Two-User Dual-Bus 8/16-port CAT5 KVM
ATEN Technology, Inc. | 23 Hubble, Irvine CA 92618 | 1-888-999-ATEN (2836) x 8776 | [email protected]
ATEN New Jersey, Inc. | 155 Pierce Street, Somerset, NJ 08873 | 1-732-356-1703 | [email protected]
www.aten-usa.com
nj.aten.com
Two-User Dual-Bus 8/16-port CAT5 KV
Simply Better ConnectionsTM
“ATEN’s KVM solutions had the scalability
we needed to expand our server room, and
at a cost that was affordable to us.”
Competitive Features/Benefits:
Order Information:
Features Benefits
Dual bus consoles 2 simultaneous and independent operators
CAT-5 Links to computers Up 130ft separation between KVM and servers
Two level KVM control Admin account sets Port-by-port access of user accounts
Three tier installation Control up to 512 / 4096 servers
Configuration Backup /Restore Speed up and simplify disaster recovery
Product ATEN Part No. Description MSRP
8 port KVM KH2508 8 port 2 user Cat-5 KVM $649.95
16 port KVM KH2516 16 port 2 user Cat-5 KVM $749.95
Cat-5 PS/2 adapter KA9520 PS/2 adapter $59.95
Cat-5 USB adapter KA9570 USB adapter $59.95
Cat-5 Sun adapter KA9130 Sun Legacy adapter $59.95
Cat-5 Sun adapter KA9170 USB adapter $99.95
Cat-5 Serial adapter KA9140 Serial adapter $399.95
Overview
The KH2508 / KH2516 Cat 5 KVM Switches are dual channel KVMs, allowing two operators independent and
simultaneous access to 8 / 16 directly connected servers to a maximum of 512 / 4096 servers through three level of
cascading.
Cascading is achieved via dedicated RJ-45 cascade ports and Cat 5e cabling. Both, first level consoles can be
configured to access all 512 / 4096 computers in the installation (non-blocked), or one console may be configured for
total access with a local user assigned to each tier (blocked access).
The Cat-5 connections allow servers to be separated from the KH2508 / KH2516 by up to 100 ft with a video resolution of
1600x1200 or 1280 x 1024 up to 130 ft
The KVM supports mixed environments of Windows, MAC , Linux, Unix, Novell, and OS/2 and will allow keyboard
emulation for the special Mac and Sun keys.
Two-User Dual Bus 8/16-port CAT5 KVM (KH216/KH2508)
16
C
at 5 KVM
S
witches are dual chan
ne
ne
l
l
KV
KV
Ms
Ms
,
,
al
al
lo
lo
wi
wi
ng
ng
t
t
w
wo
operators inde
p
www.aten-usa.com ATEN Technology, Inc. | 23 Hubble, Irvine, CA 92618 | 888-999-ATEN (2836) x8776 | [email protected]
ATEN New Jersey, Inc. | 155 Pierce Street, Somerset, NJ 08873 | 732-356-1703 | [email protected]
Specification
Function KH2508 KH2516
Computer Direct 8 16
Connections Max (cascade) 512 4096
Port Selection OSD
Connectors
Console Keyboard 2 x PS/2 (F); 2 x USB Type A(F)
Ports Video 2 x HDB-15 (F)
Mouse 2 x PS/2 (F); 2 x USB Type a (F)
USB 4x USB type A (F)
KVM Ports 8 x RJ-45 (F) 16 x RJ-45 (F)
Cascade Ports 2 x RJ- 45 (F)
FW Upgrade 1 x RJ-11 (F)
Power 1 x 3 ProngAC socket
Switches Reset, Power, FW Upgrade
LEDs On Line, Selected, Power, Cascade
Emulation Keyboard / Mouse PS/s; USB; ( PC, MAC, Sun); Serial
Video 1280x1024 @ 75Hz (95 ft)
1600x1200 @ 60Hz (130 ft)
Auto Scan Interval 1 – 255 Seconds
IP Rating 100-240VAC; 50 -60 Hz
Power Consumption 120V / 28W 120V / 30W
230V / 28W 230V / 30W
Environment
Operating Temp. 32 – 122 F
Storage Temp -4 – 140 F
Humidity 0-80% RF; Non-condensing
Physical
Properties Housing Metal
Weight 8.1 Lb / 8.2 Lb
Dimensions (L x W x H) 17 x 11.3 x 1.7 in; 19”; I U
Two-User Dual-Bus 8/16-port CAT5 KVM
ATEN Technology, Inc. | 23 Hubble, Irvine CA 92618 | 1-888-999-ATEN (2836) x 8776 | [email protected]
ATEN New Jersey, Inc. | 155 Pierce Street, Somerset, NJ 08873 | 1-732-356-1703 | [email protected]
www.aten-usa.com
nj.aten.com
Two-User Dual-Bus 8/16-port CAT5 KVM (KH2516/KH2508)
www.aten-usa.com ATEN Technology, Inc. | 23 Hubble, Irvine, CA 92618 | 888-999-ATEN (2836) x8776 | [email protected]
ATEN New Jersey, Inc. | 155 Pierce Street, Somerset, NJ 08873 | 732-356-1703 | [email protected]
Comparison - 8-Port KVMs
Comparison - 16-Port KVMs
8 Port Models ATEN
KH2508 Avocent
AV1515 Belkin
F1DA208Z Raritan
MXU28
Consoles 2 2 2 2
Console Connections PS/2 – USB PS/2 – USB PS/2 - USB PS/2
CPU Interface Cat5 Cat5 SCSI-50 DB-25
CPU Connections USB | PS/2 | Sun | Serial USB | PS/2 | Sun | Serial PS/2 I USB USB | PS/2 | Sun
Max Computers 512 128 128 64
Daisy Chain / Cascade Cascade Cascade Daisy chain Cascade
Distance CPU to KVM 130 ft 100 ft PS/2 25 ft / USB 15 ft
Resolution 1600 x 1200 to 100 ft 1600 x 1200 1920x1440 @ 75Hz 1600 x 1200
Port Selection OSD OSD Hotkey OSD Hotkey OSD
Expansion Config Auto Auto Manual* Manual **
Max user accounts 95 User 1 Admin 4 user 1 Admin 8 users 1 Admin 120 user 1 Admin
Warranty 3 Year 2 Year 3 year 2 Year
MSRP $649.95 $845.00 $649.00 $1,095.00
Notes Dual Bus
Simultaneous and
Independent
Single Bus
Share Mode function allows
two users to gain access to a
primary server
*Second tier units must
be configured manually
prior to installation
Dual Bus
Simultaneous and
Independent
**Second tier units must
be programmed
prior to installation
16 Port Models ATEN
KH2516 Avocent
AV2015 Belkin
F1DA216Z Raritan
MXU216
Consoles 2 2 2 2
Console connections PS/2 – USB PS/2 – USB PS/2 - USB PS/2
CPU Interface Cat5 Cat5 SCSI-50 DB-25
CPU Interface support USB | PS/2 | Sun | Serial USB | PS/2 | Sun | Serial USB I PS/2 USB | PS/2 | Sun
Max Computers 4096 128 256 128
Daisy Chain / Cascade Cascade Cascade Daisy chain Cascade
Distance CPU to KVM 130 ft 100 ft PS/2 25 ft / USB 15 ft
Resolution 1600 x 1200 to 100 ft 1600 x 1200 1920x1440 @ 75Hz 1600 x 1200
Port Selection OSD OSD Hotkey OSD Hotkey OSD
Expansion Config Auto Auto Manual* Manual **
Max user accounts 95 User 1 Admin 4 user 1 Admin 8 users 1 Admin 120 user 1 Admin
Warranty 3 Year 2 Year 3 year 2 Year
Street Price $499.95 $686.99 $659.99 $1,655.99
Notes Dual Bus
Simultaneous and
Independent
Single Bus
Share Mode function allows
two users to gain access to a
primary server
*Second tier units must
be configured manually
prior to installation
**Second tier units must
be programmed
prior to installation
Two-User Dual-Bus 8/16-port CAT5 KVM
ATEN Technology, Inc. | 23 Hubble, Irvine CA 92618 | 1-888-999-ATEN (2836) x 8776 | [email protected]
ATEN New Jersey, Inc. | 155 Pierce Street, Somerset, NJ 08873 | 1-732-356-1703 | [email protected]
www.aten-usa.com
nj.aten.com
Two-User Dual-Bus 8/16-port CAT5 KVM (KH2516/KH2508)
www.aten-usa.com ATEN Technology, Inc. | 23 Hubble, Irvine, CA 92618 | 888-999-ATEN (2836) x8776 | [email protected]
ATEN New Jersey, Inc. | 155 Pierce Street, Somerset, NJ 08873 | 732-356-1703 | [email protected]
Application Diagram
Non blocked access - Two operators access all servers
Blocked access - One user accesses all servers, two users access their respective tiers only
Two-User Dual-Bus 8/16-port CAT5 KVM
ATEN Technology, Inc. | 23 Hubble, Irvine CA 92618 | 1-888-999-ATEN (2836) x 8776 | [email protected]
ATEN New Jersey, Inc. | 155 Pierce Street, Somerset, NJ 08873 | 1-732-356-1703 | [email protected]
www.aten-usa.com
nj.aten.com
KH2516
KH2516
KH2516
KA9520, KA9570
KA9130
KA9170 Depending
on the server
Cat 5e cable
KH2516
KH2516
KH2516
KA9520, KA9570
KA9130
KA9170 Depending
on the server
Cat 5e cable
Two-User Dual-Bus 8/16-port CAT5 KVM (KH2516/KH2508)
