User Manual
1 by 2 Mini DisplayPort Splitter
AT-MDP12

1www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
1. Introduction .................................................. 2
2. Package Contents .................................................. 2
3. System Requirements .................................................. 2
4. Features .................................................. 2
5. Specification .................................................. 3
6. Panel Descriptions .................................................. 3
6.1 Front Panel .................................................. 3
6.2 Rear Panel .................................................. 4
7. EDID Support Format .................................................. 5
8. Connection and Installation .................................................. 5
9. Safety Information .................................................. 6
10. Warranty .................................................. 7
11. Atlona Product Registration .................................................. 8
TABLE OF CONTENTS

2www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Atlona Technologies AT-MDP12 is a 1 input to 2 outputs Mini DisplayPort splitter designed to allows any single
Mini DisplayPort enabled computer (such as MacBook Pro, MacPro, Air, MacMini and so on) the ability to be
displayed on two Mini DisplayPort monitors simultaneously. Most common monitors are Apple 24” LED and
Apple iMac 27”, the splitter will also work with DisplayPort monitors (Dell, HP and others); however a Mini
DisplayPort to DisplayPort adapter will be required, Atlona makes such an adapter as well. This unit supports
video resolution up to 2560 x 1600 and PCM audio up to 7.1. Audio can also be bypassed through the unit’s
USB connection, the same USB is used to power the splitter. With four sets of EDID formats, the AT-MDP12
provides a fast switch between source and display and saves the EDID’s reading sink time to allow image to be
displayed properly.
• AT-MDP12 Splitter
• Operation Manual
• 1 x 5ft mini-DP cable (male to male)
• 1 x 5ft Y cable 2x USB type A to 1x USB type B
Mini DisplayPort or DisplayPort output source equipment with Mini DisplayPort input monitors.
• Supports resolution up to 2560 x 1600
• Supports PCM audio 2.0 to 7.1, Apple monitors don’t allow audio to pass though Mini Display Port,
therefore please use USB connection for Audio
• Supports EDID switching and settings.
• Powered by USB.
INTRODUCTION
PACKAGE CONTENTS
SYSTEM REQUIREMENTS
FEATURES

3www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Sampling Rate 192kHz
Input port 1 x Mini DisplayPort , 1 x Mini USB
Output port 2 x Mini DisplayPort , 1 x USB (A Type)
ESD Protection Human body model: ± 8kV (air-gap discharge)
± 4kV (contact discharge)
Dimensions (inch) 7(W) x 4.8(D) x 1.96(H)
Weight (LB) 1.5
Chassis Material Aluminum
Silkscreen Color Black
Operating Temperature 00C~400C / 320F ~ 1040F
Storage Temperature -200C~600C / -40F ~ 1400F
Relative Humidity 20~90% RH (non-condensing)
1. Front Panel
1. EDID switch: Four EDID setting
*Below is the mode definition chart.
Mode Select EDID Fuction Use
1 2
1 Copy from Display DisplayPort Monitor(s) connected
2 640x480 MODE Apple 24” & 27” iMacs connected
3 1920x1200 MODE Apple 24” iMac(s) connected
4 2560x1440 MODE Apple 27” iMac(s) connected
SPECIFICATIONS
PANEL DESCRIPTION
1 2 3 4 5

4www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
2. LINK LED: When the device detects the display and sends out the signal the Link LED will illuminate.
3. SYNC LED: When the device detects the source signal the SYNC LED will illuminate.
4. Power LED: The LED will illuminate in green when power on and in red when in standby mode.
5. Reset button: Press this button to reset your EDID after each EDID setting.
2. Rear Panel
1. USB OUT: Connect a USB A type cable to the display monitor or PC/notebook for audio & USB signal
bypass.
2. USB IN: Connect a mini USB cable from your PC/notebook for power and pass-though
3. MINI-DP OUT 1 & 2: Connect the MDP cable or MDP to DP cable to your MDP/DP input display for dis-
playing a single source on two screens simultaneously.
4. MINI-DP IN: Connect the MDP cable or MDP to DP cable from the MDP/DP source for signal sending.
1 2 3 4

5www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
EDID SUPPORT FORMAT
CONNECTION AND INSTALLATION
Select MODE VGA 1920x1200 2560x1440
Video Support
640x480@60 v v v
800x600@60 v v
1024x768@60 v v
1920x1200@60 v v
1280x960@60 v v
1344x1008@60 v v
1280x1024@60 v v
1600x1200@60 v v
2560x1440 v
720p v
Audio Support
PCM 2CH 48K v
PCM 2CH 44.1K v
PCM 2CH 32K v

6www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Safeguards
Precautions
FCC regulations state that any unauthorized changes or modifications to this equipment, not expressly
approved by the manufacturer, could void the user’s authority to operate this equipment.
Operate this product using only the included external power supply. Use of other power supplies could impair
performance, damage the product, or cause fires.
In the event of an electrostatic discharge this device may automatically turn off. If this occurs, unplug the device
and plug it back in.
Protect and route power cords so they will not be stepped on or pinched by anything placed on or against
them. Be especially careful of plug-ins or cord exit points from this product.
Avoid excessive humidity, sudden temperature changes or temperature extremes.
Keep this product away from wet locations such as bathtubs, sinks, laundries, wet basements, fish tanks, and
swimming pools.
Use only accessories recommended by Atlona to avoid fire, shock, or other hazards.
Unplug the product before cleaning. Use a damp cloth for cleaning and not cleaning fluid or aerosols.
Such products could enter the unit and cause damage, fire, or electric shock. Some substances may also
mar the finish of the product.
Never open, remove unit panels, or make any adjustments not described in this manual. Attempting to
do so could expose you to dangerous electrical shock or other hazards. It may also cause damage to your
AT-MDP12. Opening the product will void the warranty.
Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or
contact Atlona directly.
To reduce the risk of electric shock, do not
expose this product to rain or moisture
If the wall plug does not fit into your local
power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug. Doing so will
void the warranty and safety features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in the case it requires
disconnection.
SAFETY INFORMATION

7www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
WARRANTY
Limited Warranty
Atlona Technologies warrants that (a) its products (the AT-MDP12) will perform
substantially in accordance with the accompanying written materials for a period of 3 years from
the date of receipt and (b) that the product will be free from defects in materials and workmanship
under normal use and service for a period of 3 years. In the event applicable law imposes any
implied warranties, the implied warranty period is limited to 3 years from the date of receipt. Some
jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation
may not apply to customers that fall within those areas.
Customer Remedies
Atlona Technologies’ and its suppliers’ entire liability and Customer’s exclusive remedy shall
be, at Atlona Technologies’ decision, either return of the price paid for the product, repair, or
replacement of the product that does not meet this Limited Warranty and which is returned to Atlona
Technologies with a copy of the Customer’s receipt. This Limited Warranty is void if failure of the
product has resulted from accident, abuse, misapplication, or natural occurrence. In example but not
limited to: power surges (electrical storms, local power outage), dropping the product (or items on
the product), contact with fluids, and physical misconduct (i.e. kicking or punching). Any replacement
product will be warranted for the remainder of the original warranty period.
No other warranties
To the maximum extent permitted by applicable law, Atlona Technologies and its suppliers
disclaim all other warranties, either expressed or implied, including, but not limited to, implied
warranties of merchantability and fitness for a particular purpose, with regard to the product and any
related written materials. This Limited Warranty gives customer specific legal rights. Customers may
have other rights depending on the jurisdiction.
No liability for damages
To the maximum extent permitted by applicable law, in no event shall Atlona Technologies or
its suppliers be liable for any damages arising out of the use of or inability to use this product, even
if Atlona Technologies has been advised of the possibility of such damages. Such damages include
but are not limited to: special, incidental, consequential, or indirect damages for personal injury, loss
of business profits, business interruption, loss of business information, or any other pecuniary loss.
Atlona Technologies’ and its suppliers’ entire liability under any provision of this agreement shall
be limited to the amount actually paid by you for the product. Some Jurisdictions do not allow the
exclusion or limitation of liability for consequential or incidental damage. The above limitations may
not apply to you in such jurisdictional cases.

8www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few
moments to register your new purchase.
Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll
receive notification of performance issues and firmware updates.
At Atlona, we respect and protect your privacy, assuring you that your registration information
is completely secure. Atlona product registration is completely voluntary and failure to register will not
diminish your limited warranty rights.
To register go to: http://www.atlona.com/registration
