Astonica 40201116 User manual

Model No. 40201116
2-Tier Brushed Bronze
Bucket Accent Fountain
Instruction Manual
Due to ongoing product development
the actual product or products may vary from
the illustrations or photos shown within this manual.
NOTE: This product is intended for residential, non-commercial use.
040710rev1
Read the instructions and precautions before use of this product
Please keep this instruction manual for future reference
®
Made in China
©2009 World Factory, Inc.
Distributed by:
World Factory, Inc.
Irving, TX 75063
For warranty information, please refer to the back page of
this instruction manual.
Limited Warranty
World Factory, Inc. Products for Home Use
World Factory, Inc. (Seller) warrants to the original Buyer only, that each Astonica Product will be free
from defects in material and workmanship for a period of one (1) year from date of purchase.
SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH
ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE
SELLER WHICH HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY
FROM REPAIRS OR ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER
MAINTENANCE, NEGLECT OR ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. This
warranty does not apply to damage, heat-induced coloration changes, scratching or alteration due to
normal use or weathering. To make a claim under this Limited Warranty, you must return the complete
product with proof of purchase, transportation prepaid, to any World Factory, Inc. authorized service
center. Call 1-888-424-3354 for the location of the nearest authorized service center.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS RELATED
TO THIS PRODUCT. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1) YEAR
FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS,
ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such
provision shall not affect any other provision herein, this Limited Warranty shall be construed as if
such invalid and/or unenforceable provision had never been contained herein.
This warranty gives you special legal rights, and you may also have other rights which vary from state
to state.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all
prior agreements, arrangements, or understandings between the parties relating to product warranty.

A Pump Handle 1
B Pump Spout 1
C Small Platform 1
D Large Platform 1
E Small Tub 1
F Large Tub 1
G Clear Tube 2
H Large Screw 3
I Small Screw 2
J Electric Pump 1
K Medium Screw 8
L Support Post 1
ELECTRICAL SAFETY INSTRUCTIONS
WARNING! ELECTRICAL SHOCK. Read and understand all instructions. Failure to follow all
instructions listed below, may result in electrical shock, fire and/or serious personal injury.
Grounding Instructions
This fountain must be plugged into a 3-wire, 3-prong outlet that is properly working and has
been installed and grounded in accordance with all local, state or federal codes and ordinances.
DANGER: IMPROPER INSTALLATION OF THE GROUNDING PLUG CAN RESULT IN A RISK OF
ELECTRICAL SHOCK. Check with a qualified electrician or serviceman if the grounding instructions
are not completely understood, or if doubt as to weather the product is properly grounded. Do not
modify the plug provided; if it will not fit the outlet, have a proper outlet installed by a qualified
electrician. Do not use any type of adapter with this product.
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
CAUTION: Do not over tighten fasteners.
ASSEMBLY INSTRUCTIONS
C
B
I
EH
F
A
J
G
Figure 3
Figure 4
Figure 1
12
K
Figure 2
1. (SEE FIGURE 1) Attach the small platform (C)
to smal tub (E) using medium screw (K) as
shown. Attach small tub (E) to the large
platform (D) using small screw (I) as shown.
2. (SEE FIGURE 2) Attach support post (L) to the
underneath of the large platform (D). Attach
the large platform (D) to the large tub (F)
using medium screws (K) in 4 places as
shown.
4. (SEE FIGURE 4) Attach the clear tube (G) to
bottom of the pump spout (B) and place the
other end of the clear tube through the bottom
of the small tub (E) and large platform (D).
Attach the end of the clear tube (G) to the
electric pump (J) at the opening on the top
of the pump as shown.
3. (SEE FIGURE 3) Attach the pump spout (B) to
small platform (C) using large screws (H)
and medium screws (K) in four places as shown.
Attach pump handle (A) to pump spout (B)
using one medium screw (K).
D
D
C
C
E
I
J
G
B
E
F
K
K
D
A
B
H
H
C
F
E
Parts Detail
K
H
K
K
E
D
Outdoor Use Extension Cords.
1. When product is used outdoors, use only extension cords marked for outdoor use.
2. Use only UL listed extension cords. Never use damaged or altered extension cords.
3. Follow extension cord manufacturer safety instruction.
Extension Cords
1. Make sure your extension cord is in good condition.
2. When using extension cords, be sure to use one heavy enough to carry the current your product
requires. An undersized cord will cause a drop in line voltage resulting in power loss and
overheating. Reference Table 1 on the bottom of next page for the correct size to use depending
on cord length and nameplate Ampere rating. If in doubt, use the next heavier gage. The smaller
the gage number, the heavier the cord.
AMP Load Volts Extension Cord Length
120V 25' 50' 100' 150'
AWG
1-5 18 16 16 14
6-10 18 16 14 12
10-12 14 14 14 12
12-16 14 12 Not recommended
Table 1. Minimum Recommended
Extension Cord Gauge (AWG) Chart
L
L
