ATEN CL5200 User manual

User Manual
CL5200
cl5200-aam-v1.book Page i Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
ii
FCC Information
This is an FCC Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
RoHS
This product is RoHS compliant.
cl5200-aam-v1.book Page ii Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
iii
User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer's software described in this manual is sold or licensed `as is'.
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VERIFY THAT THE VOLTAGE SETTING IS
CORRECT BEFORE USE.
A typical LCD (Liquid Crystal Display) monitor has millions of pixels. A dead
pixel refers to a pixel with a defect in its ability to display the correct color
output. It most often looks like a tiny black or white spot on your screen,
although it can be any other color. Since even a tiny dust particle on one of the
pixels during the manufacturing process or a slight bump during shipping can
create a dead pixel, the ISO 13406-2 norm defines 4 classes of acceptable
screens with dead pixels--Class 1 is the best; Class 4 is the worst. Almost all
manufacturers use Class 2 to establish their warranties, which allows a certain
amount of dead pixels to exist before they will replace the screen. Since the
manufacturers consider these screens to be acceptable under ISO
specifications, we cannot be responsible for replacement or warranty of the
TFT LCD panel.
cl5200-aam-v1.book Page iii Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
iv
Safety Instructions
General
Read all of these instructions. Save them for future reference.
Follow all warnings and instructions marked on the device.
Do not place the device on any unstable surface (cart, stand, table, etc.). If
the device falls, serious damage will result.
Do not use the device near water.
Do not place the device near, or over, radiators or heat registers.
The device cabinet is provided with slots and openings to allow for
adequate ventilation. To ensure reliable operation, and to protect against
overheating, these openings must never be blocked or covered.
The device should never be placed on a soft surface (bed, sofa, rug, etc.) as
this will block its ventilation openings. Likewise, the device should not be
placed in a built in enclosure unless adequate ventilation has been
provided.
Never spill liquid of any kind on the device.
Unplug the device from the wall outlet before cleaning. Do not use liquid
or aerosol cleaners. Use a damp cloth for cleaning.
The device should be operated from the type of power source indicated on
the marking label. If you are not sure of the type of power available,
consult your dealer or local power company.
The device is equipped with a 3-wire grounding type plug. This is a safety
feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not attempt to defeat the
purpose of the grounding-type plug. Always follow your local/national
wiring codes.
Do not allow anything to rest on the power cord or cables. Route the
power cord and cables so that they cannot be stepped on or tripped over.
If an extension cord is used with this device make sure that the total of the
ampere ratings of all products used on this cord does not exceed the
extension cord ampere rating. Make sure that the total of all products
plugged into the wall outlet does not exceed 15 amperes.
To help protect your system from sudden, transient increases and
decreases in electrical power, use a surge suppressor, line conditioner, or
un-interruptible power supply (UPS).
cl5200-aam-v1.book Page iv Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
v
Position system cables and power cables carefully; Be sure that nothing
rests on any cables.
When connecting or disconnecting power to hot-pluggable power
supplies, observe the following guidelines:
Install the power supply before connecting the power cable to the
power supply.
Unplug the power cable before removing the power supply.
If the system has multiple sources of power, disconnect power from the
system by unplugging all power cables from the power supplies.
Never push objects of any kind into or through cabinet slots. They may
touch dangerous voltage points or short out parts resulting in a risk of fire
or electrical shock.
Do not attempt to service the device yourself. Refer all servicing to
qualified service personnel.
If the following conditions occur, unplug the device from the wall outlet
and bring it to qualified service personnel for repair.
The power cord or plug has become damaged or frayed.
Liquid has been spilled into the device.
The device has been exposed to rain or water.
The device has been dropped, or the cabinet has been damaged.
The device exhibits a distinct change in performance, indicating a need
for service.
The device does not operate normally when the operating instructions
are followed.
Only adjust those controls that are covered in the operating instructions.
Improper adjustment of other controls may result in damage that will
require extensive work by a qualified technician to repair.
cl5200-aam-v1.book Page v Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
vi
Rack Mounting
Before working on the rack, make sure that the stabilizers are secured to
the rack, extended to the floor, and that the full weight of the rack rests on
the floor. Install front and side stabilizers on a single rack or front
stabilizers for joined multiple racks before working on the rack.
Always load the rack from the bottom up, and load the heaviest item in the
rack first.
Make sure that the rack is level and stable before extending a device from
the rack.
Use caution when pressing the device rail release latches and sliding a
device into or out of a rack; the slide rails can pinch your fingers.
After a device is inserted into the rack, carefully extend the rail into a
locking position, and then slide the device into the rack.
Do not overload the AC supply branch circuit that provides power to the
rack. The total rack load should not exceed 80 percent of the branch circuit
rating.
Ensure that proper airflow is provided to devices in the rack.
Do not step on or stand on any device when servicing other devices in a
rack.
cl5200-aam-v1.book Page vi Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
vii
Package Contents
Basic Package
The basic CL5200 package consists of:
1 CL5200 with Standard Rack Mount Kit
1 Custom KVM Cable Set
1 Power Cord (CL5200L / CL5200M)
1 User Manual*
1 Quick Start Guide
Optional Equipment
Depending on any optional equipment that you may have purchased, one of the
following may be included in your package:
Standard Rack Mount Kit - Long
Easy-Installation Rack Mount Kit - Short
Easy-Installation Rack Mount Kit - Long
Check to make sure that all the components are present and that nothing got
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of the
devices connected to it.
*Features may have been added to the CL5200 since this manual was printed.
Please visit our website to download the most up to date version of the
manual.
© Copyright 2006
Manual Part No. PAPE-0270-100G
Printing Date:01/2007
All brand names and trademarks are the registered property of their respective owners.
cl5200-aam-v1.book Page vii Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
viii
Contents
FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Basic Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Optional Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
About this Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
ATEN Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
Online Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
1. Introduction
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Switches and Computers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
OS Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Front View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CL5200C / CL5200D Rear View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
CL5200L / CL5200M Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2. Hardware Setup
Before you Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Standard Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CL5200C / CL5200D Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CL5200L / CL5200M. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. Operation
Opening the Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Closing the Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Operating Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
LCD OSD Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
The LCD Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
The Adjustment Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Console Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Port ID Numbering & Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
cl5200-aam-v1.book Page viii Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
ix
Appendix
Optional Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
CL5200C / CL5200D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
CL5200L / CL5200M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
cl5200-aam-v1.book Page ix Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
x
About this Manual
This User Manual is provided to help you get the most from your c/c system.
It covers all aspects of installation, configuration and operation. An overview
of the information found in the manual is provided below.
Chapter 1, Introduction, introduces you to the CL5200 system. Its
purpose, features and benefits are presented, and its front and back panel
components are described.
Chapter 2, Hardware Setup, describes how to setup your installation. The
necessarystep– froma basicsinglestage hookup toacomplete 32 switchdaisy
chained operation are provided.
Chapter 3, Operation, explains the fundamental concepts involved in
operating the CL5200.
An Appendix, provides specifications and other technical information
regarding the CL5200.
cl5200-aam-v1.book Page x Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
xi
Conventions
This manual uses the following conventions:
ATEN Information
Online Registration
You can register your ATEN product at our online e-Support Center:
http://support.aten.com.
Online Support
Online technical support is available to ATEN customers through our e-
Support center: http://support.aten.com.
Troubleshooting, Documentation (including online manuals), and
Software Updates (firmware and drivers) are available at the ATEN
website: http://www.aten.com.
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential steps.
→Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start →Run means to
open the Start menu, and then select Run.
Indicates critical information.
cl5200-aam-v1.book Page xi Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
xii
This Page Intentionally Left Blank
cl5200-aam-v1.book Page xii Thursday, January 25, 2007 3:36 PM

1
Chapter 1
Introduction
Overview
TheCL5200series consistsof KVMconsolemodules thatfeature anintegrated
LCD panel, full keyboard, and touchpad in a 1U rack-mountable sliding
housing. They were developed in response to the enormous popularity of the
sliding console found on the CL5208 and CL5216 KVM switches. Those
switches are made up of two major modules: the front-end sliding KVM
Console module, and the back-end KVM Switch module.
The CL5200 is similar to the front-end Console module found on the CL5208
and CL5216. Its purpose is to serve as the front end sliding console for
compatible KVM switches*. By only having to purchase the CL5200, users
who already have a compatible KVM switch can take advantage of the space
saving and efficiency benefits of the sliding console module without the
unnecessary expense of having to purchase a model that includes a KVM
Switch module.
The similarities and differences among the models in the CL5200 series are
shown in the following table:
Setup is fast and easy. Simply use the KVM cable set supplied with this
package to link the CL5200's KVM port to the console port of your KVM
switch and you are ready to go.
For convenience, ports to link an external keyboard, video, mouse console are
also provided.
*The CL5200 supports most KVM switches that have PS/2 console port
connectors. If you are unsure if your switch is supported, check with your
dealer.
Model LCD Panel Power
CL5200C 15" DC
CL5200D 17" DC
CL5200L 15" AC
CL5200M 17" AC
cl5200-aam-v1.book Page 1 Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
2
Features
Integrated KVM console with 15"or 17" LCD monitor - in a sliding
housing with top and bottom clearance for smooth operation in a 1U high
system rack
Standard rack mount kit included – optional Easy Rack Mounting (single
person installation) rack mount kit available (requires separate purchase)
Supports an external console
Compatible with most PS/2 KVM switches
Internal power supply
No software required - convenient computer selection via Hotkeys
High video resolution:
Up to 1024 x 768 @75Hz (15" LCD)
Up to 1280 x 1024 @75Hz (17" LCD)
Supports DDC, DDC2, DDC2B
DDC emulation of the LCD monitor
Video settings of attached computers are automatically adjusted for
optimal output to the LCD monitor
Language support: American English; UK English; German; French;
Spanish; Traditional Chinese; Japanese; Korean
cl5200-aam-v1.book Page 2 Thursday, January 25, 2007 3:36 PM

1. Introduction
3
Requirements
Switches and Computers
The CL5200 supports most KVM switches that have PS/2 console port
connectors. If you are unsure whether your switch is supported or not,
check with your dealer.
The integrated LCD monitor's maximum resolution is 1024 x 768 @75Hz
(15"), or 1280 x 1024 @75Hz (17"). Make sure that none of the resolution
settings of the connected computers exceed the LCD monitor's maximum
resolution.
Cables
For optimum signal integrity and to simplify the layout, we strongly
recommend that you use the high quality Custom Cable set provided with this
package. Different length cable sets, described in the table below, can be
purchased from your dealer.
OS Support
*This operating system does not support USB.
Length (m) Part Number
1.2 2L-5201P
1.8 2L-5202P
3.0 2L-5203P
6.0 2L-5206P
OS Version
Microsoft Windows: 2000 and higher
Linux RedHat 7.1–7.3, 8.0, 9.0, Fedora Core 2–4
SuSE 8.2, 9.3, 10
Mandriva (Mandrake) 9, 2005 Limited Edition, 2006
UNIX IBM AIX: 4.3, 5L
FreeBSD 4.2, 4.5
Novell Netware: 5.0*, 6.0
cl5200-aam-v1.book Page 3 Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
4
Components
Front View
No. Component Description
1 Handle Pull to slide the KVM module out; push to slide the module in.
2 Slide Release In order to slide the console out, you must first release it by
moving this tab sideways. See p. 11 for details on sliding the
console in and out.
3 LCD Display After sliding the KVM module out, flip up the cover to access
the LCD monitor.
4 LCD Controls The LCD On/Off switch is located here, as well as buttons to
control the position and picture settings of the LCD display.
See p. 14, for details.
5 Keyboard
6 Touchpad
7 Power LED Lights BLUE to indicate that the unit is receiving power.
8 Rack Mounting
Tabs The rack mounting tabs located at each corner of the unit secure the chassis to a system rack.
9 Lock LEDs The Num Lock, Caps Lock, Scroll Lock LEDs are located here.
10 Reset Switch Located to the right of the Lock LEDs. Press this recessed
switch in with a thin object to perform a system reset.
5
9
8
10
3
4
2
2
1
6
7
cl5200-aam-v1.book Page 4 Thursday, January 25, 2007 3:36 PM

1. Introduction
5
CL5200C / CL5200D Rear View (DC Power)
No. Component Description
1 Power Socket The DC power cord plugs in here.
2 Power Switch
3 Ground
4 ExternalConsole
Section For flexibility and convenience, the CL5200 supports an independent, external, KVM console. The external console's
keyboard, monitor, and mouse plug in here. Choice of which
console the video displays on is made with hotkey
combinations (see Console Selection, page 16 for details).
5 KVM Port The cable that links the CL5200 to the KVM switch plugs in
here
Note: The shape of this 15-pin connector has been
specifically modified so that only KVM cables designed to
work with this switch can plug in (see Cables, page 3, for
details).
1 2
53 4
cl5200-aam-v1.book Page 5 Thursday, January 25, 2007 3:36 PM

CL5200 User Manual
6
CL5200L / CL5200M Rear View (AC Power)
No. Component Description
1 Power Socket This is a standard 3 prong AC power socket. The power cord
from your AC source plugs in here.
2 Power Switch This is a standard rocker switch that powers the unit On and
Off.
3 ExternalConsole
Section For flexibility and convenience, the CL5200 supports an independent, external, KVM console. The external console's
keyboard, monitor, and mouse plug in here. Choice of which
console the video displays on is made with hotkey
combinations (see Console Selection, page 16 for details).
4 KVM Port The cable that links the CL5200 to the KVM switch plugs in
here
Note: The shape of this 15-pin connector has been
specifically modified so that only KVM cables designed to
work with this switch can plug in (see Cables, page 3, for
details).
1 2
4
3
cl5200-aam-v1.book Page 6 Thursday, January 25, 2007 3:36 PM

7
Chapter 2
Hardware Setup
Before you Begin
Standard Rack Mounting
A standard rack mount kit is provided with your CL5200. The kit enables the
switch to be mounted in rack with a depth of 42 - 72 cm.
Note: It takes two people to mount the switch: one to hold it in place; the other
to screw it in.
Optional mounting kits - including single person Easy Installation kits - are
available with a separate purchase. See page 17 in the Appendix for optional
rack mounting details.
1. Important safety information regarding the placement of this
device is provided on page iv. Please review it before proceed-
ing.
2. Make sure that power to all the devices you will be connecting
up have been turned off. You must unplug the power cords of
any computers that have the Keyboard Power On function.
L Brackets
Side Mountng
Brackets

CL5200 User Manual
8
To rack mount the switch, do the following:
1. While one person positions the switch in the rack and holds it in place, the
second person - using the screws provided with the rack mount kit -
loosely screws the front brackets to the rack.
2. While the first person still holds the switch in place, the second person
slides the L brackets into the switch's side mounting brackets, from the
rear until the bracket flanges contact the rack, then - using the screws
provided with the rack mount kit - screws the L brackets to the rack.
3. After the L brackets have been secured, tighten the front bracket screws
Note: 1. Cage nuts are provided for racks that are not prethreaded.
2. Allow at least 5.1 cm on each side for proper ventilation, and at least
12.7 cm at the back for the power cord and cable clearance.
cl5200-aam-v1.book Page 8 Thursday, January 25, 2007 3:36 PM
