ATB AQUAmax BASIC User manual

AQUAMAX® BASIC/CLASSIC
Operating Instructions

Important information for consumers in the EU
Disposal instructions for batteries and rechargeable batteries
Every consumer is legally obliged to return all used batteries and
rechargeable batteries according to the Battery Ordinance (Directive
2006/66/EC). Disposal in the household waste is prohibited. Since
batteries and rechargeable batteries are also included in the delivery of
products from our range, we would like to point out the following:
Used batteries and rechargeable batteries do not belong in the
household waste, but can be handed in free of charge at the public
collection points of your municipality and everywhere where batteries
and rechargeable batteries of the respective type are sold.
Furthermore, the end user has the option of returning batteries and
accumulators to the retailer from whom they were purchased (statutory
take-back obligation).
Disposal of electronic equipment
Due to the European Regulation 2012/19/EU, your electronic device
must not be disposed of with normal household waste! We will dispose
of your electrical equipment in a professional and environmentally
responsible manner. This service is free of charge, not including
transport costs. This service only applies to electrical appliances
purchased after 13.08.2005. Send the appliance you want to dispose
of to your supplier free of charge.

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 3 from 36
Contents
General and safety information…………………………… .......................................... 4
Functional description ........................................................................................ 6
Control unit ATBcontrol© 3 - Connect ..................................................................... 8
General information on operation .................................................................... 9
Commissioning .............................................................................................. 10
Main level ...................................................................................................... 12
Logbook .................................................................................................... 12
Settings ..................................................................................................... 13
Service Mode ............................................................................................. 15
Manual operation / Info .............................................................................. 16
Date/Time / Language / Error Reset ............................................................ 17
Pre-set Parameters ........................................................................................ 18
Current limiting values ................................................................................... 19
Error messages ............................................................................................. 19
UVS® ............................................................................................................ 19
Control Circuit Board / Fuses .......................................................................... 20
Potential-free Contact .................................................................................... 20
Configuration of the Connection Socket ........................................................... 21
USB-connection ............................................................................................. 21
Technical Data .............................................................................................. 22
Mobile Access via WiFi-Direct ........................................................................ 23
Information on routine maintenance .................................................................... 23
Rectification of faults ......................................................................................... 24
Important data for fault diagnosis of the electrical units ....................................... 26
EC Declaration of Conformity ............................................................................. 27

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 4 from 36
Dear customer,
At this point we would like to thank you for the trust which you have shown with the purchase of
this product.
On the following pages you will find everything necessary about the ioperation and the
maintenance requirements of your AQUAMAX® small wastewater treatment plant.
Please observe that the maintenance are very important for a good treatment performance.
General and Safety Information
With the AQUAMAX® one is concerned with a technical system which, in combination with a multi-
chamber tank, is employed as small wastewater treatment plant for the aerobic biological treatment
of domestic and comparable wastewater of up to 75 PE from single or several buildings.
Dimensioning, design and operation are to take place up to 50 PE in accordance with EN 12566-3.
With employment in accordance with regulations no hazards whatsoever emanate from the plant. If
the AQUAMAX® is used for other purposes without the explicit approval of ATB WATER GmbH
and/or the following safety information is ignored, this can lead to the hazarding or injury of
persons and to malfunctions or defects in the plant. In this case any liability is excluded,
Modifications to the plant or unauthorized conversion is not permitted.
The AQUAMAX® and accessories are not intended to be used by persons (including children) with
limited physical, sensory or mental capabilities or due to a lack of experience and/or knowledge,
unless they are supervised by or receive instruction from a person responsible for their safety, as
to how the AQUAMAX® and accessories are to be used. Children are to be supervised in order to
ensure that they do not play with them.
Before use the AQUAMAX® is to be installed correctly and in agreement with the installation
instructions. Installation instructions, operating and maintenance instructions are to be read
thoroughly and the instructions included therein are to be followed implicitly.
With assembly and installation, commissioning and operation as well as, if required,
decommissioning, national standard specifications and regulations are to be complied with. All
tasks may be carried out by trained and qualified specialists with appropriate certificate of technical
qualification. The operator is to be instructed by the fitter.
With the connection of the control system the national applicable regulations and the details on the
type plate are to be complied with (mains voltage, frequency etc.). The equipment is to be operated
on a network which includes a protective earth conductor (PE). Attention is to be paid to correct
phase connection (even with plug-in design)! The connection to the mains must take place by
means of separate fusing and residual current protective circuit breaker. Before commissioning,
the correct function of the electrical protective measures must be checked!
The installation work is to be carried out by qualified electricians only. With work on the equipment
fundamentally the mains plug is to be disconnected. A separation or extension of the cable is not
permitted. The electrical connection data is to be taken from the type plate on the equipment.
Operate no equipment which has a damaged connector/connection cable or plug, which indicates
a malfunction, has been dropped or has been damaged in any way.
With all maintenance and repair work the plant is to be disconnected from the mains. The
AQUAMAX® can be removed easily from the tank. If the plant is to be climbed into, this may take
place only with the presence of a second person (this is fundamental!). Particular care is to be

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 5 from 36
taken. The applicable accident prevention regulations and rules of technology are to be complied
with.
In the versions with submersible aerator the AQUAMAX® feeds the required air to the wastewater
through a rapidly rotating propeller. Never work in the vicinity of the aerator as long as the
AQUAMAX® is connected with the mains. Danger of injury!
The correct function can only be guaranteed with the employment of original spare parts or spare
parts approved by ATB. Before commissioning, all points of the operating instructions are to be
checked. Keep these instructions readily to hand at all times!
Explanation of the warning notices used:
Attention! Danger due to electrical voltage!
Rotating parts. Danger of crushing and being drawn into the area of the submersible aerator!
The ATBcontrol© 3 Connect is delivered as a ready-to-plug-in version. There is no need for wiring
on site.
ATTENTION! Before opening the ATBcontrol© 3 – Connect and/or the connection
box it/they must be disconnected from the mains supply. Work on opened units
may be carried out exclusively by qualified electricians! Pay attention to phase-
correct connection (even with plug-in design)!
As you are concerned with an electrical plant with submerged motor units, a
separate B16 fuse and a (separate) upstream 30 mA ELCB (earth leakage circuit
breaker) is absolutely essential!
Attention is to be paid to correct laying of the protective earth conductor up to the
earthing of the building.
Make sure that no damage to persons, material or downstream equipment can
occur, especially during the manual commissioning of units (manual operation)!

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 6 from 36
Functional Description
The wastewater treatment plant works according to the activated sludge principle using the
retention process (single tank or SBR plant). With this, the contaminants from the wastewater are
taken up by suspended micro-organisms (activated sludge) and converted into biomass.
The wastewater first reaches the coarse interceptor. Every 2 hours – according to the principle of a
communicating pipe and with the aid of an excess sludge pump – the retained wastewater is fed
into the aeration stage. The aeration takes place intermittently via a submersible motor aerator or
with a compressor and membrane tube diffusers on the tank bottom (CLASSIC ZB).
After 6 hours the aeration phase ends and the settling phase begins.
After 2 hours settling time the treated wastewater is pumped out using the clarified water pump.
The switch-off point is determined via a float switch. If, as a result of a pump defect, this minimum
water level is not achieved an alarm is triggered. After ca. 8 hours, with the end of the clarified
water removal, the cycle is ended and a new one begins.
The control unit can be matched to the respective requirement case. With commissioning the plant
is set to the maximum number of persons connected. A modification of this setting is not required
with short-term over or underloading.
The plant achieves its full treatment performance after a run-up period of ca. one month. With more
extreme underloading or temperatures under 12° C it can also take longer until the biology has
developed completely. In this case it is recommended to seed using activated sludge in order to
accelerate matters.
With the AQUAMAX® BASIC charging, removal of excess sludge and the drawing off of clarified
water take place using only one pump. The water streams with this are fed into the individual areas
using a patented hydraulic system.
*alternatively membrane tube diffuser on the tank bottom
*

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 7 from 36
Holiday / energy-saving operation
If, over a period of more than 4 hours, no wastewater flows into the plant, then the system switches
automatically into the energy-saving holiday operation. The aeration time is reduced to the point
that the micro-organisms just have sufficient oxygen available. With normal loading the plant
switches back into the operating mode set.
Sampling
As the pumping out process is of a short duration only, the treated water is collected into a suitable
container in the filtering tank (accessory: 1.5 l sampling bottle). The container is mounted in the
vicinity of the cover and is thus easily accessible from above.
Alternatively a container can be deployed in a separate sampling shaft.
Installation and dimensioning
Dimensioning and statutory installation conditions are described in more detail in the German
National General Technical Approval.
Operation and maintenance
Small wastewater treatment plants must be checked by the operator at certain intervals as well as
being serviced twice a year by a specialist. Both are important for a correct operation of the plant.
The sludge removal of the primary settling stage takes place, depending on utilisation, once a year
or as required.
Further details on this can be taken from the corresponding chapter.
Application possibilities
The AQUAMAX® is conceived for the treatment of domestic wastewater. The following may not be
fed to the small wastewater treatment: commercial/trade wastewater (insofar as it is not
comparable with domestic), infiltration water (e.g. drainage water), cooling water, runoff water from
swimming pools, precipitation water.
Technical data
The AQUAMAX® consists of the following electrical units:
 1 (BASIC) or 2 submersible pump(s)
 1 or 2 submersible motor aerator(s)
or compressor(s)
 1 float switch
 1 control unit
The units are designed for 230V, 50 Hz.
In addition, the AQUAMAX® consists of a carrier frame, pipelines and hoses.
The electrical components are subjected to systematic wear. In individual cases these components
must be exchanged after 2 years. The service life of the units, from experience, lies between 5 and
10 years.
Treatment performance
The AQUAMAX® meets the following limiting values (with standard conditions and correct
operation):
 BOD5: 20 mg/l
 COD: 90 mg/l
 NH4N (>12°C): 10 mg/l

Ntot: 25 mg/l (>12°C)

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 8 from 36

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 9 from 36
Control unit ATBcontrol© 3 - Connect
Features
Features
 Microprocessor controlled
 USB connection for data readout and input
 Splash water protected. Conditionally suitable for outside areas (IP54)
 Wall mounting
 Voltage failure detection system (UVS®)
 Floating contact for an additional alarm facility
 Simple and rapid operation
 Times for all parameters completely pre-programmed
 Automatic run-in phase with suppression of excess sludge removal
 Parameter settings freely selectable
 Alarm interval
 Alarm volume adjustable
 Deployable for AQUAMAX® BASIC / CLASSIC
 Plug-in
 Winter operation and sludge removal mode for the reduction of the aeration times
 Mobile access via internet browser (e.g. with smartphone or tablet) via WiFi-Direct
General information on operation
The operation of the control unit takes place via three short-stroke keys. By pressing a key the
display illumination is switched on (lapses if no key is operated within 5 minutes).
Key functions:
↑↓ Scroll upwards or downwards / menu selection
OK Transition of cursor to the character, which is to be changed / value input is saved /
selection of menu point / menu setback.
With temperatures below 0°C a severely limited function of the LC display is to be anticipated.

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 10 from 36
Commissioning
With first commissioning basic settings and tests are carried out. Please ensure that all information
for this is available. With input of the plant values all important parameters are pre-set. However,
we recommend that, following commissioning, the parameters are again checked under
Settings, as false values can, inter alia, lead to an increased power consumption.
In the Service Mode you have the possibility later of undertaking modifications.
Language selection
Enter language you need. German, English, French, Italian, Romanian,
Polish, Slovenian, Spanish, Dutch are available.
Password input
Please enter the six-figure code number.
Date and time
Enter the date and time.
Important for the correct entries in the logbook
Selection of the plant type
Select between BASIC or CLASSIC.
Number of inhabitants
Select the connected PT.
The settings belonging to the number of inhabitants are carried out
automatically.
Serial number
Here you enter the serial number that is located on the sewage treatment
plant. Please make sure to enter the serial number right-justified so that there
are leading zeros.
The SSID of the control unit is also defined with the entry (for mobile access
via WiFi Direct). The SSID should be assigned "systematically". If not the
system serial number (preferably), then e.g. the serial number of the control unit. A subsequent
change is possible in the settings.
(
=WiFi-No.-endin
g)

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 11 from 36
New plant?
With yes, the sludge return feed is suppressed for half a year (run-in
phase).
Test run
In test run operation the current float level and the current power input are
indicated. Pressing OK carries out the test run.
With this make absolutely sure that no one is working in the danger area of the
running submerged aerator!
The individual units are taken into operation for 4 seconds and are checked for overload and/or
underload. If the minimum permitted value is undercut or the maximum permitted value is
exceeded a warning signal results.
By manual switching of the float switch (BASIC: submerging in or removing from the water) the
test run can be repeated and concluded.
The test run can be interrupted through OK.
Saving of the parameters
Have you made an incorrect input? By selecting no and OK the
commissioning can be repeated.
If the inputs are correct, confirm with yes and OK.

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 12 from 36
Info indication / Current phase
This is followed by a change to the information display. The system type, the
selected number of PTs, the software version and serial number of the
sewage treatment plant type (or SSID for mobile access) are displayed..
With this commissioning is completed. Changes can be made by qualified personnel in service
mode.
The current phase is indicated after ca. 5 minutes. By pressing ↑↓ you,
however, have the possibility of changing over again to info indication or to
the main level.
The indication of the current phase informs you about the current status of
the wastewater treatment plant. Indicated are the operating hours of the individual units, the
current cycle phase and its duration as well as the time. In the case of malfunction, in addition, the
fault which has occurred is indicated.
ATTENTION: Feeding is integrated in a 10-minute feeding phase! The remaining time of the
feeding phase is shown in the display. The actual feeding (according to the presetting) only takes
place at the end of the feeding phase!
By a single pressing of any key the background lighting is activated lapses 5 minutes after the last
operation of a key).
Main Level
In the main level you have the possibility, using OK,↑↓ and OK again, of
accessing various sub-menus, which enables the acquisition of further
information, amendment of settings or moving into manual operation.
You leave the main level through ↑↓ until the point Return and OK.
Logbook
All relevant errors, run times, events and messages are lodged in the
logbook.
You access the individual points using ↑↓ and OK.
Errors
Recording of the error messages which have
arisen (max. 1000). An explanation of the
indicated messages can be found in the appendix.
Return using OK.
Run times
You can have the run times
shown in a weekly summary
and over the complete
operating time.
1.0 Info .
ATBcontrol 3 Connect
AQUAMAX CLASSIC
EW4
1.10.26
1000

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 13 from 36
Events
Documentation of manual interventions (max.
1000). E.g. Changes of run times.
Return using OK.
Messages
Every change of status is documented here; e.g.
when the float switch has switched, when the
compressor has switched on and off (also whether
automatically or manually), failure of the mains
supply voltage.
Settings
All relevant settings can be reviewed here.
Modifications are, with the exception of the confirmation of a sludge removal
and of the signal tone, are possible in the Service Mode.
Operating parameters
feeding: specification of the feeding time (with
the BASIC the number of charging batches) for
the build-up of the communicating pipe between
coarse filter and sludge activation.
fed. pause: Time period between batches.
Deni phase: Duration of the denitrification
phase. The denitrification phase is component
part of the aeration phase and takes place
following the charging.
Deni aer. ON/OFF: Aeration times/pauses
during the denitrification phase.
Aer. phase: Duration of the complete charging phase.
ON/Off norm: Aeration times/pauses during the normal phase.
Aer. ON/OFF econ: Aeration times/pauses during the economy
phase.
sediment.: Duration of the settling phase.
CW evacuation: If the removal of the clarified water at the end of the
settling phase takes longer than the run time specified a flooding
warning takes place.
followup: In order to prevent a "wrong" level signal accidentally
caused by water movements after reaching the actual float switch-off
current limits
WiFi-settings
alarm pause
sludge evacuation
signal sound

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 14 from 36
point, a follow-up time can be entered.
Sl back: Time for the excess sludge removal. This takes place once
during a cycle, immediately following an aeration.
Flush pulse: In order to free the clarified water pump of activated
sludge, which has collected in the casing during the aeration phase,
the pump is operated during the settling phase for the time set (with the
BASIC the number of the charging batches). Through the short-term
build-up of a head of water and the subsequent subsidence, the sludge
is driven out of the casing.
run-in phase: During the listed number of days no excess sludge
removal takes place.
Current limits
Minimum/maximum current consumption of the
individual units below/above which an alarm
signal takes place.
WiFi settings
WiFi (de)activation.
The control unit can then be accessed with a
mobile device and an internet browser. The SSID
is preset by specifying the serial number during
commissioning and can be changed here if necessary.
The default password for the network connection is "ATBWATER" and
can also be changed here. ATTENTION: If the password is changed,
access from outside may no longer be possible!
IP address (192.168.1.123): Necessary for calling up the programme in
the browser (cannot be changed).).
Alarm pause
If errors occur within the selected time interval
(max. 12 hours), then the acoustic alarm is
emitted only after run-out of this time.
Sludge evacuation
With activation the aeration times are reduced by
20% for a period of six weeks (no further reduction
in winter operation).
Following successful activation this function is
blocked for six months.
Signal sound
Selection of the volume of the alarm sound.
current limits
WiFi-settings .
alarm pause
sludge evacuation
signal sound
2.2.3 WiFi-Einstellungen ..
active yes
SSID ATBc-3-001000
PWD ATBWATER
IP 192.168.1.123
esca
p
e

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 15 from 36
Service mode
The access to the Service Mode takes place via a 6-figure code number,
which is made available exclusively to the authorised specialist firm.
In the Service Mode all parameters relevant and necessary for the
operation of the wastewater treatment plant are set and changed. Please
note that false inputs can lead to a faulty process!
The inputs are not checked for plausibility! ATB WATER
GmbH rejects any claims under warranty for the results of
inappropriate inputs!
Our service department will be very happy to provide you
with support.
Operating parameters
With the selection of the PT number with
commissioning, the parameters lodged in the
memory are loaded. At this point you have the
chance of carrying out modifications. For
description of the individual points see above
(Settings).
Product type
Selection of the product type.
Inhabitants
Selection of the connected inhabitants. The
associated parameter values are loaded
automatically.
Current Limits
Minimum/maximum current consumption of the
individual units below/above which an alarm
signal takes place.
Serial number
Here you enter the serial number that is located
on the sewage treatment plant. Please make sure
to enter the serial number right-justified so that
there are leading zeros.
The SSID of the control unit is also defined with the entry (for mobile access via WiFi
Direct). The SSID should be assigned "systematically". If not the system serial number
(preferably), then e.g. the serial number of the control unit. A subsequent change is
possible in the settings.
(
=WiFi-No.-endin
g)

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 16 from 36
Floating contact
Activation/deactivation of the floating contact
(Standard: deactivated).
Factory settings
All parameters are set back to the values for the
selected plant type and the population figure.
Test run
Mode of operation s. Commissioning.
Winter operation
Activation/deactivation of the winter operation
(Standard: activated).
With the activation the aeration times in the
months December, January and February are
reduced by 20% (no further reduction following
activated sludge removal).
Manual mode
In the manual mode the individual units can be
commissioned manually and the function of the floating
contact can be checked.
With the changeover to manual operation the normal
programme sequence is maintained (all units = OFF) and following ending of the manual operation
is continued at the respective point.
Indicated are the position of the float switch and the actual current consumption.
Info
Under this point you can call up the details for the
selected type, the PT value set, the version number and
the date of commissioning.

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 17 from 36
Date / Time
Possibility for input / correction for date and time.
Important for the correct entries in the
logbook!
Language
Possibility of modifying the language settings.
Delete error
Following acknowledgement of an error message this,
with a renewed occurrence over a period of 72 hours, is
suppressed.
If this is not wanted, i.e. the error should be reported
immediately with the next occurrence, press OK.

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 18 from 36
Pre-set Parameters
Type BASIC CLASSIC
[PT] No. Duration Pause Duration ON OFF ON OFF ON OFF
[sec] [h] [min] [sec] [min] [h]
min / max
1
4/10 4/30 1,0 /
2
10/90 5/60 5/20 3/22 0:30 / 15 7:30 / 20 0:30/15 7:30/20
100:30 00:30
2 00:30 00:30
4 00:42 00:30
6 00:48 00:30
8 01:00 00:30
10 01:18 00:39
12 01:36 00:48
16 02:12 01:06
20 01:00 00:30
24 01:12 00:36
28 01:24 00:42
32 01:36 00:48
36 01:48 00:54
40 02:00 01:00
44 02:18 01:09
48 02:30 01:15
50 02:42 01:21
60 510:00 05:00
75 615:00 07:30
Type BASIC CLASSIC BASIC CLASSIC BASIC CLASSIC ZB
[PT] No.
[min] [min] [sec] [sec] [sec] [sec] [sec]
min / max
1
60/120 10/120 0/120 0/120 0/30 0/90 0.2/1.0 0.2/0.5
120 0 0 58
220 1 1 65
420 2 2 85
620 3 3 102
820 4 4 123
10 20 5 5 142
12 22 6 6 165
16 30 8 8 201
20 36 10 258
24 43 12 290
28 50 14 332
32 58 16 374
36 65 18 565
40 72 20 607
44 80 22 659
48 86 24 706
50 90 25 746
60 20 10 885
75 25 15 1101
1Minimum or maximum possible input values
2The maximum time corresponds to the specified time of the aeration phase.
3With standard conditions. These values can, in practice, vary by +/- 10%.
379
0,510
436
522
622
1462
1068
Water
removal
Run-on time
41
30
311
2,0
1,3
6,0
4,0
0,2
Charging Denitrification Aeration
phase
Flushing surge
Aeration
[min:sec] [min:sec]
5
7
Settling
phase
07:30
Energy consumption³Sludge removal
Normal operation
Aeration Aeration
10 10
943
818
755
Economy mode
202
270
195
07:30
BASIC / CLASSIC
[kWh/a]
1561
1192
1268
1374
90 0
The setting of the control system takes place to the above details. The table is saved in the control
unit; a manual input of the individual values is not necessary and at this point serves solely for
checking.

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 19 from 36
Current Limiting Values**
Type Aerato
r
Compresso
r
Charging pump Clar. water pump
ZB-version**
[PT] [A] [A] [A] [A]
min/max 0 / 6,5 0 / 6,5 0 / 6,5 0 / 6,5
1
2Quarter-/ Half chambe
r
40,2 … 0,6
6
8Full chamber
10 0,3 … 0,9
12
16
20
24
28
32
36
40
44
48
50
60
75 1,6 … 5,0 1,5 … 4,0
0,5 ... 3,7
0,5 ... 2,0
1,3 ... 6,3
(CLASSIC
only)
0,6 … 2,0
1,2 … 4,0
** For the ZB variants (pressure aeration), the current limiting values for the
compressor until 50 PT must be entered manually!
Error Messages
"Current min" The minimum permitted current of the respective unit is undercut for
longer than 5 seconds following switching OFF of the unit. The
value of the current, which is measured, is saved as environmental
condition.
"Current max" The maximum permitted current of the respective unit is exceeded
for longer than 5 seconds following switching ON of the Unit. The
value of the current, which is measured, is saved as environmental
condition.
"Flooding" A flooding alarm is identified as, despite the maximum, activation
time of the clarified water pump, no change of the float has been
identified.
UVS® (Under Voltage Signalling / Voltage failure detection)
The UVS® simplifies the safeguarding of an efficient operation. If there is a power failure (supply
voltage < 100 V), e.g. through the activation of the residual current circuit breaker (RCCB) or a
fuse, an acoustic alarm is initiated. The pulse tone continues, depending on the charged status of
the accumulator, for up to 24 hrs. The signal is deactivated by pressing any key or as soon as a
sufficiently high voltage is generated. Adjustments do not have to be undertaken. A power failure is
recorded in the logbook.

Operating instructions AQUAMAX® BASIC/CLASSIC
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0270 / Status: 09.06.2023 / Page 20 from 36

N
L
ATBcontrol© 3 – Connect Control Circuit Board
Fuses
The control system has one socketed insert fuse of the TR5 type. The fuse can be exchange using
needle-nosed pliers.
Should an exchange of fuse be necessary the control unit MUST be disconnected
from the mains beforehand!
Floating contact
The control unit has a contact that is designed as a changeover
contact, e.g. for connecting external signal transmitters (warning
lamp, horn).
When the contact is activated and the mains voltage is connected,
the changeover contact is switched to NO* (14) in the fault-free
state. In the event of a fault (including a power failure) and manual
operation, the contact switches to NC* (12).
Signalling devices must therefore be connected to NC (12), the
power supply to C* (11).
If a separate alarm signal in case of power failure is desired, a power
source independent of the power supply for the control system is
necessary.
.
*NO(14) = Normally Open; NC(12) = Normally Closed; C/CO(11) = common conductor
ATTENTION: A floating contact is only a "switch" and not a direct voltage supply for the external
Unit fuse:
T 6,3 A; 250 V
Rel. SL-pump
(only CLASSIC)
Rel. CW-pump
Relais aerator
Floating contact
USB-connection
Switching state in a voltage-free
status or in the event of a fault.
