SH802
Bluetooth®Headset
User manual

- 2-
1. NoticeBeforeUsing
ThankyouforpurchasingtheBluetooth®HeadsetSH802.PleasereadthisUser's
ManualcompletelybeforeyouusetheHeadset.
SH802designedforlisteningthehighqualitymusicwirelesslythatbasedonthe
latestBluetooth®wirelesstechnology.SH802canbeeasilyconnectedtoamobile
phoneforcallconversationandmusiclistening,itisalsocapabletoconnecttothe
otherBluetooth®‐enableddeviceslikeNotebook,iPodetc.
SH802iscompliantwithBluetoothV3.0specification,supportsHSP,HFP,A2DPand
AVRCPprofiles.Pleasemakesureyourphoneorotherdevicesupportsthese
profiles.
2. Specification
Bluetoothspecification:V3.0
Operationfrequency:2.402‐2.48GHz
Supportedprofile:HSP,HFP,A2DP,AVRCP
Operationrange:Upto10meters
Talktime:5hours
Playtime:4.5hours
Standbytime:300hours
Chargetime:1Hours

3. PackageContentsList
Pleaseinspectthispackageandrefertothepackagecontentslistbelowtoverifyall

- 3-
itemswereincludedinthispackage:
1) SH802Bluetooth®headset(1)
2) USBChargingCable(1)
3) User'sManual(1)
4) EarCap(2x3Sizes)
5) Earfitkits(2)
4. SH802Bluetooth®HeadsetOverview

① Ear Cap
② Indicator
③ Volume Up/Previous
④ Volume Down/Next
⑤ Answer
⑥ Power/Play

- 4-
⑦ Microphone
5. Batteryinformation
Thedeviceisequippedwithanintegratedlithium‐polymerbattery.Thebattery
cannotbereplaced.Donotattempttoremovethebatteryfromthedevicesinceit
woulddamagethedevice.Thefullperformanceofanewbatteryisnotachieved
untilaftertwoorthreecompletecharging‐dischargingcycles.Thebatterycanbe
chargedanddischargedseveralhundredtimes,butitloosesitscapacityovertime.
DisconnecttheSH802fromthepowersupplyassoonasthebatteryisfullycharged,
overchargingwouldreducetheservicelifeofthebattery.Achargedbatterywilllose
itscapacityifitisnotusedonaregularbasis.
Important:Ensurethatthebatteryisfullychargedifyoudonotusethedevicefora
longperiodoftime.Toavoidacompletedischargeofthebattery,theSH802should
bechargedatleastevery3months.
6. Chargingthebattery
TheSH802isoperatedwitharechargeablebattery.Chargethebatterycompletely
beforeitsfirstuse.Readthesection"Batteryinformation"beforestartingthe
chargingprocess.
1) ConnectUSBcabletoageneralUSBpowersupplier.
2) Connectthechargertothecorrectoutlet.
3) Whenthechargerisconnectedtotheheadset,theredindicatorlightwill
turnon.Chargingthebatteryfullymaytakeupto1hours.

- 5-
4) Whenthebatteryisfullycharged,theredindicatorlightwillturnblue.
Disconnectthechargerfromtheheadsetandtheoutlet.Theheadsetis
readytouse.
NOTE:
‐Forfirsttimeuse,pleasechargetheheadsetfully.
‐Thefullychargedbatteryhaspowerforupto5hoursoftalk‐timeand4.5hours
musicplayingtime,andupto300hoursofstandbytime.However,thetalkand
standbytimesmayvarywhenusedwithdifferentmobilephonesorother
compatibleBluetooth®devices,usagesettings,usagestyles,andenvironments.

- 6-
Whenthebatterypowerislow,theheadsetwillremindyoubyvoiceprompt
"Batterylow"every20seconds,andtheredindicatorlightstartstoflash.
‐ForusingtheSH802withiPhone,anadditionalbatterymeter( )willbe
activatedandtheremainingbatterycapacitywilldisplayonyourphone.



7. PairtoyourBluetooth®phone
Beforeyouuseyourheadsetthefirsttime,youmustpairtheunitwithaBluetooth®
enabledmobilephone.Pairingisaone‐timeprocessandrequiredonlyforthefirst
connectionwiththeMobilephone.TheSH802canbeconnectedwithtwomobile
phonessimultaneously.
1) KeeptheSH802within1meterrangeofaBluetooth®‐readyMobilephone.
2) PressandholdthePower/Playbuttonforabout5s,theindicatorlightwill
flashesredandblueintermittently,thedeviceisnowinpairingmode.

- 7-
3) FindtheBluetooth®settingofyourMobilephoneandstartthesearchfor
Bluetooth®devices.(Forfurtherdetails,pleasereadtheoperating
instructionsofyourMobilephone).
4) Fromthelistofdevicesfound,selectthe"SH802".
5) Ifrequired,enterthePINcode"0000"andconfirmtheentry.Oncethe
pairingprocesswassuccessful,theSH802willconnecttoMobilephone
automaticallythenswitchtostandbymode,theindicatorwillflashblue
every5seconds.
Note:
1) Ifpairingisnotcompletedwithin2minutes,theheadsetwillturnoff.Ifthis
happens,pleaserepeatthepairingsteps.
2) TheSH802supportsMulti‐connectionthatallowsforthesimultaneoususe
oftheSH802withtwomobilephones.Afterparingsuccessfullywith2
mobilephones,switchofftheheadsetandswitchonagain,theheadsetwill
connecttoboth2mobilephonesautomatically.Otherwise,youcanconnect
theheadsetonthecellphonemanually.
8. Turningheadseton/off
Turnonyourheadset
LongpressthePower/Playfor3stoturnonyourheadset.Ifyourheadsethas
completedthepairingprocesssuccessfully,whentheheadsetisturnedon,itwill
connecttothephoneyoulastconnectedautomatically.Pleaseensureyourphone's
Bluetooth®functionisactive.

- 8-
Turnofftheheadset
Longpressthepowerbuttonfor3stoturnofftheheadset.theRedindicatorwill
flashred.
Note:
Toconservepower,iftheheadsetisnotconnectedtoadeviceforapproximately10
minutes,theheadsetwillturnoffautomatically.
9. SelectingtheVoicepromptlanguage
TheSH802supportsvoicepromptfortheheadset’sstatusannouncementin5
differentlanguages(English,Chinese,Spanish,French,German).Atthestandbystate
withconnection,longpressAnswerbuttontoshiftthelanguagesonebyone,short
pressthePower/Playtoselectthelanguages.
10. Wearingtheheadset
Forthebestsoundperformanceandasecure,comfortablefit,besuretheearbuds
torestgentlyinyourearanddrapearoundthebackofourneck.Usetheprovided
fitkittofindtheeartipthatworksbestforyou.

- 9-
11. Usingformusicplay
Play/Pause
PressPower/Playbuttontogetthemusicplayorpause.
Next/Previoussong
PressandholdNextbuttontoskiptonextsongorchapter,pressandholdPrevious
buttontogobackprevioussongorchapter.
Increase/Decreasevolume
PressVolumeUpbuttontoincreasevolume,pressVolumeDownbuttonto
decreasevolume.
Note:
TheSH802supportsA2DPprofilethatallowsstereomusicstreamingfroma
Bluetoothphone.Themusicwillpauseautomaticallywhileacallisdialed
out/incoming,andresumewhenthecallconversationhasended.
12. Usingforphonecall

- 10-
Lastnumberre‐dialing
Atstandbystatus,doublepresstheAnswer,thelastnumberyoudialedwillbe
re‐dialed.
Note:thelastnumberre‐dialingisavailableonlyforthefirstdeviceiftwoMobile
phonesareconnected.Theconnectionsequencecanbedeterminedbyreconnect
manually.
Answeringacall
PressAnswershortlytoanswertheincomingcall.
Rejectanincomingcall
PressandholdAnswerfor2secondstorejecttheincomingcall.
Transferringacall
PressandholdVolumeUpfor2secondstotransferthecallbetweenthephoneand
headset.
Endingacall
PresstheAnswershortlytoendacall.
Call‐waiting
‐Ifthereisanincomingcallwhileacallisinprogress,pressAnswershortlyto
acceptthewaitingcallandendcurrentcalling.
‐Ifthereisanincomingcallwhileacallisinprogress,pressandholdAnswerfor3
secondstoaccepttheincomingcallandplacethecurrentcallonhold.
Note:
ThesameoperationcouldbeperformedincaseofMulti‐connection.
