ATEN ALTUSEN KW1000 User manual

1X1X
• Quick Start Guide
• User Manual
• Warranty Registration Card
• KW1000 KVM over Wireless
Control Unit
• Power Adapter
1X
1X
The complete KW1000 package consists of:
System Requirements
2
The KW1000 Unit ( Front View )
3
Package Contents
1
4
KVM over Wireless (KW1000) QUICK START GUIDE
This section details the required hardware components for successful installation and use
of the KW1000
Console
• Pentium 3 with 1 GHz processor or higher
• Screen resolution is at 1024 x 768 or higher
Computers
To use and access the KW1000 successfully, your computer requires the following:
• Windows – DirectX 7.0 or higher
• Java – Sunʼs Java 2 JRE 1.4 or higher
1. Reset / FW
2. Tx / Rx
3. Link LED
4. Power LED
5. WLAN
6. WLAN Reset
7. Antenna
The KW1000 Unit ( Rear View )
1. PC / KVM
2. Local Console / Video
3. Local Console / Keyboard
4. Local Console / Mouse
5. Power Jack
• CS Custom KVM Cable Set
1X
• Software CD
1X
Reset / FW TX/AX LINK POWER WLAN WLAN Reset
1. 2. 3. 4. 5. 6.
© 2005 ALTUSEN. All rights reserved. All Other trademarks are the property of their respective owners. PAPE-1214-A00

7Software Installation
5
6
To prevent damage to your equipment, please do the following before you begin installation:
Hardware Installation
Hardware Installation
STOPSTOP
KW1000 has fixed IP address of 192.168.1.101 with a subnet mask of 255.255.255.0. Be sure to
configure your computerʼs wireless card for a corresponding IP address (192.168.1.1 –
192.168.1.254).
After you have successfully logged in, the KW1000 main screen appears:
1. Open your browser and specify the KW1000ʼs IP address in the browserʼs URL location bar:
192.168.1.10
2. Provide a valid User name and Password, then click Login to continue.
8Screen Elements
Saves the changes you make in the administration dialog boxes, but does
not implement the changes. The changes only go into effect when you
enable Reset on exit and log out.
Allows users to connect to the KW1000 using Windows software, and to
remotely control the connected server.
Allows users that have Java installed to connect to KW1000 and to
remotely control the connected server.
All the events that take place on the KW1000 are recorded in a log file.
Click this icon to log out and end your KW1000 session.
Apply
Windows Client
Java Client
Log
Logout
1. Plug the local administratorʼs keyboard, mouse, and monitor into the unitʼs console ports.
2. Use the KVM cable provided with this package to connect the KW1000ʼs KVM port to the
Keyboard, Video and Mouse ports of the server or KVM switch that you are installing.
3. Power up the following device in this order: KVM PC KW1000
4. Plug the power adapter into the power jack
!• Make sure that power to all the devices you will be connecting up have been turned
off. You must unplug the power cords of any computers that have the Keyboard
Power On function.
• Make sure that all devices on the installation are properly grounded.
PC/KVM
CONSOLE
KVM Switch
Icon Purpose
