Atlona AT-VCC-RELAY-KIT User manual

AT-VCC-RELAY-KIT
1
Installation Guide
IP to Relay Command Converter for Velocity Control System
AT-VCC-RELAY-KIT
The Atlona AT-VCC-RELAY-KIT is an accessory for the Atlona Velocity™ Control System that
provides conversion between IP control commands and relay / sensor signals. This Velocity
Control Converter is very compact and can be placed anywhere a device requires control and
is not IP-capable. The VCC-RELAY-KIT is remotely powered through Power over Ethernet (PoE),
or locally from a USB power source. The primary unit installs onto any surface via a convenient
mounting dock. A simple “click” locks it into place for a secure, reliable installation. The control
port module supports DIN rail installation, and features four relay outputs plus four sensor inputs.
The inputs and outputs are both congurable for various operating modes.
1 x AT-VCC
1 x AT-VCC-RELAY
Package Contents
Operating Notes
• The AT-VCC-RELAY-KIT is PoE, to power the unit, simply plug it into a PoE compatible
network switch. If the network switch is not PoE capable, a PoE injector (purchased separately)
or USB can be used.
• All devices (AT-VCC, Velocity, AT-VTP, switchers, etc) should be set to static IPs or the
DHCP IP address reserved for each individual device.
IMPORTANT: Velocity Gateway (AT-VGW-HW) must be set up before the AT-VCC-RELAY-
KIT is fully functional.

AT-VCC-RELAY-KIT
2
Installation Guide
Panel Description
SPST
DPDT
SPDT
Contact
Closure
Voltage
Sensor
17
1
1
2
SPST
SPST
22
3
3
4
4
56
1 Ethernet
Connect an Ethernet cable from this
port to the same network as the Velocity
Gateway.
2 USB
Optional - Connect a mini USB to USB
cable here for power.
3 3.5mm Port
Connect to a VCC relay connector.
4 Relay
Connect relay here, adjusting the jumpers
to set the unit to the correct mode.
5 Sensor
Connect sensor here, adjusting the
jumpers to the correct mode.
6 3.5mm Connector
Connect the 3.5mm connector to the
3.5mm port of the VCC.
7 Factory Reset Button
Press and hold this button to reset all
settings to the factory default.
Relay
The relay has 4 terminals which vary in function depending on how the jumpers above the ports
are set.
Place the jumpers as shown below, this can be done to a single connector or to both to create up
to 4 independent relays.
Single Pole, Single-Throw is best used when using a device with a simple open/close (on/o)
circuit is being used.
Single Pole, Single-Throw (SPST)
NOTE: Relays can only work up to a maximum of 24V and 500 mA current.
C + + C

AT-VCC-RELAY-KIT
3
Installation Guide
Place the jumpers as shown below, this can be done to a single connector or to both to create up
to 3 independent relays.
When DPDT is selected within Velocity, it will create 2 relays that work simultaneously. If one
port is opened, the other will open at the same time. The DPDT is a variant of the SPDT and the
jumpers must be placed exactly as below to work.
Single Pole, Double-Throw (SPDT)
Double Pole, Double-Throw (DPDT)
C + + C
C + + C C + + C
Both ports are set to
Contact Closure
Both ports are set to
Voltage Sensor
The ports are set to Contact
Closure for the rst two ports and
Voltage Sensor for the last two.
1
1
1
33
4
Sensor
The ports can be set to sense either voltage or contact closure. Contact closure will react to the
change in current, while voltage will react to voltage as low as +/- 3V or as high as +/- 24V.
1 2
SPST
SPDT SPDT
DPDT
SPDT
Single Pole, Double-Throw is best used when two circuits are going to one common, such as:
switching between two input circuits or selecting two power sources.

AT-VCC-RELAY-KIT
4
Installation Guide
IP
The AT-VCC is set to DHCP by default. If the network does not support DHCP, it will automatically
set the AT-VCC to the static IP of 192.168.1.70 after 30 seconds.
VHelp and webGUI
Velocity will nd the VCC when scan network is used, but if the VCC needs to be set up o site
rst, the software VHelp can be used.
1 Connect the Relay connector into the 3.5mm port on the unit.
2 Connect the AT-VCC to a network switch (PoE is best if a PoE switch is not available, a
power injector or mini USB to USB cable may be used).
3 Download VHelp from the resource tab of https://atlona.com/product/at-vcc-relay-kit/.
4 Unzip the le to the local PC
5 Double-click the VHelp executable to open the program. Vhelp will start discovery as soon
as the program is opened.
6 Double click on the VCC (to determine the correct one, look on the bottom of the VCC for
the MAC address). The PC default browser will open to the AT-VCC webGUI.
7 Select Network Settings to open the IP conguration page.
8 Select the DHCP Enabled header, this will disable DHCP and allows IP settings to be edited.
9 Type in the IP details to
match the network details
of the Gateway. e.g. If the
Velocity gateway is located at
the IP of 192.168.12.15, then
the VCC should be set to an
IP within the 192.168.12.XXX
range that has not already
been used.
10 Press the Save Changes button.

AT-VCC-RELAY-KIT
5
Installation Guide
NOTE: Connecting the VCC to Velocity can only be done once Velocity has been set
up. View the Velocity Manual for instructions.
15 Select the building that corresponds with the room of the VCC.
16 Select the room the VCC is located in. A new screen will take over the window and display
the technology in the room.
17 Select the + button located at the top right corner of the room. A new menu will open.
18 Press the scan network button. All Atlona devices found will appear in the unassigned list.
11 Open any browser on the network and type in the IP address of Velocity.
12 Log in and select the ≡button from the top left corner and select Control.
13 More options will appear. Select All Rooms. A new screen will open.
14 Select the Edit Room Technology button on the room tile. The Modify Technology screen will
open.

AT-VCC-RELAY-KIT
6
Installation Guide
19 Select the Add button next to the VCC. A new pop up will appear.
20 Select the VCC Relay/Sensor from the drop down menu.
21 Press the ADD VCC TO ROOM button. A VCC tile will appear in the room.
The VCC is now ready to use. Refer to the Macros, Event Macros, and Room Triggers section of
the Velocity manual for setting up relay control.
• Select Relay/Sensor from the drop down menu.
• Type the VCC’s IP into a web browser to open the Velocity Command Converter
Conguration.
• Select Velocity Control Cable from the two options.
NOTE: If for some reason the unit isn’t syncing or the settings aren’t being set, they
can be set up manually through the VCC webGUI.
• Select the Relay/Sensor congurations.
NOTE: Ensure to select the Relay type that matches how the connector was pinned.
Refer to Relay and Sensor sections if unsure how to set up the connector.

AT-VCC-RELAY-KIT
7
Installation Guide
Security
Security options have been provided with the VCCs, to set between web UI, API, and system
lock.
• Select Security from web UI menu. A new page will open.
• To protect the web UI from being altered, a username and password can be set, once a
username and password has been set, select the Save Changes button to enable login.
• To lock the conguration of the VCC, select API lock (after setting a username and
password) and press the Save Changes button. With the API lock set, no conguration
changes can be made through TCP commands and must be changed through the web
UI.
• System Lock should not be used unless all conguration and routing has been set
and will not need to be changed. Once System Lock has been selected and the Save
Changes button pressed, no device changes can be made unless the unit is factory reset
through the button on the side of the VCC.

AT-VCC-RELAY-KIT
8
Installation Guide
Advanced Settings
If needed, the system can be rebooted or reset from the Advanced Settings page. Select it from
the home page menu.
• Reboot - Use this button to restart the unit.
• Factory Reset - Use this to set everything back to default settings. This will reset the unit
to DHCP, which may cause the IP to change and the unit to need to be rediscovered.

AT-VCC-RELAY-KIT
9
Installation Guide
Firmware Update
To update the VCC the most recent vHelp software will be needed. The vHelp has the rmware
built into the software and will automatically detect if the VCC is on the most recent rmware.
1 Connect the AT-VCC to a network switch (PoE is best if a PoE switch is not available, a
power injector or mini USB to USB cable may be used).
2 Download VHelp from the resource tab of https://atlona.com/product/at-vcc-relay-kit/.
3 Unzip the le to the local PC
4 Double-click the VHelp executable to open the program. Vhelp will start discovery as soon
as the program is opened.
5 Once the unit is found, if it is out of date an exclamation mark will display next to it. Right
click to open the drop down menu.
6 Select Update from the drop down list. A new pop up will appear.
7 Press the Next button to start the update. The progress bar will cycle through green. This
process can take up to 2 minutes.
8 Once the update is complete, press Exit. The unit will now show a green check mark next to
it to show the unit is up to date.

AT-VCC-RELAY-KIT
10
Installation Guide
Notes

AT-VCC-RELAY-KIT
11
Installation Guide
Notes

AT-VCC-RELAY-KIT
12
Installation Guide
Version 6
The English version can be found under the resources tab at:
https://atlona.com/product/at-vcc-relay-kit/.
