Owner’s Manual AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AP-S15HR
AC Power Conditioner & Distribution Unit

AtlasSound.com – 2 –
Specifications are subject to change without notice.
Owner’s Manual
AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Table of Contents
Important Safety Instructions.................................................................................................................. 3
Introduction ........................................................................................................................................... 5
Key Features and Applications ............................................................................................................... 6
Front Panel Description ........................................................................................................................... 7
Rear Panel Description ............................................................................................................................ 8
Installation .............................................................................................................................................. 9
Specifications ........................................................................................................................................10
Warranty ................................................................................................................................................ 12

– 3 – AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this device near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other device (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they
exit from the device.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the device. When a cart is used,
use caution when moving the cart/device combination to avoid injury from tip-over.
13. Unplug this device during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled, or objects have fallen into the device, the device has been exposed
to rain or moisture, does not operate normally, or has been dropped.
15. WARNING: To reduce the risk of fire or electric shock, this device should not be exposed to rain or moisture and objects filled with
liquids, such as a vase, should not be placed on this device.
16. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle.
17. The mains plug of the power supply cord shall remain readily operable.
The lightning flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage “ within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.

AtlasSound.com – 4 –
Specifications are subject to change without notice.
Owner’s Manual
AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
When The Device Is In Use
• To prevent electric shock, do not remove the product cover as there are high voltage components inside. Refer all servicing to
Atlas Sound.
• Should any of the following irregularities occur during use, immediately switch off the power, disconnect the power cord from the
AC outlet and contact Atlas Sound. Do not to attempt to continue operation with the product as this may cause fire or electric shock:
• Smoke or strange smell coming from the unit.
• If the product falls or the case is damaged.
• If water or any metallic objects falls into the product.
• If the power supply cord is damaged in any way.
• If the unit is malfunctioning.
• Do not insert or drop metallic objects or flammable materials into the ventilation holes of the product's cover, as this may result in
electric shock or fire.
• Do not place any containers with liquid or metallic objects on the top of the product. If any liquid spills into the unit, fire or electric
shock may result.
• Never operate this product or touch the power supply cord during an electrical storm, electric shock may result.
• Never exceed the power rating on the product when connecting equipment. Fire and/or property damage may result.
• Operate the product only with the voltage specified on the unit. Fire and/or electric shock may result if a higher voltage is used.
• Do not modify, kink, or cut the power cord. Do not place the power cord in close proximity to heaters and do not place heavy objects
on the power cord, including the product itself, doing so may result in fire or electrical shock.
• Replace the protective cover over the speaker terminals after installation.
• Ensure that the safety ground terminal is connected to a proper ground. Never connect the ground to a gas pipe as a catastrophic
disaster may result.
• Be sure the installation of the product is stable, avoid slanted surfaces as the product may fall and cause
injury or property damage.
When Installing The Product
• Plugging in or unplugging the power cord with wet hands may result in electric shock.
• Never move the unit with the power cord plugged into the wall, as damage to the power cord may result.
• When unplugging the cord from the wall, grasp the plug, NOT the cord.
• Never install this product in humid or dusty locations, nor in direct sunlight, near sources of heat, or in areas where sooty smoke or
steam are present. Fire and electric shock may result.
• Keep all sides of the unit at least 31⁄2" away from objects that may obstruct air flow to prevent the unit's internal temperature rise.
When The Product Is In Use
• Never place heavy objects on the product, causing it to fall and/or break, resulting in personal injury and property damage. In
addition, the product itself may fall and cause injury and property damage.
• Contact Atlas Sound for instructions on cleaning the inside of the unit. Large accumulations of dust inside the unit may result in heat
buildup and fire.
• Ensure that the power supply plug is securely plugged into the wall outlet. Never allow dust to accumulate on the power plug or
inside the wall outlet.
• When cleaning the unit or the unit is not to be operated for an extended period, unplug the power cord from the wall.
CAUTION
WARNING
CAUTION

– 5 – AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Introduction
Thank you for purchasing the Atlas Power AP-S15HR AC Distribution and Suppressor Unit. The AP-S15HR has been designed to fit into
Atlas half width rack equipment racks. The AP-S15HR meets or exceeds most installation requirements for AC power distribution and
equipment power protection.
The AP-S15HR Half Rack design offers power management control, scalable power cord length, noise filtering, AC ground fault
indication and six AC outlets making it the most compact, cost effective power management protection system on the market today.
The AP-S15HR features noise filtering for unwanted Radio Frequency Interference (RFI) that is commonly introduced into AC lines by
nearby radio transmitters or wireless products. The benefit of the RF Filter can be seen on video products and heard audibly by reduced
static pops and external signal interference.
The AP-S15HR is unique by allowing you to select the power cord length that is required for the installation. A removable 12' IEC
power cord with a retainer bracket is supplied with the unit. If needed, a shorter or longer cord can be purchased separately to meet
installation requirements.
The AP-S15HR is designed to be mounted in a half width rack design but can also be rack mounted into 19" equipment racks by using
the optional PA702RMK kit. This kit allows you mount an AP-S15HR by itself or in conjunction with another Atlas half width rack product
such as the DPA-102PM, PA40G/PA60G, or MA40G/MA60G in a 19” 1RU space.

AtlasSound.com – 6 –
Specifications are subject to change without notice.
Owner’s Manual
AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Key Features
• Half Width Rack Design 8.9" Wide with Removable Rack Ears
• Circuit Breaker Protection @ 15A
• 6 Total Outlets
• 4 Rear Panel Switched Outlets
• 1 Rear Panel Unswitched Outlet
• 1 Front Panel Unswitched Convenience Outlet
• Removable IEC Power Cord with a Retainer Bracket
• RFI Noise Filtering to Reduce Radio Frequency Interference
• Service Required Indicator
• Earth Ground Fault Connection Indicator
• Power Switch Cover
Applications
The flexible AP-S15HR was designed with features to be used in a variety of applications. The AP-S15HR can be used solely for AC
distribution. The AP-S15HR can also be used for power conditioning to eliminate or reduce fuzzy video or audible static pops. The
following are just a few examples of applications where the AP-S15HR can be used:
• Restaurants
• Houses of Worship
• Schools
• Theaters
• Office Buildings
• Sports Bars

– 7 – AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Front Panel Description
1. Unswitched AC Outlet
The 120VAC outlet is always live when the AP-S15HR power cord is plugged into an AC mains power source. Note: The AC mains
power switch does not affect the Unswitched AC Outlet.
2. AC Mains Breaker
The 15A rated breaker will open if the combined draw of all AC outlets exceeds 15A. Note: The breaker is designed to exceed its rating
for a short period of time. If the breaker is tripped, the load must first be remove from the AP-S15HR before pushing to reset.
3. Power Switch & Cover
To turn the AP-S15HR On or Off, press the switch to the On or Off position. When in the On position and AC voltage is present the
power switch will illuminate. If the switched outlets are active the outlet active blue LED will be illuminated. The AP-S15HR incorporates
a power switch cover to prevent an accidental pressing of the power switch.
4. Switched Outlets Active Indicator
This LED will illuminate Blue when the AC Mains power switch is in the On position.
5. Service Required Indicator
If Illuminating RED, contact Atlas Customer Service before continuing use of the product.
6. Ground Fault Indicator
This LED will NOT illuminate Green when the AP-S15HR has Earth ground connection on the Earth ground pin of the AC Mains power
cord. Note: If there is no Earth ground connection the LED will illuminate and the AC wall outlet must be repaired by a qualified
electrician before continuing.
1 2 3456

AtlasSound.com – 8 –
Specifications are subject to change without notice.
Owner’s Manual
AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Rear Panel Features Description
1. AC Mains Input
Connect the IEC 14 Gauge 12' (4m) power cord to a 15A 120VAC outlet to provide power to the AP-S15HR.
2. AC Mains Input IEC Power Cord Retainer
The AP-S15HR incorporates an IEC power cord retainer bracket to prevent the cord from coming loose. See IEC power cord retainer
bracket installation.
3. AC Power Outlets
The AP-S15HR features six NEMA 5-15P AC outlets. There is one Unswitched outlet on the front and one on the rear of the unit. There
are four Switched AC outlets on the rear of the unit for a total of six AC outlets. These four Switched AC outlets are “Live” when the
front panel power switch is in the On position. The two Unswitched outlets are always live if the power cord is connected to 120VAC.
12 3

– 9 – AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Installation
Before installing, read the entire manual to ensure proper understanding of operation and that all features are being utilized. The
AP-S15HR can be placed on a shelf or rack mounted in a half width rack or a 19" width rack. When rack mounted, placement within the
rack is flexible however the AP-S15HR should be within 6' of a dedicated 15A AC outlet. When rack mounting, use rack rail type screws
of 10⁄32" x 1". Always make sure the 15A outlet is properly inspected by a certified electrician prior to connecting the AP-S15HR. Make
sure to inspect the equipment that will be connected to the AP-S15HR to ensure it does not exceed 15A total amperage draw.
AC Power Cord Retainer System
Connect the IEC 14 Gauge 12' (4m) power cord to a 15A 120VAC outlet to provide power to the AP-S15HR by aligning the pins of the
cord to the pins on the chassis and inserting the cord. Press firmly to assure a good connection. Remove the two screws from the
chassis of the AP-S15HR
The AP-S15HR incorporates an IEC Power Cord retainer bracket to prevent the cord from coming loose. To install the IEC power cord
retainer bracket, remove the two screws from the chassis of the AP-S15HR, place the retainer bracket over the cord and insert the two
screws through the bracket into the chassis as illustrated below.

AtlasSound.com – 10 –
Specifications are subject to change without notice.
Owner’s Manual
AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Specifications
Type Power Conditioner & Suppressor
Load Rating 15A / 12A
Safety Listings UL 60950 Standard
Front Panel
Outlets 1 Unswitched
Activation Switch Rocker with Security Cover
Circuit Breaker 15A Resettable
Indicators AC Power On, Outlets Active, AC Ground Fault
Rear Panel
AC Outlets 5 Outlets Total, 1 Unswitched & 4 Switched
AC Mains IEC Power Socket 15A 1800W
Technical Data
Max AC Mains Current 15A AC Mains Breaker
Operating Voltage 102VAC - 132VAC
Power Consumption 8 Watts
Noise Attenuation RFI 10dB @ 10kHz / 40dB @ 100kHz / 100dB @ 10MHz
Min. Spike Clamping Voltage 460VRMS @ 3,000A
Max. Spike Clamping Voltage 6000V
Max. Spike Clamping Resp. Time 1 nanosecond
Spike Clamping Voltage @ 100A 1250Vp for 20μs
Maximum Surge Current 6,500A
Energy Rating @ 2ms 600 Joules
Temperature Range 5° – 35°C
Humidity Range 5% to 95% Relative Humidity
Mechanical
Chassis Finish Black
Mounting Half Rack Mount, 1 RU, Optional 19" Rack Kit Available
Height 1.75" (1RU, 44.5mm)
Width 8.9" (226.1mm) Body with Rack Ears 10.5" (266.7mm)
Depth 8" (203mm)
Weight 5.5 lbs (2.49kg)
In the Box
Manual
IEC Power Cord 14 Gauge 12ft (4M)
IEC Power Cord Retainer Bracket

– 11 – AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Notes:

AtlasSound.com – 12 –
Specifications are subject to change without notice.
Owner’s Manual
AP-S15HR
AC Power Conditioner & Distribution Unit
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
Limited Warranty
All products manufactured by Atlas Sound are warranted to the original dealer/installer, industrial or commercial purchaser to be free
from defects in material and workmanship and to be in compliance with our published specifications, if any. This warranty shall extend
from the date of purchase for a period of three years on all Atlas Sound products, including SOUNDOLIER brand, and ATLAS SOUND
brand products except as follows: one year on electronics and control systems; one year on replacement parts; and one year on
Musician Series stands and related accessories. Additionally, fuses and lamps carry no warranty. Atlas Sound will solely at its discretion,
replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance
with our published operation and installation instructions. We will not be responsible for defects caused by improper storage, misuse
(including failure to provide reasonable and necessary maintenance), accident, abnormal atmospheres, water immersion, lightning
discharge, or malfunctions when products have been modified or operated in excess of rated power, altered, serviced or installed
in other than a workman like manner. The original sales invoice should be retained as evidence of purchase under the terms of this
warranty. All warranty returns must comply with our returns policy set forth below. When products returned to Atlas Sound do not
qualify for repair or replacement under our warranty, repairs may be performed at prevailing costs for material and labor unless there is
included with the returned product(s) a written request for an estimate of repair costs before any nonwarranty work is performed. In the
event of replacement or upon completion of repairs, return shipment will be made with the transportation charges collect.
EXCEPT TO THE EXTENT THAT APPLICABLE LAW PREVENTS THE LIMITATION OF CONSEQUENTIAL DAMAGES FOR PERSONAL
INJURY, ATLAS SOUND SHALL NOT BE LIABLE IN TORT OR CONTRACT FOR ANY DIRECT, CONSEQUENTIAL OR INCIDENTAL LOSS
OR DAMAGE ARISING OUT OF THE INSTALLATION, USE OR INABILITY TO USE THE PRODUCTS. THE ABOVE WARRANTY IS IN
LIEU OF ALL OTHER WARRANTIES INCLUDING BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
Atlas Sound does not assume, or does it authorize any other person to assume or extend on its behalf, any other warranty, obligation,
or liability. This warranty gives you specific legal rights and you may have other rights which vary from state to state.
Service
Should your AP-S15HR require service, please contact the Atlas Sound warranty department at
1-877-689-8055, ext. 277 to obtain an RA number.
Atlas Sound Tech Support can be reached at 1-800-876-3333.
Visit our website at www.AtlasSound.com to see other Atlas products.
©2016 Atlas Sound L.P. All rights reserved. Atlas Sound is a trademark of Atlas Sound L.P.
All other trademarks are the property of their respective owners. ATS004841 RevC 1/16
