Asus V8-P8H67E User manual

V-Series P8H67E
ASUS PC (Desktop Barebone)
User’s Manual
R

ii
E6550
Second Edition
March 2011
Copyright © 2011 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK Computer Inc. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product may contain copyrighted software that is licensed under the General Public License (“GPL”)
and under the Lesser General Public License Version (“LGPL”). The GPL and LGPL licensed code in this
product is distributed without any warranty. Copies of these licenses are included in this product.
You may obtain the complete corresponding source code (as dened in the GPL) for the GPL Software,
and/or the complete corresponding source code of the LGPL Software (with the complete machine-
readable “work that uses the Library”) for a period of three years after our last shipment of the product
including the GPL Software and/or LGPL Software, which will be no earlier than December 1, 2011, either
(1) for free by downloading it from http://support.asus.com/download;
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source code
we would be much obliged if you give us a notication to the email address [email protected], stating the
product and describing the problem (please do NOT send large attachments such as source code archives
etc to this email address).

iii
Table of contents
Notices ..........................................................................................................vi
Safety information......................................................................................... vii
About this guide........................................................................................... viii
System package contents..............................................................................ix
Chapter 1: System introduction
1.1 Welcome! ....................................................................................... 1-2
1.2 Front panel .................................................................................... 1-2
1.2.1 V6-P8H67E front panel ................................................. 1-2
1.2.2 V7-P8H67E front panel ................................................... 1-3
1.2.3 V9/V8-P8H67E front panel.............................................. 1-4
1.3 Rear panel...................................................................................... 1-5
Voltage selector.............................................................................. 1-8
1.4 Internal components....................................................................... 1-9
1.5 Qualied Vendors Lists (QVL)...................................................... 1-10
Chapter 2: Starting up
2.1 Installing an operating system........................................................ 2-2
2.2 Powering up ................................................................................... 2-2
2.3 Support DVD information ............................................................... 2-2
2.3.1 Running the support DVD ............................................... 2-3
2.3.2 Utilities menu .................................................................. 2-4
2.3.3 Make Disk menu ............................................................. 2-5
2.3.4 Manual menu .................................................................. 2-5
2.3.5 ASUS Contact information .............................................. 2-6
2.3.6 Other information ............................................................ 2-6
2.4 Software information ...................................................................... 2-8
2.4.1 AI Suite II ........................................................................ 2-8
2.4.2 ASUS AI Manager......................................................... 2-17
Chapter 3: Motherboard info
3.1 Introduction .................................................................................... 3-2
3.2 Motherboard layout ........................................................................ 3-2
3.3 Jumper ........................................................................................... 3-3

iv
Table of contents
3.4 Connectors..................................................................................... 3-4
3.4 MemOK! Switch ............................................................................. 3-9
3.5 DRAM LED................................................................................... 3-10
Chapter 4: BIOS setup
4.1 Managing and updating your BIOS................................................ 4-2
4.1.1 ASUS Update utility ........................................................ 4-3
4.1.2 ASUS EZ Flash 2............................................................ 4-4
4.1.3 ASUS CrashFree BIOS 3................................................ 4-5
4.1.4 ASUS BIOS Updater....................................................... 4-6
4.2 BIOS setup program ...................................................................... 4-9
4.3 Main menu ................................................................................... 4-13
4.3.1 System Language [English] .......................................... 4-13
4.3.2 System Date [Day xx/xx/xxxx]....................................... 4-13
4.3.3 System Time [xx:xx:xx] ................................................. 4-13
4.3.4 Security ......................................................................... 4-13
4.4 Advanced menu ........................................................................... 4-15
4.4.1 CPU Conguration ........................................................ 4-15
4.4.2 System Agent Conguration ......................................... 4-16
4.4.3 PCH Conguration ........................................................ 4-17
4.4.4 SATA Conguration ....................................................... 4-17
4.4.5 USB Conguration ........................................................ 4-18
4.4.6 Onboard Devices Conguration.................................... 4-18
4.4.7 APM .............................................................................. 4-19
4.5 Monitor menu ............................................................................... 4-20
4.5.1 CPU Temperature / MB Temperature [xxxºC/xxxºF]...... 4-20
4.5.2 CPU / Chassis / Power Fan Speed [xxxx RPM] or
[Ignore] / [N/A]............................................................... 4-20
4.5.3 CPU Q-Fan Control [Enabled] ...................................... 4-21
4.5.4 Chassis Q-Fan Control [Enabled] ................................. 4-21
4.5.5 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage .. 4-21
4.5.6 Anti Surge Support [Enabled] ....................................... 4-21
4.6 Boot menu.................................................................................... 4-22
4.6.1 Bootup NumLock State [On] ......................................... 4-22
4.6.2 Full Screen Logo [Enabled]........................................... 4-22

v
Table of contents
4.6.3 Option ROM Messages [Force BIOS]........................... 4-22
4.6.4 Setup Mode [EZ Mode] ................................................. 4-22
4.6.5 Boot Option Priorities .................................................... 4-23
4.6.6 Boot Override................................................................ 4-23
4.7 Tools menu................................................................................... 4-23
4.7.1 ASUS EZ Flash 2.......................................................... 4-23
4.8 Exit menu ..................................................................................... 4-24
ASUS contact information......................................................................... 4-25

vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
This class B digital apparatus complies with Canadian ICES-003.
WARNING! The use of shielded cables for connection of the monitor to the graphics card
is required to assure compliance with FCC regulations. Changes or modications to this
unit not expressly approved by the party responsible for compliance could void the user’s
authority to operate this equipment.
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://csr.asus.com/english/index.aspx.

vii
Safety information
Electrical safety
• To prevent electric shock hazard, disconnect the power cable from the electric outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
• Before using the product, ensure that all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
VORSICHT: Explosionsgetahr bei unsachgemäßen Austausch der Batterie. Ersatz nur
durch denselben oder einem vom Hersteller empfohlenem ähnljchen Typ. Entsorgung
gebrauchter Batterien nach Angaben des Herstellers.
LASER PRODUCT WARNING
CLASS 1 LASER PRODUCT

viii
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to complete a
task.
CAUTION: Information to prevent damage to the components when trying to
complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.
Where to nd more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS Websites
The ASUS websites worldwide provide updated information on ASUS hardware and
software products. Refer to the ASUS contact information.
2. Optional Documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the
standard package.
About this guide
Audience
This guide provides general information and installation instructions about the ASUS Vintage
V-Series P8H67E barebone system. This guide is intended for experienced users and
integrators with hardware knowledge of personal computers.
How this guide is organized
This guide contains the following parts:
1. Chapter 1: System introduction
This chapter gives a general description of the ASUS
V-Series P8H67E. The chapter lists the system features, including introduction on the
front and rear panel, and internal components.
2. Chapter 2: Starting up
This chapter helps you power up the system and install drivers and utilities from the
support DVD.
3. Chapter 3: Motherboard info
This chapter gives information about the motherboard that comes with the system. This
chapter includes the motherboard layout, jumper settings, and connector locations.
4. Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS Setup menus and
describes the BIOS parameters.

ix
System package contents
Check your V-Series P8H67E system package for the following items.
If any of the items is damaged or missing, contact your retailer immediately.
Item description
1. ASUS V-Series P8H67E barebone system with
• ASUS motherboatd
• Power supply unit
• ASUS chassis
2. Cable
• AC power cable
3. Support DVD
4. Quick Installation Guide
5. Telecom Adapter Card (Optional)
6. Keyboard/Mouse (Optional)

x

R
System introduction
This chapter gives a general description
of the ASUS V-Series P8H67E. The
chapter lists the system features including
introduction on the front and rear panel, and
internal components.
Chapter 1

1-2 Chapter 1: System introduction
1.1 Welcome!
Thank you for choosing the ASUS V-Series P8H67E!
The ASUS V-Series P8H67E is an all-in-one barebone system with a versatile home
entertainment feature.
The system comes in a stylish casing and powered by the ASUS motherboard that supports
the Second Generation Intel®Core™ i7 / Core™ i5 / Core™ i3 processors in the 1155-land
package.
The system supports up to 16 GB of system memory using DDR3-1333/1066 DIMMs. High-
resolution graphics via integrated graphics controller or PCI Express x16 slot, Serial ATA,
USB 2.0/3.0, and 8-channel audio features take you ahead in the world of power computing.
1.2 Front panel
The front panel includes the optical drive bays, power button, and several I/O ports.
1.2.1 V6-P8H67E front panel
R
1
2
3
4
5
6

1-3ASUS V-Series P8H67E
1. Two empty 5.25-inch drive bays. These bays are for 5.25-inch IDE/SATA optical
drives.
2. Two empty 3.5-inch drive bays. These bays are for 3.5-inch hard disk drives.
3. Microphone port. This Mic (pink) port connects a microphone.
4. Headphone port. This Line In (lime) port connects a headphone with a stereo mini-
plug.
5. USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports are available for
connecting USB 2.0 devices such as a mouse, printer, scanner, camera, PDA, and
others.
6. Power button. Press this button to turn the system on.
1.2.2 V7-P8H67E front panel
1
2
4
89
3
6
57
1. Two empty 5.25-inch drive bays. These bays are for 5.25-inch IDE/SATA optical
drives.
2. IEEE1394a port (optional).
3. Power button. Press this button to turn the system on.
4. USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports are available for
connecting USB 2.0 devices such as a mouse, printer, scanner, camera, PDA, and
others.

1-4 Chapter 1: System introduction
5. Microphone port. This Mic (pink) port connects a microphone.
6. Headphone port. This Line In (lime) port connects a headphone with a stereo mini-
plug.
7. CompactFlash® / Microdrive™ card slot
8. Secure Digital™/ Multimedia Card slot
9. MemoryStick® / Memory Stick Pro™ card slot
1.2.3 V9/V8-P8H67E front panel
4
1
8
9
6
2
7
1. USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports are available for
connecting USB 2.0 devices such as a mouse, printer, scanner, camera, PDA, and
others. Two empty 5.25-inch drive bays. These bays are for 5.25-inch IDE/SATA
optical drives.
2. Microphone port. This Mic (pink) port connects a microphone.
3. Headphone port. This Line In (lime) port connects a headphone with a stereo mini-
plug.
4. CompactFlash® / Microdrive™ card slot
5. Secure Digital™/ Multimedia Card slot
6. MemoryStick® / Memory Stick Pro™ card slot
3
5
10

1-5ASUS V-Series P8H67E
7. Power button. Press this button to turn the system on.
8. Optical disk drive eject button. Press this button to eject the optical disk drive tray.
9. Optical disk drive bay.
Optical disk drive bay. There is an optical disk drive in this bay.
10. Optical disk drive bay (empty).Optical disk drive bay (empty). Allows you to install an additional optical disk drive in
this bay.
1.3 Rear panel
The system rear panel includes the power connector and several I/O ports that allow
convenient connection of devices.
Do NOT cover the rear vent , and the ambient temperature is limited up to 35oC to prevent
the system from overheating.
SPDIF OUT
HDMI DVI
1
2
3
4
5
6
4
9 108
131211
14
15
16
17
18
19
20
7

1-6 Chapter 1: System introduction
1. Voltage selector. This switch allows you to adjust the system input voltage according
to the voltage supply in your area. See the section Voltage selector on page 1-8
before adjusting this switch.
2. Power connector. This connector is for the power cable and plug.
3. PS/2 keyboard port. This purple 6-pin connector is for a PS/2 keyboard.
4. USB 2.0 ports 1 ~ 4. These 4-pin Universal Serial Bus (USB) ports are available for
connecting USB 2.0 devices.
5. HDMI port. This port is for a High-Denition Multimedia Interface (HDMI) connector,
and is HDCP compliant allowing playback of HD DVD, Blu-Ray and other protected
content.
6. DVI-D Out port. This port is for any DVI-D compatible device and is HDCP compliant
allowing playback of HD DVD, Blu-Ray and other protected content.
7. USB 3.0 ports 1 ~ 2. These 4-pin Universal Serial Bus (USB) ports are available for
connecting USB 3.0/2.0 devices.
Refer to the audio conguration table on the next page for the function of the audio ports in
2, 4, 6, or 8-channel conguration.
• Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under Windows®
OS environment and after the USB 3.0 driver installation.
• USB 3.0 devices can only be used as data storage only.
• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance for your USB 3.0 devices.
8. Side Speaker Out port (gray). This port connects the side speakers in an 8-channel
audio conguration.
9. Rear Speaker Out port (black). This port connects the rear speakers in a 4-channel,
6-channel, or 8-channel audio conguration.
10. Center/Subwoofer port (orange). This port connects the center/subwoofer speakers.
11. Microphone port (pink). This port connects a microphone.
12. Line Out port (lime). This port connects a headphone or a speaker. In 4-channel, 6-
channel, and 8-channel congurations, the function of this port becomes Front Speaker
Out.
13. Line In port (light blue). This port connects the tape, CD, DVD player, or other audio
sources.

1-7ASUS V-Series P8H67E
Audio 2, 4, 6, or 8-channel conguration
Port Headset
2-channel 4-channel 6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
Gray – – – Side Speaker Out
Activity/Link Speed LED
Status Description Status Description
OFF No link OFF 10 Mbps connection
ORANGE Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1 Gbps connection
LAN port LED indications
SPEED
LED
ACT/LINK
LED
LAN port
14. Expansion slot covers. Remove these covers when installing expansion cards.
15. LAN (RJ-45) port. This port allows gigabit connection to a Local Area Network (LAN)
through a network hub. Refer to the table below for the LAN port LED indications.
16. Chassis fan vent. This vent is for the fan that provides ventilation inside the system
chassis.
17. Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other
VGA-compatible devices.
18. Optical S/PDIF Out port. This port connects an external audio output device via an
optical S/PDIF cable.
19. Power Switch. This switch is for switching on/off the power supply unit.
20. Power supply unit fan vent. This vent is for the PSU fan that provides ventilation
inside the power supply unit.

1-8 Chapter 1: System introduction
Voltage selector
The PSU has a 115 V/230 V voltage selector switch located beside the power connector. Use
this switch to select the appropriate system input voltage according to the voltage supply in
your area.
If the voltage supply in your area is 100-127 V, set this switch to 115 V.
If the voltage supply in your area is 200-240 V, set this switch to 230 V.
Setting the switch to 115V in a 230V environment or 230V in a 115V environment will
seriously damage the system!
115V/230V
Voltage selector

1-9ASUS V-Series P8H67E
1.4 Internal components
The illustration below is the internal view of the system when you remove the chassis cover
and the power supply unit. The installed components are labeled for your reference.
1. Front panel cover
2. 5.25-inch optical drive bays
3. 3.5-inch drive bay
4. Hard disk drive bay
5. Power supply unit
6. CPU socket
7. DIMM sockets
8. ASUS motherboard
9. PCI Express x16 slot (x16 mode)
10. PCI Express x16 slot (x4 mode)
11. PCI slots
12. Metal bracket lock
Refer to the bundled Quick Installation Guide for installing additional system components
and get assistance from professionals when you disassemble or assemble the system.
1
4
2
3
5
6
7
8
9
11
12 10

1-10 Chapter 1: System introduction
1.5 QualiedVendorsLists(QVL)
DDR3-1333 MHz capability
continued on the next page
Vendor Part No. Size SS/
DS Chip Brand Chip NO. Timing Voltage
DIMM
socket
support
(Optional)
A* B* C*
A-Data AD31333001GOU 1GB SS A-Data AD30908C8D-151C E0906 - - •
Apacer 78.A1GC6.9L1 2GB DS APACER AM5D5808DEWSBG - - • • •
Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808FEQSBG 9 - • • •
CORSAIR CM3X1024-1333C9DHX 1GB SS - - 9-9-9-24 1.60V • •
CORSAIR CM3X1024-1333C9 1GB SS - - 9-9-9-24 1.60V • • •
CORSAIR TR3X3G1333C9 G 3GB(3 x 1GB) SS - - 9-9-9-24 1.50V • •
CORSAIR TR3X3G1333C9 G 3GB(3 x 1GB) SS - - 9-9-9-24 1.50V • •
CORSAIR TR3X3G1333C9 3GB(3 x 1GB) SS - - 9-9-9-24 1.50V • • •
CORSAIR CMD24GX3M6A1333C9(XMP) 24GB(6x4GB) DS - - 9-9-9-24 1.60V • • •
CORSAIR CM3X2048-1333C9DHX 2GB DS - - - - • •
CORSAIR CMX8GX3M4A1333C9 8GB(4 x 2GB) DS - - 9-9-9-24 1.50V • • •
Crucial CT12864BA1339.8FF 1GB SS Micron 9FF22D9KPT 9 - • • •
Crucial CT25664BA1339.16FF 2GB DS Micron 9KF27D9KPT 9 - • • •
Crucial BL25664BN1337.16FF (XMP) 6GB(3 x 2GB) DS - - 7-7-7-24 1.65V • • •
ELPIDA EBJ10UE8EDF0-DJ-F 1GB SS ELPIDA J1108EDSE-DJ-F - 1.35V(low
voltage) • • •
ELPIDA EBJ21UE8EDF0-DJ-F 2GB DS ELPIDA J1108EDSE-DJ-F - 1.35V(low
voltage) • •
G.SKILL F3-10600CL8D-2GBHK(XMP) 1GB SS G.SKILL - - - • • •
G.SKILL F3-10666CL7T-3GBPK(XMP) 3GB(3 x 1GB) SS - - 7-7-7-18 1.5~1.6V • • •
G.SKILL F3-10666CL9T-3GBNQ 3GB(3 x 1GB) SS - - 9-9-9-24 1.5~1.6V • •
G.SKILL F3-10600CL8D-4GBHK(XMP) 4GB(2 x 2GB) DS - - 8-8-8-21 1.5-1.6V • •
G.SKILL F3-10666CL8D-4GBECO(XMP) 4GB(2 x 2GB) DS - - 8-8-8-
8-24 XMP 1.35V • •
G.SKILL F3-10666CL7T-6GBPK(XMP) 6GB(3 x 2GB) DS - - 7-7-7-18 1.5~1.6V • • •
G.SKILL F3-10666CL7D-8GBRH(XMP) 8GB(2 x 4GB) DS - - 7-7-7-21 1.5V • • •
GEIL GET316GB1333C9QC 16GB (4x
4GB ) DS - - 9-9-9-24 1.5V • •
GEIL GV32GB1333C9DC 2GB(2 x 1GB) DS - - 9-9-9-24 1.5V • • •
GEIL GG34GB1333C9DC 4GB(2 x 2GB) DS GEIL GL1L128M88BA12N 9-9-9-24 1.3V(low
voltage) • •
GEIL GV34GB1333C9DC 4GB(2 x 2GB) DS - - 9-9-9-24 1.5V • • •
Hynix HMT112U6TFR8A-H9 1GB SS HYNIX H5TC1G83TFRH9A - 1.35V(low
voltage) • • •
Hynix HMT125U6TFR8A-H9 2GB DS HYNIX H5TC1G83TFRH9A - 1.35V(low
voltage) • • •
KINGMAX FLFD45F-B8KL9 1GB SS KINGMAX KKB8FNWBFGNX-27A - - • • •
KINGMAX FLFE85F-C8KM9-NAES 2GB SS KINGMAX KFC8FNMXF-BXX-15A - - • • •
KINGMAX FLFE85F-B8KL9 2GB DS KINGMAX KKB8FNWBFGNX-26A - - • • •
KINGMAX FLFF65F-C8KM9-NEES 4GB DS KINGMAX KFC8FNMXF-BXX-15A - - • • •
Kingston KVR1333D3N9/1G 1GB SS ELPIDA J1108BDBG-DJ-F 9 1.5V • • •
KINGSTON KVR1333D3N9/2G(矮矮) 2GB DS ELPIDA J1108BDBG-DJ-F 9 1.5V • • •
Kingston KVR1333D3N9/2G 2GB DS KTC D1288JPNDPLD9U 9 1.5V • • •
Kingston KVR1333D3N9/2G 2GB DS ELPIDA J1108BDSE-DJ-F 9 1.5V • • •
Kingston KHX1333C7D3K2/4GX(XMP) 4GB(2 x 2GB) DS - - 7 1.65V • • •
Kingston KHX1333C9D3UK2/4GX(XMP) 4GB(2 x 2GB) DS - - 9 XMP 1.25V • • •
KINGSTON KVR1333D3N9/4G(矮矮) 4GB DS HYNIX H5TQ2G83AFRH9C 9 1.5V • • •
KINGSTON KVR1333D3N9/4G 4GB DS Hynix H5TQ2G83AFR - - • • •
MICRON MT4JTF12864AZ-1G4D1 1GB SS MICRON D9LGQ - - • • •
Micron MT8JTF12864AZ-1G4F1 1GB SS Micron 9FF22D9KPT 9 - • • •
MICRON MT8JTF25664AZ-1G4D1 2GB SS MICRON D9LGK - - • • •
Micron MT16JTF25664AZ-1G4F1 2GB DS Micron 9KF27D9KPT 9 - • • •
MICRON MT16JTF51264AZ-1G4D1 4GB DS MICRON D9LGK - - • • •
OCZ OCZ3F13334GK 4GB(2 x 2GB) DS - - 9-9-9-20 1.7V • • •
OCZ OCZ3G13334GK 4GB(2 x 2GB) DS - - 9-9-9-20 1.7V • •
OCZ OCZ3G1333LV4GK 4GB(2 x 2GB) DS - - 9-9-9-20 1.65V • •
OCZ OCZ3P1333LV4GK 4GB(2 x 2GB) DS - - 7-7-7-20 1.65V • • •
OCZ OCZ3RPX1333EB4GK 4GB(2 x 2GB) DS - - 6-5-5-20 1.85V
OCZ OCZ3X13334GK(XMP) 4GB(2 x 2GB) DS - - 7-7-7-20 1.75V • • •
