Astonica 40201035 User manual

IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACT CUSTOMER SERVICE AT
1-888-424-3354
120906rev1
Read the instructions and precautions before use of this product
Please keep this instruction manual for future reference
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACT CONSUMER SUPPORT AT
1-888-424-3354
OR
IF YOU ARE A STORE MANAGER OR EMPLOYEE IN NEED OF ASSISTANCE CALL
1-888-851-5569
PLEASE HAVE YOUR STORE NUMBER READY
Limited Warranty
World Factory, Inc.®Products for Home Use
World Factory, Inc.®(Seller) warrants to the original Buyer only, that each Astonica®Product will be
free from defects in material and workmanship for a period of one (1) year from date of purchase.
SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH
ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE
SELLER WHICH HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY
FROM REPAIRS OR ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER
MAINTENANCE, NEGLECT OR ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. This
warranty does not apply to damage, heat-induced coloration changes, scratching or alteration due to
normal use or weathering. To make a claim under this Limited Warranty, you must return the complete
product with proof of purchase, transportation prepaid, to any World Factory, Inc.®authorized service
center. Call 1-888-424-3354 for the location of the nearest authorized service center.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS RELATED
TO THIS PRODUCT. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1)
YEAR FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY FOR
LOSS OF PROFITS, ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such
provision shall not affect any other provision herein, this Limited Warranty shall be construed as if
such invalid and/or unenforceable provision had never been contained herein.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all
prior agreements, arrangements, or understandings between the parties relating to product warranty.
®
Made in China
©2006 World Factory, Inc.
Distributed by:
World Factory, Inc.
Coppell, TX 75019
Model No: 40201035
Wishing Well Electric Fountain
Instruction Manual
Due to ongoing product development
the actual product or products may vary from
the illustrations or photos shown within this manual.
NOTE: This product is intended for residential, non-commercial use.

 AMP Load  Volts Extension Cord Length
  120V 25'  50'  100'  150'
     AWG
  1-5  18  16 16 14
  6-10  18  16  14  12
 10-12  14  14  14  12
 12-16  14  12  Not recommended
Table 1. Minimum Recommended Extension Cord Gauge (AWG) Chart
WARNING! RISK OF ELECTRICAL SHOCK. Read and understand all instructions.
 Failure to follow all instructions listed below, may result in electrical shock,
 fire and/or serious personal injury.
Electrical Safety
WARNING! RISK OF ELECTRICAL SHOCK. This product must be plugged into an outlet
 properly installed and grounded in accordance with all codes and ordinances. Never remove
 the grounding prong or modify the plug in any way. Do not use adaptor plugs. Check with a
 qualified electrician if you are in doubt as to whether the outlet is properly grounded. If product
 should electrically malfunction or break down grounding provides a low resistance path to
 carry electricity away from the user.
Grounding Instructions
DANGER: IMPROPER INSTALLATION OF THE GROUNDING PLUG CAN RESULT IN A RISK OF
 ELECTRICAL SHOCK. Check with a qualified electrician or serviceman if the grounding
 instructions are not completely understood, or if doubt as to weather the product is properly
 grounded.
1. Do not modify the plug provided; if it will not fit the outlet, have a proper outlet
 installed by a qualified electrician.
2. Do not use any type of adapter with this product.
3. This fountain must be plugged into a 3-wire, 3-prong outlet that is properly working
 and has been installed and grounded in accordance with all local, state or federal codes
 and ordinances.
Extension Cords
1.Make sure your extension cord is in good condition.
2.When using an extension cord, be sure to use one heavy enough to carry the current your
 product will draw. An undersized cord will cause a drop in line voltage resulting in loss of
 power and overheating. Reference Table 1 for the correct size to use depending on cord
 length and nameplate Ampere rating. If in doubt, use the next heavier gage. The smaller the
 gage number, the heavier the cord.
Outdoor Use Extension Cords.
1.When product is used outdoors, use only extension cords intended for outdoor use
 and so marked.
2.Use only UL listed extension cords. Inspect extension cord before use and never use
 damaged or altered extension cords.
3.Follow extension cord manufacturer safety instruction.
1
SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Figure 4
4
Install Water Pump
1.(SEE FIGURE 4) Place water pump (C)
 into center of well bottom (B).
2.Attach plastic tubing (Q) to top of
 water pump (C). Press water pump
 downward to seat in bottom of well.
CAUTION: Read and understand all
 safety instruction before operating
 water pump.
Adjust Speed of Water Flow
 NOTE: The water flow speed can be
 adjusted at this time. Further adjustments
 may be necessary once water fountain has
 been assembled and tested.
1.Turn adjustment lever on pump (C) towards
 "--" or "min" to decrease water flow,
 or away from "--" or "min" to increase
 water flow.
Fill Fountain with Water
NOTE: Do not plug in the pump before
 filling well with water. Running the pump
 without water may damage pump.
1.Fill bottom well (B) with water.
2.Plug power cord from water pump into
 properly grounded 120V AC outlet.
3.Water should start to flow from water bucket
 into water well. See section entitled
 "Maintenance" if water is not flowing.
Maintenance
CAUTION: Never allow pump to run without water.
1.Check water level periodically, add water when necessary.
2.If water is not flowing, check pump (C), plastic tubing (Q) for clogs.
NOTE: Pump may build up calcium after a long period of time and stop running when tap water
 is used. Any calcium remover can be used to clean pump.
C
QB

PARTS LIST
PART # DESCRIPTION QUANTITY
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER. CONTACT CUSTOMER SERVICE AT
1-888-424-3354
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
ASSEMBLY INSTRUCTIONS
A Roof 1
B Bottom, Well 1
C Pump 1
D Water Bucket 1
E
Roof Support 2
F
Side Support, Bucket 1
G Side Support 1
H Mock Handle 1

J Dowel 1
K Hex Nut 6mm 4

L Washer 6mm 8

M Bolt 6 x 75mm 4

NWood Screw 3.5 x 30mm 6

P Wood Screw 3 x 16mm 4

Q Plastic Tubing 1
Figure 1
 CAUTION: Do not overtighten fasteners.
Attach Side Supports to Bottom, Well
1.(SEE FIGURE 1) Place bottom, well (B)
 on flat surface.
2.Align side support, bucket (F) with
 predrilled mounting holes at top of
 bottom well (B).
3.Insert bolt (M) through side support, bucket.
 Place washer (L) onto bolt (M) and secure
 support using hex nut (K).
4.Align side support (G) with predrilled
 mounting holes at top of bottom, well (B).
5.Insert bolt (M) through side support (G).
 Place washer (L) onto bolt (M) and secure
 support using hex nut (K).
Attach Roof Supports to Side Supports
1.(SEE FIGURE 2) Place dowel (J) between
 the two roof supports (E) and press into
 exisitng mounting holes.
2.Insert one roof support (E) into mounting
 bracket of side support, bucket (F) and
 the other roof support into mounting
 bracket of side support (G). Secure roof
 supports (E) to side support brackets
 using four small wood screws (P).
3.Attach mock handle (H) to side support (G),
 using two large wood screws (N).
NOTE: This product is intended for residential, non-commercial use.
Parts Detail
2
A
BC
D
E
F G H
JKL
M
N
P
Figure 2
Figure 3
B
F
G
M (4 places)
K
L
E
E
J
N
H
Mounting
Bracket
P (4 places)
FG
A
EE
N
N (4 places)
D
F
Bucket Supports
(Part of Side
Support, Bucket)
Install Water Bucket
1.(SEE FIGURE 3) Attach plastic tubing (Q)
 to bottom of water bucket.
2.Hang bottom of water bucket (D) on
 bucket supports. Tie rope from top of
 bucket handle to dowel (J). Adjust
 length of rope as needed.
Attach Roof to Side Supports
1.(SEE FIGURE 3) Align roof supports (E)
 with sides of roof (A). Attach each roof
 support using two large wood screws,
 (N) for each support.
Q
3
L (4 places)
L (4 places)
K (4 places)
M
L
Q
J
