AtlonA
4x2 Component with Optical/Digital
Coax/Analog Audio Matrix Switcher
AT-COMP-42M
User Manual

TABLE OF CONTENTS
1. Introduction .................................................. 1
2. Features .................................................. 1
3. Package Contents .................................................. 1
4. Panel Descriptions .................................................. 2
4.1 Front Panel .................................................. 2
4.2 Rear Panel .................................................. 2
5. Connection and Installation .................................................. 3
  
7. IR Codes .................................................. 4
8. RS232 Control Commands .................................................. 5
9. Safety Information .................................................. 7
10. Warranty .................................................. 8
11. Atlona Product Registration .................................................. 9

INTRODUCTION
1
Atlona Technologies’ AT-COMP-42M is one of the most innovative Component Video with Opti-
cal/Digital Coax/Analog Audio Matrix switcher on the market. The AT-COMP-42M has 4 indi-
vidual Component (RCA) /Optical/Digital Coax and Stereo Audio inputs and 2 individual outputs.
Because it is a matrix switch, any input can be routed to any output; and the same input can be
routed to all outputs or any other combination. This switch is ideal for connecting sources includ-
ing: (VCRs, Camcorders, Video Game Consoles, DVDs, Satellite Receivers, Set Top Boxes,
Apple TV, etc.) to desired displays such as: (HDTV, LCDs, Plasma Monitors, Video Projectors,
etc.) Selection of inputs can be achieved manually through the Front Panel, an Infrared Remote

distribution of all HDTV video formats up to 1080p as well as Digital and Analog audio signals.


Component Video: YPBPR/YCBCR/RGB(composite)+HV
Digital: Coaxial S/PDIF Digital Audio (PCM) or Composite Video
Optical: Toslink
Audio: Stereo Audio















FEATURES:
PACKAGE CONTENTS:

PANEL DESCRIPTIONS
2
1. Front Panel


3. Channel Push Buttons: Push to select desired Inputs/Outputs
2. Rear Panel
1. Output: 2 x Component with Optical/Digital/Stereo Audio.
2. Inputs: 4 x Component with Optical/Digital/Stereo Audio.
3. Power DC Input: 12V DC.

123
AT-COMP-42M
4x2 Component Video/Audio Matrix Switcher
Optical Optical Optical OpticalOpticalOptical
   
Digital
YPb
AL AL AL ALALALAR
Pr 
Digital
YPb
AR
Pr
Digital
YPb
AR
Pr
Digital
YPb
AR
Pr
Digital
YPb
AR
Pr
Digital
YPb
AR
Pr

DC 12V
RS-232
1 32

3
CONNECTION and INSTALLATION
AT-COMP-42M
Audio AMP Audio AMP
PC RS232 Control
HDTV 2 HDTV 1
VCR Player HD Player
DVD Player Satellite Receiver
Aud
i
o
A
M
Aud
i
o
A
M
t
e
llit
e
R
ece
i
ver
y

Input / Output Y,PB,PR 75 / 1~2Vpp

Digital : Digital Audio(S/PDIF), Composite Video

Video Bandwidth 
HDTV Scan Rate 480I, 480P, 576P, 1080I, 720P, 1080P, Support 1920x1080.
Digital Bandwidth 
Audio Frequency Respond 
Supported Signals 
Optical
Digital (S/PDIF)
Stereo Audio (AR/AL)
Channel switch time 25ns with 1% setting, with -83 db crosstalk,

Industrial Temp. Range -40oC to +85oC
Hostile Crosstalk 
Dimensions (W.D.H.) 17.32” (W) x 7.80” (D) x 1.23” (H)
 2000 GW (with metal case)
Power Consumed DC+12V, @500mA~2000mA
IR Codes (for use with universal remote control):

4
SPECIFICATIONS
IR CODES

RS232 - Cable Pin Lines
1. Applicable items: AT-COMP-88M, AT-SAV-84M, AT-COMP-42M, AT-PRO82.
2. Transmision rate: 9600 bps


5. Commands are send from the controller as 8 ASCII bytes.
6. Controlling commands (from a controller to)
 
The rest of bytes indicate the action of command as ASCII format.
Item Command Function Description
1  Power on System power on
2 SBSYSMOF Power off System power off
3 SBIxxO01 Channel 1 setting 1st output comes from xth input,

4 SBIxxO02 Channel 2 setting 2st output comes from xth input,

5 SBIxxO03 Channel 3 setting 3st output comes from xth input,

6 SBIxxO04 Channel 4 setting 4st output comes from xth input,

7  Locked toggle
On
Is locked toggle on. When Locked on all status
are changed by RS232 only
8  Locked toggle
Off
Is locked toggle off. When Locked off all status
are changed by RS232 only
9 SBALLRST Reset Is reset and every output
Comes from 1st input.
10  Ask Status Request status information
5
RS-232 CONTROL COMMANDS

7, Feedback commands (from a controller)
The 8 ASCII feedback commands are send after receiving the command from a controller
Item Command Function Description
1  Power on Responses the system power.
On command to the controller
2  Power off Responses the system power.
Off command to the controller
3  Channel 1 updated Changes the 1st output signal.
xx is the selected source

4  Channel 2 updated Changes the 2st output signal.
xx is the selected source

5  Channel 3 updated Changes the 3st output signal.
xx is the selected source

6  Channel 4 updated Changes the 4st output signal.
xx is the selected source

7  Lock on Is locked on
8  Lock off Is released
9  Reset Responses the reset command.
10  Status asknowledge Responses the ask status
Command to the controller
Remark: The device responds to one feedback command for every request except the
<SBASKATA> . After the device receives <SBASKATA>, it will send the 10th, 1/2th, IN/OUT
state, 7/8th command sequentially.
Note: Responses IN/OUT state command: SBUD0000XXYY
input port XX=> (01, 02, ..., 06)
output port YY=> (01, 02, ..., 06)
6

7
SAFETY INFORMATION
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture.

power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug.
Doing so will void the warranty and safety
features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in case it requires
disconnection.
Precautions
FCC Regulations state that any

this equipment not expressly approved by
the manufacturer could void the
user’s authority to operate this
equipment.
Operate this product using only the

other power supplies could impair
performance, damage the product or cause

In the event of an electrostatic discharge,
this device may automatically turn off. If this
occurs, unplug the device, and plug it back
in.
Protect and route power cords so they will
not be stepped on or pinched by anything
placed on or against them. Be especially
careful of plug-ins, or cord exit points from
this product.
Avoid excessive humidity, sudden
temperature changes or temperature
extremes.

such as bathtubs, sinks, laundries, wet
basements and swimming pools.




a damp cloth for cleaning. Do not use


electrical shock. Some substances may


any adjustments not described in this
manual. Attempting to do so could expose
you to dangerous electrical shock or other

AT-COMP-42M. Opening the product will
void the warranty.
Do not attempt to service the unit. Instead


directly.

WARRANTY
8
1. LIMITED WARRANTY
Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the

free from defects in materials and workmanship under normal use and service for a period of 3 years. In the event
applicable law imposes any implied warranties, the implied warranty period is limited to 3 years from the date of
receipt. Some jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation
may not apply to Customer.
2. CUSTOMER REMEDIES
Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technolo-
gies’ option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet
this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited
Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Prod-
uct will be warranted for the remainder of the original warranty period or 3 year, whichever is longer.
3. NO OTHER WARRANTIES
-

           

-

4. NO LIABILITY FOR DAMAGES
-
     -





-



2151 O’toole Ave, Ste D

Toll Free: 1-877-536-3976
International: 408-954-8782
FAX: [phone]
Website: www.atlona.com


9
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product — we hope you’ll enjoy it.
We also hope that you’ll take a few moments to register your new purchase. Registration creates an ownership
-
ware updates.
At Atlona, we respect and protect your privacy and assure you that your registration information is completely
secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited
warranty rights.
To register go to www.atlona.com/registration
