Technical Manual & Parts Lists
Model 12786N
Rev 0

Technical Manual & Part List

Technical Manual & Part List
Technical Manual & Part List Page 2
IMPORTANT
It is important to read and understand the information contained within this
manual before attempting to operate the machine. Atlanta Attachment Co., Inc.
shall not be held liable for damage resulting from misuse of the information
presented within, and reserves the right to change the information contained
within, without prior notification.
ATLANTA ATTACHMENT COMPANY,INC.
Confidential and Proprietary Information
The materials contained herein are confidential and proprietary information of Atlanta
Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently
exist between you and Atlanta Attachment Company, your use of these materials serves as an
acknowledgment of the confidential and proprietary nature of these materials and your duty not to
make any unauthorized use or disclosure of these materials.
All materials contained herein are additionally protected by United States Copyright law and
may not be used, disclosed, reproduced, distributed, published or sold without the express written
consent of Atlanta Attachment Company, which consent may be withheld in Atlanta Attachment
Company’s sole discretion. You may not alter or remove any copyright, trademark or other notice from
copies of these materials.

Technical Manual & Part List
Technical Manual & Part List Page 3
Table of Contents
ATLANTA ATTACHMENT COMPANY, INC. ........................................................................................................... 2
CONFIDENTIAL AND PROPRIETARY INFORMATION................................................................................................ 2
IMPORTANT SAFETY INSTRUCTION........................................................................................................................ 6
MANDATORY INFORMATION................................................................................................................................. 6
SCOPE OF THE INSTRUCTION MATERIAL ................................................................................................................ 6
INTENDED USE ....................................................................................................................................................... 6
EXCLUSION OF MISUSE .......................................................................................................................................... 7
LIABILITY................................................................................................................................................................ 7
CHOICE AND QUALIFICATION OF PERSONNEL........................................................................................................ 8
TRAINING............................................................................................................................................................... 8
RESPONSIBILITIES .................................................................................................................................................. 8
A WORD TO THE OPERATOR .................................................................................................................................. 8
SAFETY EQUIPMENT ON THE MACHINES................................................................................................................ 9
DAMAGE................................................................................................................................................................ 9
FAULTS OR ERRORS ............................................................................................................................................... 9
SIGNS ON THE MACHINE...................................................................................................................................... 10
PROTECTIVE EYEWEAR......................................................................................................................................... 10
TOOLS.................................................................................................................................................................. 10
OILS, LUBRICANTS, CHEMICALS............................................................................................................................ 10
NO SMOKING, FIRE, EXPLOSION HAZARD ............................................................................................................ 10
WORKPLACE ........................................................................................................................................................ 10
EMERGENCY STOP ............................................................................................................................................... 11
FIRST AID ............................................................................................................................................................. 11
IMPORTANT NOTICES .......................................................................................................................................... 11
REPORTING AND FIGHTING FIRES ........................................................................................................................ 11
ELECTRICAL POWER SUPPLY ................................................................................................................................ 12
DELIVERY OF THE MACHINE/PACKAGING ............................................................................................................ 13
TRANSPORT DAMAGE.......................................................................................................................................... 13
INTERIM STORAGE............................................................................................................................................... 13

Technical Manual & Part List
Technical Manual & Part List Page 4
TRANSPORTING THE MACHINE ............................................................................................................................ 13
WORKPLACE ENVIRONMENT ............................................................................................................................... 14
LOCAL REGULATIONS........................................................................................................................................... 14
CONNECTION, RECONNECTION............................................................................................................................ 14
ELECTRICAL CONNECTION.................................................................................................................................... 15
PNEUMATIC CONNECTION................................................................................................................................... 15
MAINTENANCE .................................................................................................................................................... 15
GENERAL SAFETY INSTRUCTIONS......................................................................................................................... 15
MAINTENANCE, CARE, ADJUSTMENT................................................................................................................... 15
WASTE, DISASSEMBLY, DISPOSAL ........................................................................................................................ 15
REPAIR................................................................................................................................................................. 16
REPLACEMENT PARTS .......................................................................................................................................... 16
REPAIR, ELECTRICAL............................................................................................................................................. 16
VENTILATION/HAZARDOUS GASES ...................................................................................................................... 17
HYDRAULIC AND PNEUMATIC SYSTEMS............................................................................................................... 17
GENERAL LIABILITY .............................................................................................................................................. 17
STARTING MACHINE MOVEMENTS ...................................................................................................................... 17
A WORD TO THE END USER.................................................................................................................................. 17
SET-UP ................................................................................................................................................................. 18
MACHINE FEATURES ............................................................................................................................................ 18
MAIN SCREEN ..........................................................................................................................................................19
FOOT PEDALS:..........................................................................................................................................................21
MACHINE HARDWARE FUNCTIONS:..................................................................................................................... 21
AUTOMATIC UNLOADER/STACKER....................................................................................................................................21
EJECT CYLINDER ...........................................................................................................................................................21
RIGHT ROLLER ASSEMBLY ...............................................................................................................................................21
BAND GUIDING WHEELS.................................................................................................................................................21
BODY GUIDING WHEELS .................................................................................................................................................21
BAND DETECTOR EYE.....................................................................................................................................................22
SEAM SWITCH..............................................................................................................................................................22
TENSION SENSOR ADJUSTMENT .......................................................................................................................................22
WIPE START SWITCH .....................................................................................................................................................22
UNCURLER AIR JETS.......................................................................................................................................................22

Technical Manual & Part List
Technical Manual & Part List Page 5
ELECTRONIC PULLER......................................................................................................................................................22
LEFT ROLLER ASSEMBLY..................................................................................................................................................22
JAM DETECTOR ............................................................................................................................................................22
STACKER ON/OFF SETTING .............................................................................................................................................23
LEFT EXPANSION ROLLER DISABLE ...................................................................................................................................23
LEFT ROLLER ASSEMBLY INNER STOP BRACKET...................................................................................................................23
PIECE COUNTER............................................................................................................................................................23
BAND GUIDE TEST.........................................................................................................................................................23
SPECIAL SHORT CHAIN TRIMMING FEATURE........................................................................................................................23
OPTIONAL "BAND SEAM DETECTOR"FUNCTION ................................................................................................................23
OTHER ADVANCED SETTINGS..........................................................................................................................................24
PULLER AND GUIDE WHEEL CONTROLS ............................................................................................................................24
THREAD BREAK DETECTORS............................................................................................................................................24
OPERATING INSTRUCTIONS ................................................................................................................................. 25
AUTOMATIC CYCLE WITH SEAMLESS BANDS"(NO SEAMS MODE)...........................................................................................25
LOADING FIRST GARMENT: ............................................................................................................................................25
TO FINISH THE BUNDLE:................................................................................................................................................25
"AUTOMATIC CYCLE FOR BANDS WITH SEAMS (WITH SEAM MODE)..................................................................................25
TO FINISH THE BUNDLE:................................................................................................................................................26
MANUAL SEWING FOR MAINTENANCE OR MAKING REPAIRS: ..............................................................................................26
SPECIAL FUNCTIONS ............................................................................................................................................ 26
ROUTINE MAINTENANCE ..................................................................................................................................... 27
TROUBLESHOOTING............................................................................................................................................. 28
GUIDE ASSEMBLY SET UP..................................................................................................................................... 30
TOP VIEW A..............................................................................................................................................................31
LEFT ROLLER SET-UP .....................................................................................................................................................33
RIGHT ROLLER SET-UP...................................................................................................................................................34
BODY AND BAND EYE POSITION INSTRUCTIONS..................................................................................................................35
ELECTRIC EYE INSTRUCTIONS ............................................................................................................................... 36
EDGE SENSING SENSOR .................................................................................................................................................36
SENSITIVITY ADJUSTMENT ..............................................................................................................................................36
ASSEMBLY DRAWINGS & PARTS LISTS ................................................................................................................. 37

Technical Manual & Part List
Technical Manual & Part List Page 6
Important Safety Instruction
This part of the Instruction Material is provided for the safe use of your
equipment. It contains important information to help work safely with your
machine and describes the dangers inherent in machinery. Some of these
dangers are obvious, while others are less evident.
Mandatory Information
All persons working on the machine should read and understand all parts of the Safety
Instructions. This applies, in particular, for persons who only work on the machine occasionally
(e.g. for maintenance and repair). Persons who have difficulty reading must receive particularly
thorough instruction.
Scope of the Instruction Material
•The Instruction Material comprises:
•Safety information
•Operator Instructions
•Electrical and Pneumatic diagrams
And may also include;
•A list of recommended spare parts
•Serial Bus Control system Operator instructions
•Instruction Manual(s) for components made by other manufacturers
•The layout and installation diagram containing information for installation
Intended Use
Our machines are designed and built in line with the state of the art and the accepted safety
rules. However, all machines may endanger the life and limb of their users and/or third parties
and be damaged or cause damage to other property, particularly if they are operated
incorrectly or used for purposes other than those specified in the Instruction Manual.

Technical Manual & Part List
Technical Manual & Part List Page 7
Exclusion of Misuse
Non-conforming uses include, for example, using the equipment for
something other than it was designed for, as well as operation without
duly installed safety equipment. The risk rests exclusively with the end
user.
Conforming use of the machine includes compliance with the technical data, information and
regulations in all parts of the complete Instruction Material, as well as compliance with the
maintenance regulations. All local safety and accident prevention regulations must also be
observed.
Liability
The machine should only be operated when in perfect working order, with due regard for safety
and the potential dangers, as well as in accordance with the Instruction Material. Faults and
malfunctions capable of impairing safety should be remedied immediately. We cannot accept
any liability for personal injury or property damage due to operator errors or non-compliance
with the safety instructions contained in this booklet. The risk rests exclusively with the end
user.
The Instruction Material should always be kept near the machine so that it is accessible to all
concerned.
The local, general, statutory and other binding regulations on accident prevention and
environmental protection must also be observed in addition to the Instruction Material. The
operating staff must be instructed accordingly. This obligation also includes the handling of
dangerous substances and provision/use of personal protective equipment.
The Instruction Material should be supplemented by instructions, including supervisory and
notification duties with due regard for special operational features, such as the organization of
work, work sequences, the personnel deployed, etc.

Technical Manual & Part List
Technical Manual & Part List Page 8
The personnel's awareness of the dangers and compliance with the safety regulations should be
checked at irregular intervals.
Choice and Qualification of Personnel
Ensure that work on the machine is only carried out by reliable persons who have been
appropriately trained for such work - either within the company, by our field staff or at our
office - and who have not only been duly appointed and authorized, but are also fully familiar
with the local regulations. Work on the machine should only be carried out by skilled personnel,
under the management and supervision of a duly qualified engineer.
This not only applies when the machine is used for production, but also for special work
associated with its operation (start-up and maintenance), especially when it concerns work on
the pneumatic or electrical systems, as well as on the software/serial bus system.
Training
Everyone working on or with the machine should be duly trained and informed with regard to
correct use of the safety equipment, the foreseeable dangers which may arise during operation
of the machine and the safety precautions to be taken. In addition, the personnel should be
instructed to check all safety mechanisms at regular intervals.
Responsibilities
Clearly define exactly who is responsible for operating, setting-up, servicing and repairing the
machine. Define the responsibilities of the machine operator and authorize him to refuse any
instructions by third parties if they run contrary to the machine's safety. This applies in
particular for the operators of machines linked to other equipment. Persons receiving training
of any kind may only work on or with the machine under the constant supervision of an
experienced operator. Note the minimum age limits permitted by law.
A Word to the Operator
The greatest danger inherent in our machines:
is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or
rotating tools or assemblies or of being cut by sharp tools or burned by hot elements.

Technical Manual & Part List
Technical Manual & Part List Page 9
ALWAYS BE CONSCIOUS OF THESE DANGERS!
Safety Equipment on the Machines
All machines are delivered with safety equipment, which shall not be
removed or bypassed during operation.
The correct functioning of safety equipment on machines and systems
should be checked every day and before every new shift starts, after
maintenance and repair work, when starting up for the first time and when
restarting (e.g. after prolonged shutdowns).
If safety equipment has to be dismantled for setting-up, maintenance or repair work, such
safety equipment shall be replaced and checked immediately upon completing the
maintenance or repair work.
All protective mechanisms shall be fitted and fully operational whenever the machine is at a
standstill or if it has been shut down for a longer period of time.
Damage
If any changes capable of impairing safety are observed in the machine or its mode of
operation, such as malfunctions, faults or changes in the machine or tools, appropriate steps
must be taken immediately, the machine switched off and a proper lockout tagout procedure
followed. The machine should be examined for obvious damage and defects at least once per
shift. Damage found shall be immediately remedied by a duly authorized person before
resuming operation of machine.
The machine should only be operated when in perfect working order and when all protective
mechanisms and safety equipment, such as detachable protective mechanisms, emergency
STOP systems, etc. are in place and operational.
Faults or Errors
The machine must be switched off and all moving or rotating parts allowed to come to a
standstill and secured against accidental restart before starting to remedy any faults or errors.

Technical Manual & Part List
Technical Manual & Part List Page 10
Signs on the Machine
Safety and danger signs on the machine should be observed and checked at regular intervals to
ensure that they are complete and undamaged. They should be clearly visible and legible at all
times.
Clothing, Jewelry, Protective Equipment
Long loose hair, loose-fitting clothes, gloves and jewelry, including rings, should be avoided in
order to avoid injuries due to being caught, drawn in and wound up inside the machine.
Protective Eyewear
Protective eyewear that has been tested by the local authorities should be
worn whenever there is a possibility of loose or flying objects or particles
such as when cleaning the machine with compressed air.
Tools
Always count the number of tools in your possession before starting work on the machine. This
will allow you to check that no tools have been left behind inside the machine. Never leave a
tool in the machine while working.
Oils, Lubricants, Chemicals
Note the applicable safety regulations for the product used.
No Smoking, Fire, Explosion Hazard
Smoking and open flame (e.g. welding work) should be prohibited in the production area due to
the risk of fire and explosions.
Workplace
A clear working area without any obstructions whatsoever is essential for safe operation of the
machine. The floor should be level and clean, without any waste.
The workplace should be well lit, either by the general lighting or by local lights.

Technical Manual & Part List
Technical Manual & Part List Page 11
Emergency STOP
The emergency STOP buttons bring all machine movements to a standstill. Make sure you know
exactly where they are located and how they work. Try them out. Always ensure easy access to
the nearest emergency STOP button while working on the machine.
First Aid
1. Keep calm even when injured.
2. Clear the operator from the danger zone. The decision of what to do and whether to
seek additional assistance rests entirely with you, particularly if someone has been
trapped.
3. Give First Aid. Special courses are offered by such organizations as the employers'
liability insurance association. Your colleagues should be able to rely on you and vice
versa.
4. Call an ambulance. Do you know the telephone numbers for the ambulance service,
police and fire service?
Important Notices
Reporting and Fighting Fires
Read the instructions posted in the factory with regard to reporting fires and the emergency
exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are
located and how they are operated. Pass on the corresponding information to the firemen
when they arrive. Ensure there are enough signs to avoid fire hazards.
The following fire extinguishers may be used:
- Dry powder extinguishers, ABC fire-extinguishing powder.
- Carbon dioxide fire extinguishers to DIN 14461 for electronic components. Great care must be
exercised when using carbon dioxide fire extinguishers in confined, badly ventilated rooms (see
DIN 14406 and 14270).
Isolate the machine from the power supply if a fire breaks out. Do not use water on burning
electrical parts until it is absolutely certain that they have been completely disconnected from
the power supply. Burning oils, lubricants, plastics and coatings on the machine can give off
gases and vapors that may be harmful to your health.

Technical Manual & Part List
Technical Manual & Part List Page 12
A qualified person should be consulted to repair the damage after a fire.
Electrical Power Supply
Before undertaking any maintenance or repair work on the machine,
switch off the electrical power to the machine at the main source and
secure it with a padlock so that it cannot be switched on again without
authorization.
In practice, this may mean that the technician, electrician and operator all attach their own
padlock to the master switch simultaneously so that they can carry out their work safely.
Locking extension plates should be available for multiple locks if required. The primary purpose
for a lockout/tagout procedure is to protect workers from injury caused by unexpected
energizing or start-up of equipment.
Energy sources (electrical/pneumatic/hydraulic, etc.) for the equipment shall be turned off or
disconnected and the switches locked or labeled with a warning tag. It is the responsibility of
the employer to establish control procedures. Follow lockout/tagout procedures before set-up
and/or any service or maintenance work is performed, including lubrication, cleaning or
clearance of jams.
Caution: The machine is still not completely de-energized even when the master
switch is off.
- Electricity - The machine is always isolated from the electrical power supply whenever the
master switch has been switched off. However, this does not apply for the power supply in the
control cabinet, nor for equipment that does not draw its power via the master switch.
- Pneumatic / hydraulic energy - Almost all our machines carry compressed air. In addition to
switching off the master switch, the air supply must also be disconnected and the machine
checked to ensure it is depressurized before starting any work on the machine; otherwise the
machine may execute uncontrolled movements.
- Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast
run on after being switched off.
- Potential energy - Individual assemblies may need to be secured if necessary for repair work.

Technical Manual & Part List
Technical Manual & Part List Page 13
Delivery of the Machine/Packaging
Note any markings on the packaging, such as weights, lifting points and special information.
Avoid temperature fluctuations. Condensation may damage the machine.
Transport Damage
The packaging and machine must immediately be examined for signs of damage in transit. Such
damage must be reported to the shipper/transporter within the applicable time limits. Contact
us and/or your transport insurer without delay. Never operate a damaged machine.
Interim Storage
If the machine has to be stored temporarily, it must be oiled or greased and stored in a dry
place where it is protected from the weather in order to avoid damage. A corrosion-inhibiting
coating should be applied if the machine has to be stored for a longer period of time and
additional precautions taken to avoid corrosion.
Transporting the Machine
Disconnect the machine from all external connections and secure any loose assemblies or parts.
Never step under a suspended load. When transporting the machine or assemblies in a crate,
ensure that the ropes or arms of a forklift truck are positioned as close to the edge of the crate
as possible. The center of gravity is not necessarily in the middle of the crate. Note the accident
prevention regulations, safety instructions and local regulations governing transport of the
machine and its assemblies.
Only use suitable transport vehicles, hoisting gear and load suspension devices that are in
perfect working order and of adequate carrying capacity. Transport should only be entrusted to
duly qualified personnel.
Never allow the straps to rest against the machine enclosure and never push or pull sensitive
parts of the machine. Ensure that the load is always properly secured. Before or immediately
after loading the machine, secure it properly and affix corresponding warnings.
All transport guards and lifting devices must be removed before the machine is started up
again. Any parts that are to be removed for transport must be carefully refitted and secured
before the machine is started up again.

Technical Manual & Part List
Technical Manual & Part List Page 14
Workplace Environment
Our machines are designed for use in enclosed rooms:
Permissible ambient temperature approx. 5 - 40 °C (40 - 104 °F). Malfunctions of the control
systems and uncontrolled machine movements may occur at temperatures outside this range.
Protect against climatic influences, such as electrostatic charges, lightning strikes, hail, storm
damage, high humidity, salinity of the air in coastal regions.
Protect against influences from the surroundings: no structure-borne vibrations, no grinding
dust, or chemical vapors.
Protect against unauthorized access.
Ensure that the machine and accessories are set up in a stable position.
Ensure easy access for operation and maintenance (Instruction Manual and layout diagram);
also verify that the floor is strong enough to carry the weight of the machine.
Machine Installation
This equipment must be installed by an Atlanta Attachment Co. technician, or by a properly
trained and authorized technician/mechanic. Atlanta Attachment Co. reserves the right to void
any machine warranty if the machine is installed by anyone other than a qualified person as
stated above
Local Regulations
Particular attention must be paid to local and statutory regulations, etc. when installing
machines and the plant (e.g. with regard to the specified escape routes). Note the safety zones
in relation to adjacent machines.
Connection, Reconnection
Energy feed and discharge lines must be routed so that they do not run through the operator's
working area, are not compressed, crushed or buckled, are not subjected to tensile stresses and
cannot rub against anything. This is particularly important in the case of pneumatic, hydraulic
and electricity lines or hoses. Always take the machine movements into account when routing
such lines.

Technical Manual & Part List
Technical Manual & Part List Page 15
Electrical Connection
The machine shall only be connected to the factory power supply by a qualified electrician who
is familiar with the local regulations. Before switching on the master switch, check that all
fasteners are secure.
Pneumatic Connection
Only use dry filtered compressed air. Ensure that the air pressure always remains within the
range specified, otherwise malfunctions may occur.
Maintenance
General Safety Instructions
The machine shall be switched off, come to a standstill and be secured so that it cannot be
switched on again inadvertently before starting any maintenance work whatsoever. Use proper
lockout/tagout procedures to secure the machine against inadvertent startup.
Remove any oil, grease, dirt and waste from the machine, particularly from the connections and
screws, when starting the maintenance and/or repair work. Do not use any corrosive-cleaning
agents. Use lint-free rags.
Retighten all screw connections that have to be loosened for the maintenance and repair work.
Any safety mechanisms that have to be dismantled for setting-up, maintenance or repair
purposes must be refitted and checked immediately after completing the work.
Maintenance, Care, Adjustment
The activities and intervals specified in the Instruction Manual for carrying out adjustments,
maintenance and inspections must be observed and parts replaced as specified.
All hydraulic and pneumatic lines should be examined for leaks, loose connections, rubbing and
damage whenever the machine is serviced. Any defects found must be remedied immediately.
Waste, Disassembly, Disposal
Waste products should be cleared from the machine as soon as possible as not to create a fire
hazard.

Technical Manual & Part List
Technical Manual & Part List Page 16
Ensure that fuels and operating lubricants, as well as replacement parts are disposed of in a
safe and ecologically acceptable manner. Note the local regulations on pollution control.
When scrapping (disassembling) the machine and its assemblies, ensure that these materials
are disposed of safely. Either commission a specialist company familiar with the local
regulations or note the local regulations when disposing of these materials yourself. Materials
should be sorted properly.
Repair
Replacement Parts
We cannot accept any liability whatsoever for damage due to the use of parts made by other
manufacturers or due to unqualified repair or modification of the machine.
Repair, Electrical
The power supply must be switched off (master switch off) and secured so that it cannot be
switched on again inadvertently before starting any work on live parts.
Those parts of the machine and plant on which inspection, maintenance or repair work is to be
carried out must be isolated from the power supply, if specified. The isolated parts must first be
checked to determine that they are truly de-energized before being grounded and short-
circuited. Adjacent live parts must also be isolated.
The protective measures implemented (e.g. grounding resistance) must be tested before
restarting the machine after all assembly or repair work on electric parts.
Signal generators (limit switches) and other electrical parts on the safety mechanisms must not
be removed or bypassed. Only use original fuses or circuit overloads with the specified current
rating. The machine must be switched off immediately if a fault develops in the electrical power
supply.
The electrical equipment of our machines must be checked at regular intervals and any defects
found must be remedied immediately.
If it is necessary to carry out work on live parts, a second person should be on hand to operate
the emergency OFF switch or master switch with voltage release in the event of an emergency.

Technical Manual & Part List
Technical Manual & Part List Page 17
The working area should be cordoned off and marked by a warning sign. Only use electrically
insulated tools.
Ventilation/Hazardous Gases
It is the end users responsibility to ensure adequate ventilation is provided to exhaust any and
all noxious or hazardous gases that may be present in the working environment.
Hydraulic and Pneumatic Systems
Work on hydraulic or pneumatic equipment shall only be carried out by persons with training,
knowledge and experience of hydraulic systems. Pressure lines shall be depressurized before
starting any repair work.
General Liability
Liability for machine damage and personal injury is extinguished completely if any unauthorized
conversions or modifications are undertaken. The machine must not be modified, enlarged or
converted in any way capable of affecting safety without the manufacturer's prior approval.
Starting Machine Movements
Read the Instruction Manual carefully to establish which keys and functions start machine
movements.
A Word to the End User
The end user has sole responsibility to enforce the use of safety procedures and guards on the
machine. Any other safety devices or procedures due to local regulations should be should be
retrofitted in accordance to these regulations and/or the EC Directive on the safety of
machines.
Operator’s position must always be readily accessible. Escape routes must always be kept clear
and safety areas should be identified.

Technical Manual & Part List
Technical Manual & Part List Page 18
Set-Up
1. Installing V-belt:
After removing machine from shipping crate assemble v-belt to efka motor and sewing head. Reattach efka
motor guard.
2. Installing Thread Stand:
Assemble thread stand.
3. Installing Touch Screen Assembly:
Mount the touchscreen using screws provided. Plug in cables.
4. Air Line Hook-up:
Install two 1/4" air lines to connectors located on table top. Two lines are needed to supply enough air for the
waste system.
5. Air Supply Setting:
The main air regulator should be set at 70-80 psi.
6. Power Cord:
Wire the power cord to 208-230 vac., 1 phase.
7. Installing Waste Disposal:
Attach the waste hose to the waste can.
8. Head Lubrication:
Apply two drops of sf oil to both needle bar and looper bar.Fill needle thread and looper thread reservoirs with
silicone oil.
9. Threading Machine:
Thread machine according to diagram inside looper cover. Thread must pass thru hole in thread break detector
post and between tension disc.
.
10. Stacker:
Attach the stacker frame to the console with screws provided. Plug in air lines.
Machine Features
1. Power On Button:
The Power On button located above the Touch Screen is used to turn on the machine. The E-stop switch,
which locks in, must be rotated to unlock it. The "on" button is disabled while this E-stop switch is
locked in.
2. E-stop switch:
The emergency stop switch located above the Ttouch Screen is used to turn off the machine and to stop the
machine anytime during the sewing cycle. The switch locks in and must be rotated to unlock it This switch
disconnects the main power to the machine. The "on" button is disabled while this switch is
locked in.
3. Touch Screen (Operator Screen):
The Touch Screen controls all machine functions. At power up the Main Screen is displayed.

Technical Manual & Part List
Technical Manual & Part List Page 19
MAIN SCREEN
At power-up the machine displays this screen. The machine has two modes of operation: Automatic and
Manual.
The white background on the buttons indicates the ON condition. Black background indicates the OFF
condition.
Pressing the Settings button changes the screen to the Advanced Settings page 1. Use the top arrow buttons
to change to advanced Settings page 2. These settings control all machine timing.
Pressing the Guide button while in MANUAL mode with the band detect eye covered will activate the guiding
hardware for machine set-up.
Pressing RESET completely resets the machine to its initial power up condition.
