water from the
pipeline, bottled water without additives, or distilled water
suitable for use in cooking. Water that is poured into the
water tank should be at a temperature of 20 °C +/- 10 °C.
1Press on the spot with the sticker to open the tank
door.
The sticker can be later removed.
2Remove the water tank from the housing by grabbing
the notch.
3Open the lid. Wash the tank with water. Re-assemble
the tank. Before use, add fresh water up to the MAX
marking on the tank.
4Push the water tank back into the housing to the final
position (until the short click). Then, press the tank
door to close it.
After the cooking process, the remaining water in the
steam system is pumped back into the water tank. The
lid and the water tank can be washed with standard non-
abrasive liquid cleaners or in a dishwasher.

13
SETTING THE CLOCK
After connecting your appliance or after an extended power outage, 12:00 will flash on the display. Set the time of day.
Confirm each setting by pressing the KNOB.
Press the KNOB to set the time.
Turn the KNOB and first set the TICK.
The oven will also work if the clock is not set. However, timer functions are not available in this case (see chapter
SETTING THE TIMER FUNCTIONs). After a few minutes of idling, the appliance will switch to standby mode.
CHANGING THE CLOCK SETTING
Clock settings may be changed when no timer function is activated (see chapter CHOOSING THE GENERAL SETTINGS).
SELECTING THE LANGUAGE
If you are not happy with the language in which the messages on the display are presented, select another one. English
is the preset language.
Rotate the KNOB and select your language from
the list. CONFIRM the selection.
The main menu will appear.
SWITCHING ON THE APPLIANCE FOR THE FIRST TIME

14
STEP 1: CHOOSING THE BASIC COOKING MENUS AND SETTINGS
The process of preparing food in your oven can be controlled in several ways:
Rotate the KNOB and select the symbol. The
symbol will turn white. The NAME of the selected
menu will appear at the top.
Confirm each setting by pressing the KNOB.
Automatic mode
In this mode, first select the type of food. This is followed by automatic setting of the quantity, level
of doneness, and cooking end time.The program offers a large choice of preset recipes reviewed by
professional chefs and nutrition experts.
Quick access to steam programs
This is a natural cooking mode that preserves the full flavour of the food.
Professional mode
Use this mode when you wish to prepare any type and amount of food. All settings are selected by the
user.
STEPS OF THE COOKING PROCESS (1–7)

15
1234 5
A) COOKING BY SELECTING THE TYPE OF FOOD (Auto mode)
Confirm each setting by pressing the KNOB.
Rotate the KNOB and select the Auto mode.
Confirm the setting by pressing on the KNOB.
Select the type of food and the dish. Confirm the
selection.
Preset values will appear. Rotate the KNOB and
confirm by pressing the KNOB to change these
settings.
1 Amount
2 Doneness
3 Delayed start
4 Cooking duration
5 Cooking system and recommended level
When in the Auto mode, choose the duration or system symbol to open the Professional mode (see section on
COOKING BY SELECTING THE OPERATING MODE).
Touch the START/STOP key to start oven operation.
All selected settings are indicated on the display.
PREHEAT
Some dishes in the Auto mode also include the preheat function ..
When you select the food, the following note will appear: »Selected program includes preheating.« Preheating
started. Do not insert the food yet. The symbol °C will flash on the display.
When the selected temperature is reached, the preheating process stops and an acoustic signal is emitted.
The following note will appear on the display: »Preheating complete«. Please insert the food. Open the door or confirm
by pressing the KNOB. The program then resumes the cooking process with selected settings.
When the preheat function is set, delayed start function cannot be used.

16
B) STEAM COOKING (quick access to steam programs)
Confirm each setting by pressing the KNOB.
Rotate the KNOB and select Steam. Confirm the
setting by pressing on the KNOB.
Select the settings by rotating the KNOB and
pressing it to confirm.
1 Preheating
2 Hot air with steam
3 Oven temperature
4 Cooking duration
5 Delayed start
6 Step mode (see section STEP COOKING)
Use the preheat function if you wish to heat the oven to the desired temperature as quickly as possible.
Fill the water tank with fresh water up to the MAX marking. Use the STEAM SET to cook vegetables, fish, meat, and
potatoes –when not cooking in a sauce. Place the steam set into the 2nd guide.
COOKING
SYSTEMS
DESCRIPTION PRESET
TEMPERATURE
(°C)
MIN – MAX
TEMPERATURE
(°C)
COMBINED SYSTEMS / STEAM SYSTEM
HOT AIR WITH STEAM
Used for cooking and defrosting. They allow quick and efficient
cooking without changing the colour or shape of the food. Three
options are available:
180
HIGH: cooking escalopes, steaks, and smaller chunks of meat 30 - 250
MEDIUM: reheating cool/frozen meals, cooking fish fillets and
vegetables au gratin 30 - 250
LOW: cooking large chunks of meat (roast, whole chicken),
baking risen dough (bread and rolls), cooking lasagne etc. 30 - 250
STEAM
Use this for all types of meat, stews, vegetables, pies, cakes,
bread, and dishes au gratin (i.e. food that require longer cooking
time).
100 40 –100
Touch the START key to start oven operation.
The symbol °C will flash on the display until the selected temperature is reached.
123456

17
C) COOKING BY SELECTING THE OPERATING MODE (Professional mode)
Confirm each setting by pressing the KNOB.
Rotate the KNOB and select Professional (Pro)
mode. Confirm the selection.
Select the settings by rotating the KNOB and
pressing it to confirm.
1 Preheating
2 System
3 Oven temperature
4 Cooking duration
5 Delayed start
6 Step cooking
PREHEAT
Use the preheat function if you wish to heat the oven to the desired temperature as quickly as possible. When this
symbol is selected, the preheat function will be switched on and a warning will appear. »Preheating started.« Do
not insert the food yet. The symbol °C will flash on the display.
When the selected temperature is reached, the preheating process stops and an acoustic signal is emitted. The
following note will appear on the display: »Preheating complete«. Please insert the food. Open the door or confirm by
pressing the KNOB. The program then resumes the cooking process with selected settings.
When the preheat function is set, delayed start function cannot be used.
123456

18
COOKING SYSTEMS (depending on the model)
SYSTEM DESCRIPTION PRESET
TEMPERATURE
(°C)
MIN – MAX
TEMPERA-
TURE (°C)
COOKING SYSTEMS
UPPER AND BOTTOM HEATER
The heaters in the bottom and in the ceiling of the oven cavity
will radiate heat evenly into the oven interior. Pastry or meat can
only be baked/roasted at a single height level.
200 30 –250
UPPER HEATER
Only the heater on the oven cavity ceiling will radiate heat. Use
this heater to brown the upper side of the dish.
150 30 –235
BOTTOM HEATER
Only the heater on the bottom of the oven cavity will radiate heat.
Use this heater to brown the lower side of the dish.
160 30 –235
GRILL
Only grill heater, a part of the large grill set, will operate.
Use this heater to grill a few open sandwiches or beer sausages,
or for toasting bread.
240 30 –250
LARGE GRILL
The upper heater and the grill heater will operate. The heat is
radiated directly by the grill heater installed in the oven ceiling.
To boost the heating effect, the upper heater is activated as
well. This system is used for grilling a smaller amount of open
sandwiches or beer sausages, and for toasting bread.
240 30 –250
GRILL WITH FAN
Grill heater and the fan will operate. This combination is used to
grill meat and to roast larger chunks of meat or poultry at a single
height level. It is also appropriate for dishes au gratin and for
browning to a crispy crust.
170 30 –250
HOT AIR AND BOTTOM HEATER
Bottom heater, round heater, and the fan will operate. This is
used to bake pizza, moist pastry, fruitcakes, leavened dough
and shortcrust on several levels simultaneously.
200 30 –250
360 HOT AIR
Round heater and the fan will operate. The fan installed
in the back wall of the oven cavity makes sure the hot air
constantly circulates around the roast or pastry. This mode
is used for roasting meat and baking pastry at several levels
simultaneously.
180 30 –250
ECO COOKING 1)
In this mode, power consumption during the cooking process
is optimized.This mode is used for roasting meat and baking
pastry.
180 -
BOTTOM HEATER AND FAN
This is used for baking leavened but low-rising pastry and for
preserving fruit and vegetables.
180 30 –230
AUTOMATIC COOKING OF MEAT – AUTO ROAST MODE
In the automatic meat cooking mode (Auto Roast), the upper
heater will operate in combination with the grill heater and the
round heater. It is used for roasting all types of meat.
180 30 –240
1)It is used for determining the energy efficiency class pursuant to the EN 60350-1 standard.
Touch the START key to start oven operation. All selected settings are indicated on the display.
The symbol °C will flash on the display until the selected temperature is reached. A short beep will be heard. Cooking/
baking systems cannot be changed during operation.

19
STEP 2: TIMER FUNCTIONS –DURATION
The ”Duration” setting can be selected in the basic
Professional (Pro)mode.
Cooking duration
Delayed start
Setting the cooking time
In this mode, you can define the duration of oven operation (cooking time). Set the desired cooking time
and confirm the setting (Maximum operating time is 10 hours.). Cooking end time is adjusted accordingly.
Press START to start the cooking process. All selected settings are indicated on the display.All timer
functions can be cancelled by setting the time to ”0”.
Setting the delayed start
In this mode, you may specify the duration of the cooking process (cooking time)and the time when you
wish the cooking process to stop (end time)(Delayed start function allows delaying the start by up to 24
hours.). Make sure the clock is accurately set to current time.
Example:
Current time: 12:00
Cooking duration: 2 hours
End of cooking: 6 pm
First, set the cooking time (COOKING DURATION), i.e. 2 hours. The sum of the current time and cooking
time is automatically displayed (2 pm).How, set the COOKING END TIME and set the time (6 PM). Press
START to start the cooking process. The timer will wait for the start of the cooking process. The following
note will appear on the display: ”Cooking start is delayed. Cooking will start at 16:00.”
After the set time expires, the oven will automatically stop operating (end of cooking). An acoustic signal will be
heard which you may turn offby pressing the ALARM key. After one minute, the acoustic signal will be switched off
automatically.
After a few minutes of idling, the appliance will switch to standby mode. The time of day will appear.

20
STEP 3: STEP COOKING
This mode allows you to combine three different cooking modes successively in a single cooking process.
Choose different settings to cook your food just the way you want it.
Select the ”Step cook” setting in the basic
Professional (Pro)mode and Steam Cooking
mode. Confirm the setting by pressing on the
KNOB.
Select: step 1, step 2, step 3
Confirm the settings by pressing on the KNOB.
The first step will already have been selected if you have already set the timer functions.
Set the cooking system, temperature, and time.
Confirm the setting with the CHECK MARK by
pressing on the KNOB.
Total cooking time –end.
Current step
Touch the START symbol to turn on the oven. The oven starts operating immediately, with the settings defined in Step 1.
(A strip at the bottom of the display indicates the cooking step currently in progress.)After the set cooking time elapses,
Step 2 and then Step 3 are activated, if specified.
If you wish to delete a step during operation, turn the KNOB, choose the step and cancel it by confirming the X mark.
This can only be done with steps that have not started yet.
Temperature and duration of
the selected step
