Atlona AT-HD-V216 User manual

AtlonA
2x16 HDMI Switcher
AT-HD-V216
User Manual

TABLE OF CONTENTS
1. Introduction .................................................. 1
2. Features .................................................. 1
  
4. Package Contents .................................................. 2
5. Panel Descriptions .................................................. 2
5.1 Front Panel .................................................. 2
5.2 Rear Panel .................................................. 2
6. Remote Control .................................................. 3
7. IR Extender .................................................. 3
7.1 IR Extender Connection .................................................. 3
7.2 The IR Extender Components Setup .................................................. 4
8. RS-232 Serial Interface .................................................. 4
8.1 RS-232 Serial Interface Connect a PC
or Control System .................................................. 4
8.2 RS-232 .................................................. 5
8.3 Commands .................................................. 5
9. RS-232 Protocol Commands .................................................. 5
9.1 Standby Mode .................................................. 5
9.2 Power Off Mode .................................................. 5
9.3 Front Panel Lock .................................................. 6
9.4 Unit Reset .................................................. 6
10. Applications .................................................. 6
11. Safety Information .................................................. 7
12. Warranty .................................................. 8
13. Atlona Product Registration .................................................. 9

INTRODUCTION
1
-
tion Video application. With 2 HDMI Inputs and 16 HDMI Outputs, the AT-HD-V216 is capable of switching High

manual, IR Remote, or RS232 Control. HDMI formats can reach resolutions up to 1080p or 1920x1200 and same for
DVI. With Automatic input/output HD signals detection and HDCP Compliance, Atlona’s 2x16 

displays.


, DVI
video bandwidth67
VW920
576i/576p, 720p, 1080i,1080p and 1920x1200

36









and DVI 





6.7

40ft6.7





FEATURES
SPECIFICATIONS

PANEL DESCRIPTIONS
2







1. Front Panel
1. POWER SWITCH. The power switch turns the unit on and off. The LED will illuminate red to indicate that the
switcher is ON

present on that input.


nation.

Select sources are 1-HDMI or 2-HDMI

7. 19 INCH EAR MOUNT PAIR. 19 inch case Ear Mount pair
2. Rear Panel



Female connector for serial RS-232 control.




PACKAGE CONTENTS:

3

Ensure that the power switch is OFF

Power up all HD Sources and Displays
For each desired output select the appropriate input by using the front panel select buttons, RS232 or IR remote
control
When powering up the AT-HD-V216 will return to its last used setting before Powered down.
1, 2. SWITCH POWER ON or OFF
3. INPUT-1 SOURCES SELECTION
Select input sources 1 or 2 with selection button
4. INPUT-2 SOURCES SELECTION
Select input sources 1 or 2 with selection button
1. IR Extender Connection
IR EXTENDER
REMOTE CONTROL

4
2. The IR Extender Components Setup
RS-232 SERIAL INTERFACE
RS-232 SERIAL INTERFACE CONNECT a PC or CONTROL SYSTEM
Pin RS-232 
1 - Not used
2  Transmitter
3  
4 - Not used
5  
6 - Not used
7 - Not used
8 - Not used
9 - Not used

RS-232
-
ing to a PC, The serial communication parameters are 9600 baud, 8 bit, No Parity and 1 stop bit - this is
often referred to as 9600 8N1.
-

-

settings, or similar third party control system.
COMMANDS
To Switch Inputs to Outputs
SBI0XO0Y
Unit will respond with
SBUD0XOY

SBI02O01-Send
SBUD02O1
STANDBY MODE
Note: Turning the unit System Power Off over RS232 will distinguish the LED display leaving only the
Power Switch LED on. The Video and Audio outputs will also mute. While the unit is turned off by
RS232 it will continue to accept and act upon switching commands. For example, if the unit is in the off
mode (via RS232) and you send a command to switch an input to an output, that route will complete
and the video and audio will now appear on that channel only. The front panel LED for that particular
output will also show the input selected (for that single output channel only). The remaining LED’s will
remain off and video and audio outputs muted. The unit will still return status and change messages in
response to commands sent while in Power Off state. A hard reset command (SBALLRST) will return
the unit to normal operation and also unlock the front panel.
POWER OFF MODE
SBSYSMOF
SBSYSMON
Unit will respond with
SBALOFAK- Unit is in Standby
SBALONAK- Unit is no longer in Standby

SBSYSMOF-Send
SBALOFAK
5
RS-232 PROTOCOL COMMANDS

AT-HD-V216
HDMI Player 1 HDMI Player 2
y
y
Up to 16 HDMI
Displays
APPLICATIONS
FRONT PANEL LOCK
Note : Hard resetting the unit will unlock the Front Panel controls..
SBSYSMLK- When front panel is locked, changes can only be made by RS-232
SBSYSMUK- Front Panel Unlock
Unit will respond with
SBSYSLOK- Front Panel has been Locked
SBSYSULK- Front Panel has been Unlocked
Example : Lock Front Panel Buttons
SBSYSMLK-Send
SBSYSLOK-Rcvd
UNIT RESET
SBALLRST - Reset every output to Input 1
Unit will respond with
SBRSTACK- Unit has reset each Output to Input 1
Example : Reset all outputs to Input 1
SBALLRST-Send
SBRSTACK-Rcvd
6
PC RS232 Control
IR ext.

7
SAFETY INFORMATION
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture.

power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug.

features.



disconnection.
Precautions
FCC Regulations state that any



user’s authority to operate this

Operate this product using only the
included external power supply. Use of
other power supplies could impair
performance, damage the product or cause




in.
Protect and route power cords so they will
not be stepped on or pinched by anything

careful of plug-ins, or cord exit points from
this product.

temperature changes or temperature
extremes.

such as bathtubs, sinks, laundries, wet
basements and swimming pools.
Use only accessories recommended by


Unplug the product before cleaning. Use
a damp cloth for cleaning. Do not use


electrical shock. Some substances may


any adjustments not described in this
manual. Attempting to do so could expose
you to dangerous electrical shock or other


the warranty.


ATLONA reseller or contact ATLONA
directly.

WARRANTY
8
1. LIMITED WARRANTY



applicable law imposes any implied warranties, the implied warranty period is limited to 3 years from the date of

may not apply to Customer.
2. CUSTOMER REMEDIES
-
gies’ option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet
this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited
-

3. NO OTHER WARRANTIES
-

          

-
RISDICTION.
4. NO LIABILITY FOR DAMAGES
-
   -





-


ATLONA








9
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product — we hope you’ll enjoy it.
We also hope that you’ll take a few moments to register your new purchase. Registration creates an ownership
-
ware updates.
   

warranty rights.
To register go to www.atlona.com/registration
