Atmos Multi Mk2 User manual

APPENDIX
ATMOS MULTI Mk2 version 2004 Appendix Page 1

APPENDIX 1. Spare Parts List
Atmos Multi Mk 2 Parts List
Atmos Multi 24/80
Atmos Multi 24/80 PLUS
Atmos Multi 32/80 PLUS
Drg Ref Description Part Ref.
1 Wall bracket *** 07.98.37.043
2 Bracket fixing kit *** 07.95.82.006
3 Rear casing *** 07.90.22.080
3.1 AAV Grommet 15 mm red/brown *** 07.98.68.026
3.2 Casing latches kit *** 07.90.82.009
4 Securing bolt *** 07.98.44.075
5 Air intake pipe *** 07.98.74.298
6 Automatic closing device 3/8" *** 75.06.65.001
7 Automatic air vent 3/8" *** 79.40.26.001
8 Flue gas pipe *** 07.98.74.295
8 Flue gas temp measuring point *** 07.95.15.002
9 Flue pipe *** 07.98.74.286
10 Gas pipe *** 07.98.74.282
11 Gas valve & fittings set *** 07.95.00.002
11.1 Gas valve *** 07.98.78.003
11.2 O-Ring 26,57x3,53 *** 07.98.83.190
11.3 Bolt M5x8 *** 82.27.02.908
11.4 Nipple 1/2" *** 07.98.74.312
12 Sealing washer *** 07.98.83.189
13 Connecting tube - 24 Model ** 07.95.74.024
13 Connecting tube - 32 Model * 07.95.74.025
14 Fixing nut M6 *** 07.98.82.120
15 Flow pipe set *** 07.95.00.003
15.1 Flow pipe *** 07.98.74.283
15.2 (deleted) *** 75.66.99.027
15.3 Tightening ring 22 mm *** 07.98.74.155
15.4 Tightening nut M27x1,5 *** 07.98.82.119
15.5 CH Temperature sensor *** 07.98.63.042
15.6 Plug 1/2"+ O-Ring *** 74.53.80.016
16 Tank set * 07.95.05.008
16 Tank set - Plus Version * * 07.95.05.009
16.1 Tank frame *** 07.98.30.006
16.2 Earthing washer M8 *** 07.98.82.114
16.3 Hex bolt M8x12 *** 07.98.82.112
16.4 Sealing washer M8 *** 82.74.06.903
16.5 Pump/heat exchanger pipe *** 07.98.74.285
16.6 Union nut 1" *** 07.98.82.113
16.7 O-Ring 22x3.0 *** 07.98.83.227
16.8 Bracket bolt *** 07.98.43.017
16.9 Silicone sealing ring *** 07.98.83.231
16.10 Adjusting screw M6x25 *** 07.98.82.117
16.11 Support collar 22 mm * * 07.98.74.206
16.12 Earthing tab 6,3 mm 45° *** 68.31.12.828
16.13 Screw M4x8 self tap *** 82.08.93.046
ATMOS MULTI Mk2 version 2004 Appendix Page 2

Atmos Multi Mk 2 Parts List
Atmos Multi 24/80
Atmos Multi 24/80 PLUS
Atmos Multi 32/80 PLUS
Drg Ref Description Part Ref.
17 Thermostat *** 78.76.54.981
18 Rear insulation *** 07.98.83.229
19 Burner/fan assembly - 24 Model ** 07.95.25.003
19 Burner/fan assembly - 32 Model * 07.95.25.004
19.1 Burner casting *** 07.95.07.002
19.2 Fan casing *** 07.98.83.185
19.3 Fan *** 07.98.36.003
19.4 Nut M4 *** 07.98.82.080
19.5 Viewing glass set *** 07.95.26.003
19.6 Burner set *** 07.95.25.002
19.7 Ionisation probe set *** 07.95.78.004
19.8 Ignition electrode set *** 07.95.70.006
19.9 O-Ring 80x2 *** 07.98.83.184
19.10 Mixing chamber 25 mm - 24 Model ** 07.98.16.002
19.10 Mixing chamber 28 mm - 32 Model * 07.98.16.001
19.11 Screw M6x8 *** 07.98.82.082
19.12 Grommet 15 mm *** 07.98.68.041
19.13 Nipple cover Ø 6 mm *** 07.98.15.092
20 Ceramic core *** 07.98.27.001
21 Mid baffle *** 07.98.41.027
22 Lower baffle *** 07.98.41.016
23 Condensate collector *** 07.98.07.007
24 Siphon 32x140 mm *** 07.90.74.200
25 Sealing washer 60 mm *** 07.98.83.233
26 Lifting bar set *** 07.95.74.023
27 CH pump (inc. cable loom K5) *** 07.95.36.002
28 3 Port valve (inc. cable loom K7) *** 75.83.01.004
29 Return pipe for CH pump *** 07.98.74.284
30 Pressure sensor *** 07.98.78.004
31 Pump seal 30 mm *** 07.98.83.230
32 Union nut 1" *** 07.98.82.113
33 Short pipe for pump *** 07.98.74.288
34 T-piece 22x22x22 mm *** 07.98.74.304
35 Pipe with bend - pump * 07.98.74.296
35 Pipe with bend – helix coil * * 07.98.74.287
36 Elbow connection 22x22 mm * * 74.64.30.958
37 Front insulation *** 07.98.83.228
38 Flow pipe *** 07.98.74.308
39 Bracket *** 07.98.37.042
40 Ignition transformer *** 07.98.61.001
41 Screw M4x8 self tap *** 82.08.93.046
42 Hex bolt M8x12 *** 07.98.82.112
43 Controller mounting plate *** 07.95.30.001
44 Controller *** 07.95.64.001
45 Controller front plate *** 07.98.35.288
46 Front case set *** 07.95.22.004
47 Data Plate 24 Model * 07.98.35.294
47 Data Plate 24 Plus Model * 07.98.35.295
ATMOS MULTI Mk2 version 2004 Appendix Page 3

Atmos Multi Mk 2 Parts List
Atmos Multi 24/80
Atmos Multi 24/80 PLUS
Atmos Multi 32/80 PLUS
Drg Ref Description Part Ref.
47 Data Plate 07.98.35.296
47 Data Plate 32 Plus Model * 07.98.35.297
48 Screw M3x 25 *** 07.98.82.115
100 Cable loom K1 (room thermostat) *** 07.98.66.122
101 Cable loom K2 (pressure sensor) *** 07.98.66.206
102 Cable loom K4 *** 07.98.66.212
(CH flow & tank temp sensors)
103 Appliance selection 24 Model * 07.98.63.043
103 Appliance selection 24 Plus Model * 07.98.63.044
103 Appliance selection 07.98.63.045
103 Appliance selection 32 Plus Model * 07.98.63.046
104 Tank temperature sensor *** 07.98.63.047
105 Cable loom K5 (CH pump) *** 07.98.66.208
106 Cable loom K6 *** 07.98.66.202
(Gas valve, max. thermostat,
Ionisation/ Ignition electrode)
107 Cable loom K7 (3 port valve) *** -
108 Cable loom K8 (fan) *** 07.98.66.201
109 Cable K11 (main boiler earth) *** 07.98.66.207
110 Cable loom K12 (ignition earth) *** 07.98.66.204
111 Cable loom K13 (ignition) *** 07.98.66.210
112 Mains lead *** 07.98.66.120
Note 1 Temp. & pressure relief valve *** ?
Note 1 – This part is not shown in the diagrams. Please refer to the Boiler Schematic (Section 4).
ATMOS MULTI Mk2 version 2004 Appendix Page 4

ATMOS MULTI Mk2 version 2004 Appendix Page 5

ATMOS MULTI Mk2 version 2004 Appendix Page 6

ATMOS MULTI Mk2 version 2004 Appendix Page 7

ATMOS MULTI Mk2 version 2004 Appendix Page 8

ATMOS MULTI Mk2 version 2004 Appendix Page 9

APPENDIX 2. Fault Finding
1. GENERAL
The Atmos Multi has 3 types of error messages:-
1. Warning messages
In this case, instead of the status message, a letter appears on the diagnostic display for one second, once every 5
seconds.
2. Blocking messages
A permanently illuminated letter appears on the diagnostic display.
3. Malfunction messages
A flashing letter or number appears on the diagnostic display.
In the event of a warning message, the function to which the message applies will be switched off while the appliance
continues to operate.
In the event of a malfunction message, the entire appliance will be shut down requiring manually resetting before the
boiler will continue operation.
OPERATING CODES ON ATMOS MULTI
See also Table 1 in Section 5 of the Manual. The following appear on the status display:-
1 Hot water heating operating
2 Central heating operating
3 Hot water and central heating – priority to hot water
4 Hot water and central heating - supply to both
The dot in the bottom right hand corner of the diagnostic display indicates the following burner function:-
No dot No burner
Slow flashing dot Minimum fire
Increasingly fast flashing dot Higher & higher firing
Constant dot Burner on maximum output
The dot in the bottom right hand corner of the central heating display: -
Dot Motorised valve energised to send
water to the central heating circuit
ATMOS MULTI Mk2 version 2004 Appendix Page 10

2. SUMMARY OF MESSAGES
This section provides a brief description of the warning, blocking and malfunction messages which appear on the
appliances diagnostic display. The causes of these messages are addressed in more detail in section 3.
2.1 Warning messages
A warning message is identified by a letter that appears on the diagnostic display once every 5 seconds, for a period of
1 second, instead of the status message.
Diagnostic display code
Status
message
(Number)
Warning every 5
seconds Message
b Incorrect hot water tank temperature reading, value<-10oC or> 118oC
c Incorrect central heating water pressure, value between 0 and 0.5 bar or 3 and
4 bar (capacity is limited to low setting)
d Incorrect central heating return sensor reading, value<-10oC or> 118oC
8
h Incorrect outside sensor reading, value<-15oC or>118oC
2.2 Blocking messages
A blocking is an error that occurs without causing a malfunction. The appliance waits until the blocking has been
resolved and then continues to operate normally. A blocking is indicated by a permanently lit letter on the diagnostic
display.
Code
Diagnostic
display Central heating water display Message
H H Central heating water temperature sensor error value >118oC
c L L Central heating water temperature sensor error, value <-10oC
C* Central heating pressure lower than 1 bar (occurs when the plug is inserted
into the power socket)
F Mains frequency error
H Internal error
L Electrical mains plug error-correct supply polarity
n Mains or reference voltage too low
H H Appliance type recognition error, value >118oC
L L Appliance type recognition error, value <-10oC
1 0 Appliance type recognition error, control unit is set to 24/80
1 1 Appliance type recognition error, control unit is set to 24/80plus
2 0 Appliance type recognition error, control unit is set to 32/80
t
2 1 Appliance type recognition error, control unit is set to 32/80plus
* this code will not be stored in the memory
ATMOS MULTI Mk2 version 2004 Appendix Page 11

2.3 Malfunction messages
A malfunction is an error which is so serious that the appliance is locked. A malfunction message is identified by a
locked control unit accompanied by a flashing number or letter on the diagnostic display. The appliance can only be
unlocked by pressing the reset button.
Code
Diagnostic
display Central heating water display Message
2 Fan defective (5Hz deviation per minute)
3 Incorrect ionisation (flame) signal
3. No ionisation (flame) signal during start-up procedure
4 Ionisation signal absent during heat supply (diagnostic code 1-4)
4. Ionisation signal remains present too long after heat supply
6. Gas valve control defective
7 Insufficient flow of central heating water during hot water heating
7. Insufficient flow of central heating water during radiator heating
8 Maximum thermostat cuts out and central heating water pressure was lower
than 0.5 bar
9 Maximum thermostat cuts out and central heating water sensor was higher
than 80oC
9. Safety internal malfunction in control unit
Letter Internal malfunction in control unit
(Dark display) Appliance receiving no voltage
3. CAUSES OF MESSAGES
3.1 Warning messages
A warning message is identified by a letter that appears on the diagnostic display every five seconds for a period of one
second instead of the status message. The appliance continues to operate, but the function to which the message applies
will be switched off of ignored. Once the cause of the warning message has been solved, the appliance will start up
again automatically so resetting is not necessary. The possible causes are described below in order of probability. Also
look for the malfunction in this order.
Diagnostic display code Central heating water display code
Status
message
(Number)
Warning
every 5
seconds
Diagnosis Message Cause
H H
•Central heating temperature >118oC
•Connector K4 loose or improperly
connected
•Temperature sensor wiring interrupted
•Sensor defective
•Control unit
b
Hot water tank temperature <-10oC or
>118oC. In sub-program sensor values
the message HH (>118oC) or LL (<-
10oC) appears on the central heating
water display.
L L
•Control heating temperature <-10oC
•Short circuit in temperature sensor
wiring
•Sensor defective
•Control unit
ATMOS MULTI Mk2 version 2004 Appendix Page 12

0 – 0.5
BAR
•Central heating system lacking water
pressure
•No venting of the central heating
system through the automatic de-
aerator
•Leak in the appliance or central
heating system
•Central heating pressure sensor
defective
c
Central heating water pressure too low
or too high. Limiting the output to the
appliances lowest capacity. The
current central heating water pressure
is shown on the central heating
display. If the central heating water
temperature is set on the central
heating display, the current central
heating water pressure can be read
through ‘sub-program sensor values’ 3 – 4 BAR •Central heating system over
pressurised
•Expansion tank defective
•Central heating pressure sensor
defective
H H
•See cause of HH in status message
d
Central heating return temperature
<-10oC or >118oC. In sub-program
sensor values, HH (>118oC) or LL (<-
10oC) will appear on the central
heating water display.
L L
•See cause of LL in status message
H H
•See cause of HH in status message
h
Outside temperature<-10oC or >118oC.
In sub-program sensor values,
HH (>118oC) or LL (<-10oC) will
appear on the central heating water
display.
L L •See cause of LL in status message
3.2 Blocking messages
A blocking message is identified by a permanently illuminated letter on the diagnostic display. Once the blocking has
been solved, the appliance will start up again automatically. So resetting is not necessary.
The possible causes are described below in order of probability. Also look for the malfunction in this order.
Code Diagnosis Cause
Diagnostic
display Central heating water display
c H H
Central heating water temperature > 118°C •See cause of HH in ‘status message/b’ [3.1]
L L
Central heating water temperature < -10°C •See cause of LL in ‘status message/b’ [3.1]
C*
Appliance blocked because central heating
system pressure is too low •Central heating pressure lower than 1 bar
F
Mains frequency error •If this blocking occurs frequently or for a
long period, replace control unit
H
Internal error •If this blocking occurs frequently or for a
long period, replace control unit
L
Electrical mains supply •Mains supply has wrong polarity
•Not earthed
•Ionisation electrode earth wire loose
•Control unit
n
Mains or reference voltage too low •Mains voltage < 200 volts
•Mains voltage insufficient
•Control unit
t H H
Appliance type recognition error, value >
118°C •Control unit selected incorrectly
•Selection resistance defective
•Control unit defective
L L
Appliance type recognition error, value < -
10°C
1 0
Appliance type recognition error, the control
unit is set to 24/80
1 1
Appliance type recognition error, the control
unit is set to 24/80plus
2 0
Appliance type recognition error, the control
unit is set to 32/80
2 1
Appliance type recognition error, the control
unit is set to 32/80plus
* this code will not be stored in the memory
ATMOS MULTI Mk2 version 2004 Appendix Page 13

3.2 Malfunction messages
A malfunction message is indicated by a flashing number or letter on the diagnostic display combined with a locked
control unit. Once the malfunction is solved, the control unit must be unlocked by pressing the reset button once.
Should the control unit fail to unlock, try again after approx. 20 seconds.
The possible causes are described below in order of probability. Also look for the malfunction in this order.
Code Diagnosis Cause
Diagnostic
display
2 Fan defective (5 hz deviation per
minute) • Fan not turning
• Fan’s electrical connection loose or improperly connected
• Control unit
3 Incorrect ionisation (flame) signal • Valve in gas valve remains open or leaks
• Control unit
3. No ionisation (flame) signal during
start-up procedure • No gas supply
− gas tap closed
− gas valve defective
− gas valve’s electrical connection loose or improperly connected
• Air supply obstructed
• Flue tube obstructed
• Siphon obstructed
• Ionisation cabling not in order
• Ionisation probe defective or causing short-circuit such as against burner
• No ignition
− ignition transformer electrical connection loose or improperly
connected
− power cable defective
− ignition electrode defective or causing short-circuit
• Control unit
4 Ionisation signal lost during heat
supply (diagnostic code 1 - 4) • Insufficient gas supply
• Siphon obstructed
• Ionisation electrode defective / causing short-circuit such as against
burner
• Gas valve set incorrectly
• O2content more than 7.5% at low setting
• Fan’s low capacity circuit defective or interrupted
• Burner damaged
• Control unit
4. Ionisation signal remains too long
after heat supply • Valve in gas valve defective, remains open or leaks
• Control unit
6 Gas valve control receiving voltage
erroneously • Wiring error
• Control unit
ATMOS MULTI Mk2 version 2004 Appendix Page 14

Malfunction messages (continued)
Code Diagnosis Cause
Diagnostic
display
7 Insufficient circulation
of central heating
water during hot water
heating
•Insufficient central heating water in the central heating water circuit - Central
heating water pressure too low (minimum 1 bar at the appliance)-
Automatic de-aerator not functioning properly (Air in the appliance)
Central heating pump not running - Central heating pump stuck - Connector
K5 loose - Central heating pump defective - Thermal safety switched off
- Control unit
7. Insufficient circulation
of central heating
water during radiator
heating
•Insufficient central heating water in the central heating water circuit
- Central heating water pressure too low (minimum 1 bar at the
appliance)
- All (thermostat) radiator taps are closed (pressure difference regulator
not set properly if present)
- Accumulation of air caught somewhere in the central heating water
circuit
-Automatic de-aerator not functioning properly (air in the appliance)
•Central heating pump not running
- Central heating pump stuck
- Connector K5 loose
- Central heating pump defective
- Control unit
8 High limit thermostat
switches off and
central heating water
pressure lower than
0.5 bar
•Central heating water pressure incorrect
•Central heating water temperature sensor not properly connected to central
heating water pipe
•Thermal safety connection defective
•Thermal safety defective
•Control unit
•Central heating pump not running
- Central heating pump stuck
- Connector K5 loose
- Central heating pump defective
- Control unit
9 High limit thermostat
switches off and
temperature of central
heating water sensor
exceeds 80oC
•Central heating water temperature sensor not properly connected to central
heating water pipe
•Thermal safety connection defective
•Thermal safety defective
•Control unit
•Central pump not running
- Central heating pump stuck
- Connector K5 loose
- Central heating pump defective
- Control unit
9. Control unit safety
malfunction •Control unit
LETTER [Letter such as A or E]
Internal error in control
unit.
•Control unit
[Dark
display] Appliance not receiving any power • Plug not inserted in wall socket
• No electricity from wall socket
• Wire loom connector k6 not connected
• Control unit fuse defective
• Mains voltage wiring defective
• Control unit
ATMOS MULTI Mk2 version 2004 Appendix Page 15

4. USER PROGRAM
The user program is identified by a permanently lit letter followed by a dot.
•Access : Press ‘Set’ button for approx. 5 seconds until the letter b. appears
•Next setting : Press ‘Set’ button
•Different value : Press ‘Hot water’ button
•Exit program : Press ‘Reset’ button
Code
Diagnostic
display Central heating water display Function Setting
b. 0 1
Hot water tank temperature 60°C
0 2
*65°C
0 3
70°C
C. 8 8 Central heating temperature °C
0. 0 Central heating pressure sensor is not active
8.8 Central heating pressure *BAR
F. 8 8 Serial number + last malfunction
G. 8 8 Serial number + last blocking
0.** 0 0
Weather-dependent regulation *Off
0 1
Room thermostat time
switch
0 2
S. 0 0
Non-standard setting (only applies to User program)
0 1
Return to standard* (only applies to User program)
* standard
** only visible if outside temperature sensor is connected
5. INSTALLER PROGRAM
The Installer program is identified by a permanently illuminated letter without a dot.
•Access : Press ‘Set’ button for approx. 10 seconds until the letter A appears
•Different value : Press ‘Hot water’ button
•Next setting : Press ‘Set’ button
•Exit program : Press ‘Reset’ button
•To sub-program : Press ‘Set’ button followed by ‘Hot water’ button
Code
Diagnostic
display Central heating water display Function Setting
A 8 8 Fictitious ionisation flow
L L
Low capacity (continuous)
H H
High capacity (continuous)
b 5 b
To sub-mode sensor values
c 0 0
Modulate at central heating temperature Off
1 1
*On
C 6 0
Central heating water temperature (maximum) 60°C
7 5
75°C
9 0
*90°C
E 0 0
Three-way valve capacity control Off
1 1
*On
F 8 Malfunctions (maximum 15) Begin/end
8 8- 8= service identification number (0 - 6) Last malfunction code
8 8- 8= malfunction code Last malfunction code -1
8 8etc.
G 8 Blocks (maximum 16) Begin/end
8 8- 8= service identification number (0 - 6) Last blocking code
8 8- 8= blocking code Last blocking code -1
8 8etc.
* standard
ATMOS MULTI Mk2 version 2004 Appendix Page 16

Code
Diagnostic
display Central heating water display Function Setting
h 0 1
Pump over-run for central heating * 1 min.
0 3
3 min.
0 5
5 min.
H 0. 1
Pump over-run for boiler *10 min.
0. 2
20 min.
0. 3
30 min.
0. 4
40 min.
1. 0
1 hour
2 4
Continuous
L 0 0
Low capacity burner time off
0 5
5 min.
1 0
* 10 min.
1 5
15 min.
n 0 0
Central heating acceleration off
0 2
2 min.
0 5
*5 min.
1 0
10 min.
0** 5 b
To sub-program weather-dependent setting Last blocking code
P 0 0
Anti-cycling central heating off
0 3
*3 min.
0 6
6 min.
Q 5
Frost-protection (internal on central heating water) 5°C
1 0
*10°C
15
15°C
2 0
20°C
5 0 0
Non-standard setting
(only applies to service program)
1 1
Return to standard
(only applies to service program)
t*** 1 0
Appliance recognition 24/80
1 1
Appliance recognition 24/80plus
2 0
Appliance recognition 32/80
2 1
Appliance recognition 32/80plus
Y 7
Capacity limitation for central heating supply 24/80 and
24/80plus 7.5 kW
1 5
15 kW
2 4
*24.5 kW
1 0
Capacity limitation for central heating supply 32/80 and
32/80plus 10 kW
2 1
21 kW
3 2
*32 kW
* standard
** only visible if outside temperature sensor is connected
*** with the proper selection, the code twill not be visible in the service program
ATMOS MULTI Mk2 version 2004 Appendix Page 17

6. SERVICE SERIAL NUMBER
Every malfunction is preceded by a service identification number. The service identification number is a handy tool for
servicing the ATMOS MULTI. By changing this number after every service, the next time, one can see which blocks
and/or malfunctions occurred since the last service.
To change the service identification number, the malfunction logbook Fmust first be selected. Then the ‘Hot water’
button is kept pressed in while finally the ‘Set’ button is pressed.
The service identification number will be increased by 1 to a maximum of 6, and will then start again from the number
0. When changing the service identification number, it is simultaneously changed in the blocking logbook.
The example below shows the logbook codes in the CH Water display, obtained by stepping through the most recent
logged faults using the ‘Hot water’ button.
Example DIAGNOSIS CENTRAL HEATING WATER DISPLAY
• OCT ‘02 INSTALLATION OF THE APPLIANCE
− CONTENTS OF MALFUNCTION LOGBOOK
− CONTENTS OF BLOCKING LOGBOOK
F
G
0-
0-
• OCT ‘03 ANNUAL INSPECTION
− CONTENTS OF MALFUNCTION LOGBOOK
− CONTENTS OF BLOCKING LOGBOOK
− SERVICE ID NUMBER INCREASED BY MEANS OF
‘HOT WATER’ AND ‘SET’ BUTTON
F*
G**
0-
0-
0-
07.
0c
1-
07.
0-
0-
• OCT ‘04 ANNUAL INSPECTION
− CONTENTS OF MALFUNCTION LOGBOOK
− CONTENTS OF BLOCKING LOGBOOK
− SERVICE ID NUMBER INCREASED BY MEANS OF
‘HOT WATER’ AND ‘SET’ BUTTON
F***
G
1-
1-
1-
13.
0c
2-
07.
1-
07 1-
* Two times 07. means insufficient central heating water flow during central heating operation.
** One 0c means for example that the central heating water temperature connector was loose.
*** Malfunction 13 was added last year. This can be seen by the first number 1(service identification number). The
second number 3. is the malfunction (in this case no ionisation signal during start-up procedure). The two last
malfunctions are preceded by a different service number and are therefore from the previous services.
COMMENT!
Do not forget to increase the service identification number after each service/maintenance and record this with the date
on the service chart of the appliance.
ATMOS MULTI Mk2 version 2004 Appendix Page 18

APPENDIX 3. Appliance Guarantee
GUARANTEE

What is covered by the Guarantee?
Atmos guarantees the heat exchanger and the water
heater tank for material and construction faults for five
years and the other parts for two years. Both periods
are calculated from the date of commissioning.
This guarantee implies that the purchaser of this
appliance is entitled to free delivery of the replacement
part. Your installer may charge for the costs of
dismantling and replacing the defective part.
Repairing or replacing parts during the guarantee
period does not extend the length of the guarantee.
Atmos gives a 1 year guarantee on replacement parts.
Parts or appliances sent to the factory for repair or
replacement must always be sent postage paid.
Defects caused by corrosion - both internally and
externally - of any nature whatsoever, whatever their
cause, and defects resulting from scale deposits are not
covered by the guarantee.
Secondary damage, including water damage resulting
from the appliance leaking, loss of earnings resulting
from the failure of the appliance to perform correctly,
fire, legal liability of the user to third parties and so on,
do not come under the guarantee. The right to assess
guarantee claims is reserved to Atmos, who must
always be given the opportunity of inspecting the
appliance on site.

Who conducts the Guarantee?
The provision of service and the execution of this
guarantee is the responsibility of the installer from
whom you bought the appliance.
Guarantee stipulations
Claims can only be made on the guarantee if the
enclosed GUARANTEE REGISTRATION CARD has
been completed and signed and returned to Atmos
within 14 days of the installation date.
The appliance should be installed by a recognised
installer according to the Atmos Multi installation
instructions and the general and local regulations
applicable at the time of installation.
The user must operate the appliance in accordance with
the OPERATING INSTRUCTIONS. The guarantee
becomes null and void if the appliance is used
incorrectly, or in the event of proven negligence, or
incorrectly implemented repairs. The guarantee also
becomes null and void if changes are made to the
appliance without our knowledge. The same applies if
the data plate on the appliance is removed, crossed out
or made illegible.
Repairs should be carried out by a recognised installer.
Exclusively Atmos parts must be used.
The annual inspection and maintenance must be carried
out by a recognised installer in accordance with the
maintenance advice provided by Atmos.
If a defect occurs, the appliance will be assessed as it
was originally set up and connected.
Receipt, Guarantee Registration card and Proof
of Guarantee
Claims can only be made on the guarantee described
above upon submission of the receipt invoice together
with the fully completed proof of guarantee. You must
retain this PROOF OF GUARANTEE, which you will
find at the back of the USER OPERATING
INSTRUCTIONS. The appliance serial number is also
stated on this document. The purchase date and the
name of your supplier must be clearly stated on your
receipt.
ATMOS MULTI Mk2 version 2004 Appendix Page 19
