User manual
Bluetooth®Headset H35

- 2-
1. NoticeBeforeUsing
ThankyouforpurchasingtheBluetooth®HeadsetH35.
PleasereadthisUser'sManualcompletelybeforeyouuse
theHeadset.TheH35hasbeendevelopedusingBluetooth®
wirelesstechnologyandiscapableofconnectingwith
Bluetooth®devicesdesignedwithAudioGateway.PDAs,
DesktopsandNotebookcomputerscanbeconnectedand
pairedwiththeHeadsetusingaUSBBluetooth®Dongleor
built‐inBluetoothcapability(ifapplicable).Beforeusingthe
HeadsetpleaseverifyyourBluetooth®device(Phone,PDA)
complieswithBluetooth®V1.1/V1.2/V2.0/V2.1andsupports
theBluetooth®HeadsetorHands‐freeprofile.




2. PackageContentsList

- 3-
Pleaseinspectthispackageandrefertothepackage
contentslistbelowtoverifyallitemswereincludedinthis
package:

A.H35Bluetooth®headset(IncludesEarhook).................1
B.ACCharger.........................................................................1
C.USBChargingCable...........................................................1
D.ExtraEarpiece...................................................................1
E.ExtraEarcap......................................................................1
F.User'sManual....................................................................1





- 4-

3. H35Bluetooth®HeadsetOverview
1. Earhook
2. On/Off
3. Speaker
4. Earcap
5. Volume(+)
6. Volume(‐)
7. Dual‐colorindicator
8. Microphone
9. Chargingsocket
10. Earcap(Extra) 




- 5-
4. Batteryinformation
Thedeviceisequippedwithanintegratedlithium‐polymer
battery.Thebatterycannotbereplaced.Donotattemptto
removethebatteryfromthedevicesinceitwoulddamage
thedevice.Thefullperformanceofanewbatteryisnot
achieveduntilaftertwoorthreecomplete
charging‐dischargingcycles.Thebatterycanbechargedand
dischargedseveralhundredtimes,butitloosesitscapacity
overtime.
DisconnecttheH35fromthepowersupplyassoonasthe
batteryisfullycharged,overchargingwouldreducethe
servicelifeofthebattery.Achargedbatterywillloseits
capacityifitisnotusedonaregularbasis.
Important:Ensurethatthebatteryisfullychargedifyoudo
notusethedeviceforalongperiodoftime.To avoida
completedischargeofthebattery,theH35shouldbe
chargedatleastevery3months.

- 6-
5. Chargingthebattery
TheH35isoperatedwitharechargeablebattery.Chargethe
batterycompletelybeforeitsfirstuse.Readthesection
"Batteryinformation"beforestartingthechargingprocess.
1) ConnectUSBcabletotheACcharger.
2) Whenthechargerisconnectedtotheheadset,thered
indicatorlightwillturnon.Chargingthebatteryfully
maytakeupto2hour. 
3) Whenthebatteryisfullycharged,theredindicator
lightwillturnblue.Disconnectthechargerfromthe
headsetandtheoutlet.Theheadsetisreadytouse.
NOTE:

- 7-
‐Forfirsttimeuse,pleasechargetheheadsetfully.
‐Thefullychargedbatteryhaspowerforupto5hoursof
talk‐time,andupto120hoursofstandbytime.However,
thetalkandstandbytimesmayvarywhenusedwith
differentmobilephonesorothercompatibleBluetooth®
devices,usagesettings,usagestyles,andenvironments.
Whenthebatterypowerislow,theheadsetwillremindyou
bya"Beep"toneevery20seconds,andtheredindicator
lightstartstoflash.
6. PairtoyourBluetooth®phone
Beforeyouuseyourheadsetthefirsttime,youmustpair
theunitwithaBluetooth®enabledmobilephone.Pairingis
aone‐timeprocessandrequiredonlyforthefirst
connectionwiththecellphoneTheH35canbepairedwith
uptoeightcellphonesandbeconnectedsimultaneously
withtwocellphones.
1) KeeptheH35withinrangeofaBluetooth®‐readycell

- 8-
phone;thedistanceshouldnotexceedameter.
2) Theheadsetmustbeturnedoff.
3) HoldtheOn/Offbuttonforapprox.5secondsuntilyou
hearashort‐lowsignaltoneandtheindicatorlight
intermittentlyflashesredandblue.Thedeviceisin
pairingmode.Pairingmodeshouldengage
automaticallyuponthefirsttimeturningonthe
headset.
4) FindtheBluetooth®settingofyourcellphoneand
startthesearchforBluetooth®devices.(Forfurther
details,pleasereadtheoperatinginstructionsofyour
cellphone).
5) Fromthelistofdevicesfound,selectthe"H35".
6) Ifrequired,enterthePINcode"0000"andconfirmthe
entry.Ifthepairingprocesswassuccessful,youwill
hearasignaltoneandtheindicatorlightsbluefor3
seconds.(Note:ThePINcodeispreprogrammedand

- 9-
cannotbechanged.)
7) Afterpairing,theH35automaticallyconnectwiththe
cellphone.Forsomecellphones,youhaveto
manuallyconfirmtheconnection.Oncepaired,the
headsetwillchangetostandbymodeandtheindicator
lightwillflashblue2timesevery5seconds.
Note:Ifpairingisnotcompletedwithin2minutes,the
headsetwillturnoff.Ifthishappens,repeatthepairing
process.
7. Multi‐connectionfunction
Themulti‐connectionfunctionallowsforthesimultaneous
useoftheH35withtwocellphones.Thisisanadvantage
foruserswithapersonalandabusinesscellphone.
Establishingaconnectionwithtwocellphones
ThereareseveraloptionsofconnectingtheH35with
alreadypairedcellphones.
1) Automaticconnection

- 10-
WhenturningontheH35,aconnectionisautomatically
establishedwiththetwomostrecentlyconnectedcell
phones.
2) EstablishingaconnectionviatheH35
TomanuallyestablishaconnectionbetweentheH35and
thetwomostrecentlyconnectedcellphones,pressthe
On/Offbutton.TheH35firstconnectsitselfwiththemost
recentlyconnectedcellphone.Thenitconnectsitselfwith
thenextmostrecentlyconnectedone.
3) Establishingaconnectionviathecellphone
Ifthecellphoneisnotoneofthetwomostrecently
connectedcellphoneswiththeH35,youhavetoestablish
theconnectionviatheBluetooth®menuofthecellphone.
Aftersuccessfulconnection,youcanestablishanother
connectionwithasecondcellphone.Thisallowsyouto
determinethesequenceofconnections.Iftwocellphones
areconnectedwiththeH35,thecellphoneconnectedfirst
