AT&T Digital Life User manual

AT&T Proprietary (Internal Use Only)
Installation and Operations Manual
Version 2.1

AT&T Proprietary (Internal Use Only)

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—i—
Table of Contents
1 Introduction ..........................................................................................................................................1
2 Digital Life System Overview.................................................................................................................2
2.1 System Architecture......................................................................................................................2
2.2 Digital Life Controller Cabinet.......................................................................................................3
2.3 Digital Life Premises Devices......................................................................................................... 6
2.3.1 Wireless Premises Devices....................................................................................................6
2.3.2 Optional Takeover Module ...................................................................................................8
2.3.3 Optional Z-Wave Devices (Not Evaluated by UL)..................................................................8
2.4 Digital Life System Installation and Configuration........................................................................9
2.5 Digital Life System Operation .......................................................................................................9
2.6 Digital Life System Alarm Reporting ...........................................................................................12
2.7 Event Notification Service (Not Evaluated by UL).......................................................................12
2.8 Remote Video Monitoring (Not Evaluated by UL) ......................................................................13
2.9 Home Automation & Control (Not Evaluated by UL)..................................................................13
2.10 Digital Life System Operation Under a Local Power Failure Condition.......................................13
3 Digital Life Direct Overview.................................................................................................................15
3.1 Access Customer’s DLC ...............................................................................................................15
3.2 Device Discovery Mode and Discovery Process..........................................................................18
3.3 Administer DLC Features.............................................................................................................22
3.3.1 Security/Duress Code..........................................................................................................24
3.3.2 Entry Delay.......................................................................................................................... 24
3.3.3 Exit Delay.............................................................................................................................25
3.3.4 Abort Delay .........................................................................................................................25
3.3.5 Alarm Timeout ....................................................................................................................25
3.3.6 Cross Zoning Delay..............................................................................................................25
3.3.7 Swinger Shutdown ..............................................................................................................26
3.3.8 Exit Time Restart Enable .....................................................................................................26

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—ii—
3.3.9 Abort Sound On/Off............................................................................................................26
3.3.10 Chirp on Entry/Exit Door/Open Close.................................................................................26
3.3.11 Enable Cross Zone 2nd Trigger by Same Device...................................................................26
3.3.12 Enable Swinger Shutdown ..................................................................................................27
3.3.13 Auto Stay on Unvacated Premises Enable ..........................................................................27
3.3.14 Cancel Sound On/Off .......................................................................................................... 27
3.3.15 Chirp on Non-Entry/Exit Open Close...................................................................................27
3.3.16 Enable Fire Alarm Verification ............................................................................................27
3.4 Troubleshooting Wireless Devices..............................................................................................28
4 Digital Life Controller (DLC) Cabinet and Internal Components .........................................................31
5 System Installation..............................................................................................................................34
5.1 DLC AC-to-AC Adapter with Integrated HPAV Connection .........................................................39
5.1.1 Connecting the AC-to-AC Adapter with Integrated HPAV to the DLC Cabinet...................40
5.1.2 Connecting the AC-to-AC Adapter with Integrated HPAV to the DLC Cabinet...................41
5.2 DLC Cabinet Installation..............................................................................................................42
5.3 Mounting the DLC Cabinet..........................................................................................................44
5.3.1 DLC Cabinet Installation on a Sheetrock Wall.....................................................................44
5.3.2 DLC Cabinet Installation on an Open Wall..........................................................................47
5.3.3 Assembling the DLC Antennas ............................................................................................51
5.4 Installing the Battery...................................................................................................................52
6 Device Installation, Discover, Registration and Operation.................................................................55
6.1 915MHz Products........................................................................................................................55
6.1.1 Keypad (915MHz)................................................................................................................55
6.1.1.1 Installing the Keypad.......................................................................................................57
6.1.1.2 Discovering and Registering the Keypad (Digital Life Direct)..........................................58
6.1.2 Siren (915MHz) ...................................................................................................................61
6.1.2.1 Installing the Siren ..........................................................................................................62
6.1.2.2 Discovering and Registering the Siren ............................................................................62
6.1.2.3 Installing/Replacing Batteries .........................................................................................63

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—iii—
6.1.3 Device Controller (915MHz) (Not Evaluated by UL) ...........................................................63
6.1.3.1 Discovering and Registering the Device Controller ........................................................64
6.1.4 915MHz Repeater ...............................................................................................................64
6.1.4.1 Installing the 915MHz Repeater .....................................................................................65
6.1.4.2 Discovering and Registering the 915MHz Repeater .......................................................65
6.1.4.3 Installing/Replacing Batteries .........................................................................................66
6.2 433MHz Products........................................................................................................................66
6.2.1 FCC Regulations...................................................................................................................68
6.2.1.1 RF Exposure Information ................................................................................................68
6.2.2 Smoke Detector ..................................................................................................................69
6.2.2.1 Smoke Detector LED Functions.......................................................................................69
6.2.2.2 Discovering and Registering the Smoke Detector ..........................................................70
6.2.2.3 Installing the Smoke Detector.........................................................................................70
6.2.2.4 Installing/Replacing Batteries .........................................................................................72
6.2.2.5 Testing the Smoke Detector............................................................................................72
6.2.2.6 Maintaining the Smoke Detector....................................................................................73
6.2.2.7 Specifications—Smoke Detector.....................................................................................73
6.2.3 Carbon Monoxide (CO) Detector ........................................................................................74
6.2.3.1 Discovering and Registering the CO Detector.................................................................75
6.2.3.2 Selecting Location(s) for Installation...............................................................................75
6.2.3.3 Locations to Avoid...........................................................................................................76
6.2.3.4 Mounting the CO Detector .............................................................................................76
6.2.3.5 Installing/Replacing Batteries .........................................................................................78
6.2.3.6 Testing the CO Detector..................................................................................................79
6.2.3.7 Normal CO Alarm Test ....................................................................................................79
6.2.3.8 Troubleshooting..............................................................................................................79
6.2.3.9 Specifications—CO Detector...........................................................................................80
6.2.3.10 Operation Characteristics of CO Detector ..................................................................80
6.2.4 Vanishing Door/Window (D/W) Sensor..............................................................................81

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—iv—
6.2.4.1 Discovering and Registering the V2 Sensor ....................................................................81
6.2.4.2 Installing and Mounting the V2 Sensor...........................................................................81
Transmitter—Door......................................................................................................................81
Transmitter—Window ................................................................................................................82
Mounting the Transmitter ..........................................................................................................82
Using Adhesive Tape...................................................................................................................83
6.2.4.3 Installing/Replacing Battery............................................................................................83
6.2.4.4 Specifications ..................................................................................................................84
6.2.5 Recessed Door/Window (RDW) Sensor ..............................................................................84
6.2.5.1 Discovering and Registering the RDW Sensor.................................................................84
6.2.5.2 Installing and Mounting the RDW Sensor.......................................................................84
6.2.5.3 Installing the Transmitter................................................................................................85
6.2.5.4 Mounting the Magnet Assembly ....................................................................................86
6.2.5.5 Installing/Replacing Battery............................................................................................86
6.2.5.6 Specifications—RDW Sensor...........................................................................................87
6.2.6 Glass Break Detector...........................................................................................................88
6.2.6.1 Discovering and Registering the Glass Break Detector...................................................88
6.2.6.2 Installing/Mounting the Glass Break Detector ...............................................................89
6.2.6.3 Installing/Replacing Batteries .........................................................................................91
6.2.6.4 Testing the Glass Breakage Detector.............................................................................. 92
Functional Test............................................................................................................................92
Wireless Range (RF) Test.............................................................................................................92
6.2.6.5 Specifications—GB Detector...........................................................................................92
6.2.7 Motion Detector (PIR).........................................................................................................93
6.2.7.1 Discovering and Registering the PIR Motion Sensor.......................................................94
6.2.7.2 Selecting a Mounting Location........................................................................................94
6.2.7.3 Assembling the PIR..........................................................................................................94
6.2.7.4 Wall Mounting ................................................................................................................95
6.2.7.5 Corner Mounting.............................................................................................................96

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—v—
6.2.7.6 Configuring the PIR .........................................................................................................97
Jumper Settings...........................................................................................................................97
Additional Detection Options .....................................................................................................97
6.2.7.7 Installing/Replacing Battery............................................................................................98
6.2.7.8 Testing the PIR ................................................................................................................98
6.2.7.9 Specifications—PIR Motion Sensor.................................................................................98
6.2.8 Key Fob................................................................................................................................99
6.2.8.1 Discovering and Registering the Key Fob......................................................................100
6.2.8.2 Replacing the Batteries .................................................................................................100
6.2.8.3 Specifications—Key Fob................................................................................................101
6.2.9 Takeover Module ..............................................................................................................101
6.2.9.1 Discovering and Registering the Takeover Module ......................................................103
6.2.9.2 Installation and Mounting Guidelines...........................................................................103
6.2.9.3 Connecting Wired Zones...............................................................................................104
6.2.9.4 Powering the 915MHz Two-Way Keypad .....................................................................104
6.2.9.5 Connecting Power.........................................................................................................105
6.2.9.6 Enrolling the Transmitter..............................................................................................108
6.2.9.7 Final Installation............................................................................................................109
6.2.9.8 Specifications─Takeover Module..................................................................................110
6.2.10 433MHz Repeater .............................................................................................................111
6.2.10.1 Status LED Indicators and LEARN Button Operation.................................................112
6.2.10.2 Repeater Function.....................................................................................................112
6.2.10.3 Learning Transmitters ...............................................................................................112
6.2.10.4 Determining the number of transmitters learned into the memory........................113
6.2.10.5 Erasing Transmitters from Memory..........................................................................113
6.2.10.6 Discovering and Registering the 433MHz Repeater .................................................114
6.2.10.7 Installing the 433MHz Repeater ...............................................................................114
6.2.10.8 Specifications—433MHz Repeater ...........................................................................114
6.2.10.9 Installing/Replacing Batteries ...................................................................................115

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—vi—
6.2.11 Temperature/Flood Sensor (Not Evaluated by UL)...........................................................115
6.2.11.1 Flood Conditions .......................................................................................................116
6.2.11.2 Temperature Conditions........................................................................................... 116
6.2.11.3 Discovering and Registering the Temperature/Flood Sensor...................................116
6.2.11.4 Installing/Mounting the Temperature/Flood Sensor Transmitter............................116
6.2.11.5 Configuring the Sensor..............................................................................................117
6.2.11.6 Installing/Replacing Battery......................................................................................119
6.2.11.7 Specifications—Temperature/Flood Sensor.............................................................120
6.2.12 Garage Door Tilt Sensor (Not Evaluated by UL)................................................................120
6.2.12.1 Discovering and Registering the Tilt Garage Door Sensor ........................................120
6.2.12.2 Installing the Battery.................................................................................................121
6.2.12.3 Locating the Transmitter...........................................................................................122
6.2.12.4 Mounting the Transmitter ........................................................................................122
6.2.12.5 Specifications—Garage Door Tilt Sensor ..................................................................122
6.3 IP Camera (Not Evaluated by UL)..............................................................................................123
6.3.1 IP Camera AC-to-DC Adapter with Integrated HPAV (Not Evaluated by UL)....................123
6.3.2 Wi-Fi IP Camera Installation (Not Evaluated by UL)..........................................................124
6.4 Z-Wave Devices (Not Evaluated by UL).....................................................................................125
6.4.1.1 Discovering and Registering the Z-Wave Indoor Power Outlet Controller Module .....126
6.4.1.2 Specifications—Z-Wave Indoor Power Outlet Controller Module ...............................126
7 System Operation .............................................................................................................................127
7.1 Keypad.......................................................................................................................................127
7.1.1 Ready to Arm ....................................................................................................................128
7.1.2 Not Ready to Arm..............................................................................................................129
7.1.3 Arming the System—STAY ................................................................................................130
7.1.4 Arming the System—AWAY ..............................................................................................131
7.1.5 Arming the System─BYPASS..............................................................................................132
7.1.6 Disarming the System –Entry Delay ................................................................................134
7.1.7 Disarming the System .......................................................................................................135

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—vii—
7.1.8 Alarm Sounding─Cancel Alarm .........................................................................................136
7.1.9 Fire Emergency..................................................................................................................138
7.1.10 AUX (Auxiliary) Emergency ...............................................................................................139
7.1.11 Police Emergency..............................................................................................................140
7.2 Duress Code .............................................................................................................................. 141
7.3 Key Fob......................................................................................................................................141
7.4 Web Access via Digital Life Direct –Alarm Manager ................................................................142
7.4.1 Check System Status .........................................................................................................142
7.4.2 Arming the System............................................................................................................143
7.4.3 Disarming the System .......................................................................................................145
8 System Messages on Keypad LCD.....................................................................................................147

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—viii—
Table of Figures
Figure 1: AT&T Digital Life System Architecture ..........................................................................................2
Figure 2: AT&T Digital Life Controller Cabinet .............................................................................................4
Figure 3: Inside View of AT&T Digital Life Controller Cabinet ..................................................................... 5
Figure 4: Digital Life Wireless Premises Devices.......................................................................................... 6
Figure 5: Dual Frequency Wireless Transceiver Module –Proprietary 433/915MHz .................................7
Figure 6: Optional Takeover Module—Wired Window/Door Contacts and Wireless Keypad Power.........8
Figure 7: Z-Wave Wireless Transceiver Module—908MHz Two-Way......................................................... 9
Figure 8: 915MHz Two-Way Wireless Keypad ...........................................................................................10
Figure 9: 433MHz One-Way Key Fob .........................................................................................................11
Figure 10: DLD Login Screen.......................................................................................................................15
Figure 11: DLD—Enter Account Number ...................................................................................................16
Figure 12: DLD—Account Information.......................................................................................................16
Figure 13: DLD—Devices Screen................................................................................................................17
Figure 14: DLD—DLC Specific Details Screen.............................................................................................18
Figure 15: DLD—Start Discovery –Initializing Please Wait........................................................................19
Figure 16: DLD—Start Discovery –Discovery In Progress...........................................................................20
Figure 17: DLD—Devices Screen................................................................................................................21
Figure 18: DLD—Specific Device Screen ....................................................................................................21
Figure 19: DLD—Alarm Manager Information..........................................................................................22
Figure 20: Enabling Signal Strength Monitoring ........................................................................................29
Figure 21: Signal Strength Monitoring Alert ...............................................................................................29
Figure 22: Signal Strength Monitoring........................................................................................................30
Figure 23: Signal Strength Monitoring for a Repeated Signal.....................................................................30
Figure 24: AT&T Digital Life Controller Cabinet and Internal Components...............................................32
Figure 25: DLC Cabinet with Shipping Tray.................................................................................................33
Figure 26: DLC Cabinet Connection to AC Power using AC-to-AC Adapter with HPAV Connection..........39
Figure 27: DLC Cabinet Assembled ............................................................................................................42
Figure 28: Wall Plate Installation................................................................................................................44
Figure 29: Cabinet Installation on a Sheetrock Wall...................................................................................45
Figure 30: Final Assembly on a Sheetrock Wall ..........................................................................................46
Figure 31: Mounting Bracket and Wall Plate Assembly..............................................................................47
Figure 32: Mounting Bracket and Wall Plate Installation ...........................................................................48
Figure 33: Cabinet Installation on an Open Wall........................................................................................49
Figure 34: Final Assembly for an Open Wall Installation ............................................................................50
Figure 35: Installing Antennas—DLC Cabinet ............................................................................................51
Figure 36: Battery Compartment—Front Panel.........................................................................................52
Figure 37: Keypad Features........................................................................................................................56

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—ix—
Figure 38: Keypad Connection to AC/DC Adapter and Installation of AA Batteries...................................57
Figure 39: Siren ..........................................................................................................................................62
Figure 40: Device Controller (915MHz).......................................................................................................63
Figure 41: Device Controller Controlling AC Power to a Lamp ...................................................................64
Figure 42: 915MHz Repeater .....................................................................................................................65
Figure 43: Smoke Detector ........................................................................................................................69
Figure 44: Smoke Alarm Battery Compartment.........................................................................................70
Figure 45: Smoke Alarm to Base Alignment...............................................................................................71
Figure 46: CO Detector...............................................................................................................................74
Figure 47: CO Detector Recommended Locations.....................................................................................75
Figure 48: Vertical Mounting .....................................................................................................................77
Figure 49: Horizontal Mounting.................................................................................................................77
Figure 50: Install Batteries in CO Detector.................................................................................................78
Figure 51: Mounting Vanishing DW Sensor ...............................................................................................82
Figure 52: Install/Replace Battery—V2 Sensor.......................................................................................... 83
Figure 53: Installing Recessed DW Sensor .................................................................................................85
Figure 54: Installing Recessed DW Sensor .................................................................................................87
Figure 55: Glass Break Detector................................................................................................................. 88
Figure 56: Mounting Glass Break Detector—Step 1 ..................................................................................89
Figure 57: Mounting Glass Break Detector—Step 2 ..................................................................................90
Figure 58: Installing/Replacing Batteries ...................................................................................................91
Figure 59: PIR Motion Sensor.....................................................................................................................93
Figure 60: PIR back cover with brackets ....................................................................................................94
Figure 61: PIR Wall Mount Screw Holes.....................................................................................................95
Figure 62: PIR Back Cover with Corner Mount Screw Holes......................................................................96
Figure 63: Key Fob......................................................................................................................................99
Figure 64: Takeover Module Connections ...............................................................................................101
Figure 65: Takeover Module ....................................................................................................................102
Figure 66: Takeover Module Mounted ....................................................................................................103
Figure 67: Takeover Module - Hardwired Zone Connectors....................................................................104
Figure 68: Takeover Module - Powering 915MHz Two-Way Keypad ......................................................105
Figure 69: Takeover Module - DC Power Input........................................................................................106
Figure 70: Takeover Module - 24-Hour Battery Backup ..........................................................................107
Figure 71: Takeover Module - AC to DC Adapter Plugged into AC Power Outlet....................................108
Figure 72: 433MHz Repeater ..................................................................................................................111
Figure 73: Mounting the Temperature/Flood Sensor...............................................................................117
Figure 74: Temperature Only Configuration.............................................................................................118
Figure 75: Temperature/Flood Configuration...........................................................................................118
Figure 76: Install Battery in Temperature/Flood Sensor ..........................................................................119

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—x—
Figure 77: Install/Replace Battery —Tilt Garage Door Sensor..................................................................121
Figure 78: Indoor Power Outlet Controller Module.................................................................................125
Figure 79: Keypad Operation ....................................................................................................................127
Figure 80: Keypad - Ready to Arm ...........................................................................................................128
Figure 81: Keypad –Number of Open State Devices................................................................................129
Figure 82: Keypad –List of Open State Devices (Bedroom Window).......................................................129
Figure 83: Keypad - List of Open State Devices (Kitchen Door) ................................................................129
Figure 84: Keypad ─Arming - Exit Now.....................................................................................................130
Figure 85: Keypad─Armed - STAY.............................................................................................................130
Figure 86: Keypad ─Arming - Exit Now....................................................................................................131
Figure 87: Keypad ─Armed - AWAY.........................................................................................................131
Figure 88: Keypad –Number of Open State Devices................................................................................132
Figure 89: Keypad - BYPASS .....................................................................................................................132
Figure 90: Keypad –Example: Bedroom Window Open...........................................................................132
Figure 91: Keypad –Example: Arming Exit Now.......................................................................................133
Figure 92: Keypad –BYPASS in Ready to Arm State .................................................................................133
Figure 93: Keypad - Entry Delay, Alarm Enter Code to Cancel.................................................................134
Figure 94: Ready to Arm ...........................................................................................................................134
Figure 95: Keypad - Armed-STAY .............................................................................................................135
Figure 96: Ready to Arm ...........................................................................................................................135
Figure 97: Keypad –Alarm, Enter Code to Cancel ....................................................................................136
Figure 98: Keypad - Alarm, Triggered Device(s).......................................................................................136
Figure 99: Keypad –Alarm Canceled ........................................................................................................137
Figure 100: Keypad –Ready to arm..........................................................................................................137
Figure 101: Keypad - Confirm Fire ............................................................................................................138
Figure 102: Keypad - Fire Alarm Sent........................................................................................................138
Figure 103: Keypad –Alarm, Enter Code to Cancel ..................................................................................138
Figure 104: Keypad - Confirm AUX Emergency........................................................................................139
Figure 105: Keypad –Aux Emergency Sent...............................................................................................139
Figure 106: Keypad –Alarm, Enter Code to Cancel ..................................................................................139
Figure 107: Keypad –Confirm Police Emergency .....................................................................................140
Figure 108: Keypad - Police Emergency Sent...........................................................................................140
Figure 109: Keypad –Alarm, Enter Code to Cancel ..................................................................................140
Figure 110: 433MHz One-Way Key Fob....................................................................................................141
Figure 111: System Status........................................................................................................................142

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—xi—
List of Tables
Table 1: UL to DLD Features Mapping ........................................................................................................23
Table 2: System Messages on Keypad LCD ...............................................................................................147
Table 3: Local Power Failure and Low Battery Warnings on Keypad LCD ................................................151

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—xii—
SAFETY REGULATIONS
Notice to Installers
The servicing instructions in this notice are for use by qualified service personnel only. To
reduce the risk of electric shock, do not perform any servicing other than that contained in
the operating instructions, unless you are qualified to do so.
Notice à l’attention des installateurs de réseaux câblés
Les instructions relatives aux interventions d’entretien, fournies dans la présente notice,
s’adressent exclusivement au personnel technique qualifié. Pour réduire les risques de
chocs électriques, n’effectuer aucune intervention autre que celles décrites dans le mode
d'emploi et les instructions relatives au fonctionnement, à moins que vous ne soyez qualifié
pour ce faire.

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—xiii—
Mitteilung für CATV-Techniker
Die in dieser Mitteilung aufgeführten Wartungsanweisungen sind ausschließlich für
qualifiziertes Fachpersonal bestimmt. Um die Gefahr eines elektrischen Schlags zu
reduzieren, sollten Sie keine Wartungsarbeiten durchführen, die nicht ausdrücklich in der
Bedienungsanleitung aufgeführt sind, außer Sie sind zur Durchführung solcher Arbeiten
qualifiziert.
Aviso a los instaladores de sistemas CATV
Las instrucciones de reparación contenidas en el presente aviso son para uso exclusivo
por parte de personal de mantenimiento cualificado. Con el fin de reducir el riesgo de
descarga eléctrica, no realice ninguna otra operación de reparación distinta a las
contenidas en las instrucciones de funcionamiento, a menos que posea la cualificación
necesaria para hacerlo.

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—xiv—
IMPORTANT SAFETY INSTRUCTIONS
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water.
6.
Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding-type plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11.
Only use attachments/accessories specified by the manufacturer.
12.
Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13.
Unplug this apparatus during lightning storms or when unused for long periods of time.
14.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as a power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
Power Source Warning
A label on this product indicates the correct power source for this product. Operate this
product only from an electrical outlet with the voltage and frequency indicated on the

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—xv—
product label. If you are uncertain of the type of power supply to your home or business,
consult your service provider or your local power company.
The AC inlet on the unit must remain accessible and operable at all times.
Ground the Product
WARNING: Avoid electric shock and fire hazard! If this product connects to
coaxial cable wiring, be sure the cable system is grounded (earthed).
Grounding provides some protection against voltage surges and built-up
static charges.
Protect the Product from Lightning
In addition to disconnecting the AC power from the wall outlet, disconnect the signal inputs.
Verify the Power Source from the On/Off Power Light
When the on/off power light is not illuminated, the apparatus may still be connected to the
power source. The light may go out when the apparatus is turned off, regardless of whether
it is still plugged into an AC power source.
Eliminate AC Mains Overloads
WARNING: Avoid electric shock and fire hazard! Do not overload AC mains,
outlets, extension cords, or integral convenience receptacles. For products
that require battery power or other power sources to operate them, refer to the
operating instructions for those products.
Provide Ventilation and Select a Location
Remove all packaging material before applying power to the product.
Do not place this apparatus on a bed, sofa, rug, or similar surface.
Do not place this apparatus on an unstable surface.
Do not install this apparatus in an enclosure, such as a bookcase or rack, unless the
installation provides proper ventilation.
Do not place items such as lamps, books, vases with liquids, or other objects on top
of this product.
Do not block ventilation openings.

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—xvi—
Protect from Exposure to Moisture and Foreign Objects
WARNING: Avoid electric shock and fire hazard! Do not expose this product to
dripping or splashing liquids, rain, or moisture. Objects filled with liquids, such
as vases, should not be placed on this apparatus.
WARNING: Avoid electric shock and fire hazard! Unplug this product before
cleaning. Do not use a liquid cleaner or an aerosol cleaner. Do not use a
magnetic/static cleaning device (dust remover) to clean this product.
WARNING: Avoid electric shock and fire hazard! Never push objects through the
openings in this product. Foreign objects can cause electrical shorts that can
result in electric shock or fire.
Service Warnings
WARNING: Avoid electric shock! Do not open the cover of this product. Opening
or removing the cover may expose you to dangerous voltages. If you open the
cover, your warranty will be void. This product contains no user-serviceable
parts.
Check Product Safety
Upon completion of any service or repairs to this product, the service technician must
perform safety checks to determine that this product is in proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when moving the apparatus or connecting or
disconnecting cables.
20090915_Modem No Battery_Safety

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—1—
1 Introduction
The AT&T Digital Life System (DLS) is a service delivery platform that AT&T will be
commercially deploying. The DLS includes a Network Platform and a Premises Platform
wherein the primary communication path between the platforms is provided via AT&T
Cellular Data Service. The DLS includes AT&T Digital Life Data Centers and AT&T Digital
Life Central Monitoring Centers. AT&T will be utilizing the DLS in delivering services to
consumer and business customers.
The purpose of this document is to provide an overview of the DLS and instructions
concerning the installation and operations of the DLS.

Installation and Operations Manual
AT&T Proprietary (Internal Use Only)
—2—
2 Digital Life System Overview
2.1 System Architecture
The AT&T Digital Life System (DLS) provides an Internet Protocol (IP) based end-to-end
services delivery platform that AT&T will utilize in providing services to customers. The
DLS includes a Network Platform and a Premises Platform. AT&T Cellular Data Service
provides the primary communication between the Network Platform and the Premises
Platform. Optionally, a secondary communication path between the Network Platform
and the Premises can be established via a Bring-Your-Own-Broadband service, which
could be based on an ADSL, VDSL, FiOS, cable modem or some other wireline
broadband service.
The initial commercial deployment of DLS will be utilized to offer consumer customers
Professionally Monitored Home Security and Home Automation & Control services.
Figure 1 is a representation of the AT&T DLS Architecture. Within the system
architecture the Network Platform includes AT&T Digital Life Data Centers.
Figure 1: AT&T Digital Life System Architecture
