Asko OT8687S User manual

Instructions for use
OVEN
OT8687S / BO6CO4F3-42
OT8687A / BO6CO4F3-42

EN Manual EN 3 - EN 35
Pictograms used
Important information
Tip

EN 3
YOUR OVEN
Your oven
Introduction 4
Control panel 5
Description 6
Guide rails 7
Door 7
Cooling fan 7
Main functions 7
Keys 9
Navigation 10
Initial use
What to do first 12
Operation
Selecting your function 13
Functions settings mode 13
Progress mode 15
Finish display 15
Changing settings during the progress 16
Use
Functions table 17
Settings menu 21
Plus menu 22
Cooking information 23
Fast preheat 23
Delayed start 24
Gratin 25
Stage cooking 25
Go to manual cooking 26
Programs and Favourites 26
Egg timer 27
Child lock 27
Plate warming 28
Warming 28
Defrost 28
Cleaning
Cleaning the appliance 29
Aqua clean 29
Removing and cleaning the guide rails 30
Removal and installation of the oven door 30
Removal and installation of the oven door glass 31
Replacing the oven lamp 32
Solving problems
33
Your oven and the environment
Disposing of the appliance and the packaging 35

EN 4
Introduction
Congratulations on choosing this ASKO oven.
This product is designed to offer simple operation and optimum
user-friendliness. The oven has a wide range of settings enabling you
to select the correct cooking method every time.
This manual shows how you can best use this oven. In addition to
information about operating the oven, you will also find background
information that may be useful when using the appliance.
Please read the separate safety instructions
carefully before using the appliance!
Read this manual before using the appliance and keep it in a safe
place for future use.
Installation instructions are supplied separately.
YOUR OVEN

EN 5
YOUR OVEN
Control panel
1. Function knob (in ‘Off’ position)
2. Defrost
3. Programs & Favourites
4. Fast preheat
5. Oven
6. Eco hot air
7. Plate warming
8. Warming
9. Aqua clean
10. Display
11. Selection knob
12. On/off key and stop key (cancel)
13. Light key
14. Timer key
15. Navigation key left
16. Navigation key right
17. Plus key
18. Child lock key (lock key)
19. Confirm key
Note:
The keys respond best if you touch them with a large area of your
fingertip. Every time you press a key during use, a short acoustic signal
will sound.
12 13 14 15 16 17 18 19
1 10 116 7 8 95432

EN 6
YOUR OVEN
Description
1. Control panel
2. Oven levels
▷OT86: 5 levels*
▷OT84: 4 levels
3. Oven door
4. Door handle
The following accessories are supplied with your oven:
• Baking tray; used for pastries and cakes.
• Oven rack; mainly used for grilling. A dish or pan with food can
also be placed on the oven rack.
The oven rack is equipped with a safety peg. Lift the rack slightly at
the front to slide it out of the oven.
• Deep Baking Tray (OT86 only); is used for roasting meat and
baking moist pastry. It can also be used as a drip tray. Place the
deep baking tray into the first level only for grilling or for use as a
drip tray.
1
3
Level 1
Level 2
Level 3
Level 4
Level 5*
2
4

EN 7
Guide rails
• The oven has four or five guide rails (level 1 to 4/5), depending on
the model. Level 1 is mainly used in combination with bottom heat.
The upper two levels are used mainly for the grill function.
• Place the oven rack or baking tray in the gap between the guide
rail sliders.
Door
• The door switches interrupt the operation of the oven when the door
is opened during use. The oven continues operating when the door
is closed.
• This oven has a ‘Soft close door system’. When closing the oven
door, this system dampens the movement, from a certain angle, and
silently closes the oven door.
Cooling fan
• The appliance is equipped with a cooling fan that cools the casing
and control panel.
YOUR OVEN

EN 8
YOUR OVEN
Main functions
With the function knob you can select the main functions of your oven.
Setting Description
Off/standby mode
Oven
Hot air
Hot air + bottom heat
Bottom + top heat
Large grill
Grill
Large grill + fan
Upper heat
Bottom heat
Bottom heat + fan
Pro roasting
Fast preheat
Eco hot air
Programs and favourites
Favourites
Programs
Defrost
Manual defrost
Plate warming
Warming
Keep warm
Aqua clean

EN 9
Keys
In the table below you can find the discription of the different keys.
Keys Description of the keys
On/off key and stop key:
- Press short: cancel operation or go one step back in
the menu.
- Press long: turn the appliance off or on.
Light key:
- To turn the cavity light on or off.
Egg timer
- The egg timer can be used independent of the oven
function.
- The longest possible timer setting is 23:59.
Navigation key left
- To move the active area to the left.
Navigation key right
- To move the active area to the right.
Plus key
- To open or exit the settings menu (in standby-
mode).
- To open or exit the plus menu with the extra options
possible at that moment (in on-mode).
Child lock key
- Press and hold the lock key to lock the appliance.
Confirm key
- To confirm all the white settings/elements in the
screen.
YOUR OVEN

EN 10
YOUR OVEN
Navigation
active area
stop key confirm keyfunction knob selection knobnavigation keys
By turning the function knob away from the 0-position, the icon of the
chosen main function is lit. The display will show the icon and name
of the activated function for about 1,5 seconds. Next you will see the
chosen main function and sub-function at the top of the display in the
feedback bar. Also the function settings mode will become active (grey
background). In this activated area you can select your settings using
the selection knob.
180 °C
OVEN l HOT AIR 14:30
Within every menu the navigation is as follows:
• Use the navigation keys or press the selection knob to move the
active area (grey background).
• The setting in the active area can be changed by turning the
selection knob (left = decrease, right = increase). The setting will be
saved automaticallly.
• When all elements in the screen are set, confirm these settings by
pressing the confirm key (this key is blinking if it is possible to start
the program).
• Press the stop key to go one step back in the menu.
At the top of the display is a feedback bar. This bar will inform where
you are in the menu and what setting you are changing. Functions are
separated with a vertical line.
SETTINGS l GENERAL l SOUND l KEY SOUND
