Aspect SUNSOCKET EP-55A User manual

SUNSOCKET™
EP-55 SOLAR PANEL
USER GUIDE
Model No: EP-55A

Did you add AspectCare protection to your
EP-55 Solar Panel?
We want you to enjoy your new EP-55 Solar Panel to the fullest, and without any
worries. Please contact us if you did not already add any product protection with
your purchase. You have 30 days from the date of purchase to add coverage.
To inquire about our AspectCare protection, please contact us at
[email protected] or call us direct at
1-877-717-7778
Product Specifications
PV PANELS
Rated Power
55W
Cell type
Mono-crystalline silicone
OUTPUT
SOLMAX™ OUT
DC 15V 3.7A Max
GENERAL
Dimensions
Packed
Deployed
Total Weight
Operating Temperature
Model Number
21.3" x 15.4" x 2"
21.3" x 30.9" x 14.2"
8.6 LBS (3.9kg)
14°F – 140°F (-10°C – 60°C)
EP-55A

Using EP-55 Solar Panel
A"
B"
C"
D"
E"
A"
B"
C"
D"
E"
Unzip&the&zipper&
Open&the&bag&
Lift&up&the&PV&panel&
Lift&up&and&position&the&stand&
Mate&the&Velcro&on&the&surface&of&both&&
the&PV&panel&and&the&stand.&
F"
Face&EP=55&solar&panel&to&the&sun!&
F"
SOLMAX™&Box&inside&

Charging ENERGYBAR™-250 with EP-55
Solar Panel
EP-55 is specifically designed to be used for charging AspectSolar’s
ENERGYBAR™-250 (“EB-250”). To use the EP-55 to charge the EB-250, take out
the SOLMAX™ Box that is stored inside EP-55 pouch. Connect the SOLMAX™ DC
output to the DC input of the EB-250 as shown in the figure below to get it
charged. Typically, it takes 7-13 hours to fully charge the EB-250 using
EP-55 Solar Panel.
SOLMAX™ provides an estimate of the power harnessed by the EP-55 Solar
Panel via Power Indication LED. The LED can be seen in the picture below.
Power Indication LED
LED
state
Power
Off
<5W
Blinking
5-30W
Solid On
>30W
SOLMAX™ DC output plug&

FREQUENTLY ASKED QUESTION
Q: Is EP-55 Solar Panel waterproof?
A: EP-55 Solar Panel is weather-resistant which means it will resist the
occasional rain or snow. It is not designed for immersion in water.
Q: How long does it take to fully charge EnergyBar™-250 from empty?
A: On clear sunny days, when the EP-55 Solar Panel is facing the sun, it typically
takes 7-13 hours depending on how bright the sun is.
Q: Can we use EP-55 Solar Panel to charge batteries other than EnergyBar™-
250?
A: EP-55 Solar Panel is specifically designed for the EnergyBar™-250 product
and is not recommended to be used to charge other battery system.
Q: Why is there a repetitive clicking sound coming from the EnergyBar™-250
when it is being charged by EP-55 Solar Panel?
A: The clicking sound is the indication that the EnergyBar™-250 is fully charged
by the EP-55 Solar Panel.
Q: Why is the Power Indication LED of the SOLMAX™ Box blinking very fast
when EP-55 Solar Panel is plugged onto the EnergyBar™-250?
A: The very fast blinking state of the power indication LED on the SOLMAX™ Box
is its way of indicating that the EnergyBar™-250 has stopped accepting charge.
This condition may be followed by a repetitive clicking sound from the
EnergyBar™-250 if the level of sunshine fluctuates.
Q: Does leaving EP-55 Solar Panel plugged onto the EnergyBar™-250 even after
it is fully charged cause any problem to the system?
A: No. However do note that when the EnergyBar™-250 is fully charged, the
Power Indicator LED will blink rapidly and may be followed by a loud repetitive
clicking sound as explained above.
Q: Why does the PV panel sag during use?
A: The stand that props up the PV panels is made of light polypropylene plastic
and will flex as the sun reaches its peak point so that the panels are relatively
more horizontal to maximize harvest of the sunshine.
Still need help?
Email us at [email protected]
or call 1 [phone] and we will be happy to assist you!

LIMITED WARRANTY
Aspect Technologies, Inc.
SunSocket™ EP-55
Effective October 28, 2013
WHAT IS COVERED BY THIS WARRANTY?
Aspect Technologies, Inc. (dba AspectSolar) warrants the SunSocket™ EP-55 (‘product”) contained in its
original packaging against defects in materials and workmanship when used normally in accordance with
AspectSolar’s published guidelines for a period of ONE (1) YEAR from date of original purchase by the end user
purchaser (“Warranty Period”). AspectSolar’s published guidelines include but are not limited to information
contained in technical specifications, user manuals, service communications and this document.
LIMITED WARRANTY EXCLUSIONS
Specifically excluded from this warranty are:
!All consumable parts, such as manual, cable or strap, MPPT charger, solar panels, unless failure has
occurred due to a defect in materials or workmanship.
!Cosmetic damage, including but not limited to scratches, rust, dents, broken ports or normal color
fading.
!Damage caused by accident, abuse, misuse, liquid contact, fire, earthquake or other external causes.
!Damage caused by operating the product outside of AspectSolar’s published guidelines. (SEE SAFETY
INFORMATION BELOW)
!Damage caused by anyone who is not a representative of AspectSolar, or an AspectSolar authorized
Service Provider.
!Product that has been modified, serviced, tampered with, or had screws and/or nuts removed without
the written consent of AspectSolar.
!Defects caused by normal wear and tear or otherwise due to normal aging of the product.
!Product wherein any AspectSolar serial number and/or warranty seal has been removed or defaced
from the product.
!Product not purchased from AspectSolar.com or authorized retailer/reseller.
Other Limits and Exclusions:
!There are no other express warranties except what is listed above
HOW TO OBTAIN WARRANTY SERVICE?
Before receiving warranty service, AspectSolar, or its agents will require that you provide proof of purchase
details, respond to questions designed to assist with diagnosing potential issues and follow AspectSolar’s
procedures for obtaining warranty service.
For Service*:
Online: aspectsolar.com/Contact_Us-@-Contact_Us.aspx
Call: 1-877-717-7778
E-Mail: [email protected]
* PLEASE NOTE WARRANTY INFORMATION BELOW
If during the Warranty Period you submit a claim for service, AspectSolar will, at its sole option, (a) repair the
product using new or previously used parts that are equivalent in performance and reliability for the remaining
period of the warranty, (b) replace the AspectSolar product with a product that is at least functionally
equivalent to the AspectSolar product and which may be constructed from new and/or refurbished parts that
are equivalent in performance and reliability, or (c) exchange the AspectSolar product for a refund of your
purchase price. Incomplete returns may be subject to a restocking fee.
AspectSolar, may request that you replace certain user-installable parts or products. A replacement part or
product, including a user-installable part that has been installed in accordance with instructions provided by
AspectSolar, assumes the remaining warranty of the AspectSolar product or ninety (90) days from the date of
replacement or repair, which ever provides longer coverage for you. When a product is replaced or a refund
provided, any replacement item becomes your property and the replaced or refunded item becomes
AspectSolar’s property.
Service where AspectSolar requires the return of the replaced product or part, may require a credit card
authorization as security for the retail price of the replacement product or part and applicable shipping costs.
AspectSolar will ship a replacement product or part. Once the product or part being replaced is returned as
instructed, AspectSolar, will cancel the credit card authorization, so you will not be charged for the product or
part and shipping to and from your location. If you fail to return the replaced product or part as instructed or
return a replaced part that is ineligible for service, AspectSolar will charge your credit card for the authorized
amount.
AspectSolar reserves the right to change the method by which AspectSolar may provide warranty service to
you.

SAFETY INFORMATION –
•Do not connect the EP-55 DC output plug to any devices other than specific products designed by
AspectSolar that are labeled compatible with the EP-55 product;
•Do not insert any foreign objects into any of the sockets or attempt to use incompatible connectors
with the sockets;
•The product does not require any installation or tools for operation;
•Only the solar panels and carrying case is weather-resistant. The MPPT charger is not waterproof, nor
water resistant;
•The product must not be dismantled except by authorized AspectSolar, service personnel whereupon
warranty is otherwise voided;
•The product is capable of generating high voltages and necessary precautions should be taken to
safeguard against electrocution or burns;
•The device is intended solely for use by adults and as prescribed.
ENVIRONMENTAL REQUIREMENTS
Attributes
Description
Operating Temp
0° to 50° C, 32° to 120° F
Environment
Best to use in dry locations
LIMITATION OF LIABILITY -
EXCEPT AS PROVIDED IN THIS WARRANTY AND TO THE MAXIMUM EXTENT PERMITTED BY LAW,
ASPECTSOLAR, IS NOT RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM ANY BREACH OF WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL THEORY,
INCLUDING BUT NOT LIMITED TO LOSS OF USE; LOSS OF ACTUAL OR ANTICIPATED PROFITS (INCLUDING
LOSS OF PROFITS ON CONTRACTS); LOSS OF THE USE OF MONEY; LOSS OF ANTICIPATED SAVINGS; LOSS
OF BUSINESS; LOSS OF OPPORTUNITY; LOSS OF GOODWILL; LOSS OF REPUTATION.
THE FOREGOING LIMITATION SHALL NOT APPLY TO ANY STATUTORY LIABILITY FOR INTENTIONAL AND
GROSS NEGLIGENT ACTS AND/OR OMMISSIONS.
SOME STATES (COUNTRIES OR PROVINCES) DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
Safety
WARNING: ELECTRIC SHOCK HAZARD!
- This product is intended for use by adults only.
- USE THIS PRODUCT IN DRY CONDITIONS ONLY. This product is weather-resistant but not
waterproof.
- You must only use compatible products designed by AspectSolar with this product.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try and correct
the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or experienced radio/TV technician for help.
&
