ATEN UE3310 User manual

USB 3 Extender Cable
UE3310 / UE3315A
User Manual
www.aten.com
UE3310 / UE3315A User Manual
ii
EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT: This equipment has been tested and found to comply with the
limits for a Class B digital service, pursuant to Part 15 of the FCC rules These
limits are designed to provide reasonable protection against harmful
interference in a residential installation Any changes or modifications made to
this equipment may void the user’s authority to operate this equipment This
equipment generates, uses, and can radiate radio frequency energy If not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications However, there is no guarantee that
interference will not occur in a particular installation
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment
This device complies with Part 15 of the FCC Rules Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation
KCC Statement:
RoHS
This product is RoHS compliant
UE3310 / UE3315A User Manual
iii
User Information
nline Registration
Be sure to register your product at our online support center:
Telephone Support
For telephone support, call this number:
User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose Any of
the manufacturer's software described in this manual is sold or licensed as is
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device It is the
responsibility of the user to correct such interference
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation PLEASE VERIFY THAT THE VOLTAGE SETTING IS
CORRECT BEFORE USE
International http://eservice.aten.com
International 886 2 8692 6959
China 86 400 810 0 810
Japan 81 3 5615 5811
Korea 82 2 467 6789
North America 1 888 999 ATEN ext 4988
1 949 428 1111
UE3310 / UE3315A User Manual
iv
Package Contents
1 UE3310 / UE3315A USB 3 Extender Cable
1 Power Adapter
1 Extension Cable
1 User Instructions
Note: Make sure that ll of the components are present and in good order If
anything is missing or was damaged in shipping, contact your dealer
UE3310 / UE3315A User Manual
v
Table of Contents
EMC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
RoHS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Package Contents iv
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
1. Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
The UE3310 / UE3315A Top View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
The UE3310 / UE3315A Side View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. Hardware Setup
Connecting the UE3310 / UE3315A Unit . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Daisy Chaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Connecting a USB Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Appendix
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
UE3310 / UE3315A User Manual
vi
About this Manual
This user manual is provided to help you get the most from the UE3310 /
UE3315A unit It covers all aspects of installation, configuration, and
operation An overview of the information found in the manual is provided
below
Chapter 1, Introduction introduces you to the UE3310 / UE3315A USB 3
Extender Cable Its purpose, features, and panel components are presented and
described
Chapter 2, Hardware Setup describes the steps that are necessary to
quickly and safely set up your installation
Appendix provides a list of safety instructions and precautions, contact
information for ATEN technical support, product specifications, and other
technical information
Note:

Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit or any connected
devices.

ATEN regularly updates its product documentation for new features and
fixes. For an up to date UE3310 / UE3315A documentation, visit http://
www.aten.com/global/en/
UE3310 / UE3315A User Manual
vii
Conventions
This manual uses the following conventions:
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
Reseller Visit ATEN on the Web for a list of locations and telephone numbers:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential steps.
→Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start
→
Run means to
open the Start menu, and then select Run.
Indicates critical information.
International http://www.aten.com
North America http://www.aten usa.com
UE3310 / UE3315A User Manual
viii
This Page Intentionally Left Blank
1
Chapter 1
Introduction
verview
The ATEN UE3310 / UE3315A USB 3 Extender Cable allows you to extend
the distance between your computer and your USB peripherals by 10 / 15
meters Unlike typical cables the UE3310 / UE3315A is an active extension
cable The UE3310 / UE3315A provides a reliable, high performance
transmission that utilizes USB 3 data bandwidth up to 5Gb/s and also backward
compatible with USB 2 0/1 1 standard The USB can be powered through the
computer via the extender cable It’s plug and play and no additional software
installation required, makes it easy to deploy and operate on the fields
The UE3310 / UE3315A provides a quick and high quality cost effective
solution for all kinds of professional environments like: hospitals, factories, or
business facilities
Features
Supports USB 3 Specification (5 Gbps)
Ultra slim lightweight design
Unique locker head design for long-distance extension usage – daisy-chain
a further one unit for a maximum distance of up to 30 m (UE3315A) and a
further four units for a maximum distance of up to 50 m (UE3310)
Multiplatform support – Windows and Mac
Additional power supply included
Requirements
To complete the installation, you will also require the following items that are
not included with the product:
USB 1 1, 2 0, or 3 compatible computer (host computer) with a USB
compliant operating system
USB 1 1, 2 0, or 3 compatible device
UE3310 / UE3315 User Manual
2
The UE3310 / UE3315A Top View
The UE3310 / UE3315A Side View
ITEM TYPE DESCRIPTI N
1 USB Connector Connect the USB peripherals to the USB Connector.
2 Power LED LED lights green when power is on and the UE3310 /
UE3315A is connected.
3 AC Power
Adapter Port
Use this port to connect a power adapter.
4 USB lock Used to connect to the host device (computer).
ITEM TYPE DESCRIPTI N
1 USB Connector Connect the USB peripherals to the USB Connector.
2 AC Power
Adapter Port
Use this port to daisy chain other UE3310 / UE3315A
extender cables.
3 USB lock Used to connect to the host device (computer).
3
Chapter 2
Hardware Setup
Connecting the UE3310 / UE3315A Unit
Follow the steps below to connect the UE3310 / UE3315A units
UE3310
UE331 A
Please review the safety information regarding the placement of this
device in Safety Instructions, page 5
10M
x1
x2
x3
x4
x5
Max. 50m
15M
x1
x2
Max. 30m
UE3310 / UE3315A User Manual
4
Before you can install the UE3310 / UE3315A, you need to:
1 Connect your UE3310 / UE3315A to the computer’s USB port
2 Use the UE3310 / UE3315A extender cable to connect the computer to
your USB peripheral device
3 Turn on your computer, and your USB device
(Optional) To utilize the maximum extended distance follow these steps:
1 Attach additional USB 3 Extender Cables (up to 30 meters maximum for
UE3315A or 50 meters maximum for UE3310) to the installation using a
daisy chain configuration
2 Use a power adapter if used in a daisy chain configuration If the USB
devices have high usage consumption you may need to add extra power
adapters The power adapter should be attached to the last USB connector
in the daisy chain set up
Daisy Chaining
To extend the signal to a greater distance, up to 30 meters maximum for
UE3315A or 50 meters maximum for UE3310 Extender cables can easily be
daisy chained from the original UE3310 / UE3315A via a unique daisy chain
port
The maximum number of cables that can be daisy chained together is
dependent on cable model number The UE3310 can connect a total of 5 cables
and the UE3315A can connect a total of 2 cables The UE3310 and UE3315A
can be combined together using a daisy chain set up Be aware that all setups
should be on the premise of there is up to 5 layers of Hub under one USB host
controller
Connecting a USB Device
If the USB device’s connector is too small to fit the connection on the USB
extender cable Type A female lock, then use the extension cable to connect
your device
Compatibility
Compatible with USB 3 specifications and backwards compatibility with USB
1 1/2 0 governing the design of USB devices However, ATEN does not
guarantee that all USB devices are compatible with the UE3310 / UE3315A,
as there are a number of different configurations that may impact the operation
of USB devices over extended distances
5
Appendix
Safety Instructions
General
This product is for indoor use only
Read all of these instructions Save them for future reference
Follow all warnings and instructions marked on the device
Do not place the device on any unstable surface (cart, stand, table, etc ) If
the device falls, serious damage will result
Do not use the device near water
Do not place the device near, or over, radiators or heat registers
The device cabinet is provided with slots and openings to allow for
adequate ventilation To ensure reliable operation, and to protect against
overheating, these openings must never be blocked or covered

The device should never be placed on a soft surface (bed, sofa, rug, etc ) as
this will block its ventilation openings Likewise, the device should not be
placed in a built in enclosure unless adequate ventilation has been provided

Never spill liquid of any kind on the device

Unplug the device from the wall outlet before cleaning Do not use liquid
or aerosol cleaners Use a damp cloth for cleaning

The device should be operated from the type of power source indicated on
the marking label If you are not sure of the type of power available,
consult your dealer or local power company

To prevent damage to your installation it is important that all devices are
properly grounded

Do not allow anything to rest on the power cord or cables Route the
power cord and cables so that they cannot be stepped on or tripped over

Position system cables and power cables carefully; Be sure that nothing
rests on any cables

Never push objects of any kind into or through cabinet slots They may
touch dangerous voltage points or short out parts resulting in a risk of fire
or electrical shock

Do not attempt to service the device yourself Refer all servicing to
qualified service personnel
UE3310 / UE3315A User Manual
6

If the following conditions occur, unplug the device from the wall outlet
and bring it to qualified service personnel for repair

The power cord or plug has become damaged or frayed

Liquid has been spilled into the device

The device has been exposed to rain or water

The device has been dropped, or the cabinet has been damaged

The device exhibits a distinct change in performance, indicating a need
for service

The device does not operate normally when the operating instructions
are followed

Only adjust those controls that are covered in the operating instructions
Improper adjustment of other controls may result in damage that will
require extensive work by a qualified technician to repair
Appendix
7
Technical Support
International
For online technical support – including troubleshooting, documentation,
and software updates: http://support aten com
For telephone support, see Telephone Support, page iii:
North America
When you contact us, please have the following information ready beforehand:
Product model number, serial number, and date of purchase
Your computer configuration, including operating system, revision level,
expansion cards, and software
Any error messages displayed at the time the error occurred
The sequence of operations that led up to the error
Any other information you feel may be of help
Email Support support@aten usa.com
Online Technical
Support
Troubleshooting
Documentation
Software Updates
http://www.aten usa.com/support
Telephone Support 1 888 999 ATEN ext 4988
1 949 428 1111
UE3310 / UE3315A User Manual
8
Specifications
Function UE3310 UE3315A
Connectors USB
upstream
1 x USB 3 Type A Male (Blue) 1 x USB 3 Type A Male (Blue)
USB
Downstream
1 x USB 3 Type A Female (Blue) 1 x USB 3 Type A Female (Blue)
USB Specifications USB 3 / 2.0 / 1.1 for Super / High
/ Full or Low Speed
USB 3 / 2.0 / 1.1 for Super / High
/ Full or Low Speed
USB Data Rate Up to 5 Gbps Up to 5 Gbps
Cable Length 10m 15 m
Device Color Black Black
Power Consumption (Watt) 5V, 4.5W 5V, 4.5W
Environmental Operating
Temp.
0–40°C 0–40°C
Storage
Temp.
20–60°C 20–60°C
Humidity 0–80% RH, Non condensing 0–80% RH, Non condensing
Physical
Properties
Housing Plastic Plastic
Weight 0.76 kg
(1.67 lb)
1.19 kg
(2.62 lb)
Dimensions
(L x W x H)
8.19 x 2.22 x 1.75 cm
(3.22 x 0.87 x 0.69 in.)
8.19 x 2.22 x 1.75 cm
(3.22 x 0.87 x 0.69 in.)
Appendix
9
Limited Warranty
ATEN warrants its hardware in the country of purchase against flaws in
materials and workmanship for a Warranty Period of two [2] years (warranty
period may vary in certain regions/countries) commencing on the date of
original purchase This warranty period includes the LCD panel of ATEN LCD
KVM switches Select products are warranted for an additional year (see A+
Warranty for further details) Cables and accessories are not covered by the
Standard Warranty
What is covered by the Limited Hardware Warranty
ATEN will provide a repair service, without charge, during the Warranty
Period If a product is detective, ATEN will, at its discretion, have the option
to (1) repair said product with new or repaired components, or (2) replace the
entire product with an identical product or with a similar product which fulfills
the same function as the defective product Replaced products assume the
warranty of the original product for the remaining period or a period of 90 days,
whichever is longer When the products or components are replaced, the
replacing articles shall become customer property and the replaced articles
shall become the property of ATEN
To learn more about our warranty policies, please visit our website:
http://www aten com/global/en/legal/policies/warranty-policy
© Copyright 2023 ATEN® International Co., Ltd.
Released: 2023 05 30
ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.

Other manuals for UE3310

2

This manual suits for next models

1

Other ATEN Cables And Connectors manuals

ATEN VS-132 User manual

ATEN

ATEN VS-132 User manual

ATEN VS0108H User manual

ATEN

ATEN VS0108H User manual

ATEN VS-102 User manual

ATEN

ATEN VS-102 User manual

ATEN UN-201 User manual

ATEN

ATEN UN-201 User manual

ATEN VanCryst VS1804T User manual

ATEN

ATEN VanCryst VS1804T User manual

ATEN VanCryst VS172 User manual

ATEN

ATEN VanCryst VS172 User manual

ATEN VS1814T User manual

ATEN

ATEN VS1814T User manual

ATEN UC331C User manual

ATEN

ATEN UC331C User manual

ATEN VS-162 User manual

ATEN

ATEN VS-162 User manual

ATEN 2X-EA10 User manual

ATEN

ATEN 2X-EA10 User manual

ATEN VS1814T User manual

ATEN

ATEN VS1814T User manual

ATEN UC1284B User manual

ATEN

ATEN UC1284B User manual

ATEN VanCryst VS172 User manual

ATEN

ATEN VanCryst VS172 User manual

ATEN VS0110HA User manual

ATEN

ATEN VS0110HA User manual

ATEN DigiProcessor KG9900T User manual

ATEN

ATEN DigiProcessor KG9900T User manual

ATEN VS0108HA User manual

ATEN

ATEN VS0108HA User manual

ATEN CV-131A User manual

ATEN

ATEN CV-131A User manual

ATEN VanCryst VE872 User manual

ATEN

ATEN VanCryst VE872 User manual

ATEN VS0108HB User manual

ATEN

ATEN VS0108HB User manual

ATEN Lok-u-Plug 2X-EA07 User manual

ATEN

ATEN Lok-u-Plug 2X-EA07 User manual

ATEN VanCryst VS172 User manual

ATEN

ATEN VanCryst VS172 User manual

ATEN UC1284B User manual

ATEN

ATEN UC1284B User manual

ATEN VS182A User manual

ATEN

ATEN VS182A User manual

ATEN 2X-EA08 User manual

ATEN

ATEN 2X-EA08 User manual

Popular Cables And Connectors manuals by other brands

LEGRAND Green up 0 904 72 instruction manual

LEGRAND

LEGRAND Green up 0 904 72 instruction manual

nvent Erico Ericore instruction sheet

nvent

nvent Erico Ericore instruction sheet

HRS DF51 Series quick start guide

HRS

HRS DF51 Series quick start guide

Telegärtner STX V6 Assembly instructions

Telegärtner

Telegärtner STX V6 Assembly instructions

Pentair DigiTrace E104 installation instructions

Pentair

Pentair DigiTrace E104 installation instructions

Bosch B99 installation manual

Bosch

Bosch B99 installation manual

Altrad BELLE MAXIPAVE Operator's manual

Altrad

Altrad BELLE MAXIPAVE Operator's manual

Lütze LION microPLC operating instructions

Lütze

Lütze LION microPLC operating instructions

Philips Sonicare 300 SerieS user manual

Philips

Philips Sonicare 300 SerieS user manual

Gefen EXT-HDMI1.3-145 user manual

Gefen

Gefen EXT-HDMI1.3-145 user manual

CableMax DASL-102 user manual

CableMax

CableMax DASL-102 user manual

PCB Piezotronics 010P20 Installation and operating manual

PCB Piezotronics

PCB Piezotronics 010P20 Installation and operating manual

NCR 7403-K112 Kit instructions

NCR

NCR 7403-K112 Kit instructions

SP CONNECT 53218 Mounting instructions

SP CONNECT

SP CONNECT 53218 Mounting instructions

Gefen TOOLBOX GTB-HD4K2K-148C-BLK user manual

Gefen TOOLBOX

Gefen TOOLBOX GTB-HD4K2K-148C-BLK user manual

Lindy 32356 user manual

Lindy

Lindy 32356 user manual

Lindgren-Pitman LP S-1200 Instruction and maintenance

Lindgren-Pitman

Lindgren-Pitman LP S-1200 Instruction and maintenance

GoMax Electronics SP-4004Z-PT user manual

GoMax Electronics

GoMax Electronics SP-4004Z-PT user manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
