ATI Technologies H900 User manual

Bluetooth Headset
H900
Made in China

Contents ,
What s in the box
The headset contains the following parts:
1.Ear Hook
2. Volume Down Button
3.Volume Up Button
4.Multi-function Button
5.Speaker
6.Microphone
7.Indicator Light
8.Charging Socket
1
1
Package Contents List
A. H900 Bluetooth headset
B. Travel Charger
C. USB Cable
D. User's Guide
1
2
3
5
4
6
8
7
,
What s in the box ..........................................................................................
Charge the battery .......................................................................................
Battery information .....................................................................................
Pair to your Bluetooth phone .....................................................................
Turning headset on /off ...............................................................................
Wearing your headset ..................................................................................
Making a call .................................................................................................
Ending a call .................................................................................................
Reject an incoming call ...............................................................................
Answering a call ...........................................................................................
Transferring a call ........................................................................................
Call-waiting ( Three-Way Calling) ...............................................................
Volume control..............................................................................................
Mute................................................................................................................
Safety and general information.................................................................
FCC & IC Statement .......................................................................................
EU.....................................................................................................................
Warranty.........................................................................................................
1
2
13
12
12
11
10
10
9
9
9
9
8
8
7
6
4
3

Charge the battery
1. Connect the charger to the correct outlet.
2. While the charger is connected, the red indicator
light displaying during charging. If charging does
not start, disconnect the charger, plug it in again,
and retry. Charging the battery fully may take up
to 2 hours.
3. When the battery is fully charged, the red indicator light turn blue.
Disconnect the charger from the headset and the wall outlet.
The fully charged battery has power for up to 3 hours of talk-time or up to 80 hours
of standby time. However, the talk and standby times may vary when used with
different mobile phones or other compatible Bluetooth devices, usage settings,
usage styles, and environments.
When battery power is low, the headset will remind you by beeps every 20 seconds,
and the red indicator light starts to flash.
2
2
1. For first time use, please charge the headset fully. If you cannot see the indicator
light when charging, please leave the headset on the charging for a while
(Approx 15-35 Minutes), then the indicator light will be on.
2. If after a full charge, you cannot turn the headset on, please re-plug the headset
to the charger for a few second to activate it.
IMPORTANT NOTICE!
Battery information
3
3
This device has a built-in rechargeable battery. Do not attempt to remove the battery
from the device as you may damage the device.
l Your device is powered by a built-in chargeable battery. The full performance of a
new battery is achieved only after two or three complete charge and discharge
cycles. The battery can be charged and discharged hundreds of times.
l Unplug the charger from the vehicle and the device when not in use.
Do not leave a fully charged battery connected to a charger, since overcharging
may shorten its lifetime. If left unused, a fully charged battery will lose its charge
over time. If the headset will go unused for a long time, please charge fully and
turn off the headset.
l To prevent over discharge endangering the battery, you are recommended to
charge the headset fully each month.

4Pair to your Bluetooth phone
Before you use your headset for the first time, ensure that it is paired to use it with
devices such as your Bluetooth phone.
Bluetooth devices
H900
Scan results
Enter Bluetooth
Passkey
****
Once you pair the headset with a device, the Headset will be automatically connected
to the device wherever you turn the headset on.
Enter PIN code"0000"
(4 zeros) and confirm to
complete pairing.
Press and hold the
Multi-Function until you see
the LED light flash blue and
red alternately indicating
the unit is in pairing mode.
(Approximately 6 seconds)
Following your phone's instruction
guide, set your Bluetooth enabled
phone into search mode
Insure the
headset is off.
Your phone will find the
headset and show the
device name on the
screen, select the device
name to confirm pairing.
45
IMPORTANT!
When the headset paired with
mobile phone, the blue indicator
will have two flashes very 5
seconds. If failed, the blue
indicator will have one flash
every 3 seconds
NOTE:
l If the pairing is successful, the headset will connect to your phone automatically,
you may need to confirm the enquiry on your phone.
l While the headset is paired with the phone and connected, the indication light
will flash 2 times every 5 seconds. If failed or didn't connect to the phone, the blue
indicator light will flash 1 time every 3 seconds.
l Once you paired the headset with one device or more, the Headset will
automatically connect to the phone you last connected wherever you turn the
headset on, but make sure your phone's Bluetooth function is active.
l The headset is supports Bluetooth v2.1+EDR specification, the simplified pairing
process will make paring your devices easily, if your mobile phone supports
Bluetooth v2.1+EDR specification, you just need turn on both of them, and add
new Bluetooth device on your phone, the headset and your phone will find each
other and connect automatically.
l The headset supports multi-point technology. If you need connect the headset to
nd
the 2 Bluetooth phone, please repeat the pairing operation steps above. When
finish the pairing, turn off the headset and turn on again, the headset will connect
to the both 2 phones automatically.

Turning headset on /off
5Wearing your headset
6
The headset can be worn on either the Left or Right ear. If you want to carry the
headset on the other ear, please change the direction of the ear clamp follow
the figures below.
Please wear the headset follow the below.
Left
Right
21
67
*Turn on the headset
If the headset is turned off, press and hold MFB for 2 seconds until you hear a melody
from low to high, the headset turns on, the Blue indicator light will flash 3 times at the
same time.
*Connects to the phone
1. If your headset has finished the pairing operation successfully, when the headset
is turned on, it will connect to the phone(s) you last connected automatically, but
make sure your phone's Bluetooth function is active.
2. The headset supports multi-point and connects to 2 phones at the same time. In
some operations, you need to distinguish the connection sequence, so we appoint
the phone first connected as phone 1, the second one as phone 2.
*Turn off the headset
At any working state, press and hold MFB for 4 seconds, you will hear a melody from
high to low, and the Red indicator light will flash 3 times at the same time, the headset
turns off.
Note
l For saving the power, while the headset didn't connect to any device over 1 hour,
the headset will turn off automatically.

Making a call
Ending a call
Reject an incoming call
7
8
9
Answering a call
Transferring a call
Call-waiting (Three-Way Calling)
10
11
12
* By phone's keypad
At the stand-by state, dial the number on your phone directly to make a call.
* Use Voice-Dialing
At the stand-by state, press the MFB shortly, you will hear a short tone from the
headset, and the phone will prompt you say the voice tag like your friend's name. If the
voice tag is identified by the phone, the related number will be dial-out later.
Make sure whether your mobile phone supports voice dialing function, and you need
to set up voice tags on your mobile phone first. If the headset has connected to 2
phones, double press the MFB will start Voice-Dialing of phone 2.
* Last number re-dialing
Press and hold Volume Down button for 2 seconds, you will hear 2 short tones, the last
number you dialed will be re-dial out. If the headset has connected to 2 phones, press
and hold Volume Up button for 2 seconds will start last number re-dialing of phone 2.
NOTE
l If the headset has connected to 2 phones, when one phone has active a call, the
headset will disconnect to other phone temperately, when you end the call the
headset will re-connect it automatically, please make sure your phone's Bluetooth
function would not be inactive during the calling.
When you receive an incoming call, press and hold MFB for 2 seconds will reject the
incoming call.
When you receive an incoming call, press the MFB shortly can pick up the incoming
call; also you can pick up the call on your mobile.
When in the calling, press and hold Volume Up button for 2 seconds can transfer the
call from headset to phone. Repeat the operation can transfer the call between the
phone and headset each other.
Before using Call-waiting function on your headset, please ensure that your phone
supports the Hands-free profile, and you have been provide the service by the net
provider.
* If there is another incoming call while you are in the calling, press MFB shortly can
accept the waiting call and end current calling.
* If there is another incoming call while you are in the calling, press and hold MFB for
2 seconds can accept the waiting call and hold on current calling.
* While you are in the calling and another call was holding on, press MFB shortly can
end current call and resume the holding on calling.
When in the calling, press the MFB shortly will end the call, also you can end call on
your mobile. 89

* While you are in the calling and another call was holding on, press and hold MFB for
2 seconds can shift the current calling to the holding on calling.
* While you are in the calling and another call was holding on, press Volume Up button
shortly can add the holding on call to the current conversation to make a multiparty
call.
* While you are in the calling and another call was holding on, or you are in a multiparty
calling, double press MFB can end the calling or remove yourself from the multiparty
calling.
Volume Control
13
While you are in the calling, you can adjust the volume by pressing volume up and
volume down button or you can adjust the volume on your mobile.
Mute
14
While you are in the calling, Press and hold the Volume Down Button for 2 seconds,
you will hear a melody from low to high, then the headset's MIC will be muted, and
you will hear remindful melody every 10 seconds. Repeat the operation your will hear
the melody from high to low, the mute function is cancelled.
15 Safety and general information
CAUTIONS: ELECTRIC SHOCK HAZARD
The battery used in this device may present a risk of fire or chemical burn
if mis-treated.
!
10 11
1. Please read this guidebook carefully and follow the instruction.
2. To avoid any damage or malfunction of the unit do not drop unit .
3. Keep the unit away from humidity, water and any other liquid. And if the unit is
,
exposed by water, moisture and other liquid directly then don t operate it to avoid
any electrical shock, explosion and damage of the unit.
4. Do not place or keep the unit near the heat sources such as direct sun light,
radiators, stoves or other apparatus which produce heat. It may cause explosion,
degrade of performance and reduce battery life.
5. Do not modify, repair & disassemble unit (Especially battery: It may cause an
explosion)
6. Do not place the heavy objects on the unit.
7. Use only supplied and approved charger.
8. Replacement or service must be done by qualified service center or manufacture.
9. Unplug this unit when unused for long periods of time or during lightening storms.

FCC & IC Statement
Operation is subject to the following two conditions:
16
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Note: The manufacturer is not responsible for ANY interference, for example
RADIO or TV interference, caused by unauthorized modifications to this
equipment.
Such modifications could void the user’
sauthority to operate the equipment.
EU
17
This product is Ce marked according to the provision of the R&TTE Directive
(99/5/EC).
Declares that this product is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
Please note that this product uses radio frequency bands not harmonized
within EU.
Within the EU this product is intended to be used in Austria, Belgium, Denmark,
Finland, France, Germany, Greece, Ireland, Italy, Luxembourg,
The Netherlands, Portugal, Spain, Sweden, United Kingdom and within EFTA
in Iceland, Norway and Switzerland.
Bluetooth is a trademark owned by the Bluetooth SIG, Inc.
The condition of this warranty and our responsibilities under this warranty are as
follows: Warranty is non-transferable and is limited to the original purchaser only.
* Modification and repair of the unit should be done by authorized and qualified
service center or returned to the manufacturer
* You must be able to prove the date of original purchase of the unit with a dated
receipt.
* The warranty is not applicable if the product has been subject to physical abuse,
improper installation, modification or repair by unauthorized third party.
* The responsibility of supplier's products shall be limited to the repair or replacement
of the product at it's sole discretion.
* Specifically exempt from any warranty are limited-life consumable components
subject to normal wear and tear such as batteries, decorates and other accessories.
* Supplier will not take any responsibility if the failure of the unit has resulted from
accident, abuse, misuse, or any unauthorized repair, modification or disassemble.
* This warranty gives you specific legal rights, and you may also have other rights
which vary under local laws.
Warranty
18
12 13

This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
