Atlantic 38435887 User manual

PART NO: 38435887
For factory use only
IMPORANT SAFETY INFORMATION. PLEASE
Congratulations on your latest Atlantic purchase. Follow these simple instructions and you’ll
have your DVD shelf assembled in no time.
Max loading weight of each shelf up to 11lbs (5kgs).
Keep this Instruction Manual for future reference.
Keep your original proof of purchase (store receipt).
Assembly video is available at www.atlantic-inc.com
www.atlantic-inc.com
If you have any questions and/or wish to order parts, please call us toll free at 800-747-2660, or
email ‘[email protected]’
2-Tier DVD Shelf with Drawer

11 5
product.
1
Max loading of each shelf
machine plus DVD shelf
.

2
Safety Glasses Lag Bolt Drill
Bit 5/32 in or
4mm
Drill
Philips
Screwdriver Stud Finder
Tools Needed (not included)
5/32”or 4mm
K
Parts List
metI#traP#traP .ytQmetI
D1
1
1
1
C
B
AH
J
2
2
4
E1
F 1
G 2
L 4
M 4
N2
Qty.

Step 1 Fix wall plate(A) to the wall.
This shelf is designed to be mounted into wood studs.
Included hardware is not designed to be used in hollow walls, cinder block, red brick, or
metal studs. Should you want to mount your TV mount into any surface other than wood
studs, Atlantic recommends that you seek the assistance of a professional installer.
Using a stud finder, locate center of wood studs in your wall, then hold wall plate (A) against
wall at your desired location. Use a pen or pencil to mark the location of where the 2
mounting screws(G) will go into wall. Before marking, ensure that wall plate is level using
bubble level (attached to wall plate).Pre-drill the marked 2 holes using 5/32in. (4mm) drill bit.
Fasten wall plate(A) to wall with screws (G).
DO NOT MOUNT ONLY INTO DRYWALL. MUST BE BOLTED TO STUDS.
Bubble level
Step 2 Attach glass support(B) to hook(C) with screws(J).
3
UP
A
G
C
J
B
5/32in./4mm

Step 3 Hang the glass support into the holes of wall plate.
Step 4 Fix the glass support with screws(H).
4
H

Step 5 Pull the drawer out, then attach the drawer(D) to the wall plate with
screw(K), washer(N) and hex screwdriver(P).
Step 6 Insert rubber pad(L) into the holes of glass support, put glass shelf(E) onto
rubber pad, then fix it with screw(K).
Put the glass shelf(F) onto the rubber pad of the drawer.
5
N
K
D
K
E
L
F

OK
11lbs(5kgs)
11lbs(5kgs)
6
U.S. and other foreign patents pending /
Patentes de los EUA y países extranjeros en trámite /
Brevets en cours pour les États-Unis et autres pays /
U.S. und andere ausländische Patente sind hängig
All rights reserved / Derechos Reservados /
Tous droits réservés
Made in China / Hecho en China /
Fabriqué en Chine
www.atlantic-inc.com
R1.0 130709 #38435887
2012
Product Warranty: Atlantic Inc., warrants to the original purchaser that its products are
free from defect in materials and workmanship. If after inspection, we find that the product
was defective in materials or workmanship we shall repair or replace the product at our
discretion. This warranty does not cover accidental damage, misuse, improper care or
alteration and excludes claims for incidental or conswqunetial loss. This limited warranty
applies to product purchased in the U.S. and Canada. This warranty gives you specific
legal rights and you may also have other rights which vary from State to State. This war-
ranty duration will last one year from date of purchase.
