Asus TF0070 Series User manual

ASUS Transformer Pad
User Manual
TF700/TF0070 Series
EXXXX
ASUS is devoted to creating environment-friendly products/
packagings to safeguard consumers’ health while minimizing
the impact on the environment. The reduction of the number
of the manual pages complies with the reduction of carbon
emission.
For the detailed user manual and related information, refer
to the user manual included in the device or visit the ASUS
Support Site at http://support.asus.com/
There are three main types of airport security devices: X-ray machines (used
on items placed on conveyor belts), magnetic detectors (used on people
walking through security checks), and magnetic wands
(hand-held devices used on people or individual items). You can send your
ASUS Transformer Pad through airport X-ray machines. But do not send
your ASUS Transformer Pad through airport magnetic detectors or expose
it to magnetic wands.
Airplane Precautions
Ask an airline personnel if you want to use your ASUS Transformer Pad onboard
an aircraft. Most airlines have restrictions for using electronic devices. Most
airlines allow electronic use only between and not during takeos and landings.
Charging Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack
before going on long trips. Remember that the power adapter charges the
battery pack as long as it is plugged into the computer and an AC power source.
Be aware that it takes much longer to charge the battery pack when the ASUS
Transformer Pad is in use.
Fully charge the battery up to eight hours for the rst-time use. The battery
reaches its maximum capacity after one full charging and discharging cycle.
+eXXXX_TF700_TF0070_series_UM.in1 1 5/16/12 6:11:34 PM

ASUS Transformer Pad Manual
2
Package Contents
• If any of the items is damaged or missing, contact your retailer.
• The bundled power plug varies with country or region.
ASUS Transformer Pad USB Charger
User Manual
USB Dock cable User Manual
Cleaning cloth Warranty Card
+eXXXX_TF700_TF0070_series_UM.in2 2 5/16/12 6:11:36 PM

ASUS Transformer Pad Manual
3
Your ASUS Transformer Pad
11
2
1
12
3
5
4
6
810 9
14
13
15
7
12
+eXXXX_TF700_TF0070_series_UM.in3 3 5/16/12 6:11:37 PM

ASUS Transformer Pad Manual
4
1
Power button
Press and hold the Power button for one second to power on your
ASUS Transformer Pad.
When the ASUS Transformer Pad is powered on, press the Power
button to put the ASUS Transformer Pad into sleep mode or wake it
up from sleep mode.
Press the Power button for one second to display the shutdown
dialog box, and tap OK.
Battery charge indicator (dual-color)
Dim: The power charger is not plugged in the ASUS Transformer Pad.
Green: The battery level is up to 100%
Orange: The ASUS Transformer Pad is in battery charging mode.
2
Volume key
Press this button to increase or decrease the system volume.
3
SIM card slot
Insert a SIM card into this slot.
4
Micro SD Card Slot
Insert Micro SD card into this slot.
5
Reset button
If the system becomes unresponsive, use a paper clip to press the
reset button and force the ASUS Transformer Pad to restart.
Forcing the system to restart may result in data loss. We strongly
recommend that you back up your important data regularly.
6
Micro HDMI port
Insert a micro HDMI cable into this port to connect to a high-
denition multimedia interface (HDMI) device.
7
Headphone output/Microphone input combo jack
The stereo combo jack (3.5mm) connects the ASUS Transformer Pad’s
audio out signal to amplied speakers or headphones. Using this jack
automatically disables the built-in speaker.
The jack is also designed to connect the microphone used for voice
narrations or simple audio recordings.
+eXXXX_TF700_TF0070_series_UM.in4 4 5/16/12 6:11:37 PM

ASUS Transformer Pad Manual
5
8
Light sensor
The light sensor detects the amount of light in your environment and
automatically adjusts the brightness of the touch screen panel for
better viewing.
9
Built-in front camera
Use the built-in camera for picture taking, video recording, video
conferencing and other interactive applications.
10
Touch screen panel
The touch screen panel allows you to operate your ASUS Transformer
Pad using touch gestures.
11 Dock port
• Insert the power adapter into this port to supply power to your
ASUS Transformer Pad and charge the internal battery pack.
To prevent damage to your ASUS Transformer Pad and battery
pack, always use the bundled power adapter.
• Connect the USB Dock cable to the ASUS Transformer Pad and
another system (notebook or desktop PC) for data transmission.
• Dock the ASUS Transformer Pad to the mobile dock for extended
functions, such as keyboard, touchpad and USB connectivity.
12
Built-in microphone (right and front)
The built-in mono microphone can be used for video conferencing,
voice narrations or simple audio recordings.
13
Built-in rear camera
Use the built-in camera for picture taking, video recording, video
conferencing and other interactive applications.
14
Camera LED ash
Use the ash to take photos when lighting conditions are poor or
when there is a backlight.
15
Audio speaker system
Your ASUS Transformer Pad is equipped with a built-in high quality
stereo speaker. Audio features are software controlled.
+eXXXX_TF700_TF0070_series_UM.in5 5 5/16/12 6:11:38 PM

ASUS Transformer Pad Manual
6
Charging the ASUS Transformer Pad
• Use only the power adapter that comes with your device. Using a
dierent power adapter may damage your device.
• Using the bundled power adapter and USB Dock cable to connect
your ASUS Transformer Pad to a power outlet is the best way to
charge the ASUS Transformer Pad.
• Ensure that the 40-pin USB connector is fully inserted into your ASUS
Pad.
• The input voltage range between the wall outlet and the power
adapter is AC 100V–240V, and the output voltage of the power
adapter is DC 15V, 1.2A.
• Fully charge the battery up to eight hours for rst-time use.
• Ensure that your ASUS Transformer Pad is turned o before charging
it via your computer’s USB port.
• Charging through the USB port may take a longer time to complete.
• If your computer does not provide enough power for charging the
ASUS Transformer Pad, use the wall outlet instead.
1
2
3
+eXXXX_TF700_TF0070_series_UM.in6 6 5/16/12 6:11:38 PM

ASUS Transformer Pad Manual
7
Tips for using your ASUS Transformer
• Using File Manager
Internal storage
Open File Manager
and the internal storage
location is displayed.
Pad
Removing the external storage devices
Tap the microSD card
icon at the bottom right
corner and tap
to safely remove the
microSD card. Then,
press the card slightly
until it ejects.
Removable devices
In the Root Directory, locate and enter the Removable folder. You may
see folders for MicroSD,
SD or USBdisk1
according to your
connecting storage
devices.
SD and USBdisk1 appear
only when you dock
your ASUS Transformer
Pad on the optional
mobile dock.
+eXXXX_TF700_TF0070_series_UM.in7 7 5/16/12 6:11:41 PM

ASUS Transformer Pad Manual
8
• Adobe Flash player
For a better web surng experience, we recommend you download and
install Adobe Flash player from Android Market. Browsing websites made
with Flash will be troublefree.
• Microphone Input function
For microphone input function, the jack supports the HEADSET MICROPHONE
ONLY.
• Further information
Visit ASUS Transformer Pad website at http://eee.asus.com/eeepad for
updated information.
+eXXXX_TF700_TF0070_series_UM.in8 8 5/16/12 6:11:41 PM

ASUS Transformer Pad Manual
9
Declarations and Safety Statements
Federal Communications Commission Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiated radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio
waves. This device is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The exposure standard employs a unit of measurement known as the Specic
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. Tests for SAR
are conducted using standard operating positions accepted by the FCC with
the EUT transmitting at the specied power level in dierent channels.
The highest SAR value for the device as reported to the FCC is 0.500 W/kg
when placed next to the body.
+eXXXX_TF700_TF0070_series_UM.in9 9 5/16/12 6:11:42 PM

ASUS Transformer Pad Manual
10
The FCC has granted an Equipment Authorization for this device with all
reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this device is on le with the FCC and can
be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after
searching on FCC ID: MSQTF700T.
This device is compliance with SAR for general population /uncontrolled
exposure limits in ANSI/IEEE C95.1-1999 and had been tested in accordance
with the measurement methods and procedures specied in OET Bulletin 65
Supplement C.
IC Regulations
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
This Category II radiocommunication device complies with Industry Canada
Standard RSS-310.
Ce dispositif de radiocommunication de catégorie II respecte la norme
CNR-310 d’Industrie Canada.
IC Radiation Exposure Statement
This EUT is compliance with SAR for general population/uncontrolled
exposure limits in IC RSS-102 and had been tested in accordance with
the measurement methods and procedures specied in IEEE 1528. This
equipment should be installed and operated with minimum distance 0cm
between the radiator & your body.
This device and its antenna(s) must not be co-located or operating in
conjunction with any other antenna or transmitter.
The County Code Selection feature is disabled for products marketed in the
US/Canada.
For product available in the USA/ Canada markets, only channel 1~11 can be
operated. Selection of other channels is not possible.
+eXXXX_TF700_TF0070_series_UM.in10 10 5/16/12 6:11:42 PM

ASUS Transformer Pad Manual
11
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more than
3Kg must use approved power cords greater than or equal to: H05VV-F, 3G,
0.75mm2or H05VV-F, 2G, 0.75mm2.
DO NOT throw the battery in municipal waste. The symbol of the
crossed out wheeled bin indicates that the battery should not be
placed in municipal waste.
DO NOT throw the ASUS Transformer Pad in municipal waste. This
product has been designed to enable proper reuse of parts and
recycling. The symbol of the crossed out wheeled bin indicates that
the product (electrical, electronic equipment and mercury-containing
button cell battery) should not be placed in municipal waste. Check
local regulations for disposal of electronic products.
SAFE TEMP: This ASUS Transformer Pad should only be used in
environments with ambient temperatures between 0°C (32°F) and 35°C
(95°F).
Risk of Explosion if Battery is Replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
CE Mark Warning
CE marking for devices without wireless LAN/Bluetooth
The shipped version of this device complies with the requirements of the EEC
directives 2004/108/EC “Electromagnetic compatibility” and 2006/95/EC “Low
voltage directive”.
CE marking for devices with wireless LAN/ Bluetooth
This equipment complies with the requirements of Directive 1999/5/EC of the
European Parliament and Commission from 9 March, 1999 governing Radio
and Telecommunications Equipment and mutual recognition of conformity.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the
highest standards for protecting our environment. We believe in providing
solutions for you to be able to responsibly recycle our products, batteries,
other components as well as the packaging materials. Please go to http://csr.
asus.com/english/Takeback.htm for detailed recycling information in dierent
regions.
+eXXXX_TF700_TF0070_series_UM.in11 11 5/16/12 6:11:43 PM

ASUS Transformer Pad Manual
12
Copyright Information
No part of this manual, including the products and software described
in it, may be reproduced, transmitted, transcribed, stored in a retrieval
system, or tranPadd into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS and ASUS Transformer Pad logo are trademarks of ASUSTek Computer
Inc.
Information in this document is subject to change without notice.
Copyright © 2012 ASUSTeK COMPUTER INC. All Rights Reserved.
Limitation of Liability
Circumstances may arise where because of a default on ASUS’ part or other
liability, you are entitled to recover damages from ASUS. In each such
instance, regardless of the basis on which you are entitled to claim damages
from ASUS, ASUS is liable for no more than damages for bodily injury (including
death) and damage to real property and tangible personal property; or
any other actual and direct damages resulted from omission or failure of
performing legal duties under this Warranty Statement, up to the listed
contract price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims
based in contract, tort or infringement under this Warranty Statement.
This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for
which ASUS, its suppliers, and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1)
THIRD-PARTY CLAIMS AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE
TO, YOUR RECORDS OR DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT
DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING
LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR YOUR RESELLER
IS INFORMED OF THEIR POSSIBILITY.
Manufacturer ASUSTek COMPUTER INC.
Address, City No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN R.O.C
Country TAIWAN
Authorized
Representative in Europe
ASUS COMPUTER GmbH
Address, City HARKORT STR. 21-23, 40880 RATINGEN
Country GERMANY
+eXXXX_TF700_TF0070_series_UM.in12 12 5/16/12 6:11:43 PM
