ASRock Industrial iEPF-9010S-EY4 User manual

iEPF-9010S-EY4
iEPF-9012S-EY4
iEP-9010E
iEP-9012E
User Manual
Version 1.0
Published June 2022
Copyright©2022 ASRockInd INC. All rights reserved.

Version 1.0
Published July 2022
Copyright©2022 ASRockInd Inc. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Rack Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to
infringe.
Disclaimer:
Specications and information contained in this documentation are furnished
for informational use only and subject to change without notice, and should not
be constructed as a commitment by ASRock Rack. ASRock Rack assumes no
responsibility for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Rack does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.
In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable
for any indirect, special, incidental, or consequential damages (including damages
for loss of prots, loss of business, loss of data, interruption of business and the
like), even if ASRock Rack has been advised of the possibility of such damages
arising from any defect or error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Rack’s Website: www.ASRockRack.com

Important Safety Instructions
For user safety, please read and follow all instructions, Warnings, Cautions,
and Notes marked in this manual and on the associated device before handling/
operating the device, to avoid injury or damage.
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Read the Specications section of this manual for detailed information on the
recommended operating environment.
4. Disconnect the equipment from all AC outlets before cleaning. Use only a damp cloth
for cleaning. Do not use liquid or sprayed detergent.
5. Place the equipment on a reliable surface during installation. Dropping or letting the
equipment fall may cause damage.
6. Do not leave the equipment in an environment with a storage temperature of below
-40 °C (-40 °F) or above 85 °C (185 °F) as this may cause damage. e equipment
should be stored in a controlled environment.
7. Ensure that the voltage of the power source is correct before connecting the equipment
to a power outlet.
8. Position the power cord away from high-trac areas. Do not place anything over the
power cord.
9. If the equipment is not used for a long time, disconnect the equipment from the power
source to avoid damage from transient over-voltage.
10. All cautions and warnings on the equipment should be noted.
11. To avoid electrical shock and/or damage to the device:
• Keep the device away from water or liquid sources.
• Keep the device away from high heat or humidity.
• Keep device properly ventilated (do not block or cover ventilation openings).
• Always use designated voltage and power source settings.
• Always install and operate the device near an easily accessible electrical outlet.
• Secure the power cord (do not place any object on/over the power cord).
• Only install/attach and operate the device on stable surfaces and/or designated
mountings.
• e power cord must be connected to a socket or outlet with a ground connection.
12. If one of the following occurs, have the equipment checked by service personnel:
• e power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• e equipment has been exposed to moisture.
• e equipment is malfunctioning or does not operate according to the user manual.
• e equipment has been dropped and damaged.
• e equipment shows obvious signs of breakage.

13. Never attempt to repair the device, which should only be serviced by qualied technical
personnel using suitable tools.
14. Any unveried component may cause unexpected damage. To ensure correct
installation, always use the components (e.g., screws) provided in the accessory box.
15. is equipment is not suitable for use in locations where children are likely to be
present.
16. e equipment should only be installed in a restricted access area.
17. Restricted Access Location:
e device must be installed only in a server room or computer room where access is:
• Access can only be gained by service persons or by users who have been instructed
about the reasons for the restrictions applied to the location and about any precautions
that shall be taken.
• Access is through the use of a tool or lock and key, or other means of security, and is
controlled by the authority responsible for the location.
• Leave enough clearance (25 inches in the front and 30 inches in the back of the rack) to
allow the front door to be opened completely and to allow for sucient airow.
• is product is for installation merely in a Restricted Access Location.
• is product is not suitable for use with visual display workplace devices according to §2
of "the German Ordinance for Work with Visual Display Units".
18. e equipment is intended to be supplied by the external power source (UL listed/ IEC
60950-1/ IEC 62368-1 approved) whose output complies with ES1/SELV. To reduce
potential safety issues, only the AC adapter provided with the product, a replacement
AC adapter provided by ASRock Industrial or agency, or an AC adapter purchased as
an accessory from ASRock Industrial or agency should be used with the product.
19. is power adapter (FSP330-AAAN3) is intended to be supplied based on a UL-
certied and suitable for use at an operating/storage temperature of 0 °C (32 °F)~ 40 °C
(104 °F)/ -20 °C (-4 °F)~80 °C (176 °F), and the current output is rated 13.75A. If you
need further assistance, contact ASRock Industrial for additional information.
20. e ambient temperature of the iEP-9010E series: 70 °C (158°F) max.; the ambient
temperature of the iEPF-9010S series: 75 °C (167°F) max.
21. e terminal block is suitable for V+& V-, 3 units for each (16~18AWG) which means
6 units in total. e torque value is 0.69Nm. And use copper conductors only. Kindly
note that must be installed by a skilled person.
22. LAN port must use shielded LAN cable.

Replaceable Batteries
BURN HAZARD
Hot surface! Do not touch! Touching this surface could result in bodily injury. To reduce
risk, allow the surface to cool before touching.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE
OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
CAUTION
e equipment is equipped with a battery-powered real-time clock circuit. ere is a risk
of explosion if a battery is incorrectly replaced. Replace only with the same or equivalent
type as designated by the manufacturer. Discard all used batteries according to the
manufacturer's instructions.
LITHIUM-METAL BATTERY WARNING
Danger of explosion if the battery is incorrectly replaced. Replace only with the same or
equivalent type designated by the manufacturer. Dispose of used batteries according to the
manufacturer's instructions.
WARNING
All interconnection to the EUT is for indoor location and therefore PoE network
interconnected to the EUT is considered as ES1/SELV for connected only to PoE network
without routing to the outside plant.
WARNING
Input voltage rated 9~36V, 30~18A
Packing: e unit should be carried with both hands and handled with care.
Maintenance: Use only approved products or a dry applicator to clean and maintain the
surfaces.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
Contact Information
If you need to contact ASRock Industrial or want to know more about ASRock Industrial,
you’re welcome to visit ASRock Industrial’s website at www.asrockind.com ; or you may
contact your dealer for further information.
ASRock Industrial Incorporation
Email: [email protected]
.

Contents
Chapter 1 Introduction 1
1.1 Key Features 1
1.2 Package List 3
1.3 Specications 5
1.4 Dimensions 13
1.5 Block Diagram 21
Chapter 2 System Overview 23
2.1 System Front Panel 23
2.1.1 Control Panel Buttons and LED Indicators 25
2.1.2 I/O Connectors 27
2.2 HDD Panel 28
2.3 Drive Tray LEDs 29
Chapter 3 Hardware Installation and Maintenance 30
3.1 How to Install the Hard Disk Drive 31
3.2 How to Install the SIM Card 33
3.3 How to Disassemble the System 35
3.4 How to Install the Desk Mount Bracket 40
3.5 How to Install the Rubber Foot 41
Chapter 4 Motherboard 42
4.1 Motherboard Layout 42
Chapter 5 UEFI Setup Utility 50
5.1 Introduction 50
5.2 Main Screen 51

5.3 Advanced Screen 52
5.3.1 CPU Conguration 53
5.3.2 Chipset Conguration 55
5.3.3 Intel(R) Time Coordinated Computing 57
5.3.4 Storage Conguration 59
5.3.5 Super IO Conguration 60
5.3.6 ACPI Conguration 62
5.3.7 USB Conguration 63
5.3.8 Trusted Computing 64
5.4 Hardware Health Event Monitoring Screen 65
5.5 Security Screen 66
5.6 Boot Screen 67
5.7 Exit Screen 68

iEPF-9010S-EY4 / iEPF-9012S-EY4
iEP-9010E / iEP-9012E
PB 1
English
Chapter 1 Introduction
ank you for purchasing iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP-9010E / iEP-9012E,
a reliable barebone system produced under ASRock Industrial’s consistently stringent
quality control. It delivers excellent performance with robust design conforming to
ASRock Industrial’s commitment to quality and endurance.
1.1 Key Features
iEPF-9010S -EY4
• Intel® 12th Gen Core™ Processors with R680E Chipset
• 4 x 260-pin DDR4 SO-DIMM up to 128GB (32GB per DIMM)
• 1 x PCIe x16 (PCIe Gen4) or 2 x PCIe x8 (PCIe Gen4), 2 x PCIe x4 (PCIe Gen4)
• 1 x M.2 Key M, 1 x M.2 Key B, 1 x M.2 Key E, 2 x Mini PCIe
• 6 x USB 3.2 Gen2x1, 6 x COM, 4 x SATA3, 8 x DI, 8 x DO
• 5 x Intel 2.5G LAN (2 support PoE, 1 supports vPro)
• 1 x Displayport, 1 x HDMI 2.0b, 1 x VGA
• Powerful Edge AI acceleration enabled by the most exible mechanical, thermal, and
power design, with support for 275mm x 111.15 mm (L x H) max. and up to 255W
graphic cards
iEPF-9012S-EY4
• Intel® 12th Gen Core™ Processors with H610 Chipset
• 2 x 260-pin DDR4 SO-DIMM up to 64GB (32GB per DIMM)
• 1 x PCIe x16 (PCIe Gen4), 1 x M.2 Key B, 1 x M.2 Key E, 2 x Mini PCIe
• 2 x USB 3.2 Gen2x1, 2 x USB 3.2 Gen1x1, 2 x USB 2.0, 6 x COM, 4 x SATA3, 8 x DI, 8 x
DO
• 4 x Intel 2.5G LAN (2 support PoE)
• 1 x Displayport, 1 x HDMI 2.0b, 1 x VGA
• Powerful Edge AI acceleration enabled by the most exible mechanical, thermal, and
Because the hardware specications might be updated, the content of this documentation
will be subject to change without notice. In case any modications of this documentation
occur, the updated version will be available on ASRock Industrial’s website without further
notice. If you require technical support related to this product, please visit our website for
specic information about the model you are using.
ASRock Industrial’s Website: www.ASRockInd.com
e illustrations shown in this manual are examples only. e actual system may dier
depending on the product model you purchsed.

2 3
English
power design, with support for 275mm x 111.15 mm (L x H) max. and up to 255W
graphic cards
iEP-9010E
• Intel® 12th Gen Core™ Processors with R680E Chipset
• 4 x 260-pin DDR4 SO-DIMM up to 128GB (32GB per DIMM)
• 1 x M.2 Key M, 1 x M.2 Key B, 1 x M.2 Key E, 2 x Mini PCIe
• 6 x USB 3.2 Gen2x1, 6 x COM, 4 x SATA3, 8 x DI, 8 x DO
• 5 x Intel 2.5G LAN (2 support PoE, 1 supports vPro)
• 1 x Displayport, 1 x HDMI 2.0b, 1 x VGA
iEP-9012E
• Intel® 12th Gen Core™ Processors with H610 Chipset
• 2 x 260-pin DDR4 SO-DIMM up to 64GB (32GB per DIMM)
• 1 x M.2 Key B, 1 x M.2 Key E, 2 x Mini PCIe
• 2 x USB 3.2 Gen2x1, 2 x USB 3.2 Gen1x1, 2 x USB 2.0, 6 x COM, 4 x SATA3, 8 x DI, 8 x
DO
• 4 x Intel 2.5G LAN (2 support PoE)
e LAN ports also supporting IEEE 802.3AT PoE (PoE output max 30W/port) only use
12~36V DC insource.

iEPF-9010S-EY4 / iEPF-9012S-EY4
iEP-9010E / iEP-9012E
2 3
English
1.2 Package List
Note:
Please refer to the following for more information about the adapter:
330W Power adapter
- Input voltage: 100-240 Vac
- Input frequency: 47-63 Hz(±1Hz)
- Rating output current: 13.75A
- Rating output voltage: 24.0 V ±5%
Item Quantity
iEPF-9010S Series / iEP-9010E Series 1
Rubber foot 4
M3x8L Round Head Bolts for Rubber foot 4
Desk Mount 2
M3x5L Countersunk Screws for Desk Mount 8
M4x10L Round Head Bolts for Desk Mount 4
M3x4L Round Head Bolts for SODIMM Bracket 4
Terminal Block 1X3P ST 7.62m 1
Terminal Block 1X3P ST 5.0m 1
Terminal Block 1X10P ST 3.5m 2
Screw for M.2 I-Head M2*2 3
Screw for MiniPCIe 3.7xM2.0x3.3L 2
Screw M3*4mm for 2.5” Tray 16
M.2 Heatsink 1
SODIMM Bracket w/Mylar 2
SODIMM Heatsink 2
Nut M2 H=3.35mm w/read(Hex) 1
Option: Power Adapter 330W, FSP330-AAAN3 /9NA3300208 1
1. If any items are missing or appear damaged, contact your authorized dealer.
2. Based on dierent conguration, package list may be dierent.

4 5
English
Actual power consumption may dier based on dierent applications and dierent hard-
ware congurations. Sucient power for the entire system is required to meet these spec-
ications. We recommend that 330W adapter (Certied adapter, Output: 24Vdc,13.75A)
is used if there is no PCIe or PCI add-on cards assembled on the iEPF-9010S-EY4. Users
may use a DC source instead of the optional 330W adapter (Certied adapter, Output:
24Vdc,13.75A) when power consumption is over 330W in an environment where the
temperature is 40OC and DC source should be within 9~36 VDC/30~18A.
WARNING! Use ONLY approved NRTL LISTED ITE power supply with electrical ratings.

iEPF-9010S-EY4 / iEPF-9012S-EY4
iEP-9010E / iEP-9012E
4 5
English
1.3 Specications
iEPF-9010S -EY4
Processor System
CPU
Chipset
Socket
Intel®12th Gen Core™, Pentium or CeleronProcessors
Intel®R680E
LGA 1700
Memory
Technology
Capacity
Socket
Dual Channel DDR4 2933MHz
(ECC memory supported by R680E + SelectedCPU)
128 GB (32 GB per DIMM)
4 x 260-pin SO-DIMM
Graphics
Controller
DisplayPort
HDMI
VGA
Intel®UHD Graphics
DisplayPort 1.4a , DP++
Max resolution up to 4096x2160@60Hz
HDMI 2.0b
Max resolution up to 4096x2160@60Hz
Max resolution up to1920x1200@60Hz
Audio
Interface Realtek ALC897, High Definition Audio.
Ethernet
Controller/ Speed
Connector
5 x Intel 2.5G LAN (2 support PoE, each port supports IEEE 802.3AF PoE,
PoE output max.15.4W/port), (1 supports vPro)
5 x RJ45
Expansion Slot
PCIe
Mini-PCIe
RF& Antenna
M.2
SIM Socket
1 x PCIeGen4 x16 (single x16 or dual x8), PCIe x16 slot with
default power cable can support up to180W graphiccard
(275mm x 111.15 mm (L x H), dual slot width max)..
Graphic card can be upto 255W with optional VGA module
1 x PCIeGen4 x8 (shared with dual x8)
2 x PCIeGen4 x4
2 x Full/Half size with PCIe Gen3 x1 and USB 2.0
8 x SMA connector hole reserved
1 x M.2 (Key E, 2230) with CNVI/PCIe Gen3 x1
and USB2.0 for Wi-Fi/BT module
1 x M.2 (Key B, 2280/3042/3052)
with PCIe Gen3 x1 / USB3.2 Gen1x1 for 4G/ 5G
2 x NanoSIM Card slot
(1 connected to Mini PCIe, 1 connected toM.2 Key B)

6 7
English
Environment
Operating Temperature
Storage Temperature
Humidity
Shock
Vibration
ESD
EMC
Safety
35W CPU: -40°C~75°C ( -40°F~167°F)
46W~65W CPU: -40°C~55°C ( -40°F~131°F)
(with FAN inside) (w/ air flow 0.5~0.8 m/s)
-40°C~85°C( -40°F~185°F)
~95% @ 40°C (non-condensing)
Operating: 50 G, half sine11ms duratiowith SSD
Operating: 5 Grms,5-500 Hz, 3 axes with SSD
Contact +/-4kV, Air +/-8kV
EN61000-6-4/-2, CE & FCC Class A
LVD
Watchdog Timer
Output
Interval
From Super I/O todrag RESETCON#
256 Segments, 0, 1, 2, ...255sec
Storage
M.2
SATA
CFast (Option)
1 x M.2 (Key M, 2280) with Gen4/Gen3 x4 for NVMe SSD
4 x SATA3 (6Gb/s),support RAID 0/1/5/10
4 x 2.5" HDD/SSD Tray
1 x Type II socket (Shared with SATA3)
Power Requirements
Input PWR9V~36V VDC with Ignitioncontroland remote power on/off switch.
80V Surge Protection,OVP, UVP, OCP andreverse protection
Ignition Power Input w/ 13-mode condition
Front I/O
DisplayPort
HDMI
VGA
Ethernet
USB
Audio
COM
DIO
1
1
1
5 x 2.5G LAN
6 x USB 3.2 Gen2x1, 1 x USB2.0 internal connectorw/ lockfunction
1 x Mic-in, 1 x Line-out
4 x RS232/422/485
2 x RS232
8DIs/8DOs
Mechanical
Construction
Mounting
Dimensions
Net Weight
Aluminum heatsink + Metal chassis
Desk Mount
202mm (W) x 290mm (D) x 209.3mm (H) (7.95" x 11.42"x 8.24")
10kg
Others
OS Support
SW Support
TPM
Real-Time Enablement
Windows 10 & Linux
ACRN (https://projectacrn.org/)
TPM 2.0
TSN, TCC support under YOCTO

iEPF-9010S-EY4 / iEPF-9012S-EY4
iEP-9010E / iEP-9012E
6 7
English
iEPF-9012S-EY4
Processor System
CPU
Chipset
Socket
Intel®12th Gen Core™, Pentium or CeleronProcessors
Intel®H610
LGA 1700
Memory
Technology
Capacity
Socket
Dual Channel DDR4 2933MHz
64 GB (32 GB perDIMM)
2 x 260-pin SO-DIMM
Graphics
Controller
DisplayPort
HDMI
VGA
Intel®UHD Graphics
DisplayPort 1.4a , DP++
Max resolution up to 4096x2160@60Hz
HDMI 2.0b
Max resolution up to 4096x2160@60Hz
Max resolution up to1920x1200@60Hz
Audio
Interface Realtek ALC897, High Definition Audio.
Storage
SATA
CFast (Option)
4 x SATA3 (6Gb/s)
4 x 2.5" HDD/SSD Tray
1 x Type II socket (Shared with SATA3)
Expansion Slot
PCIe
Mini-PCIe
RF& Antenna
M.2
SIM Socket
1 x PCIeGen4 x16*, PCIe x16 slot with default power cable
can support up to 180W graphic card
(275mm x 111.15 mm (L x H), dual slot width max)..
Graphic card can be upto 255W with optional VGA module
1 x Full/Half size with PCIe Gen3 x1 and USB 2.0
1 x Full/Halfsize with PCIeGen3 x1
8 x SMA connector hole reserved
1 x M.2 (Key E, 2230) with CNVI/PCIe Gen3 x1
and USB2.0 for Wi-Fi/BT module
1 x M.2 (Key B, 2280/3042/3052) with PCIe Gen3 x1 /
USB2.0 for 4G / 5G
2 x NanoSIM Card slot
(1 connected to Mini PCIe, 1 connected toM.2 Key B)
Ethernet
Controller/ Speed
Connector
4xIntel 2.5G LAN(2 support PoE, PoE output max.15.4W/port,
eachport supports IEEE802.3AF PoE)
4 x RJ45

8 9
English
Environment
Operating Temperature
Storage Temperature
Humidity
Shock
Vibration
ESD
EMC
Safety
35W CPU: -40°C~75°C ( -40°F~167°F)
46W~65W CPU: -40°C~55°C ( -40°F~131°F)
(with FAN inside) (w/ air flow 0.5~0.8 m/s)
-40°C~85°C ( -40°F~185°F)
~95% @ 40°C (non-condensing)
Operating: 50 G, half sine11ms duration with SSD
Operating: 5 Grms,5-500 Hz, 3 axes with SSD
Contact +/-4kV, Air +/-8kV
EN61000-6-4/-2, CE & FCC Class A
LVD
Mechanical
Construction
Mounting
Dimensions
Net Weight
Aluminum heatsink + Metal chassis
Desk Mount
202mm (W) x 290mm (D) x 209.3mm (H) (7.95" x 11.42"x 8.24")
10kg
Watchdog Timer
Output
Interval
From Super I/O todrag RESETCON#
256 Segments, 0, 1, 2, ...255sec
Power Requirements
Input PWR9V~36V VDC with Ignitioncontroland remote power on/off switch.
80V SurgeProtection, OVP, UVP, OCP andreverse protection
Ignition Power Input w/ 13-mode condition
Rear I/O
DisplayPort
HDMI
VGA
Ethernet
USB
Audio
COM
DIO
1
1
1
4 x 2.5G LAN
2xUSB 3.2 Gen2x1, 2 xUSB 3.2 Gen1x1, 2 xUSB2.0,
1xUSB2.0internal connector w/lockfunction
1 x Mic-in, 1 x Line-out
4 x RS232/422/485
2 x RS232
8DIs/8DOs
Others
OS Support
TPM
Real-Time Enablement
Windows 10 & Linux
TPM 2.0
TSN, TCC support under YOCTO
*The PCIe x16 slot locates at the second slot from the right hand side.

iEPF-9010S-EY4 / iEPF-9012S-EY4
iEP-9010E / iEP-9012E
8 9
English
iEP-9010E
Processor System
CPU
Chipset
Socket
Intel®12th Gen Core™, Pentium or CeleronProcessors
Intel®R680E
LGA 1700
Memory
Technology
Capacity
Socket
Dual Channel DDR4 2933MHz
(ECC memory supported by R680E + SelectedCPU)
128 GB (32 GB per DIMM)
4 x 260-pin SO-DIMM
Graphics
Controller
DisplayPort
HDMI
VGA
Intel®UHD Graphics
DisplayPort 1.4a , DP++
Max resolution up to 4096x2160@60Hz
HDMI 2.0b
Max resolution up to 4096x2160@60Hz
Max resolution up to1920x1200@60Hz
Audio
Interface Realtek ALC897, High Definition Audio.
Ethernet
Controller/ Speed
Connector
5 x Intel 2.5G LAN(2 support PoE, each port supports IEEE802.3AFPoE,
PoE output max.15.4W/port), (1 supports vPro)
5 x RJ45
Expansion Slot
Mini-PCIe
RF& Antenna
M.2
SIM Socket
2 x Full/Half size with PCIe Gen3 x1 and USB 2.0
8 x SMA connector hole reserved
1 x M.2 (Key E, 2230) with CNVI/PCIe Gen3 x1
and USB2.0 for Wi-Fi/BT module
1 x M.2 (Key B, 2280/3042/3052)
with PCIe Gen3 x1 / USB3.2 Gen1x1 for 4G / 5G
2 x NanoSIM Card slot
(1 connected to Mini PCIe, 1 connected to M.2 Key B)
Storage
M.2
SATA
CFast (Option)
1 x M.2 (Key M, 2280) with Gen4/Gen3 x4 for NVMe SSD
4 x SATA3 (6Gb/s), support RAID 0/1/5/10
4 x 2.5" HDD/SSD Tray
1 x Type IIsocket (Shared with SATA3)

10 11
English
Environment
Operating Temperature
Storage Temperature
Humidity
Shock
Vibration
ESD
EMC
Safety
35W CPU: -40°C~70°C ( -40°F~158°F)
46W~65W CPU: -40°C~50°C ( -40°F~122°F)
(w/ air flow 0.5~0.8 m/s)
-40°C~85°C( -40°F~185°F)
~95% @ 40°C (non-condensing)
Operating: 50G, half sine 11ms duration with SSD
Operating: 5 Grms,5-500 Hz, 3 axes with SSD
Contact +/-4kV, Air +/-8kV
EN61000-6-4/-2, CE & FCC Class A
LVD
Watchdog Timer
Output
Interval
From Super I/O todrag RESETCON#
256 Segments, 0, 1, 2, ...255sec
Power Requirements
Input PWR9V~36V VDC with Ignitioncontroland remote power on/off switch.
80V Surge Protection,OVP, UVP, OCP andreverse protection
Ignition Power Input w/ 13-mode condition
Rear I/O
DisplayPort
HDMI
VGA
Ethernet
USB
Audio
COM
DIO
1
1
1
5 x 2.5G LAN
6 x USB 3.2 Gen2x1, 1 x USB2.0 internal connector w/ lock function
1 x Mic-in, 1 x Line-out
4 x RS232/422/485
2 x RS232
8DIs/8DOs
Mechanical
Construction
Mounting
Dimensions
Net Weight
Aluminum heatsink + Metal chassis
Desk Mount
202mm (W) x 244mm (D) x 108.7mm (H) (7.95" x 9.61" x 4.28")
6.5kg
Others
OS Support
SW Support
TPM
Real-Time Enablement
Windows 10 & Linux
ACRN (https://projectacrn.org/)
TPM 2.0
TSN, TCC support under YOCTO

iEPF-9010S-EY4 / iEPF-9012S-EY4
iEP-9010E / iEP-9012E
10 11
English
iEP-9012E
Processor System
CPU
Chipset
Socket
Intel®12th Gen Core™, Pentium or CeleronProcessors
Intel®H610
LGA 1700
Audio
Interface Realtek ALC897, High Definition Audio.
Storage
SATA
CFast (Option)
4 x SATA3 (6Gb/s)
4 x 2.5" HDD/SSD Tray
1 x Type II socket (Shared with SATA3)
Memory
Technology
Capacity
Socket
Dual Channel DDR4 2933MHz
64 GB (32 GB perDIMM)
2 x 260-pin SO-DIMM
Graphics
Controller
DisplayPort
HDMI
VGA
Intel®UHD Graphics
DisplayPort 1.4a , DP++
Max resolution up to 4096x2160@60Hz
HDMI 2.0b
Max resolution up to 4096x2160@60Hz
Max resolution up to1920x1200@60Hz
Ethernet
Controller/ Speed
Connector
4 x Intel 2.5G LAN (2 support PoE, each port supports IEEE802.3AF PoE,
PoE output max.15.4W/port)
4x RJ45
Expansion Slot
Mini-PCIe
RF& Antenna
M.2
SIM Socket
1 x Full/Half size with PCIe Gen3 x1 and USB 2.0
1 x Full/Halfsize with PCIeGen3 x1
8 x SMA connector hole reserved
1 x M.2 (Key E, 2230) with CNVI/PCIe Gen3 x1
and USB2.0 for Wi-Fi/BT module
1 x M.2 (Key B, 2280/3042/3052)
with PCIe Gen3 x1 / USB2.0 for 4G / 5G
2 x NanoSIM Card slot
(1 connected to Mini PCIe, 1 connected to M.2 Key B)

12 13
English
Environment
Operating Temperature
Storage Temperature
Humidity
Shock
Vibration
ESD
EMC
Safety
35W CPU: -40°C~70°C ( -40°F~158°F)
46W~65W CPU: -40°C~50°C ( -40°F~122°F)
(w/ air flow 0.5~0.8 m/s)
-40°C~85°C( -40°F~185°F)
~95% @ 40°C (non-condensing)
Operating: 50 G, half sine11ms duration with SSD
Operating: 5 Grms,5-500 Hz, 3 axes with SSD
Contact +/-4kV, Air +/-8kV
EN61000-6-4/-2, CE & FCC Class A
LVD
Mechanical
Construction
Mounting
Dimensions
Net Weight
Aluminum heatsink + Metal chassis
Desk Mount
202mm (W) x 244mm (D) x 108.7mm (H) (7.95" x 9.61" x 4.28")
6.5kg
Watchdog Timer
Output
Interval
From Super I/O todrag RESETCON#
256 Segments, 0, 1, 2, ...255sec
Power Requirements
Input PWR9V~36V VDC with Ignitioncontroland remote power on/off switch.
80V Surge Protection,OVP, UVP, OCP andreverse protection
Ignition Power Input w/ 13-mode condition
Rear I/O
DisplayPort
HDMI
VGA
Ethernet
USB
Audio
COM
DIO
1
1
1
4 x 2.5G LAN
1 x Mic-in, 1 x Line-out
4 x RS232/422/485
2 x RS232
8DIs/8DOs
Others
OS Support
TPM
Real-Time Enablement
Windows 10 & Linux
TPM 2.0
TSN, TCC support under YOCTO
2 x USB 3.2 Gen2x1, 2 x USB 3.2 Gen1x1, 2 x USB 2.0,
1 x USB2.0 internal connector w/ lock function
