Astonica 50105605 User manual

IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACT CUSTOMER SERVICE AT
1-888-424-3354
100107rev1
Read the instructions and precautions before use of this product
Please keep this instruction manual for future reference
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACT CONSUMER SUPPORT AT
1-888-424-3354
OR
IF YOU ARE A STORE MANAGER OR EMPLOYEE IN NEED OF ASSISTANCE CALL
1-888-851-5569
PLEASE HAVE YOUR STORE NUMBER READY
Limited Warranty
World Factory, Inc. Products for Home Use
World Factory, Inc. (Seller) warrants to the original Buyer only, that each Astonica Product will be free
from defects in material and workmanship for a period of one (1) year from date of purchase.
SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH
ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE
SELLER WHICH HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY
FROM REPAIRS OR ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER
MAINTENANCE, NEGLECT OR ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. This
warranty does not apply to damage, heat-induced coloration changes, scratching or alteration due to
normal use or weathering. To make a claim under this Limited Warranty, you must return the complete
product with proof of purchase, transportation prepaid, to any World Factory, Inc. authorized service
center. Call 1-888-424-3354 for the location of the nearest authorized service center.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS RELATED
TO THIS PRODUCT. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1)
YEAR FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY FOR
LOSS OF PROFITS, ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such
provision shall not affect any other provision herein, this Limited Warranty shall be construed as if
such invalid and/or unenforceable provision had never been contained herein.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all
prior agreements, arrangements, or understandings between the parties relating to product warranty.
®
Made in China
©2006 World Factory, Inc.
Distributed by:
World Factory, Inc.
Coppell, TX 75019
Model No: 50105605
Samoa Cushion Cast Curl Design
Hi Back Dining Chair
Instruction Manual
Due to ongoing product development
the actual product or products may vary from
the illustrations or photos shown within this manual.
NOTE: This product is intended for residential, non-commercial use.

ASSEMBLY INSTRUCTIONS
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
Figure 1
Figure 2
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER. CONTACT CUSTOMER SERVICE AT
1-888-424-3354.
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
A Chair Back 1
B Seat 1
C Left Leg/Arm  1
D Right Leg/Arm  1
E M8 Studs 4
F M8 Bolts 4
G Flat Washer 8
H Lock Washers 8
I Hex Nuts 4
Parts Detail
NOTE: This product is intended for residential, non-commercial use.
12
B
B
A
C
C
D
F
E
D
E
E
G
G
G
H
H
H
I
I
I
D
Install Studs to Left and Right Leg/Arms
(See Figure 1)
1.Install 2 threaded M8 Studs (E) into Left
 Leg/Arm (C) with slotted end of stud
 pointing outwards.
2.Repeat Step 1 with the Right Leg/Arm (D).
Attach Seat to Right and Left Leg/Arm
of Chair
(See Figure 2)
1.Slide the Seat (B) onto studs in the Right
 Leg/Arm through the bolt holes in mounting
 tabs located on the side of the Seat (B).
 Secure the Seat to the studs using Flat
 Washer (G) first, then Lock washer (H) and
 Hex Nut (I). Finger tighten the Hex Nuts (I).
 Do not over tighten.
2.Repeat Step 1 with the Left Leg/Arm (C).
Attach Back to Seat and Leg/Arm Assembly
(See Figure 3)
1.Position the Chair Back (A) between the
 Left (C) and Right (D) Leg/Arms at the rear
 of the seat. Place Lock Washers (H) onto
 the M8 Bolts (F) first, and then place Flat
 Washers (G) onto the M8 Bolts. Thread the
 M8 Bolts through the 4 holes located inside
 of the Chair Back near the bottom and into
 the 4 holes inside the Leg/Arm assembly.
 Tighten the M8 Bolts until the bolt is seated
 securely in the Leg/Arms with an open end
 wrench. Do not force the bolts to turn . This
 will strip the threads.

2.Tighten the Hex Nuts (I) on the studs under
 the seat.
Figure 3
D
B
A
C
H
G
F
