1. Support CD information
The support CD contains the drivers and utilities for your VGA card. Click the



Menu launches automatically.
• The screens in this manual are for reference only and may not exactly
match what you see on your screen.
 
VGA card models.
• You may need administrator rights to install the drivers and utilities. See
your Windows®XP/Vista/7/8/8.1 documentation for details.
• The contents of the support CD are subject to change at any time without
notice. Visit the ASUS website at www.asus.com for updates.
Click to display
CD contents Click to exit
application
Click to
view Read
Me le
Click to open
the ASUS
website.
Click to
Install
software
Click
to open
User
Manual
If Autorun is NOT enabled on your computer, browse the contents of the support
UI.exe. Double-click the UI.exe to run the support CD
installation program.
Q7624_Nvidia_Graphic_Card_Manual8 8 22/10/13 15:17:21

9
English
2. VGA drivers
The VGA driver is the software program that makes the device work with your
operating system. After physically installing your graphics card, use any of the
recommended methods in this section to install, update, or remove the VGA driver.
If you are replacing an old graphics card with a new ASUS graphics card,
uninstall the old display driver from your system.
1. From the Found New Hardware
Cancel to
enter the Windows desktop.
2. Insert the support CD into your
optical drive.
3. If Autorun is enabled, the main
menu appears automatically.
If Autorun is disabled, run UI.exe
from the root directory of your
support CD.
2.1 Installing the VGA driver
2.1.1 Installing the VGA drivers in Windows®XP
To install the VGA driver in Windows®XP:
3. From the main menu, click
Install.
Q7624_Nvidia_Graphic_Card_Manual9 9 22/10/13 15:17:23

English
10
3. Select Display Driver and click
the Install button.
4. Once installation is complete,
click OK to reboot the system.
Q7624_Nvidia_Graphic_Card_Manual10 10 22/10/13 15:17:24

11
English
2.1.2 Installing the VGA Drivers in Windows® Vista and Windows®
7/8/8.1 (32/64 bit)
To install the VGA driver in Windows®Vista and Windows®7/8/8.1:
1. Insert the support CD into your
optical drive.
2. If Autorun is enabled, the main
menu appears automatically.
If Autorun is disabled, run
UI.exe from the root directory of
your support CD.
4. Select Display Driver and click
the Install button.
5. Once installation is complete,
click OK to reboot the system.
3. From the main menu, click
Install.
Q7624_Nvidia_Graphic_Card_Manual11 11 22/10/13 15:17:25

English
12
2.2 Uninstalling the VGA driver
2.2.1 Uninstalling VGA drivers in Windows®XP
To remove the VGA driver in Windows®XP:
• Click Start > Control Panel > Add or Remove Programs, select graphics
driver. Click Remove.
Q7624_Nvidia_Graphic_Card_Manual12 12 22/10/13 15:17:25

13
English
2.2.2 Uninstalling VGA drivers in Windows® Vista
To remove the VGA driver in Windows®Vista:
• Click Start > Control Panel > Programs and Features, select graphics driver.
Click Uninstall.
2.2.3 Uninstalling VGA drivers in Windows®7/8/8.1
To remove the VGA driver in Windows®7/8/8.1:
• Click Start > Control Panel > Programs > Programs and Features, select
graphics driver. Click Uninstall.
Q7624_Nvidia_Graphic_Card_Manual13 13 22/10/13 15:17:26

English
14
3. ASUS GPU Tweak utility
ASUS GPU Tweak utility allows you to monitor and optimize the settings of your ASUS
Graphics card.
1. Insert the support CD into your
optical drive.
2. If Autorun is enabled, the main
menu appears automatically.
If Autorun is disabled, run
UI.exe from the root directory of
your support CD.
4. Once installation is complete,
click OK.
3.1 Installing ASUS GPU Tweak
3.1.1 Installing ASUS GPU Tweak in Windows® XP / WindowsWindows®
Vista / Windows® 7/8/8.1 (32/64 bit)
To install ASUS GPU Tweak:
3. From the main menu, click
Install.
Select ASUS GPU Tweak and
click the Install button.
Q7624_Nvidia_Graphic_Card_Manual14 14 22/10/13 15:17:26

15
English
3.2 Uninstalling ASUS GPU Tweak
3.2.1 Removing ASUS GPU Tweak in Windows®XP
To remove ASUS GPU Tweak in Windows®XP:
• Click Start > Control Panel > Add or Remove Programs, select ASUS GPU
Tweak. Click Remove.
3.2.2 Removing ASUS GPU Tweak in WindowsRemoving ASUS GPU Tweak in WindowsASUS GPU Tweak in Windowsin Windows® Vista
To remove ASUS GPU Tweak in Windows®Vista:
• Click Start > Control Panel > Programs and Features, select ASUS GPU
Tweak. Click Uninstall.
Q7624_Nvidia_Graphic_Card_Manual15 15 22/10/13 15:17:27

English
16
3.2.3 Removing ASUS GPU Tweak in WindowsRemoving ASUS GPU Tweak in WindowsASUS GPU Tweak in Windowsin Windows®7/8/8.17/8/8.1
To remove ASUS GPU Tweak in Windows®7/8/8.1:
• Click Start > Control Panel > Programs > Programs and Features, select
ASUS GPU Tweak. Click Uninstall.
Q7624_Nvidia_Graphic_Card_Manual16 16 22/10/13 15:17:27

17
English
1. Insert the support CD into your
optical drive.
2. If Autorun is enabled, the main
menu appears automatically.
If Autorun is disabled, run
UI.exe from the root directory of
your support CD.
4. Other information
4.1 Browse the Support CD
To browse the support CD:
4.1.2 Contact Information
1. Insert the support CD into your optical drive.
2. If Autorun is enabled, the main menu appears automatically.
If Autorun is disabled, run UI.exe from the root directory of your support CD.
3. From the main menu, click Contact Us to open the ASUS website for
additional information.
3. From the main menu, click
Browse CD to view the contents
of the CD.
Q7624_Nvidia_Graphic_Card_Manual17 17 22/10/13 15:17:28

English
18
4.1.3 Viewing the Read Me le

1. Insert the support CD into your
optical drive.
2. If Autorun is enabled, the main
menu appears automatically.
If Autorun is disabled, run UI.exe
from the root directory of your
support CD.
3. From the main menu, click Read
Me to display the Readme text

Q7624_Nvidia_Graphic_Card_Manual18 18 22/10/13 15:17:29

19
English
Appendix: Basic troubleshooting
If you encounter any of the following scenarios after installing your graphics card,
try performing one of the possible solutions before calling for technical support.
Problem No display after the card is installed
Cause Your card might not be properly installed.
Solution Make sure that the card is not tilted or skewed on the slot.
Cause Your monitor might not be properly connected.
Solution Make sure that the signal cable is properly connected to
your monitor and graphics card.
Cause Your graphics card is not supported by your motherboard.
Solution Check the technical documentation that came with your

your graphics card (e.g. AGP voltage requirement).
Cause 
Solution Make sure that the auxiliary power cables are properly
connected with the power supply unit.
Cause 
Solution Make sure that your power supply unit can provide the
minimum power requirement to your system.
Cause Incorrect motherboard hardware system settings (e.g.
system control panel connections).
Solutions • Make sure that the system control panel cables are con-
nected properly (e.g. power switch, reset).
• Make sure that your CPU, CPU fan and/or memory
DIMMs are in good working condition and are con-
nected properly.
Q7624_Nvidia_Graphic_Card_Manual19 19 22/10/13 15:17:29

English
20
Problem Wrong color balance
Cause Your card might not be properly installed.
Solution Make sure that the card is not tilted or skewed on the slot.
Cause Your video controls might not be properly set.
Solution        
settings.
       -
play properties.
Cause There may be unsupported graphics card drivers installed

drivers from different vendors.
Solution • Remove any unused graphics card drivers installed on
your system.
•Install the graphics card driver from the support CD thatInstall the graphics card driver from the support CD that
came with your graphics card package.
Cause 
Solution Make sure that the auxiliary power cables are properly
connected to the power supply unit.
Cause If your monitor comes with BNC connectors, the port con-
nections may be incorrect.
Solution Make sure that all BNC connectors are connected prop-
erly to its corresponding port.
Cause Your monitor software settings might be incorrect.
Solution .
Cause Your monitor might not be properly connected.
Solution Make sure that the signal cable is properly connected to
your monitor and graphics card.
Q7624_Nvidia_Graphic_Card_Manual20 20 22/10/13 15:17:29
