Asus N43JF User manual

Notebook PC User Manual
October 2010
E6170

2 Notebook PC User Manual
Table of Contents
Chapter 1: Introducing the Notebook PC
About This User’s Manual................................................................................ 6
Notes for This Manual....................................................................................... 6
Safety Precautions ............................................................................................. 7
Preparing your Notebook PC.......................................................................11
Chapter 2: Knowing the parts
Top Side ...............................................................................................................14
Bottom Side........................................................................................................17
Right Side............................................................................................................20
Left Side...............................................................................................................22
Front Side............................................................................................................24
Rear Side..............................................................................................................24
Chapter 3: Getting Started
Power System ....................................................................................................28
Using AC Power...............................................................................................28
Using Battery Power......................................................................................30
Battery Care ......................................................................................................31
Powering ON the Notebook PC.................................................................32
The Power-On Self Test (POST) ..................................................................32
Checking Battery Power...............................................................................34
Charging the Battery Pack...........................................................................35
Power Options.................................................................................................36
Power Management Modes .......................................................................38
Sleep and Hibernate......................................................................................38
Thermal Power Control.................................................................................40
Special Keyboard Functions.........................................................................41
Colored Hot Keys ............................................................................................41
Microsoft Windows Keys..............................................................................43
Keyboard as a Numeric Keypad ...............................................................43
Keyboard as Pointers.....................................................................................44
Multimedia Control Keys (on selected models)...................................45

Notebook PC User Manual 3
Switches and Status Indicators ...................................................................46
Switches.............................................................................................................46
Status Indicators .............................................................................................47
Chapter 4: Using the Notebook PC
Pointing Device.................................................................................................50
Using the Touchpad.......................................................................................51
Touchpad Usage Illustrations.....................................................................52
Caring for the Touchpad ..............................................................................55
Automatic Touchpad Disabling.................................................................55
Storage Devices ................................................................................................57
Optical Drive.....................................................................................................57
Hard Disk Drive................................................................................................61
Memory (RAM).................................................................................................63
Connections.......................................................................................................64
Network Connection.....................................................................................64
Wireless LAN Connection (on selected models) .................................66
Windows Wireless Network Connection................................................68
Bluetooth Wireless Connection(on selected models).......................70
Appendix
Optional Accessories.....................................................................................A-2
Optional Connections.................................................................................A-2
Operating System and Software...............................................................A-3
System BIOS Settings ..................................................................................A-4
Common Problems and Solutions .........................................................A-7
Recovering Your Notebook PC ............................................................... A-13
Using Recovery Partition ....................................................................... A-13
Using Recovery DVD (on selected models)...................................... A-14
DVD-ROM Drive Information................................................................. A-16
Internal Modem Compliancy ................................................................ A-18
Declarations and Safety Statements .................................................... A-22
Federal Communications Commission Statement........................ A-22
FCC Radio Frequency (RF) Exposure Caution Statement............ A-23
Declaration of Conformity(R&TTE directive 1999/5/EC).............. A-23

4 Notebook PC User Manual
CE Marking................................................................................................... A-24
IC Radiation Exposure Statement for Canada ................................. A-24
Wireless Operation Channel for Different Domains...................... A-25
France Restricted Wireless Frequency Bands .................................. A-25
UL Safety Notices....................................................................................... A-27
Power Safety Requirement .................................................................... A-28
TV Tuner Notices (on selected models) ............................................. A-28
REACH ........................................................................................................ A-28
Nordic Lithium Cautions (for lithium-ion batteries)...................... A-29
Optical Drive Safety Information ......................................................... A-30
Laser Safety Information......................................................................... A-30
Service warning label............................................................................... A-30
CDRH Regulations ..................................................................................... A-30
Macrovision Corporation Product Notice......................................... A-31
CTR 21 Approval(for Notebook PC with built-in Modem) .......... A-32
European Union Eco-label...................................................................... A-34
Global Environmental Regulation Compliance
and Declaration ......................................................................................... A-35
Takeback Services...................................................................................... A-35
Copyright Information .............................................................................. A-37
Limitation of Liability................................................................................. A-38
Service and Support................................................................................... A-38

1
Chapter 1:
Introducing the
Notebook PC

6 Notebook PC User Manual
About This User’s Manual
You are reading the Notebook PC User’s Manual.This User’s Manual
provides information regarding the various components in the
Notebook PC and how to use them.The following are major sections
of this User’s Manual:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this User’s Manual.
2. Knowing the Parts
Gives you information on the Notebook PC’s components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PC’s components.
5. Appendix
Introduces you to optional accessories and gives additional
information.
The actual bundled operating system and applications differ by
models and territories.There may be differences between your
Notebook PC and the pictures shown in this manual. Please
accept your Notebook PC as being correct.
Notes for This Manual
A few notes and warnings are used throughout this guide, allowing
you to complete certain tasks safely and effectively.These notes have
different degrees of importance as follows:
WARNING! Important information that must be followed for safe
operation.
IMPORTANT! Vital information that must be followed to prevent
damage to data, components, or persons.
TIP: Tips for completing tasks.
NOTE: Information for special situations.

Notebook PC User Manual 7
Safety Precautions
The following safety precautions will increase the life of the
Notebook PC. Follow all precautions and instructions. Except as
described in this manual, refer all servicing to qualified personnel.
Battery safety warning:
DO NOT throw the
battery in fire. DO NOT
short circuit the contacts.
DO NOT disassemble the
battery.
DO NOT leave the
Notebook PC on your lap
or any part of the body
to prevent discomfort
or injury from heat
exposure.
DO NOT expose to dirty
or dusty environments.
DO NOT operate during a
gas leak.
DO NOT expose to
strong magnetic or
electrical fields.
DO NOT expose to or
use near liquids, rain,
or moisture. DO NOT
use the modem during
electrical storms.
DO NOT press or touch
the display panel. Do not
place together with small
items that may scratch or
enter the Notebook PC.
DO NOT place on
uneven or unstable work
surfaces. Seek servicing
if the casing has been
damaged.
DO NOT place or drop
objects on top and
do not shove any
foreign objects into the
Notebook PC.
Disconnect the AC power and remove the battery pack(s) before
cleaning.Wipe the Notebook PC using a clean cellulose sponge
or chamois cloth dampened with a solution of nonabrasive
detergent and a few drops of warm water and remove any extra
moisture with a dry cloth.

8 Notebook PC User Manual
SAFE TEMP:This
Notebook PC should
only be used in
environments with
ambient temperatures
between 10°C (50°F) and
35°C (95°F).
DO NOT carry or cover
a Notebook PC that
is powered ON with
any materials that will
reduce air circulation
such as a carrying bag.
DO NOT throw the Notebook PC in municipal waste.This
product has been designed to enable proper reuse of parts
and recycling.The symbol of the crossed out wheeled bin
indicates that the product (electrical, electronic equipment
and mercury-containing button cell battery) should not
be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT throw the battery in municipal waste.The symbol
of the crossed out wheeled bin indicates that the battery
should not be placed in municipal waste.
INPUT RATING: Refer to
the rating label on the
bottom of the Notebook
PC and be sure that your
power adapter complies
with the rating.
Incorrect installation
of battery may cause
explosion and damage
the Notebook PC.
DO NOT use damaged
power cords, accessories,
or other peripherals.
DO NOT use strong
solvents such as
thinners, benzene, or
other chemicals on or
near the surface.

Notebook PC User Manual 9
Transportation Precautions
To prepare the Notebook PC for transport, you should turn it OFF
and disconnect all external peripherals to prevent damage to
the connectors.The hard disk drive’s head retracts when the power
is turned OFF to prevent scratching of the hard disk surface during
transport.Therefore, you should not transport the Notebook PC
while the power is still ON. Close the display panel and check that
it is latched securely in the closed position to protect the keyboard
and display panel.
CAUTION! The Notebook PC’s surface is easily dulled if not
properly cared for. Be careful not to rub or scrape the Notebook
PC surfaces.
Cover Your Notebook PC
Purchase a carrying bag to protect the Notebook PC from dirt, water,
shock, and scratches.
Charge Your Batteries
If you intend to use battery power, be sure to fully charge your
battery pack and any optional battery packs before going on long
trips. Remember that the power adapter charges the battery pack as
long as it is plugged into the computer and an AC power source. Be
aware that it takes much longer to charge the battery pack when the
Notebook PC is in use.

10 Notebook PC User Manual
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the
airplane. Most airlines will have restrictions for using electronic
devices. Most airlines will allow electronic use only between and not
during takeoffs and landings.
CAUTION! There are three main types of airport security
devices: X-ray machines (used on items placed on conveyor
belts), magnetic detectors (used on people walking through
security checks), and magnetic wands (hand-held devices used
on people or individual items).You can send your Notebook
PC and diskettes through airport X-ray machines. However, it
is recommended that you do not send your Notebook PC or
diskettes through airport magnetic detectors or expose them to
magnetic wands.

Notebook PC User Manual 11
Preparing your Notebook PC
These are only quick instructions for using your Notebook PC.
Installing the Battery Pack
Connecting the Power Adapter
2
1
3
1
2
3
110V-220V

12 Notebook PC User Manual
Opening the LCD display panel
1. Carefully lift up the display panel with your thumb.
2. Slowly tilt the display panel forward or backward to a
comfortable viewing angle.
Turning on the Power
1. Push and release the power button located beneath the LCD
display panel.
2. Use [Fn]+[F5] or [Fn]+[F6] to adjust the LCD brightness.
OFF ON

2
Chapter 2:
Knowing the parts

14 Notebook PC User Manual
Top Side
OFF ON
Audio by Bang & Olufsen ICEpower R
5
7
6
10
1
2
4
3
11
8
9
Camera Cover Switch (on selected models)
The camera cover switch allows you to open and close the
protective camera cover. Slide the switch to the left to close
the camera cover. Slide the switch to the right to open the
camera cover.
1
The keyboard differs for each territory.

Notebook PC User Manual 15
3
4
5
6
2
Camera
The built-in camera allows picture taking or video
recording. Can be used with video conferencing and other
interactive applications.
Camera Indicator
The camera indicator shows when the built-in camera is in
use.
Microphone (Built-in)
The built-in mono microphone can be used for video
conferencing, voice narrations, or simple audio recordings.
Display Panel
The display panel functions the same as a desktop monitor.
The Notebook PC uses an active matrix TFT LCD, which
provides excellent viewing like that of desktop monitors.
Unlike desktop monitors, the LCD panel does not produce
any radiation or flickering, so it is easier on the eyes. Use
a soft cloth without chemical liquids (use plain water if
necessary) to clean the display panel.
Audio Speaker System
The built-in stereo speaker system allows you to hear audio
without additional attachments.The multimedia sound
system features an integrated digital audio controller
that produces rich, vibrant sound (results improved with
external stereo headphones or speakers). Audio features
are software controlled.
Express Gate Key / Power4Gear Key
When the Notebook PC is powered off, Press this key
to launch Express Gate. Press again in the Express Gate
environment to turn off the Notebook PC. Refer to the
Express Gate User’s Manual for details.
7

16 Notebook PC User Manual
9
10
11
8
Under the Windows OS, this key functions as the
Power4Gear Hybrid key.The key toggles power savings
between various power saving modes.The power saving
modes control many aspects of the Notebook PC to
maximize performance versus battery time. Applying or
removing the power adapter will automatically switch
the system between AC
mode and battery mode.The
selected mode is shown on
the display.
Power Switch
The power switch turns ON and OFF the Notebook PC or
putting the Notebook PC into sleep or hibernation modes.
Actual behavior of the power switch can be customized in
Windows Control Panel “Power Options.”
Status Indicators (top)
Status indicators represent various hardware/software
conditions. See indicator details in section 3.
Keyboard
The keyboard provides full-sized keys with comfortable
travel (depth at which the keys can be depressed) and
palm rest for both hands.Two Windows function keys are
provided to help ease navigation in the Windows operating
system.
Touchpad and Buttons
The touchpad with its buttons is a pointing device that
provides the same functions as a desktop mouse. A
software-controlled scrolling function is available after
setting up the included touchpad utility to allow easy
Windows or web navigation.

Notebook PC User Manual 17
Bottom Side
2
5
1 3
4
The bottom of the Notebook PC can get very hot. Be careful
when handling the Notebook PC while it is in operation or
recently been in operation. High temperatures are normal during
charging or operation. DO NOT USE ON SOFT SURFACES SUCH
AS SOFAS OR BEDS, WHICH MAY BLOCK THE VENTS. DO NOT
PUT THE NOTEBOOK PC ON YOUR LAP OR OTHER PARTS OF
THE BODY TO AVOID INJURY FROM THE HEAT.
The bottom side may vary in appearance depending on model.
The battery pack size varies depending on model.

18 Notebook PC User Manual
Battery Lock - Spring
The spring battery lock is used to keep the battery
pack secured.When the battery pack is inserted, it will
automatically lock.To remove the battery pack, this spring
lock must be held in the unlocked position.
Battery Pack
The battery pack is automatically charged when the
Notebook PC is connected to an AC power source and
maintains power to the Notebook PC when AC power is
not connected.This allows use when moving temporarily
between locations. Battery time varies by usage and by
the specifications for this Notebook PC.The battery pack
cannot be disassembled and must be purchased as a single
unit.
Battery Lock - Manual
The manual battery lock is used to keep the battery pack
secured. Move the manual lock to the unlocked position to
insert or remove the battery pack. Move the manual lock to
the locked position after inserting the battery pack.
Memory (RAM) Compartment
The memory compartment provides expansion capabilities
for additional memory. Additional memory will increase
application performance by decreasing hard disk access.
The BIOS automatically detects the amount of memory in
the system and configures CMOS accordingly during the
POST (Power-On-Self-Test) process.There is no hardware or
software (including BIOS) setup required after the memory
is installed.Visit an authorized service center or retailer for
information on memory upgrades for your Notebook PC.
Only purchase expansion modules from authorized retailers
of this Notebook PC to ensure maximum compatibility and
reliability.
1
2
3
4

Notebook PC User Manual 19
Hard Disk Drive Compartment
The hard disk drive is secured in a compartment.Visit an
authorized service center or retailer for information on hard
disk drive upgrades for your Notebook PC. Only purchase
hard disk drives from authorized retailers of this Notebook
PC to ensure maximum compatibility and reliability.
5

20 Notebook PC User Manual
Right Side
OFF
ON
1 2 7
4 5 6
3
1
2
USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB
2.0 or USB 1.1 devices such as keyboards, pointing devices,
cameras, hard disk drives, printers, and scanners connected
in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec
(USB 2.0). USB allows many devices to run simultaneously
on a single computer, with some peripherals acting as
additional plug-in sites or hubs.USB supports hot-swapping
of devices so that most peripherals can be connected or
disconnected without restarting the computer.
USB Port (3.0/2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB
3.0, 2.0, or USB 1.1 devices such as keyboards, pointing
devices, cameras, hard disk drives, printers, and scanners
connected in a series up to 4.8Gbits/sec (USB 3.0),
480Mbits/sec (USB 2.0), and 12Mbits/sec (USB 1.1). USB
allows many devices to run simultaneously on a single
computer, with some peripherals acting as additional
plug-in sites or hubs. USB supports hot-swapping of devices
so that most peripherals can be connected or disconnected
without restarting the computer.
