ELGA PURELAB Classic - US User manual

PURELAB Classic - US
Operator Manual

ELGA PURELAB Classic Operator Manual
PURELAB Classic - US Version 2 11/15 Page i
Copyright Note
The information contained in this document is the property of VWS
(UK) Ltd. and is supplied without liability for errors or omissions.
No part of this document may be reproduced or used except as
authorized by contract or other written permission from VWS (UK) Ltd.
The copyright and all restrictions on reproduction and use apply to all
media in which this information may be placed.
VWS (UK) Ltd. pursue a policy of continual product improvement and
reserve the right to alter without notice the specification, design, price
or conditions of supply of any product or service.
© VWS (UK) Ltd. 2014
All rights reserved.
Publication ref: MANU40555
Version 2 11/15
ELGA LabWater is a trading name of VWS (UK) Ltd.
ELGA® and PURELAB® are registered trademarks.
Minncare is a trademark of Minntech Corporation.
EfferSan™ is a trademark of Activon Inc.

PURELAB Classic Operator Manual ELGA
Page ii PURELAB Classic –US Version 2 11/15
TABLE OF CONTENTS
1. INTRODUCTION...........................................................1
1.1 Product Range.....................................................1
1.2 Use of this Manual................................................1
1.3 Customer Support................................................1
2. HEALTH AND SAFETY NOTES...................................2
2.1 Electricity..............................................................2
2.2 Ultraviolet Light.....................................................2
2.3 Control of Substances Hazardous to Health
(COSHH)..............................................................2
2.4 Chemical and safety notes ...................................3
3. PRODUCT AND PROCESS DESCRIPTION.................4
3.1 Product Description..............................................4
3.2 Process Description .............................................5
3.3 Technical Specification.........................................9
4. CONTROLS................................................................12
5. INSTALLATION INSTRUCTIONS...............................13
5.1 Unpacking the PURELAB Classic.......................13
5.2 Positioning the PURELAB Classic......................13
5.3 Connecting the PURELAB Classic .....................15
5.4 Initial Controller Set up.......................................17
5.5 Setting Up Password / Resetting Replacement
Timers................................................................21
5.6 Initial Start Up.....................................................23
5.7 POU Filter Installation (LC134) –Optional
Accessory...........................................................25
6. OPERATION...............................................................26
6.1 Intermittent Recirculation....................................26
6.2 Manual Dispense................................................26
7. MAINTENANCE..........................................................27
7.1 Replacing the Purification Pack (LC186) ............27
7.2 Replacing the Ultrafilter (LC169) ........................28
7.3 Replacing the Ultraviolet Lamp (LC170).............31
7.4 Replacing the Point-Of-Use Filter (LC134) .........32
7.5 Cleaning Inlet Strainer........................................33
8. SANITIZATION PROCEDURES .................................34
8.1 Tablet sanitization process ....................................34
8.1 EfferSan™Sanitization Tablet - Safety Information37
8.2 Liquid sanitization...............................................38
9. TROUBLE SHOOTING...............................................41
10. CONSUMABLES AND ACCESSORIES.....................42

ELGA PURELAB Classic Operator Manual
PURELAB Classic - US Version 2 11/15 Page iii
11. KEY TO CONTROL PANEL....................................... 43
11.1 Icons.................................................................. 43
11.2 Alarm Conditions ............................................... 44
11.3 Replacement Timers.......................................... 44
11.4 Quality Alarms ................................................... 45
12. WARRANTY/CONDITIONS OF SALE ....................... 46
13. USEFUL CONTACT DETAILS................................... 48

ELGA PURELAB Classic Operator Manual
PURELAB Classic Version 2 11/15 Page 1
1. INTRODUCTION
1.1 Product Range
This operator manual has been prepared for the PURELAB Classic
product models:
PURELAB Classic DI - US
PURELAB Classic UV - US
PURELAB Classic UF - US
PURELAB Classic UVF - US
1.2 Use of this Manual
This manual contains full details on installation, commissioning and
operation of the PURELAB Classic unit. If the instructions in this
handbook are not followed then the performance of this product
and/or the safety of the user may be compromised.
1.3 Customer Support
Service support and consumable items are available from your local
ELGA LabWater distributor. Refer to customer service contact details
shown at the end of this publication.
PURELAB Classic

PURELAB Classic Operator Manual ELGA
Page 2 PURELAB Classic Version 2 11/15
2. HEALTH AND SAFETY NOTES
PURELAB Classic products have been designed to be safe,
however, it is important that personnel working on these units
understand any potential dangers. All safety information detailed in
this handbook is highlighted as WARNING and CAUTION
instructions. These are used as follows:
WARNING! WARNINGS ARE GIVEN WHERE
FAILING TO OBSERVE THE
INSTRUCTION COULD RESULT IN
INJURY OR DEATH TO PERSONS.
CAUTION! Cautions are given where failure to
observe the instruction could result in
damage to the equipment, associated
equipment and processes.
2.1 Electricity
It is essential that the electrical supply to the PURELAB Classic is
isolated before any items are changed or maintenance work
performed.
The ON/OFF switch is located at the left-hand side of the unit. The
mains power lead is located just behind the ON /OFF switch.
WARNING! THIS APPLIANCE MUST BE EARTHED.
The main water supply should be isolated and residual pressure
released prior to removal of any Purification Packs or carrying out
work on the unit.
Switching off the electrical supply will isolate the source of mains
water pressure.
2.2 Ultraviolet Light
WARNING! UNDER NO CIRCUMSTANCES SHOULD
THE LAMP BE CONNECTED AND
ACTIVATED WHEN OUTSIDE THE
HOUSING.
The Classic UV and Classic UVF units are fitted with an ultraviolet
lamp. The UV lamp is enclosed in a stainless steel chamber ensuring
that the operator will not be exposed to UV light.
2.3 Control of Substances Hazardous to Health (COSHH)
Material safety data sheets covering the various replaceable
Purification Packs are available upon request. Contact your local
supplier or distributor.
UV Lamp
Classic with UV Lamp
Fuse
ON/OFF
switch
Mains power lead
Mains power socket

ELGA PURELAB Classic Operator Manual
PURELAB Classic Version 2 11/15 Page 3
2.4 Chemical and safety notes
WARNING! ALWAYS WEAR RUBBER GLOVES, APRON AND FACEMASK.
DO NOT BREATHE FUMES OR ALLOW TO COME IN CONTACT
WITH SKIN OR EYES. ALWAYS FOLLOW RECOMMENDATIONS
FOUND IN THE MANUFACTURERS MATERIAL SAFTEY DATA
SHEET AND ANY APPLICABLE OSHA STANDARDS FOR
CHEMICAL USED.
WARNING! LABEL THE MACHINE WITH APPROPRIATE SIGNS SUCH AS
“DO NOT USE/CONTAINS STERILANT” (NOT PROVIDED)
2.4.1Tablet sanitization
During the sanitization cycle ONE of EfferSan™multi-purpose
disinfecting tablet is used and relevant safety information is included
in this handbook. Please refer to the manufacturer for material safety
data sheets.
EfferSan™is EPA registered as Multi-purpose disinfecting tablets.
2.4.2Liquid sanitization
During the sanitization cycle Minncare Cold Sterilant is used and
relevant safety guidance is included in this handbook. Please refer to
the manufacturer for material safety data sheets.
Minncare Cold Sterilant is EPA registered as a sterilant, high level
disinfectant, and sanitizer.
Spent Minncare Cold Sterilant is acidic and requires normal
neutralization as specified by your local state and local regulations.
1% of Minncare Cold Sterilant has a pH of 3.5.
Container
Level Indicator

PURELAB Classic Operator Manual ELGA
Page 4 PURELAB Classic Version 2 11/15
3. PRODUCT AND PROCESS
DESCRIPTION
3.1 Product Description
The PURELAB Classic water purification unit has been specifically
designed to provide a supply of ultrapure water with very low levels
of impurities for laboratory, medical and industrial applications.
The PURELAB Classic can be bench, under bench or wall mounted
with an optional wall mounting kit. A range of accessories is available
to complement the unit (see Section 10 - Consumables and
Accessories, for details).
Control Panel Dispense Nozzle Dispense Controller
Door
PURELAB Classic
The PURELAB Classic range of water purification units has been
designed to provide high purity water for laboratory applications. The
products need to be fed with pre-treated water, typically from a
reverse osmosis supply. They can be operated directly from a
ringmain feed as point of use polishers, with or without local buffer
storage, using a Docking Vessel or suitable reservoir. Alternatively,
they can be supplied from a local pre-treatment/storage system, for
example a PURELAB Prima and Docking Vessel combination.

ELGA PURELAB Classic Operator Manual
PURELAB Classic Version 2 11/15 Page 5
3.2 Process Description
Classic DI
Pre-treated water enters via an inlet solenoid and is then
pumped through the purification pack and temperature and
water quality sensors before being dispensed or re-circulated
through a non-return valve back to the pump inlet.
Ionic and organic impurities are removed by the purification
pack. Product water resistivity and temperature are
measured before dispense and will indicate when the
purification pack needs to be replaced.
The water within the unit is re-circulated through the
purification technologies to maintain purity. To reduce heat
build up the recirculation is at reduced flow rate and is set to
be intermittent (5 minutes every hour).
An optional POU filter is available if required to protect the
outlet from bacterial contamination.

PURELAB Classic Operator Manual ELGA
Page 6 PURELAB Classic Version 2 11/15
Classic UV
Pre-treated water enters via an inlet solenoid and is then
pumped through the UV chamber, a purification pack and
temperature and water quality sensors before being
dispensed or re-circulated through a non-return valve back to
the pump inlet.
Purified water flows directly through the UV chamber where it
is exposed to intense UV radiation at a wavelength of 185 nm
to provide continuous bacterial control.
Ionic and organic impurities are removed by the purification
pack. Product water resistivity and temperature are
measured before dispense and will indicate when the
purification pack needs to be replaced.
The water within the unit is re-circulated through the
purification technologies to maintain purity. To reduce heat
build up the recirculation is at reduced flow rate and is set to
be intermittent (5 minutes every hour).
An optional POU filter is available if required to protect the
outlet from bacterial contamination.

ELGA PURELAB Classic Operator Manual
PURELAB Classic Version 2 11/15 Page 7
Classic UF
Pre-treated water enters via an inlet solenoid and is then
pumped through the purification pack, an ultrafilter and
temperature and water quality sensors before being
dispensed or re-circulated through a non-return valve back to
the pump inlet.
Ionic and organic impurities are removed by the purification
pack; the ultrafilter removes pyrogens, bacteria and other
microbial impurities as well as particles. Product water
resistivity and temperature are measured before dispense and
will indicate when the purification pack needs to be replaced.
The water within the unit is re-circulated through the
purification technologies to maintain purity. To reduce heat
build up the recirculation is at reduced flow rate and is set to
be intermittent (5 minutes every hour).
An optional POU filter is available if required to protect the
outlet from bacterial contamination.

PURELAB Classic Operator Manual ELGA
Page 8 PURELAB Classic Version 2 11/15
Classic UVF
Pre-treated water enters via an inlet solenoid and is then
pumped through the UV chamber, a purification pack, an
ultrafilter and temperature and water quality sensors before
being dispensed or re-circulated through a non-return valve
back to the pump inlet.
Purified water flows directly through the UV chamber where it
is exposed to intense UV radiation at a wavelength of 185 nm
to provide continuous bacterial control and the photo-
oxidation of residual organic impurities.
Ionic and organic impurities are removed by the purification
pack; the ultrafilter removes pyrogens, bacteria and other
microbial impurities as well as particles. Product water
resistivity and temperature are measured before dispense
and will indicate when the purification pack needs to be
replaced.
The water within the unit is re-circulated through the
purification technologies to maintain purity. To reduce heat
build up the recirculation is at reduced flow rate and is set to
be intermittent (5 minutes every hour).
An optional POU filter is available if required to protect the
outlet from bacterial contamination.

ELGA PURELAB Classic Operator Manual
PURELAB Classic Version 2 11/15 Page 9
3.3 Technical Specification
The Technical Specifications for the PURELAB Classic are as
follows:
Feedwater*
Parameter
Limits
Source - Originally from potable supply,
then pre-treated
Preferably reverse osmosis (RO) or filtered service deionisation (SDI) or distilled.
Note: mixed bed or twin bed deionised supplies should be cation limited at exhaustion.
Fouling Index (max)
1 for all models. A 0.2 micron membrane prefilter is recommended for all non-RO feeds.
Service Deionisation (SDI) - M-cm
1 M-cm minimum resistivity at exhaustion.
Reverse Osmosis (RO) - µS/cm
Recommended < 30 µS/cm
Free Chlorine
0.05 ppm max.
TOC
Recommended 50 ppb max.
Carbon Dioxide
30 ppm max.
Silica
2 ppm max.
Particulates
Filtration down to 0.2 micron advisable to protect internal and/or point of use filters.
Temperature
1 - 40°C - Recommended 10 - 15°C
Flowrate (maximum requirement)
130 l/hr
Drain requirements (gravity fall with air gap).
Maximum during service
Up to 2 l/min
Feedwater Pressure
0.7 bar (10 psi), maximum, 0.07 bar (1 psi) minimum
* Contact technical support for advice on feedwaters outside the range listed.
Note: Different system configurations are available for different feedwater sources. See system set up.
Dimensions
Height
490 mm (19.3")
Width
410 mm (16.2")
Depth
365 mm (14.4")
Weight
DI
14.0 kg (30.8 lb)
UV
14.5 kg (32.0 lb)
UF
14.5 kg (32.0 lb)
UVF
15.0 kg (33.1 lb)
Connections
Inlet-quick connect
8 mm (5/16") OD
Flush - UF/UVF
8 mm (5/16") OD
Positioning
Wall, bench or under bench mounted.
Environment
Clean dry indoor. Temp 5 - 40°C.
Humidity max 80% non-condensing.

PURELAB Classic Operator Manual ELGA
Page 10 PURELAB Classic Version 2 11/15
Electrical Requirements
Mains input
100 -240 V ac, 50-60 Hz all models
System voltage
24 V dc
Power consumption during recirculation
60 VA
Power consumption during dispense
75 VA
Fuses
2 x T6.3 Amp
Reservoir level connection
Jack Plug 3.5 mm
Noise level during recirculation
<40 dBA
User Interface
Display
Continuous graphical quality display
Graphical flow schematic on screen with mimic display
Backlit display with Intuitive Icons
Adjustable settings
Display viewing angle
Adjustable electronically
Water quality units
Selectable (M.cm or µS/cm)
Water quality alarm
Selectable alarm setpoints
Date / time
Adjustable
Auto restart after power failure
Selectable (On/Off)
Audible alarm
Selectable (On/Off)
Temperature control
Selectable alarm setpoints
Reservoir
Selectable (On/Off)
Indicators
Product water quality
Resistivity or conductivity
Temperature
Degrees Centigrade
Purification pack
Replacement date
UV lamp*
Replacement date
Filter*
Replacement date
Alarms-Audiovisual
Purified water purity
Below set point alarm
Temperature
Above set point alarm
UV lamp operation*
Imminent lamp failure or failure to start
Purification pack
Change reminder
UV lamp*
Change reminder
Filter*
Change reminder
Reservoir****
Low level / level control disconnect alarm
Outputs
RS232 printer connection
RS232 remote display connection
Volt free contact-internal
Remote dispense

ELGA PURELAB Classic Operator Manual
PURELAB Classic Version 2 11/15 Page 11
Safety Features
Power fail safe
Water temperature alarm
Water quality alarm
Purification pack interlock
UV current monitoring
Timeout of dispense
Low operating voltage 24 V
Volt free contact alarm connection
Visual alarms
Audible alarms
Operational Features
Low noise levels –minimum intrusion
Variable dispense flowrate
Restart on power interrupt
Optional printer kit to record operating parameters
Optional remote display
Purified Water Specification
DI
UV
UF
UVF
Flowrate
2.0 l/min max.
Inorganic
Resistivity 18.2 M.cm (0.055S/cm)
TOC
**<15 ppb
**<5 ppb
**<15 ppb
**<10 ppb
Bacteria
***<1 cfu/ml
<1 cfu/ml
<1 cfu/ml
<1 cfu/ml
Pyrogens
<0.02 Eu/ml
<0.005 Eu/ml
pH
Effectively neutral
Particles
***0.2 m
***0.2 m
Ultrafiltration
RNase / DNase
-
Capacity
(LC162)
45,000 liters >18M.cm per single purification pack/S at pH 7.0
70,000 liters >1M.cm per single purification pack/S at pH 7.0
Confirms to ASTM, CAP, NCCLS –Type 1 and BS3978 Grade 1 Specification.
* On some models only.
** Dependant on feedwater - recommended RO feed <50 ppb TOC.
*** With POU filter fitted.
As part of our policy of continual improvement we reserve the right to
alter the specifications given in this document.

PURELAB Classic Operator Manual ELGA
Page 12 PURELAB Classic Version 2 11/15
4. CONTROLS
The PURELAB Classic operates with a tactile membrane control
panel, which has a graphics display window and four multi-purpose
control buttons.
Details of how to use the controls will be given in the appropriate
sections.
The PURELAB Classic control panel has a range of control icons as
follows:
Button
Icon
Function
PROCESS
Turns the process
on/off.
ESCAPE from any
feature
LEFT
Menu
Scroll
CENTRE
Accept
RIGHT
Mute Alarm
Printer
Process button
Left hand Centre Right hand
Control button Control button Control button
Control Panel

ELGA PURELAB Classic Operator Manual
PURELAB Classic Version 2 11/15 Page 13
5. INSTALLATION INSTRUCTIONS
5.1 Unpacking the PURELAB Classic
The following items are supplied with your PURELAB Classic:
1. PURELAB Classic unit.
2. By-pass block LA638 (1 off, fitted in unit).
3. 6 metres of 8mm (5/16") O/D tube.
4. 1 off Strainer Assembly.
5. Operator Manual in English.
6. Mains Lead.
7. Reservoir Level Connecting Lead.
5.2 Positioning the PURELAB Classic
Before installation and operation of the PURELAB Classic unit,
please read and observe the following points.
Environment
The unit should be installed on a flat, level surface, in a clean,
dry environment. The unit can also be wall mounted against a
vertical wall capable of supporting the weight (for this we
recommend the use of the wall mounting kit Part No. LA610
on substantial brick/concrete walls or LA622 for stud partition
walls).
WARNING!IF THE UNIT IS TO BE WALL MOUNTED,
ENSURE IT IS MOUNTED USING THE
CORRECT WALL MOUNTING KIT AND
THAT THE WALL IS CAPABLE OF
SUPPORTING THE OPERATING WEIGHT
OF THE SYSTEM. ALWAYS CAREFULLY
FOLLOW THE INSTRUCTIONS
INCLUDED IN THE KIT.
Note: Refer to Specifications for unit weights
(Section 3.3 - Technical Specification).
The unit is designed to operate safely under the following conditions:
Indoor Use
Altitude up to 2000 m
Temperature Range 5 - 40°C
Maximum Relative Humidity 80% @ 31°C decreasing
linearly to 50% @ 40°C, non-condensing
The unit is in Installation Category II, Pollution Degree 2, as per
IEC1010-1.
Rear Mounting Points
Unit Rear Mounting Points

PURELAB Classic Operator Manual ELGA
Page 14 PURELAB Classic Version 2 11/15
Electrical
The units can be connected universally to any electrical
supply in the range of 100 –240 V and 50 –60 Hz. The mains
lead is supplied with a molded plug on one end and a molded
connector to the unit on the other. The unit should be
connected to an earth. The unit includes a battery which will
require changing on a periodic basis, typically every 3-5 years.
(Contact local Service provider)
WARNING! DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE
ONLY WITH THE SAME OR
EQUIVALENT TYPE RECOMMENDED BY
THE MANUFACTURER (3 VOLTS,
LITHIUM CR2032). DISPOSE OF USED
BATTERIES ACCORDING TO THE
MANUFACTURER’S INSTRUCTIONS.
Drain/Flush
A semi-rigid flexible connection to a sink or suitable drain
capable of at least 2.0 l/min is required for Classic UF and
Classic UVF versions. The drain point should have a gravity
fall below the level of the unit and any connections direct to
drain should have an air-break device fitted. A flexible tube
should be temporarily connected to the dispense outlet and
directed to drain during rinsing of purification packs.
Feed Water
The feedwater should be potable water, pre-purified using
reverse osmosis, deionisation, or distillation. If using a supply
other than reverse osmosis treated, it is strongly
recommended that a 0.2 micron membrane filter is installed
within the feed line to remove colloidal impurities. The
feedwater should enter the PURELAB Classic via an 8 mm
(5/16") O/D semi rigid tube, and should be in the temperature
range 1 to 40C (34 to 104F). To ensure optimum
performance it is recommended that the feedwater
temperature be between 10 to 15°C.
CAUTION! Operating with feed water temperatures
outside the range from 1 to 40°C (33.8 to
104F) will cause damage to the
PURELAB Classic unit.
For pressurized feeds, the minimum direct inlet pressure is
0.07 bar (1.0 psi) and maximum inlet pressure is 0.7 bar
(10 psi). Feedwater pressures up to 4 bar (60 psi) must be
reduced using a pressure regulating valve (Part No. LA652).
CAUTION! High feedwater pressures which may
exceed 4bar (60 psi) must be reduced
using a pressure regulator with built in
pressure relief (Part No. LA575).
Failure to install the correct pressure
regulator will cause damage to the
PURELAB Classic unit.
Reservoir feeds to the PURELAB Classic unit should be
positioned at the same height, or above the unit, to provide a
positive flooded inlet pressure of approximately 0.07 bar
(1 psi).
Fuse
ON/OFF
switch
Mains power lead
Mains power socket
Electrical Connections

ELGA PURELAB Classic Operator Manual
PURELAB Classic Version 2 11/15 Page 15
5.3 Connecting the PURELAB Classic
Once the PURELAB Classic unit has been positioned either on a wall
or on a bench, it should be connected as follows:
Mains water inlet tube
UF drain tube - to drain
Step 1 - Remove Transit Plugs
1. PUSH in collet on connector.
2. PULL out transit plug.
3. CUT a clean square end on an 8 mm OD semi-rigid
drain tube.
4. PUSH tube into connector.
Step 2 - Connect Water Inlet
1. Connect 8 mm tube from the PURELAB Classic inlet to
the inlet strainer.
2. Connect the inlet strainer to the pre-purified water
supply.
Step 3 - Connect Drain
1. Connect 8 mm tube from the UF drain (if fitted) and
direct to a suitable drainage point.
CAUTION! The drain line should allow a gravity
fall to drain with no restrictions.
Inlet and Drain Connection
Feed Water Inlet
Connector
Collet
Blanking
transit plug
Pull plug
Depress
collet
Clean square
cut end
Tube 8mm OD
Simply push in tube to attach
Tube in secured position
Fitting tubes
UF Drain
Inlet
